Photo: SLV-ED939ME

RMT-V408

— Continued on next page —

SERVICE MANUAL

VIDEO CASSETTE RECORDER

TS-10 MECHANISM

Refer to the SERVICE MANUAL of VHS MECHANI-

CAL ADJUSTMENT MANUAL VII for MECHANICAL

ADJUSTMENTS. (9-921-790-11)

SPECIFICATIONS

SLV-ED333/ED939/EZ131/EZ735/EZ737/GA58

RMT-V408/V409/V411

Middle East Model

SLV-ED333ME/ED333SG/ED939ME/

ED939SG/GA58ME/GA58SG

Australia Model

New Zealand Model

SLV-EZ131AZ/EZ735AZ/EZ737AZ

System

Colour system

ED333ME/ED333SG/ED939ME/ED939SG/

GA58ME/GA58SG:

PAL, MESECAM, NTSC 3.58, NTSC 4.43

EZ131AZ/EZ735AZ:

PAL, NTSC 4.43

EZ737AZ:

PAL, NTSC 3.58, NTSC 4.43

TV system

ED333ME/ED333SG/ED939ME/ED939SG:

B/G, D/K, I

EZ131AZ/EZ735AZ/EZ737AZ:

B/G, B/B

GA58ME/GA58SG:

G, K, I

Channel coverage

B/G: VHF E2 to E12/UHF E21 to E69/

CATV S01 to S05, S1 to S41

D/K: VHF R1 to R12/UHF R21 to R69

I: VHF SA4 to SA13/UHF B21 to B69/

CATV S01 to S05, S1 to S41

B/B: VHF R1 to R12/UHF R21 to R69

RF output signal

UHF channels:21 to 69 (B/G, D/K, I)

28 to 69 (B/B)

Aerial out

75-ohm asymmetrical aerial socket

Tape speed

ED333ME/ED333SGED939ME/ED939SG/

EZ737AZ:

LP: PAL 23.39 mm/s (recording/playback)

NTSC 33.35 mm/s

(recording (Line input only)/playback)

LP: PAL 11.70 mm/s (recording/playback)

NTSC 16.67 mm/s (playback only)

EP: NTSC 11.12 mm/s

(recording (Line input only)/playback)

EZ131AZ/EZ735AZ:

LP: PAL 23.39 mm/s (recording/playback)

NTSC 33.35 mm/s (playback only)

LP: PAL 11.70 mm/s (recording/playback)

NTSC 16.67 mm/s (playback only)

EP: NTSC 11.12 mm/s (playback only)

GA58ME/GA58SG:

LP: PAL 23.39 mm/s

NTSC 33.35 mm/s

LP: PAL 11.70 mm/s

NTSC 16.67 mm/s (playback only)

EP: NTSC 11.12 mm/s

Maximum recording/playback time

10 hrs. in LP mode (with E300 tape)

Rewind time

Approx. 1 min.(with E180 tape)

Inputs and outputs

ED333ME/ED333SG/EZ131AZ/GA58ME/GA58SG:

LINE IN

VIDEO IN, phono jack (1)

Input signal: 1 Vp-p, 75 ohms,

unbalanced, sync negative

AUDIO IN, phono jack (1)

Input level: 327 mVrms

Input impedance: more than 47 kilohms

123

456

789

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

— 2 —

SAFETY CHECK-OUT

1. Check the area of your repair for unsoldered or poorly-soldered

connections. Check the entire board surface for solder splashes

and bridges.

2. Check the interboard wiring to ensure that no wires are

“pinched” or contact high-wattage resistors.

3. Lookforunauthorized replacement parts, particularlytransistors,

that were installed during a previous repair. Point them out to

the customer and recommend their replacement.

After correcting the original service problem, perform the following

safety checks before releasing the set to the customer:

4. Look for parts which, though functioning, show obvious signs

ofdeterioration. Pointthemouttothecustomerand recommend

their replacement.

