SERVICE MANUAL BA-5 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO.
KV-27FS13 RM-Y180 USA SCC-S40NA
KV-27FS13 RM-Y180 CND SCC-S41LA
KV-27FS17 RM-Y181 USA SCC-S40PA
KV-27FV17 RM-Y181 USA SCC-S40MA
KV-27FV17 RM-Y181 CND SCC-S41KA
KV-29FV17 RM-Y181 E SCC-S38XA
KV-29FV17C RM-Y181 E SCC-S38YA
KV-32FS13 RM-Y180 USA SCC-S40QA
KV-32FS13 RM-Y180 CND SCC-S41MA
KV-32FS17 RM-Y181 USA SCC-S40RA
KV-34FS13C RM-Y180 E SCC-S56DA
KV-34FS17 RM-Y181 E SCC-S56JA
RM-Y181
KV-27FV17 KV-27FS17
Self Diagnosis
Supported model
TRINITRON®COLOR TELEVISION
9-965-911-03

— 2 —
KV-27FS13 27FS17 27FV17 29FV17 29FV17C 32FS13 32FS17 34FS13C 34FS17
TABLE OF CONTENTS
Specifi cations.......................................................................................................................................3
Warnings and Cautions........................................................................................................................4
Safety Check-Out.................................................................................................................................5
Self-Diagnostic Function......................................................................................................................
1. Disassembly
1-1. Rear Cover Removal.....................................................................................................................8
1-2. Chassis Assembly Removal..........................................................................................................8
1-3. Service Position ............................................................................................................................8
1-4. Picture Tube Removal ...................................................................................................................9
Anode Cap Removal Procedure...................................................................................................9
2. Set-Up Adjustments
2-1. Beam Landing...............................................................................................................................10
2-2. Convergence.................................................................................................................................11
2-3. Focus ............................................................................................................................................12
2-4. Screen (G2) ..................................................................................................................................12
2-5. Method of Setting the Service Adjustment Mode..........................................................................13
2- . White Balance Adjustments ..........................................................................................................13
3. Safety Related Adjustments
3-1.
X R5 4 Confi rmation Method (Hold Down Confi rmation) and Readjustments...........................14
3-2. B+ Voltage Confi rmation and Adjustment .....................................................................................14
4. Circuit Adjustments
4-1. Setting the Service Adjustment Mode...........................................................................................1
4-2. Memory Write Confi rmation Method .............................................................................................1
4-3. Remote Adjustment Buttons and Indicators .................................................................................1
4-4. MA Board Adjustments .................................................................................................................21
5. Diagrams
5-1. Circuit Boards Location.................................................................................................................23
5-2. Printed Wiring Board and Schematic Diagram Information ..........................................................24
5-3. Block Diagram and Schematics ....................................................................................................25
A Board ........................................................................................................................................31
BC Board......................................................................................................................................3
CA Board......................................................................................................................................39
D Board ........................................................................................................................................41
HA Board......................................................................................................................................43
HB Board......................................................................................................................................44
HX Board......................................................................................................................................44
K Board ........................................................................................................................................45
MA Board .....................................................................................................................................47
P Board ........................................................................................................................................52
VA Board ......................................................................................................................................53
5-4. Semiconductors ............................................................................................................................55
6. Exploded Views
-1. Chassis (KV-27FV17/29FV17/29FV17C ONLY) ...........................................................................5
-2. Picture Tube Removal (KV-27FV17/29FV17/29FV17C ONLY) .....................................................57
-3. Chassis (KV-27FS13/27FS17 ONLY) ...........................................................................................58
-4. Chassis (KV-32FS13/32FS17/34FS13C/34FS17 ONLY)..............................................................59
-5. Picture Tube Removal (KV-27FS13/27FS17/32FS13/32FS17/34FS13C/34FS17 ONLY) ............ 0
7. Electrical Parts List ...................................................................................................................................... 1
SECTION TITLE PAGE

— 3 —
KV-27FS13 27FS17 27FV17 29FV17 29FV17C 32FS13 32FS17 34FS13C 34FS17
Television system
American TV Standard/NTSC
Channel coverage
VHF: 2-13/ VHF: 14- 9/ CATV: 1-125
Picture tube
Flat Trinitron
®
tube
Visible screen size
27-inch picture measured diagonally (KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
32-inch picture measured diagonally (KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
Actual screen size
29-inch measured diagonally (KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
34-inch measured diagonally (KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
Antenna
75 ohm external terminal for VHF/UHF
Supplied Accessories
Remote Commander RM-Y180 (KV-27FS13/32FS13/34FS13C ONLY)
Remote Commander RM-Y181 (KV-27FS17/27FV17/29FV17/29FV17C/32FS17/34FS17 ONLY)
Size AA (R ) batteries (2)
Optional Accessories
Connecting cables: VMC-810S/820S, VMC-720M,
YC-15V/30V, RK74A
U/V mixer EAC-
TV Stand: SU-27FD4 (KV-27FS13/ 27FS17/ 27FV17 ONLY)
TV Stand: SU-27FD3 (KV-29FV17/ 29FV17C ONLY)
TV Stand: SU-32FD3 (KV-34FS17/34FS13C ONLY)
TV Stand: SU-32FD4 (KV-32FS13/ 32FS17 ONLY)
SPECIFICATIONS
Design an specifi cations are subject to change without notice.
1) 1 Vp-p 75 ohms unbalanced, sync negative
2) Y: 1 Vp-p 75 ohms unbalanced, sync negative
C: 0.28 Vp-p (Burst signal), 75 ohms
3) 500 m Vrms (100% modulation), Impedance: 47 kilohms
4) More than 408 mVrms at the maximum volume setting (variable)
More than 408 mVrms (fi x); Impedance (output): 2 kilohms
5) Y: 1.0 Vp-p, 75 ohms, sync negative; P
B
: 0.7 Vp-p, 75 ohms
P
R
: Vp-p, 75 ohms
(
•
) SRS (SOUND RETRIEVAL SYSTEM)
The (
•
) SRS (SOUND RETRIEVAL SYSTEM) is manufactured by
Sony Corporation under license from SRS Labs, Inc. It is covered by U.S.
Patent No. 4,748, 9. Other U.S. and foreign patents pending.
The word ‘SRS’ and the SRS symbol (
•
) are registered trademarks of
SRS Labs, Inc. BBE and BBE symbol are trademarks of BBE Sound, Inc.
and are licensed by BBE Sound, Inc. under U.S. Patent No. 4, 38,258.
KV-27FV17/
29FV17 KV-29FV17C KV-27FS13 KV-27FS17 KV-32FS13 KV-34FS13C
KV-32FS17/
34FS17
Power requirements 120V, 60 Hz 220V, 50 Hz 120V, 60 Hz 120V, 60 Hz 120V, 60 Hz 220V, 50 Hz 120V, 60 Hz
Number of inputs/outputs
Video 1) 3333333
S Video 2) 2 211111
Audio 3) 3333333
Audio Out 4) 1111111
Y,PB, PR 5) 1111111
Monitor Out 1 1 -- -- -- -- --
Spea er output(W) 15W 2 15W 2 7.5W 2 7.5W 2 10W 2 10W 2 10W 2
Power Consumption(W)
In use(Ma ) 220W 210W 170W 180W 195W 195W 205W
In standby 1W 1W 1W 1W 1W 1W 1W
Dimensions(W/H/D)
(mm) 762 604 519 mm 762 604 519 mm 700 632 512 mm 762 604 519 mm 800 704 582 mm 700 632 512 mm 762 604 519 mm
(in) 30 23 7/8 20 1/2 in. 30 23 7/8 20 1/2 in. 275/8 25 201/4 in. 30 23 7/8 20 1/2 in. 31 1/2 27 3/4 23 in. 275/8 25 201/4 30 23 7/8 20 1/2 in.
Mass
(kg) 49 kg. 49 kg. 47 kg. 49 kg. 75 kg. 75 kg. 75 kg.
(lbs) 108 lbs. 108 lbs. 103 lbs. 10 oz. 108 lbs. 163 lbs. 163 lbs. 163 lbs.

