SLV-669HF
RMT-V266A
US Model
SERVICE MANUAL
VIDEO CASSETTE PLAYER
MICROFILM
S MECHANISM
Refer to the SERVICE MANUAL of VHS
MECHANICAL ADJUSTMENT for
MECHANICAL ADJUSTMENTS. (9-921-647-11)
Differences Manual
• This Service Manual shows only the differences from SLV-679HF (US model).
Refer to the Service Manual (9-921-709-11) of SLV-662HF/679HF also for repair.
• Main Differences
1. Changed of SERVO/SYSTEM CONTROL IC (IC160)
2. Changed of Remote Commander
• Differences Table
Remote Commander
MA-341 Board, Complete
Front Panel
SLV-679HF (US)
RMT-V266
A-6791-734-A
X-3949-201-1
SLV-669HF
RMT-V266A
A-6713-521-A
X-3949-993-1
SPECIFICATIONS

— 2 —
SECTION 4. PRINTEDWIRING BOARDS AND SCHEMATIC DIAGRAMS
MA-341 (3/7) (SERVO/SYSTEM CONTROL) SCHEMATIC DIAGRAM (Refer to page 4-9)
Page SLV-679HF (US) SLV-669HF
Ref. No. Description Ref. No. Description
IC160 M37760M8A127GP IC160 M37760M8A157GP
4-9
: Changed portion.

— 3 —
SECTION 7. REPAIR PARTS LIST
7-1. EXPLODED VIEWS : Changed portion.
: Deleted portion.
Page SLV-679HF (US) SLV-669HF
Ref. No. Part No. Description Ref. No. Part No. Description
1 X-3949-201-1 PANEL ASSY, FRONT (679)
12 1-418-153-11 COMMANDER,STANDARD (RMT-V266)
1 X-3949-993-1 PANEL ASSY, FRONT
12 1-418-694-11 COMMANDER,STANDARD (RMT-V266A)
7-1
7-1-1. FRONT PANEL AND UPPER CASE SECTION
12
13
8
65
14
7
3
2
1
4
Ref. No. Part No. Description Ref. No. Part No. Description
*52 A-6791-734-A MA-341 BOARD, COMPLETE (679:US,CND) *52 A-6713-521-A MA-341 BOARD, COMPLETE
7-2
7-2. ELECTRICAL PARTS LIST
Page SLV-679HF (US) SLV-669HF
7-6
Ref. No. Part No. Description Ref. No. Part No. Description
*A-6791-734-A MA-341 BOARD, COMPLETE(679: US, CND)
*********************** *A-6713-521-A MA-341 BOARD, COMPLETE ***********************
Ref. No. Part No. Description Ref. No. Part No. Description
IC160 8-759-580-37 IC M37760M8A120GP IC160 8-759-647-76 IC M37760M8A157GP
7-9
7-13E
Ref. No. Part No. Description Ref. No. Part No. Description
MISCELLANEOUS
***************
12 1-418-153-11 COMMANDER,STANDARD (RMT-V266)
*********************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-575-334-11 CORD, CONNECTION
3-865-038-11 MANUAL, INSTRUCTION (ENGLISH)
3-865-038-21 MANUAL, INSTRUCTION
(FRENCH/CHINESE)(CND)
MISCELLANEOUS
***************
12 1-418-694-11 COMMANDER,STANDARD (RMT-V266A)
*********************************************************
ACCESSORIES & PACKING MATERIALS
********************************
______________________
3-867-940-11 MANUAL, INSTRUCTION (ENGLISH)
______________________

SLV-669HF
— 4 —
Sony Corporation
HomeVideo Company
9-921-735-11 99H1629-1D
Printed in Japan ©1999.8
Published by Quality Assurance Dept.