5. Check the B+ voltage to see it is at the values specified.

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0OR DOTTED

LINE WITH MARK 0ON THE SCHEMATIC DIAGRAMS

AND IN THE PARTS LIST ARE CRITICAL TO SAFE

OPERATION. REPLACE THESE COMPONENTS WITH

SONY PARTS WHOSE PART NUMBERS APPEAR AS

SHOWN IN THIS MANUAL OR IN SUPPLEMENTS

PUBLISHED BY SONY.

LINE OUT

VIDEO OUT, phono jack (1)

Output signal: 1 Vp-p, 75 ohms,

unbalanced, sync negative

AUDIO OUT, phono jack (1)

Standard output: 327 mVrms

Load impedance: 47 kilohms

Output impedance: less than 10 kilohms

ED939ME/ED939SG/EZ131AZ/EZ735AZ/

EZ737AZ:

LINE IN 1/LINE-2 IN

VIDEO IN, phono jack (1)

Input signal: 1 Vp-p, 75 ohms,

unbalanced, sync negative

AUDIO IN, phono jack (2)

Input level: 327 mVrms

Input impedance: more than 47 kilohms

LINE OUT

VIDEO OUT, phono jack (1)

Output signal: 1 Vp-p, 75 ohms,

unbalanced, sync negative

AUDIO OUT, phono jack (2)

Standard output: 327 mVrms

Load impedance: 47 kilohms

Output impedance: less than 10 kilohms

General

Power requirements

ED333ME/ED333SG/ED939ME/ED939SG/

GA58ME/GA58SG:

110 – 240 V AC, 50/60 Hz

EZ131AZ/EZ735AZ/EZ737AZ:

220 – 240 V AC, 50 Hz

Power consumption

GA58ME/GA58SG:

10 W

ED333ME/ED333SG/EZ131AZ:

15 W

1.2 W (POWER SAVE is set to ON, minimum)

ED939ME/ED939SG/EZ735AZ/EZ737AZ:

17 W

1.3 W (POWER SAVE is set to ON, minimum)

Operating temperature

5 °C to 40 °C

Storage temperature

–20 °C to 60 °C

Dimensions including projecting parts and controls

(w/h/d)

GA58ME/GA58SG:

Approx. 360 ×95 ×245 mm

ED333ME/ED333SG/EZ131AZ:

Approx. 360 ×95 ×253 mm

ED939ME/ED939SG/EZ735AZ/EZ737AZ:

Approx. 430 ×96 ×253 mm

MassED333ME/ED333SG/GA58ME/GA58SG/

EZ131AZ:

Approx. 2.8 kg

ED939ME/ED939SG/EZ735AZ/EZ737AZ:

Approx. 3.1 kg

Supplied accessories

Remote commander (1)

R6 (size AA) batteries (2)

ED333ME/ED333SG/ED939ME/ED939SG/

EZ131AZ/EZ735AZ/EZ737AZ:

Aerial cable (1)

GA58ME/GA58SG:

75-ohm coaxial cable with F-type connector (1)

ED333/ME/ED939ME/GA58ME:

Plug adaptor (1)

Design and specifications are subject to change without

notice.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

— 3 —

TABLE OF CONTENTS

Important Service Guide

◆Mode Switch (Program Switch) Assembly Point·························4

◆How to eject the cassette tape

(If the unit does not operate on condition that tape is inserted

into housing ass’y)································································· 4

1. General

Getting Started

Index to parts and controls ················································· 1-1

Step 1 : Unpacking ····························································· 1-2

Step 2 : Setting up the remote commander························· 1-2

Step 3 : Connecting the VCR ············································· 1-3

Step 4 : Setting up the VCR with the Auto

Set Up function ····················································· 1-3

Step 5 : Setting the clock ···················································· 1-4

Step 6 : Selecting the TV system········································ 1-5

Selecting a language·············································· 1-5

Presetting channels················································ 1-5

Changing/disabling programme positions············· 1-6

Basic Operations

Playing a tape ····································································· 1-7