— 4 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
WARNINGS AND CAUTIONS
CAUTION
Short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT shield, or carbon painted on the CRT,
after removing the anode.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of
this receiver is directly connected to the AC power line.
! SAFETY-RELATED COMPONENT WARNING!!
Components identifi ed by shading and ! mark on the schematic diagrams, e ploded views, and in the parts list are critical for
safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements
published by Sony. Circuit adjustments that are critical for safe operation are identifi ed in this manual. Follow these procedures
whenever critical components are replaced or improper operation is suspected.
ATTENTION!!
Apres avoir deconnecte le cap de l’anode, court-circuiter l’anode du tube cathodique et celui de l’anode du cap au chassis metallique
de l’appareil, ou la couche de carbone peinte sur le tube cathodique ou au blindage du tube cathodique.
Afi n d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout
dépannage. Le chássis de ce récepteur est directement raccordé à l’alimentation du secteur.
! ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identifi es par une trame et par une marque ! sur les schemas de principe, les vues e plosees et les listes de
pieces sont d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont
le numero de piece est indique dans le present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont
l’importance est critique pour la securite du fonctionnement sont identifi es dans le present manuel. Suivre ces procedures lors de
chaque remplacement de composants critiques, ou lorsqu’un mauvais fonctionnement suspecte.

— 5 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the B+ and HV to see if they are specifi ed values. Make sure
your instruments are accurate; be suspicious of your HV meter if sets
always have low HV.
8. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other e posed metal parts for AC leakage. Check leakage
as described below.
Lea age Test
The AC leakage from any e posed metal part to earth ground and from
all e posed metal parts to any e posed metal part having a return to
chassis, must not e ceed 0.5 mA (500 microamperes). Leakage current
can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or
RCA WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245 digital
multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75 V,
so analog meters must have an accurate low voltage scale. The
Simpson’s 250 and Sanwa SH-63TRD are e amples of passive VOMs
that are suitable. Nearly all battery-operated digital multimeters that
have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate retaining
screw on most AC outlet bo es is also at earth ground. If the retaining
screw is to be used as your earth ground, verify that it is at ground
by measuring the resistance between it and a cold-water pipe with an
ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt trouble-
light (not a neon lamp) between the hot side of the receptacle and the
retaining screw. Try both slots, if necessary, to locate the hot side on the
line; the lamp should light at normal brilliance if the screw is at ground
potential (see Figure B).
To E posed Metal
Parts on Set
0.15 F 1.5 K ΩAC
Voltmeter
(0.75 V)
Earth Ground
Trouble Light
AC Outlet Bo Ohmmeter
Cold-water Pipe
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

— 6 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
Detected Symptoms
SELF-DIAGNOSTIC FUNCTION
*If a +B overcurrent is detected, stoppage of the vertical defl ection is detected simultaneously. The symptom that is diagnosed fi rst by the
mircrocontroller is displayed on the screen.
**Refer to Screen (G2) Adjustments in Section 2-4. of this manual.
Display of Standby/Timer LED Flash Count
2 times
4 times
5 times
LED ON 0.3 sec.
LED OFF 0.3 sec. LED OFF
3 sec.
Diagnostic Item Flash Count*
+B Overcurrent 2 times
I-Prot 4 times
IK (AKB) 5 times
*One fl ash count is not used for self-diagnostic.
Stopping the Standby/Timer LED Flash
Turn off the power switch on the TV main unit or unplug the power cord from the outlet to stop the STANDBY/TIMER LAMP from fl ashing.
Self Diagnosis
Supported model
Standby/Timer LED
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER LED will automatically begin to fl ash. The number
of times the LED fl ashes translates to a probable source of the problem. A defi nition of the STANDBY/TIMER LED fl ash indicators is listed in the
instruction manual for the user’s knowledge and reference. If an error symptom cannot be reproduced, the Remote Commander can be used to review
the failure occurrence data stored in memory to reveal past problems and how often these problems occur.
Diagnostic Test Indicators
When an error occurs, the STANDBY/TIMER LED will fl ash a set number of times to indicate the possible cause of the problem. If there is more than
one error, the LED will identify the fi rst of the problem areas.
Results for all of the following diagnostic items are displayed on screen. No error has occurred if the screen displays “0”.
Power does not turn on
+B overcurrent (OCP)*
I-Prot
IK (AKB)
Does not light
2 times
4 times
5 times
2:0 or 2:1
4:0 or 4:1
5:0 or 5:1
• Power cord is not plugged in.
• Fuse is burned out (F601). (A Board)
• H.OUT (Q502) is shorted. (A Board)
• IC702 is shorted. (CA Board)
• +13V is not supplied. (A Board)
• IC502 is faulty. (A Board)
• Viedo OUT (IC502) is faulty. (A Board)
• IC301 is faulty. (MA Board)
• Screen (G2) is improperly adjusted.**
No. of times
STANDBY/ TIMER
lamp fl ashes
Diagnostic Item
Description
Self-Diagnositc
Display/
Diagnostic Result
Probable Cause Location
• Power does not come on.
• No power is supplied to the TV.
• AC Power supply is faulty.
• Power does not come on.
• Load on power line is shorted.
• Has entered standby state after horizontal raster.
• Vertical defl ection pulse is stopped.
• Power line is shorted or power supply is stopped.
• No raster is generated.
• CRT Cathode current detection reference pulse
output is small.