Recording TV programmes ················································ 1-8

Recording TV programmes using the Easy Timer ············· 1-9

Recording TV programmes using the timer ····················· 1-10

Additional Operations

Playing/searching at various speeds ································· 1-11

Setting the recording duration time ·································· 1-11

Checking/changing/cancelling timer settings··················· 1-11

Recording stereo and bilingual programmes···················· 1-12

Searching using the index function ·································· 1-13

Adjusting the picture ························································ 1-13

Reducing the VCR’s power consumption ························ 1-13

Changing menu options···················································· 1-13

Editing

Connecting to a VCR or stereo system····························· 1-14

Basic editing ····································································· 1-14

Additional Information

Troubleshooting································································ 1-15

Index ················································································· 1-16

2. Disassembly

2-1 Mono Models

2-1-1 Cabinet Top ········································································ 2-1

2-1-2 Cover Bottom ····································································· 2-1

2-1-3 Ass’y-Panel Front ······························································· 2-2

2-1-4 Ass’y Main PCB, Deck ······················································ 2-3

2-2 Hi-Fi Models

2-2-1 Cabinet Top ········································································ 2-4

2-2-2 Cover Bottom ····································································· 2-4

2-2-3 Ass’y-Panel Front ······························································· 2-5

2-2-4 Ass’y Jack PCB ·································································· 2-5

2-2-5 Ass’y Main PCB, Deck ······················································ 2-6

3. P.C.Boards

3-1 Main PCB ··········································································· 3-3

3-2 Function PCB (Hi-Fi model) ·············································· 3-7

3-3 Dial Timer PCB (Hi-Fi model)··········································· 3-7

3-4 Dial Timer PCB (ED333/EZ131) ······································· 3-9

3-5 Display PCB (GA58)·························································· 3-9

4. Schematic Diagrams

◆Block Identification of Main PCB············································ 4-3

4-1 S.M.P.S. ·············································································· 4-5

4-2 Power ·················································································· 4-7

4-3 System Control/Servo························································· 4-9

4-4 Audio/Video ····································································· 4-11

4-5 Hi-Fi (Hi-Fi model) ·························································· 4-13

4-6 TM-Block ········································································· 4-15

4-7 OSD/VPS/PDC································································· 4-17

4-8 A2/NICAM (Hi-Fi model) ··············································· 4-19

4-9 Input-Output ····································································· 4-21

4-10 Function (Hi-Fi model) ···················································· 4-23

4-11 LED Signal Display (GA58) ············································ 4-25

5. Alignment and Adjustment

5-1 Reference············································································ 5-1

5-1-1 Location of adjustment button of remote control ··············· 5-1

5-1-2 Test point location for adjustment mode setting

(Mono model)····································································· 5-2

5-1-3 SW7T01 (TEST) location for adjustment mode setting

(Hi-Fi model)······································································ 5-3

5-2 Mechanical Adjustment ······················································ 5-4

5-2-1 The number and position of test point ································ 5-4

5-2-2 ACE Head Position (X-Point)Adjustment ························· 5-4

5-3 Head Switching Point Adjustment ····································· 5-5

5-4 NVRAM Option Setting····················································· 5-5

6. Repair Parts List

6-1 Exploded Views ·································································· 6-2

6-1-1 Instrument Assembly (Mono Models) ································ 6-2

6-1-2 Instrument Assembly (Hi-Fi Models)································· 6-3

6-1-3 Mechanical Parts (Top Side) ·············································· 6-4

6-1-4 Mechanical Parts (Bottom Side)········································· 6-5

6-2 Electrical Parts List ···························································· 6-6

•Hi-Fi model: ED939/EZ735/EZ737

Mono model: ED333/EZ131/GA58

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

— 4 —

IMPORTANT SERVICE GUIDE

◆MODE SWITCH (PROGRAM SWITCH) ASSEMBLY POINT

1) When installing the ass’y deck on the Main PCB, be sure to align the assembly point of mode switch.