— 7 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
Self-Diagnostic Screen Display
For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confi rmed, it is possible to bring up
past occurrences of failure on the screen for confi rmation.
To Bring Up Screen Test
In standby mode, press buttons on the Remote Commander sequentially, in rapid succession, as shown below:
Display Channel 5
Sound Volume - Power ON
Self-Diagnostic Screen Display
Numeral “0” means that no fault was detected.
Numeral “1” means a fault was detected one time only.
SELF DIAGNOSTIC
2: 000
3: N/A
4: 000
5: 001
101: N/A
Handling of Self-Diagnostic Screen Display
Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen during repairs. When you
have completed the repairs, clear the result display to “0”.
Unless the result display is cleared to “0”, the self-diagnostic function will not be able to detect subsequent faults after completion of the repairs.
Clearing the Result Display
To clear the result display to “0”, press buttons on the Remote Commander sequentially when the diagnostic screen is displayed, as shown below:
Channel 8 ENTER
Quitting the Self-Diagnostic Screen
To quit the entire self-diagnostic screen, turn off the power switch on the Remote Commander or the main unit.
Self-Diagnostic Circuit
+B overcurrent (OCP)
Occurs when an overcurrent on the +B (135V) line is detected by pin 33 of IC301 (MA Board). If the voltage of pin 33 of IC301 (MA Board) is less than
1V when V.SYNC is more than seven verticals in a period, the unit will automatically turn off.
I-Prot
Occurs when an absence of the vertical defl ection pulse is detected by pin 5 of IC001 (MA Board). Power supply will shut down when waveform
interval e ceeds 2 seconds.
IK (AKB)
If the RGB levels* do not balance within 2 seconds after the power is turned on, this error will be detected by IC301 (MA Board). TV will stay
on, but there will be no picture.
*(Refers to the RGB levels of the AKB detection Ref pulse that detects 1K).
Note that this differs from entering the Service Mode (Sound Volume + ).
MA BOARD
IC301
Y/CHROMA JUNGLE
A BOARD
IC502
V. OUT
MA BOARD
IC001
SYSTEM
MA BOARD
IC003
MEMORY
IK IN
FROM
CA BOARD
IC702 PIN 5
HP/PROTECT
SDA
A BOARD
FROM
IC501
PIN 3
33
IO-SDAT
O-LED
REF I-Prot
IO-BDAT
BDA
DISPLAY
36
61
35
43 22
42 5

— 8 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
1-1. REAR COVER REMOVAL
1-2. CHASSIS ASSEMBLY REMOVAL 1-3. SERVICE POSITION
SECTION 1: DISASSEMBLY
CA Board
A Board
VA Board
MA Board
D Board
Chassis Assembly
Claw
2 Screws
(+BVTP 3x12)
4 Screws
(+BVTP 4x16)
3 Screws (+BVTP 4x16)
3 Screws
(+BVTP 4x16)
2 Screws
(+BVTP 4x16)
Rear Cover 3 Screws (+BVTP 4x16)
6 Screws
(+BVTP 4x16)
5 Screws
(+BVTP 4x16)
Rear Cover
2 Screws
(+BVTP 3x12)
KV-27FS13/27FS17/27FV17/29FV17/29FV17C KV-32FS13/32FS17/34FS13C/34FS17 ONLY

— 9 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
1. Discharge the anode of the CRT and remove the anode cap.
2. Unplug all interconnecting leads from the defl ection yoke, neck
assembly, degaussing coils and CRT grounding strap.
3. Remove the CA and VA Board from the CRT.
4. Remove the chassis assembly.
5. Loosen the neck assembly fi ing screw and remove.
6. Loosen the defl ection yoke fi ing screw and remove.
7. Place the set with the CRT face down on a cushion and remove
the degaussing coil holders.
8. Remove the degaussing coils.
9. Remove the CRT grounding strap and spring tension devices.
10. Unscrew the four CRT fi ing screws [located on each CRT
corner] and remove the CRT [Take care not to handle the CRT
by the neck].
1-4. PICTURE TUBE REMOVAL
WARNING: BEFORE REMOVING THE ANODE CAP
High voltage remains in the CRT even after the power is disconnected. To avoid electric shoc ,
discharge CRT before attempting to remove the anode cap. Short between anode and CRT
coated earth ground strap.
Coated
Earth
Ground
Strap
ANODE CAP REMOVAL PROCEDURE
WARNING: High voltage remains in the CRT even after the power is disconnected. To avoid electric shock, discharge CRT before attempting to remove
the anode cap. Short between anode and coated earth ground strap of CRT.
NOTE: After removing the anode cap, short circuit the anode of the picture tube and the anode cap to either the metal chassis, CRT shield, or
carbon painted on the CRT.
HOW TO HANDLE AN ANODE CAP
1. Do not use sharp objects which may cause damage to the surface of the anode
cap.
2. To avoid damaging the anode cap, do not squeeze the rubber covering too hard.
A material fi tting called a shatter-hook terminal is built into the rubber.
3. Do not force turn the foot of the rubber cover. This may cause the shatter-hook
terminal to protrude and damage the rubber.
10
1
9
8
7
6
5
3
2
4
ab
Anode Button
c
Turn up one side of the rubber cap
inthe direction indicated by arrow a .
1Use your thumb to pull the rubber
cap fi rmly in the direction indicated
by arrow b .
2When one side of the rubber cap separates from
the anode button, the anode cap can be removed
by turning the rubber cap and pulling it in the
direction of arrow c .
3

— 10 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
The following adjustments should be made when a complete
realignment is required or a new picture tube is installed.
These adjustments should be performed with rated power supply
voltage unless otherwise noted.
Set the controls as follows unless otherwise noted:
VIDEO MODE: Standard
PICTURE CONTROL: Normal
BRIGHTNESS CONTROL: Normal
SECTION 2: SET-UP ADJUSTMENTS
Perform the adjustments in order as follows:
1. Beam Landing
2. Convergence
3. Focus
4. Screen (G2)
5. White Balance
Note Test Equipment Required:
1. Color Bar Pattern Generator
2. Degausser
3. DC Power Supply
4. Digital Multimeter
2-1. BEAM LANDING
Before beginning adjustment procedure:
1. Degauss the entire screen.
2. Feed in the white pattern signal.
ADJUSTMENT PROCEDURE
1. Input a raster signal with the pattern generator.
2. Loosen the defl ection yoke mounting screw, and set the purity control
to the center as shown below:
Purity Control
3. Turn the raster signal of the pattern generator to green.
4. Move the defl ection yoke backward, and adjust with the purity control
so that green is in the center and red and blue are even on both
sides.
Blue Red
Green
5. Move the defl ection yoke forward, and adjust so that the entire screen
becomes green.
6. Switch over the raster signal to red and blue and confi rm the
condition.
7. When the position of the defl ection yoke is determined, tighten it with
the defl ection yoke mounting screw.
8. If landing at the corner is not right, adjust by using the disk magnets.
a
c
b
d
b
a
cd
Purity control
corrects this area.
Disk magnets
or rotatable disk
magnets correct
these areas. (a-d)
Deflection yoke positioning
corrects these areas.

— 11 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
2-2. CONVERGENGE
Before starting convergence adjustments:
1 Perform FOCUS, VLIN and VSIZE adjustments.
2. Set BRIGHTNESS control to minimum.
3. Feed in dot pattern.
VERTICAL STATIC CONVERGENCE
1. Adjust V. STAT magnet to converge red, green and blue dots in the
center of the screen (Vertical movement adjusts V.STAT RV701 to
converge).
B
G
R
Center dot
V.STAT magnet
RV701
V.STAT
B
G
R
2. Tilt the V. STAT magnet and adjust static convergence to open or close
the V. STAT magnet.
When the V. STAT magnet is moved in the direction of arrow a and b,
red, green, and blue dots move as shown below:
a
bbB
G
R
ab
B
G
R
aBGR
RGB
b
R
G
B
b
b
a
R
G
B
(1)
(3)
(2)
HORIZONTAL STATIC CONVERGENCE
If the blue dot does not converge with the red and green dots, peform
the following:
1. Move BMC magnet (a) to correct insuffi cient H.Static convergence.
2. Rotate BMC magnet (b) to correct insuffi cient V.Static convergence.
3. After adjusting the BMC magnet, repeat Beam Landing Adjustment.
BMC MAGNET
PURITY
V.STAT
b
BMC magnet
a

— 12 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
DYNAMIC CONVERGENCE ADJUSTMENT
Before performing this adjustment, perform Horizontal and Vertical Static
Convergence Adjustment.
1. Slightly loosen defl ection yoke screw.
2. Remove defl ection yoke spacers.
3. Move the defl ection yoke for best convergence as
shown below:
BGR GB
R
GB
R
R
R
G
B
GB
G
B
R
BGR G
B
G
B
R
R
G
BG
G
B
RB
R
R
4. Tighten the defl ection yoke screw.
5. Install the defl ection yoke spacers.
TLH PLATE ADJUSTMENT
1. Input crosshatch pattern.
2. Adjust PICTURE QUALITY to standard, PICTURE and BRIGHTNESS
to 50%, and OTHER to standard.
3 Adjust the Horizontal Convergence of red and blue dots by tilting the
TLH plate on the defl ection yoke.
(TLV)
YCH
XCV TLV
CA
Board
VA
Board
RV701
V. STAT
TLH Plate
B R R B
(R)(B) (B)(R)
TLH+
TLH-
4. Adjust XCV core to balance X a is.
5. Adjust YCH VR to balance Y a is.
6. Adjust vertical red and blue convergence with V.TILT (TLV VR).
Note: Perform adjustment 3-6 while tracking items 1 and 2.
SCREEN-CORNER CONVERGENCE
1. Affi a permalloy assembly corresponding to the misconverged areas:
ba
cd
a
b
d
a-d: screen-corner
misconvergence
c
2-3. FOCUS
1. Adjust FOCUS control for best pictures.
2-4. SCREEN (G2)
1. Input a dot pattern.
2. Set the PICTURE and BRIGHTNESS controls at minimum and
COLOR control at normal.
3. Adjust SBRT, GCUT, BCUT in service mode with an oscilloscope as
shown below so that voltages on the red, green, and blue cathodes
are 170 ± 2VDC.
Pedestal
170 ± 2 VDC
Ground
Focus (FV)
Screen (G2)

— 13 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
2-5. METHOD OF SETTING THE SERVICE
ADJUSTMENT MODE
SERVICE MODE PROCEDURE
1. Standby mode (power off).
2. Press Display Channel 5 Sound Volume + Power
on the Remote Commander (press each button within a second).
SERVICE ADJUSTMENT MODE ON
1. The CRT displays the time being adjusted.
Mode Category
Display
Item
Display
Item
Signal
Type ntsc
service defl
vchp 00000000 00000000
hsiz 16
2. Press 1 or 4 on the Remote Commander to select the time.
3. Press 3 or 6 on the Remote Commander to change the data.
4. Press MUTING then ENTER to save into the memory.
SERVICE ADJUSTMENT MODE MEMORY
Turn the set off then on to e it Service Adjustment Mode.
service defl hsiz 16
ntsc
vchp 00000000 00000000
Category
Display
Item
Mode
Item
Data
Signal
Type
write
ENTER
Green
Red
MUTING
2-6. WHITE BALANCE ADJUSTMENTS
1. Input an entire white signal with burst.
2. Set to Service Adjustment Mode.
3. Set the PICTURE and BRIGHTNESS to minimum.
4. Adjust with SBRT if necessary.
5. Select GCUT and BCUT with 1 and 4 .
6. Adjust with 3 and 6 for the best white balance.
7. Set the PICTURE and BRIGHTNESS to ma imum.
8. Select GDRV and BDRV with 1 and 4.
9. Adjust with 3 and 6 for the best white balance.
10. To write into memory, press MUTING then ENTER .