ASSEMBLY POINT

(ALIGN TWO ARROWS)

Fig. 1

Fig. 2

1GEAR WORM

Fig. 3

FRAME

◆HOW TO EJECT THE CASSETTE TAPE

(If the unit does not operate on condition that tape is inserted into housing ass’y)

1) Turn the Gear Worm 1clockwise in the direction of arrow with screw driver. (See Fig. 2)

(Other method ; Remove the screw of Motor Load Ass’y, Separate the Motor Load Ass’y)

2) When Slider S, T are approached in the position of unloading, rotate holder Clutch counterclockwise after inserting screw driver in the

hole of frame’s bottom in order to wind the unwiunded tape. (Refer to Fig. 3)

(If you rotate Gear Worm 1continuously when tape is in state of unwinding, you may cause a tape contamination by grease and

tape damage. Be sure to wind the unwiunded tape in the state of set horizontally.)

3) Rotate Gear Worm 1clockwise using screw driver again up to the state of eject mode and then pick out the tape. (Refer to Fig. 2)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-1

1. GENERAL

SLV-ED333/ED939/EZ131/

EZ735/EZ737/GA58

This section is extracted from SLV-ED333ME/ED333SG/

ED939ME/ED939SG instruction manual. (3-082-203-11)

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Getting Started

Index to parts and controls

Refer to the pages indicated in parentheses ( ) for details.

Front panel

For SLV-ED939ME/SG

1?/1 ON/STANDBY switch

2Remote sensor (11)

3Tape compartment

4AEJECT button (30)

5mREW (rewind) button (30) (45)

6HPLAY button* (30) (45)

7MFF (fast-forward) button (30)

(45)

8zREC (record) button (33) (46)

(59)

9xSTOP button* (17) (30) (59)

q; XPAUSE button (30) (41) (59)

qa PROGRAM/TRACKING +/—

buttons* (37) (53)

qs EASY TIMER (36)

qd LINE-2 IN VIDEO/AUDIO L/R

(left/right) jacks (57)

*The HPLAY, xSTOP and PROGRAM/

TRACKING + buttons have a tactile dot.

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

For SLV-ED333ME/SG

1?/1 ON/STANDBY switch

2AEJECT button (30)

3Remote sensor (11)

4Tape compartment

5mREW (rewind) button (30) (45)

6HPLAY button (30) (45)

7MFF (fast-forward) button (30)

(45)

8zREC (record) button (33) (46)

(57)

9xSTOP button (17) (30) (59)

q; XPAUSE button (30) (41) (59)

qa EASY TIMER (36)

qs PROGRAM/TRACKING +/—

buttons* (37) (53)

*The PROGRAM/TRACKING + button

has a tactile dot.

continued

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Display window

1Tape indicator

2START indicator (37)

3STOP indicator (37)

4MONTH indicator (40)

5YEAR indicator (40)

6NICAM indicator* (50)

7STEREO indicator* (49)

8Timer indicator (39) (43)

9Recording indicator (33)

0Time counter/clock/line/programme

position indicator (31) (32) (58)

qa Tape speed indicators (32) (38)

*SLV-ED939ME/SG only

31452678

90qa

Index to parts and controls (continued)

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Rear panel

For SLV-ED939ME/SG

For SLV-ED333ME/SG

1(in from antenna) connector (13)

2LINE IN 1 AUDIO R/L/VIDEO

(audio right/audio left/video) jacks*1

(58)

LINE IN 1 AUDIO/VIDEO jacks*2

(57)

3Mains lead (13)

4LINE OUT AUDIO R/L/VIDEO

(audio right/audio left/video) jacks*1

LINE OUT AUDIO/VIDEO jacks*2

(14)

5(out to tv) connector (13)

SLV-ED939ME/SG only

SLV-ED333ME/SG only

continued

321

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-2

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Remote commander

123

456

789

1ZEJECT button (30)

2INPUT SELECT button (32) (42)

(59)

3TV/VIDEO button (for TV)

4CLEAR button (31) (47)

5Programme number buttons*

6-/-- (tens digit) button

7VOL (volume) +/—buttons

8zREC (record) button (33) (46)

9REC SPEED (recording speed)

button (32)

q; MENU button (21) (47)

qa XPAUSE/Mbutton (21) (30)

xSTOP/mbutton (21) (30)

mREW (rewind)/<button (21)

(30) (45)

MFF (fast-forward)/,button

(21) (30) (45)

HPLAY/OK button* (21) (30)

(45)

*The HPLAY, AUDIO MONITOR,

number 5 and PROG + buttons have a

tactile dot.