— 14 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
HOLD-DOWN READJUSTMENT
If the setting indicated in Step 2 of Hold-Down Operation Confi rmation
cannot be met, readjustment should be performed by altering the
resistance value of R564 component marked with
X .
+
IABL
ABL
T505
FBT
range
-
ampmeter
3.0 mA DC
A
3-2. B+ VOLTAGE CONFIRMATION AND
ADJUSTMENT
Note: The following adjustments should always be performed when
replacing the following components, which are marked with
Y on the
schematic diagram on the A Board:
A BOARD: IC601, PH601
1. Using a Variac, apply AC input voltage: 130 + 2.0/ -0.0 VAC
2. Input a monoscope pattern.
3. Set the PICTURE and the BRIGHTNESS controls to minimum.
4. Confi rm the voltage of A Board TP-600 is <136.5 VDC.
5. If step 4 is not satisfi ed, replace the components listed above, then
repeat Steps 1 – 3.
SECTION 3: SAFETY RELATED ADJUSTMENTS
3-1. X R564 CONFIRMATION METHOD
(HOLD-DOWN CONFIRMATION) AND
READJUSTMENTS
The following adjustments should always be performed when replacing
the following components which are marked with
Y on the schematic
diagram:
Part Replaced ( ) Adjustment ( )
DY, T505, CRT, IC501 C507,
C520, C505, C509, C515, T504,
T503, C551, L510, C546, C537,
C547, D517, D518, D519, R560,
R561, R562, R563, R565, R566,
R567, R525....................A Board
IC301........................MA Board
HV HOLD-DOWN
R564
PREPARATION BEFORE CONFIRMATION
1. Using a Variac, apply AC input voltage: 120 ±2 VAC.
2. Turn the POWER switch ON.
3. Input a white signal and set the PICTURE and BRIGHTNESS controls
to ma imum.
4. Confi rm that the voltage between C546 (+) or TP503 and ground is
more than 21.0 VDC (27/29 inch) or 23.0 VDC (32/34 inch).
HOLD-DOWN OPERATION CONFIRMATION
1. Connect the current meter between Pin 11 of the FBT (T505) and
the PWB land where Pin 11 would normally attach (See Figure 1 on
the ne t page).
2. Input a dot signal and set PICTURE and BRIGHTNESS to minimum:
IABL = 1730 ± 100µA. (27/29 inch) or 2175 +100 - 325µA (32/34inch).
3. Confi rm the voltage of A Board TP-600 is 135 ± 1.5 VDC.
4. Connect the digital voltmeter and the DC power supply via Diode
1SS119 to C546 (+) and ground (See Figure 1 on ne t page).
5. Increase the DC power voltage gradually until the picture blanks out.
6. Turn DC power source off immediately.
7. Read the digital voltmeter indication (standard 24.78 +0/ -0.1 VDC
[27/29 inch] or 27.24 +0/-0.1 VDC [32/34 inch]).
8. Input a white signal and set PICTURE and BRIGHTNESS to
ma imum: IABL = 1730 ± 100µA (27/29 inch) or 2175 +100/-325 µA
(32/34 inch).
9. Repeat steps 4 to 7.

— 15 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
R438
R438R438
R438
R522
R522R522
R522
R541
R541R541
R541
R450
R450R450
R450
R445
R445R445
R445
C611
C611C611
C611
C448
C448C448
C448
R449
R449R449
R449
R454
R454R454
R454
C213
C213C213
C213
R527
R527R527
R527
R525
R525R525
R525
R514
R514R514
R514
R567
R567R567
R567
R225
R225R225
R225
R529
R529R529
R529
C530
C530C530
C530
C546
C546C546
C546
R563
R563R563
R563
R218
R218R218
R218
R227
R227R227
R227
C542
C542C542
C542
C541
C541C541
C541
C518
C518C518
C518
R231
R231R231
R231R232
R232R232
R232
R557
R557R557
R557
C552
C552C552
C552
R554
R554R554
R554
R555
R555R555
R555
R543
R543R543
R543
C532
C532C532
C532
R537
R537R537
R537
C523
C523C523
C523
R540
R540R540
R540
C543
C543C543
C543
C519
C519C519
C519
R535
R535R535
R535
CN504
CN504CN504
CN504
L507
L507L507
L507
R546
R546R546
R546
R534
R534R534
R534
R545
R545R545
R545
C551
C551C551
C551
L510
L510L510
L510 R533
R533R533
R533
R515
R515R515
R515
R516
R516R516
R516 C503
C503C503
C503
C536
C536C536
C536
C504
C504C504
C504
C513
C513C513
C513
R507
R507R507
R507
T503
T503T503
T503
T502
T502T502
T502
R659
R659
R659
R659
C629
C629C629
C629
L602
L602L602
L602
R447
R447R447
R447
D507
D507D507
D507
C659
C659
C659
C659
T504
T504T504
T504
FB610
FB610
FB610
FB610
C524
C524C524
C524
C550
C550C550
C550
R539
R539R539
R539
R518
R518R518
R518
FB502
FB502FB502
FB502
R505
R505R505
R505
L505
L505L505
L505
R506
R506R506
R506
L501
L501L501
L501
C517
C517C517
C517
L509
L509L509
L509
C510
C510C510
C510
R615
R615R615
R615
R601
R601R601
R601 IC502
IC502IC502
IC502
CN502
CN502CN502
CN502
Q411
Q411Q411
Q411
CN511
CN511CN511
CN511
CN506
CN506CN506
CN506
CN515
CN515CN515
CN515
Q501
Q501Q501
Q501
JR503
JR503JR503
JR503
JR502
JR502JR502
JR502
R573
R573R573
R573
R531
R531R531
R531
Q505
Q505Q505
Q505
C654
C654C654
C654
IC501
IC501IC501
IC501
L502
L502L502
L502
R532
R532R532
R532
D233
D233D233
D233
D232
D232D232
D232
D520
D520D520
D520
R561
R561R561
R561
D234
D234D234
D234
D235
D235D235
D235
R565
R565R565
R565
FB503
FB503FB503
FB503
R558
R558R558
R558 R559
R559R559
R559
TH501
TH501TH501
TH501
R511
R511R511
R511
R503
R503R503
R503
C554
C554C554
C554
C525
C525C525
C525
C511
C511C511
C511
D616
D616D616
D616
D521
D521D521
D521
R502
R502R502
R502
R547
R547R547
R547
R504
R504R504
R504
C505
C505C505
C505
D506
D506D506
D506
CN501
CN501
CN501
CN501
R568
R568R568
R568
T505
T505T505
T505
D511
D511D511
D511
D514
D514D514
D514 D517
D517D517
D517
D518
D518D518
D518
D516
D516D516
D516
R226
R226R226
R226
D236
D236D236
D236
D510
D510D510
D510
R407
R407R407
R407
C211
C211C211
C211
D620
D620D620
D620
R403
R403R403
R403
Q201
Q201Q201
Q201
Q503
Q503Q503
Q503
Q206
Q206Q206
Q206
Q205
Q205Q205
Q205
Q502
Q502
Q502
Q502
R553
R553R553
R553
C555
C555C555
C555
C515
C515C515
C515
C509
C509C509
C509
C624
C624C624
C624
R804
R804R804
R804
R803
R803R803
R803
R801
R801R801
R801
1
1
1
1
2
2
2
26
6
6
6
7
7
7
7
B
B
B
BE
E
E
E
1
11
17
77
7
B
B
B
BE
E
E
E
1
11
19
99
9
10
1010
1018
1818
18
1
1
1
16
6
6
6
1
11
15 55
5
1
11
14 44
4
E
E
E
E
135V
135V135V
135V
+
+
+
+
1
11
1
4
44
4
5
55
5
8
88
8
C
C
C
C
B
B
B
B
2
2
2
26
6
6
6
4
4
4
4
H DY +
H DY +H DY +
H DY +
H DY -
H DY -H DY -
H DY -
V DY +
V DY +V DY +
V DY +
V DY -
V DY -V DY -
V DY -
H DY +
H DY +H DY +
H DY +
H DY -
H DY -H DY -
H DY -
1
11
1
2
22
2
3
33
3
4
44
4
5
55
5
6
66
6
H-OUT
H-OUT
H-OUT
H-OUT
H.PROT
H.PROTH.PROT
H.PROT
HEATER
HEATERHEATER
HEATER
-13V
-13V-13V
-13V
200V
200V200V
200V
H.PULSE
H.PULSEH.PULSE
H.PULSE
H.DRIVE
H.DRIVEH.DRIVE
H.DRIVE
+B
+B+B
+B
JUMPER-ID
JUMPER-IDJUMPER-ID
JUMPER-ID
Figure 1
TP600
X R564 C546
+
-
DIGITAL
MULTIMETER
+
-
POWER
SUPPLY
1SS119
T505 FBT
+
-
AMMETER
3mA dc range
A