Index to parts and controls (continued)

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

qs ?/1 (on/standby) switch (43)

qd ¥TV/VIDEO remote control switch

(11)

qf AUDIO MONITOR button*1*2(51)

qg DISPLAY button (31) (33)

qh PROG (programme) +/—buttons*1

(34)

qj ySLOW button (45)

qk ×2 button (45)

ql ./> INDEX SEARCH

buttons (52)

The HPLAY, AUDIO MONITOR,

number 5 and PROG + buttons have a

tactile dot.

SLV-ED939ME/SG only

123

456

789

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Step 1 : Unpacking

Check that you have received the following items with the VCR:

¥Remote commander ¥Aerial cable

¥R6 (size AA) batteries ¥Plug adaptor (SLV-ED939ME and

ED333ME only)

Check your model name

The instructions in this manual are for the 4 models: SLV-ED939ME/SG and

ED333ME/SG. Check your model name by looking at the rear panel of your

VCR. SLV-ED939ME is the model used for illustration purposes. Any

difference in operation is clearly indicated in the text, for example,

SLV-ED939ME only.

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

123

456

789

Step 2 : Setting up the remote

commander

Inserting the batteries

Insert two R6 (size AA) batteries

by matching the + and —on the

batteries to the diagram inside the

battery compartment.

Insert the negative (—) end first,

then push in and down until the

positive (+) end clicks into

position.

Using the

remote commander

You can use this remote

commander to operate this VCR

and a Sony TV. Buttons on the

remote commander marked with

a dot (¥) can be used to operate

your Sony TV. If the TV does

not have the symbol near the

remote sensor, this remote

commander will not operate the

TV.

Remote sensor

To operate Set ¥TV/VIDEO to

the VCR VIDEO and point at the remote sensor at the VCR

a Sony TV ¥TV and point at the remote sensor at the TV

continued

¥TV/VIDEO

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-3

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Notes

¥With normal use, the batteries should last about three to six months.

¥If you do not use the remote commander for an extended period of time, remove

the batteries to avoid possible damage from battery leakage.

¥Do not use a new battery together with an old one.

¥Do not use different types of batteries together.

¥Some buttons may not work with certain Sony TVs.

Step 2 : Setting up the remote commander (continued)

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Step 3 : Connecting the VCR

Connect the aerial to your VCR and TV as shown below to watch TV

programmes and VCR pictures on your TV. In addition, if your TV has

audio/video (A/V) input jacks, we recommend you connect the VCR to your

TV using an audio/video cable to get a better picture and sound.

Connecting the aerial

Mains lead

AERIAL IN

to mains

Aerial cable (supplied)

: Signal flow

Disconnect the aerial cable from your

TV and connect it to on the rear

panel of the VCR.

Connect of the VCR and the aerial

input of your TV using the supplied

aerial cable.

Connect the mains lead to the mains.

Note

¥When you connect the VCR and your TV only with an aerial cable, you have to

tune your TV to the VCR (see page 15).

continued

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

To a stereo system

(SLV-ED939ME/SG

only)

You can improve sound

quality by connecting a

stereo system to the LINE

OUT AUDIO R/L jacks as

shown on the left.

Note

¥To play a tape in stereo, you must connect your VCR either to a TV with audio/

video input jacks or to a stereo system as shown on above left.

Additional connections

To a TV that has audio/

video input jacks

This additional connection

improves picture and sound

quality. Connect the TV as

shown on the left.

LINE OUT

AUDIO R/L

Audio cable (not supplied)

For SLV-ED939ME/SG

LINE OUT

LINE IN

Audio/video cable (not supplied)

For SLV-ED333ME/SG

LINE OUT

LINE IN

Audio/video cable (not supplied)

LINE IN

Step 3 : Connecting the VCR (continued)

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Step 4 : Setting up the VCR with

the Auto Set Up function

Before using the VCR for the first time, set up the VCR using the Auto Set Up

function. With this function, you can set the language for the on-screen display and

TV channels automatically.

Turn on your TV and set it to the video channel.

Tune the TV to channel 32 (the initial RF channel for this VCR).

Refer to your TV manual for TV tuning instructions. If the picture

does not appear clearly, see To change the RF channelon

page 17.

Connect the mains lead to the mains.

The VCR automatically turns on.

The LANGUAGE SET menu

appears on the TV screen.

Press </,to select the desired

language, ENGLISH or ARABIC,

then press OK.

The message for the Auto Set Up

function appears.

EXIT MENU:OK:SET

SELECT

ENGLISH ARABIC

PLAY

continued

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-4

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Press OK.

The SYSTEM SELECT menu appears.

Press M/m/</,to select the

appropriate TV system, then press

OK.

The VCR starts searching for all of

the receivable channels and presets

them (in the appropriate order for

your local area).

If you want to change the order of

the channels or disable unwanted

programme positions, see

Changing/disabling programme

positionson page 25.

After the search is complete, the clock setting menu appears. See

Setting the clockon page 18.

PLAY

MENU:

PLEASE WAIT

AUTO SET UP

40%

EXIT

PLAY

Step 4 : Setting up the VCR with the Auto Set Up function (continued)

EXIT MENU:OK:SET

SELECT

SYSTEM

SYSTEM SELECT

—B/G

D/K—

—

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

To cancel the Auto Set Up function

Press MENU.

To change the RF channel

If the picture does not appear clearly on the TV, change the RF channel on

the VCR and TV. Select INSTALLATION from the menu, then press M/m

to highlight VCR OUTPUT CH and press ,. Select the RF channel by

pressing the M/mbuttons. Then, tune the TV to the new RF channel so that

a clear picture appears.

Tip

¥If you want to change the language for the on-screen display from the one preset

in the Auto Set Up function, see page 21.

Notes

¥Whenever you operate the Auto Set Up function, some of the settings (timer, etc.)

will be reset. If this happens, you have to set them again.

¥Auto preset starts automatically only when you plug in the mains lead for the first

time after you purchase the VCR.

¥After using the Auto Set Up function, the LANGUAGE SET menu does not

appear automatically when you connect the mains lead again. If you want to use

the Auto Set Up function again, press MENU, then press M/m/</,to highlight

INSTALLATION and press OK. Press M/mto highlight AUTO SET UP, then

repeat all procedures from step 3.

¥Auto preset can be performed by pressing xSTOP on the VCR continuously for

5 seconds or more with no tape inserted.

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Step 5 : Setting the clock

You must set the time and date on the VCR to use the timer features properly.

Before you start

¥Turn on the VCR and the TV.

¥Set the TV to the video channel.

¥Refer to Index to parts and controlsfor button locations.

Press MENU, then press M/m/</

,to highlight CLOCK SET and

press OK.

Press M/mto set the hour.

Press ,to select the minutes and

set the minutes by pressing M/m.

SET

MENU:

OK:END

SELECT

12 0 1 JAN/0:20

WED

03/

EXIT

PLAY

SET

MENU:

OK:END

SELECT

18 0 1 JAN/0:20

WED

03/

EXIT

SET

MENU:

OK:END

SELECT

18 3 1 JAN/0:20

WED

03/

EXIT

PLAY

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Set the day, month, and year in

sequence by pressing ,to select

the item to be set, and press M/mto

select the digits, then press ,.

The day of the week is set

automatically.

Press MENU to exit the menu.

Tip

¥To change the digits while setting, press <to return to the item to be changed,

and select the digits by pressing M/m.

PLAY

SET

MENU:

OK:END

SELECT

18 3 82SEP/0:20

SUN

03/

EXIT

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-5

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Step 6 : Selecting the TV system

You must select the appropriate TV system for your area.

Before you start

¥Turn on the VCR and the TV.

¥Set the TV to the video channel.