— 16 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
4-2. MEMORY WRITE CONFIRMATION
METHOD
1. After adjustment, pull out the plug from the AC outlet, then replace
the plug in the AC outlet again.
2. Turn the power switch ON and set to Service Mode.
3. Call the adjusted items again to confi rm they were adjusted.
4-3. REMOTE ADJUSTMENT BUTTONS AND
INDICATORS
4-1. SETTING THE SERVICE ADJUSTMENT
MODE
1. Standby mode (Power off).
2. Press the following buttons on the remote commander within a
second of each other:
Display Channel 5 Sound Volumne + Power
SERVICE ADJUSTMENT MODE ON
1. The CRT displays the item being adjusted.
service defl hsiz 16
ntsc
vchp 00000000 00000000
Category
Display
Item
Mode
Item
Data
Signal
Type
2. Press 1 or 4 on the Remote Commander to select the item.
3. Press 3 or 6 on the Remote Commander to change the data.
4. Press MUTING then ENTER to write into memory.
SERVICE ADJUSTMENT MODE MEMORY
service defl hsiz 16
ntsc
vchp 00000000 00000000
Category
Display
Item
Mode
Item
Data
Signal
Type
write
ENTER
Green
Red
MUTING
1. Press 8 then ENTER on the Remote Commander to initialize.
service defl hsiz 16
ntsc
vchp 00000000 00000000
Category
Display
Item
Mode
Item
Data
Signal
Type
write
ENTER
Green
Red
MUTING
Carry out Step 1 when adjusting
IDs 0-6 and when replacing and
ad
j
ustin
g
IC003
2. Turn set off then on to e it service adjustment mode.
SECTION 4: CIRCUIT ADJUSTMENTS
ELECTRICAL ADJUSTMENTS BY REMOTE COMMANDER
Use the Remote Commander (RM-Y180, RM-Y181) to perform the circuit adjustments in this section.
Test Equipment Required: 1. Pattern generator 2. Frequency counter 3. Digital multimeter 4. Audio oscillator
RM-Y181
MUTING POWER
(Enter into
memory) (Service Mode)
DISPLAY
1
2
3
4
5
6
8
0
VOLUME (+)
ENTER
(Service Mode)
Disp. (Item up)
(Device Item Up)
Disp. (Item down)
(Initialize)
Item (Data up)
Item (Data down)
(Device item down)
(Enter into
memory)
(Remove from
memory)
(Service Mode)