¥Refer to Index to parts and controlsfor button locations.

Press MENU, then press M/m/</

,to highlight INSTALLATION

and press OK.

Press M/mto highlight TV

SYSTEM, then press ,.

Press ,to select the appropriate TV system.

Select For

Gthe B/G TV system

Kthe D/K TV system

Ithe I TV system

Press MENU to exit the menu.

PLAY

SET

MENU:

OK:END

SELECT

AUTO SET UP

MANUAL SET UP

TV SYSTEM

32:

VCR OUTPUT CH

EXIT

SET

MENU:

OK:END

SELECT

AUTO SET UP

MANUAL SET UP

TV SYSTEM

32:

VCR OUTPUT CH

EXIT

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Selecting a language

You can change the on-screen display language from the one you selected with the

Auto Set Up function.

Before you start

¥Turn on the VCR and the TV.

¥Set the TV to the video channel.

¥Refer to Index to parts and controlsfor button locations.

Press MENU, then press M/m/</

,to highlight LANGUAGE SET

and press OK.

Press </,to highlight the desired language, ENGLISH or

ARABIC, then press OK.

PLAY

EXIT MENU:OK:SET

SELECT

ENGLISH ARABIC

PLAY

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Presetting channels

If some channels could not be preset using the Auto Set Up function, you can preset

them manually.

Before you start

¥Turn on the VCR and the TV.

¥Set the TV to the video channel.

¥Refer to Index to parts and controlsfor button locations.

Press MENU, then press M/m/</

,to highlight INSTALLATION

and press OK.

Press M/mto highlight MANUAL

SET UP, then press ,.

Press M/mto highlight the row

which you want to preset, then

press ,.

To display other pages for

programme positions 6 to 80, press

M/mrepeatedly.

PLAY

SET

MENU:

OK:END

SELECT

AUTO SET UP

MANUAL SET UP

TV SYSTEM

32:

VCR OUTPUT CH

EXIT

PLAY

EXIT MENU:CLEAR:DELETE

SWAPPING OK

TV STATION TABLE

—

B/G/D/K

PR CH NAME SYSTEM

PLAY

MENU:OK:END

SELECT

PR : 5

SYSTEM : B/G/D/K

MFT : —

NAME : ————

:SET :

EXIT

MANUAL TUNING

CH : ———

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Press </,repeatedly until the

channel you want is displayed.

Select the appropriate TV system, if

necessary.

Press M/mto highlight NAME,

then press ,.

Enter the station name.

1Press M/mto select a character.

Each time you press M, the

character changes as shown

below.

A tB t tZ t0 t1

t t9 tA

2Press ,to set the next character.

The next space flashes.

To correct a character, press </,until the character you want

to correct flashes, then reset it.

You can set up to 4 characters for the station name.

Press OK to confirm the station name.

Press MENU to exit the menu.

PLAY

MENU:OK:END

SELECT

PR : 5

SYSTEM : B/G/D/K

MFT : —

NAME : ————

:SET :

EXIT

MANUAL TUNING

CH : 033

PLAY

MENU:OK:END

SELECT

PR : 5

SYSTEM : B/G/D/K

MFT : —

NAME : ————

:SET :

EXIT

MANUAL TUNING

CH : 033

PLAY

MENU:OK:END

SELECT

PR : 5

SYSTEM : B/G/D/K

MFT : —

NAME : O———

:SET :

EXIT

MANUAL TUNING

CH : 033

continued

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

1-6

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

If the picture is not clear

If the picture is not clear, you may use the Manual Fine Tuning (MFT)

function. After step 4, press M/mto select MFT. Press </,to get a clear

picture, then press MENU to exit the menu.

Notes

¥If the TV sound is distored or noisy, select the appropriate TV system (G, K

or I) for your area (see page 20).

¥When adjusting MFT, the menu may become difficult to read due to interference

from the picture being received.

Presetting channels (continued)

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Changing/disabling programme

positions

After setting the channels, you can change the programme positions as you like. If

any programme positions are unused or contain unwanted channels, you can disable

them.