— 17 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
ADJUSTMENT ITEMS (1 OF 4)
Reg # ITEM FUNCTION RANGE
FIX
DATA
NTSC
27 VIDEO
NTSC
32 RF
AVERAGE
DATA 27
AVERAGE
DATA 32
1 HSIZ Horizontal Size Adjustment 0-63 0 18 11 22
2 HPOS Horizontal Position Adjustment 0-63 13 13 20 22
3 VBOW Vertical Line Bowing Adj. 0-15 9 9 7 9
4 VANG Vertical Line Bowing Slant Adj. 0-15 8 3 9 7
5 VTRP TRAPEZIUM 0-31 19 18 21 17
6 HTRP Horiz. Trapezoid 0-15 6 6 0 2
7 TROT Tilt Correction 0-63 31 31 31 31
8 PAMP Horizontal PIN distortion Adj. 0-63 19 27 20 27
9 UPIN Upper PIN Distortion Adj. 0-63 34 41 37 38
10 LPIN Lower PIN Distortion Adj. 0-63 32 39 33 35
11 VSIZ Vertical Size Adjustment 0-63 32 51 33 51
12 VPOS Vertical Position Adj. 0-63 30 42 36 39
13 VLIN Vertical Lineality Adj. 0-15 3 5 3 4
14 SCOR Vertical "S" Correction Adjustment 0-15 6 8 8 8
15 VZOM 16:9 CRT Z Mode on/off 0-1 0 0 0
16 EHT Vertical High-Voltage Compensation 0-15 5 5 5
17 ASP Aspect Ratio Control 0-63 47 47 47
18 SCRL 16:9 CRT Z Mode Trans. Scroll 0-63 31 31 31
19 HBLK Horizontal Blanking on/off 0-1 1 1 1
20 LBLK Left Blanking Adjustment 0-15 **** 13 13
21 RBLK Rigth Blanking Adjustment 0-15 ***** 7 8
22 HDW Horizontal Drive Pulse Width 0-1 1 1 1
23 EWDC "Parabola" EW, D.C. Adjustment 0-1 0 0 0
24 LVLN Lower Screen BTM Vertical Line Adj. 0-15 0 0 0
25 UVLN Uppe Screen BTM Vertical Line Adj. 0-15 0 0 0
26 INTL INTERLACE 0-3 0 0 0
27 G2SW 0-1 0 0 0
28 G2LV 0-7 0 0 0
29 HOSC Horizontal VCO Oscillation Freq. 0-15 12 7 7
30 VSS Vertical Sync Slice Level 0-3 0 0 0
31 HSS Horizontal Sync Slice Level 0-1 0 0 0
32 HMSK For Macro Vision 0-1 0 0 0
33 VTMS Select Signal VTIM Pin 0-3 0 0 0
34 CDMD Vertical Count Down Mode Switching 0-3 3 * 3 3
35 AFC AFC Loop Gain Switching 0-3 0 0 0
36 FIFR Field Frequency 0-3 3 3 3
37 VBLK VBLKW 0-3 0 0 0
38 REFP REFP 0-1 0 0 0
39 JPSW JUMPSW 0-1 MENU 0 0
40 RDRV R Output Drive control 0-63 *** 31 40
41 GDRV G Output Drive control 0-63 25 22 42
42 BDRV B Output Drive control 0-63 25 21 31
43 RCUT R Output Cutoff control 0-63 31 31 31
44 GCUT G Output Cutoff control 0-63 15 13 12
45 BCUT B Output Cutoff control 0-63 12 14 15
46 SCON SUB CONT 0-15 8 11 11
47 SHUE Sub HUE adjustment 0-15 16 17 16
48 SCOL Sub COLOR adjustment 0-15 18 17 18
49 SBRT Sub BRIGHTNESS adjustment 0-31 16 15 16
50 CHUE SUB COLOR (RF) 0-31 7 6 6
51 CCOL SUB COLOR (RF) 0-31 7 7 4
52 UOFS YUV U OFFSET 0-15 7 7 7
53 VOFS YUV V OFFSET 0-15 7 7 7
54 RON R Output on/off 0-1 1 1 1
* CDMD = 3 for US & CND, CDMD = 0 for Other
*** RDRV = 41 for 27FS/32FS families, 31 for 27FV family
****LBLK = 0 for 27FV/29FV/32FS/34FS family, 5 FOR 27FS family
***** RBLK = 3 for 27FV/29FV/32FS/34FS family, 2 for 27FS family

— 18 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
ADJUSTMENT ITEMS (2 OF 4)
Reg # ITEM FUNCTION RANGE
FIX
DATA
NTSC
27 VIDEO
NTSC
32 RF
AVERAGE
DATA 27
AVERAGE
DATA 32
55 GON G Output on/off 0-1 1 1 1
56 BON B Output on/off 0-1 1 1 1
57 AXPL A is PAL 0-1 0 0 0
58 AXNT A is NTSC 0-1 1 1 1
59 CBPF Chroma BPF on/off 0-1 1 1 1
60 CTRP Y TRAP FILTER on/off 0-1 1 1 1
61 COFF Color On/off 0-1 0 0 0
62 KOFF Set Color Killer 0-1 0 0 0
63 SSHP Sub SHARPNESS 0-15 5 5 5
64 SHPF SHARPNESS Circuit Fo 0-3 Palette Mode Controls This Register 2 2
65 PREL Pre-Shoot/ Over-Shoot 0-1 1 0 0
66 Y-DC DC transmission Ratio Switching 0-3 Palette Mode Controls This Register 2 2
67 GAMM Gamma Correction 0-3 Palette Mode Controls This Register 2 2
68 ABLM ABL Mode Switch 0-1 1 1 1
69 VTH ABL CD VHT Switching 0-1 1 1 1
70 YDEL Y Delay Time Control 0-15 7 7 7
71 NCOL No Color ID 0-1 1 1 1
72 FSC FSC Out on/off 0-1 1 1 1
73 K-ID Killer ID Control on/off 0-1 0 0 0
74 GDOF 0-31 3 3 3
75 BDOF 0-31 16 16 16
76 GCOF 0-31 16 16 16
77 BCOF 0-31 7 7 7
78 SYSC Color System 0-7 4 4 4
79 VENH Vertical Enhancement 0-7 Palette Mode Controls This Register 5 3
80 PDSO PDS OFF 0-1 0 0 0
81 CK CK 0-1 0 0 0
82 VNL VNL 0-15 3 3 3
83 HPK HPK 0-1 0 0 0
84 HPKO HPK OFF 0-1 Palette Mode Controls This Register 0 0
85 CORE CORE 0-3 2 1 1
86 TRAP TRAP 0-1 1 1 1
87 CHTR CH TRAP 0-1 0 0 0
88 CBPF CBPF 0-1 1 1 1
89 ENHO ENH OFF 0-1 0 0 0
90 NMRD NMRD 0-3 0 0 0
91 YAPS YAPS 0-3 3 3 3
92 CLKS CLKS 0-3 0 0 0
93 NSTD NSTDS 0-3 0 0 0
94 MSS MSS 0-3 0 0 0
95 KILS KILS 0-3 1 1 1
96 ADIN ADIN 0-1 0 0 0
97 EXCS EXCSS 0-3 1 1 1
98 CPP CPP 0-3 2 2 2
99 HDP HDP 0-7 4 4 4
100 CDL CDL 0-7 4 4 4
101 DYCR DYCOR 0-15 2 2 2
102 DYGN DYGAIN 0-15 10 10 10
103 DCCR DCCOR 0-15 3 3 3
104 DCGN DCGAIN 0-15 6 6 6
105 YNRL YNRLIM 0-3 1 1 1
106 CNRL CNRLIM 0-3 1 1 1
107 WSC WSC 0-3 1 1 1
108 VTRH VTRH 0-3 1 1 1

— 19 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
ADJUSTMENT ITEMS (3 OF 4)
Reg # ITEM FUNCTION RANGE
FIX
DATA
NTSC
27 VIDEO
NTSC
32 RF
AVERAGE
DATA 27
AVERAGE
DATA 32
109 VTRR VTRR 0-3 1 1 1
110 LDSR LDSR 0-3 2 2 2
111 VAPG VAPGAIN 0-7 3 3 3
112 VAPI VAPINV 0-31 6 6 6
113 TEST TEST 0-1 0 0 0
114 YPFT YPFT 0-3 3 3 3
115 YPFG YPFG 0-15 7 7 7
116 CC3N CC3N 0-1 0 0 0
117 SELD 0-1 1 1 1
118 D2GN D2GAIN 0-7 4 5 5
119 YHCR YHCOR 0-3 0 0 0
120 YPFC YPFCOR 0-1 0 0 0
121 SHT SHT 0-3 0 0 0
122 MVT MVT 0-1 0 0 0
123 OTT OTT 0-1 0 0 0
124 CL2D CL2D 0-1 1 1 1
125 CLKG CLKGGT 0-1 0 0 0
126 HPLL HPLLFS 0-1 1 1 1
127 BPLL BPLLFS 0-1 0 0 0
128 FSCF FSCFG 0-1 0 0 0
129 PLLS PLLS 0-1 1 1 1
130 KILR KILR 0-15 3 3 3
131 HSSL HSSL 0-15 12 12 12
132 VSSL VSSL 0-15 8 8 8
133 BGPS BGPS 0-15 4 4 4
134 BGPW BGPW 0-15 10 10 10
135 ADCK ADCLKS 0-3 3 3 3
136 NDSW NSDSW 0-1 1 1 1
137 PFRN FREE_RUN 0-1 0 0 0
138 PRVS RVS 0-1 0 0 0
139 PCON CONTRAST 0-127 97 45 45
140 PUCO U-DAC 0-127 5 16 16
141 PVCO V-DAC 0-127 5 24 24
142 PHUE 0-31 12 15 15
143 PKIL KILLER 1 0 0 0
144 PSEP EXT_SC_SEL 0-3 1 2 2
145 PHIM 0-1 0 0 0
146 PSUB 0-1 0 0 0
147 PBGS BG_START 0-63 14 14 14
148 PDL0 0-15 10 6 6
149 PDL1 0-15 13 13 13
150 PBRT Y_OFFSET 0-31 25 25 25
151 PVP1 0 0 0
152 PUP1 0 0 0
153 PVP2 0 0 0
154 PUP2 0 0 0
155 PVP3 0 0 0
156 PUP3 0 0 0
157 PACS SET_ACC 0-1 1 1 1
158 PSDL YUV_Color (More Significant) 0-3 2 0 0
159 PDCO YUV_Color (Less Significant) 0-3 2 0 0

— 20 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
service id's id5 19
ntsc
M37280MK-00SP VERB.O
Function
ID
Number
Mode
Signal
Type
00010011
Chip
Version
Data
Notes:
No. 1-206 show the order that each adjustment mode may be selected while in Service Mode.
Data Range shows the range of possible settings for each Adjustment Mode.
Initial Data shows the standard settings for each Adjustment Mode.
ADJUSTMENT ITEMS (4 OF 4)
Reg # ITEM FUNCTION RANGE
FIX
DATA
NTSC
27 VIDEO
NTSC
32 RF
AVERAGE
DATA 27
AVERAGE
DATA 32
160 PCGA C_GAIN 0-1 1 1 1
161 PAAF 0-1 0 0 0
162 PSU2 0-1 0 0 0
163 PCVF 0-1 0 0 0
164 PBIT BITSEL 0-1 0 0 0
165 PAFC AFCBITSEL 0-1 0 0 0
166 PACC ACC_LEVEL 0-63 21 22 22
167 PBUR BURST_CLK 0-1 0 0 0
168 PEVE EVENUPRA 0-1 0 0 0
169 PINW INV_WFF 0-1 0 0 0
170 PINR INV_REF 0-1 0 0 0
171 PREF RFF_FIX 0-1 0 0 0
172 PARE AUTO_REF 0-1 1 1 1
173 PAVE AVERAGE 0-1 0 0 0
174 PFRA FREE_RUN_ADJ 0-15 0 0 0
175 PPAL SUB_PALM_JUDGE 0-255 0 0 0
176 PHPO 0-31 9 7 6
177 PVPO 0-31 22 22 22
178 PHTI HT 0-15 5 9 9
179 PHAJ ADJ 0-15 1 1 1
180 PBGY BGY 0-15 0 0 0
181 PCRO CROSS_SEL 0-1 0 0 0
182 PPAR PALRY 0-63 2 2 2
183 PHPF HPFOFF 0-1 0 0 0
184 PFSC FSC_OUTPUT 0-1 0 0 0
185 PVCH SET_VCHIP 0-1 0 0 0
186 PVON VCHIP_ONLY 0-1 1 1 1
187 PVLN LINE_NUM 0-31 17 17 17
188 PVSB STB_DLY 0-255 64 64 64
189 PVLV L_LEVEL 0-255 130 130 130
190 SBAL Sub Balance 0-7 5 5 5
191 SBAS Sub Bass 0-7 **** 0 0
192 STRE Sub Treble 0-7 ***** 3 3
193 BBEL BBE Low 0-15 ****** 0 0
194 BBEH BBE High 0-15 ******* 0 0
195 BBE BBE 0-1 ******** 0 0
196 AUX SRS, Simulated 0-3 0 0 0
197 DISP O.S.D Display position 0-127 20 32 34
198 HCLW Horizontal Count Lower limit 0-255 16 16 16 16
199 HCHG Horizontal Count High limit 0-255 64 64 64 64
200 ID0 0-255 25 See ID Map
201 ID1 0-255 3 See ID Map
202 ID2 0-255 91 See ID Map
203 ID3 0-255 2 See ID Map
204 ID4 0-255 233 See ID Map
205 ID5 0-255 17 See ID Map
206 ID6 0-255 0 See ID Map
****SBAS = 0 for 27FV/29FV/32FS/34FS family, 5 for 27FS family
***** STRE = 3 for 27FV/29FV/32FS/34FS family, 2 for 27FS family
****** BBEL = 5 for 27FV family; 6 for 29FV family and 0 for 27FS/29FS/32FS family
******* BBEH = 5 for 27FV family; 7 for 29FV family and 0 for 27FS/29FS/32FS family
******** BBE = 1 for 27FV/29FV families and 0 for 27FS/29FS/32FS family