You can also change the station names. If the station names are not displayed, you

can enter them manually.

Changing programme positions

Before you start

¥Turn on the VCR and the TV.

¥Set the TV to the video channel.

¥Refer to Index to parts and controlsfor button locations.

Press MENU, then press M/m/</

,to highlight INSTALLATION

and press OK.

Press M/mto highlight MANUAL

SET UP, then press ,.

Press M/mto highlight the row

containing the programme position

you want to change.

To display other pages for

programme positions 6 to 80, press

M/mrepeatedly.

PLAY

SET

MENU:

OK:END

SELECT

AUTO SET UP

MANUAL SET UP

TV SYSTEM

32:

VCR OUTPUT CH

EXIT

EXIT MENU:CLEAR:DELETE

SWAPPING OK

TV STATION TABLE

—

B/G/D/K

PR CH NAME SYSTEM

PLAY

MENU:CLEAR:DELETE

SWAPPING OK

TV STATION TABLE

—

B/G/D/K

PR NAME SYSTEM

EXIT

PLAY

continued

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Press OK, then press M/mto move

to the desired programme position.

Press OK to confirm the setting.

To change the programme position of another station, repeat steps 3

through 5.

Press MENU to exit the menu.

Disabling unwanted programme positions

After presetting channels, you can disable unused programme positions. The

disabled positions will be skipped later when you press the PROG +/—buttons.

Before you start

¥Turn on the VCR and the TV.

¥Set the TV to the video channel.

¥Refer to Index to parts and controlsfor button locations.

Press MENU, then press M/m/</

,to highlight INSTALLATION,

and press OK.

PLAY

MENU:

SWAPPING OK

TV STATION TABLE

—

B/G/D/K

PR NAME SYSTEM

EXIT

PLAY

SET

MENU:

OK:END

SELECT

AUTO SET UP

MANUAL SET UP

TV SYSTEM

32:

VCR OUTPUT CH

EXIT

Changing/disabling programme positions (continued)

Getting Started

SLV-ED939ME/SG 3-082-203-11 (1) GB ME/SG

Press M/mto highlight MANUAL

SET UP, then press ,.

Press M/mto highlight the row

which you want to disable.

To display other pages for

programme positions 6 to 80, press

M/mrepeatedly.

Press CLEAR.

The selected row will be cleared as

shown on the left.

Repeat steps 3 and 4 for any other programme positions you want

to disable.

Press MENU to exit the menu.

Note

¥Be sure to select the programme position you want to disable correctly. If you

disable a programme position by mistake, you need to reset that channel manually.

PLAY

EXIT MENU:CLEAR:DELETE

SWAPPING OK

TV STATION TABLE

—

B/G/D/K

PR CH NAME SYSTEM

PLAY

EXIT MENU:CLEAR:DELETE

SWAPPING OK

TV STATION TABLE

—

B/G/D/K

PR CH NAME SYSTEM

MENU:CLEAR:DELETE

SWAPPING OK

TV STATION TABLE

—

B/G/D/K

PR NAME SYSTEM

EXIT

CLEAR

continued

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

This manual suits for next models

Table of contents

Other Sony VCR System manuals

Sony

Sony SLV-N71 - Video Cassette Recorder User guide

Sony

Sony Video Walkman GV-D200 User manual

Sony

Sony SLV-KA195CH User manual

Sony

Sony 1080i User manual

Sony

Sony DSR-40/40P User manual

Sony

Sony DNW-A28 User manual

Sony

Sony RDR-VX515 - Dvd Recorder/vcr Combo User manual

Sony

Sony SLV-KF295SV User manual

Sony

Sony SLV-SE610A User manual

Sony

Sony SLV-478 User manual

Sony

Sony HDV HVR-1500 User manual

Sony

Sony HVR-1500A User manual

Sony

Sony DSR-1800 User manual

Sony

Sony SVT-124 User manual

Sony

Sony SLV-N51 - Video Cassette Recorder Operator's manual

Sony

Sony HVR-M10N User manual

Sony

Sony SRW-5000 User manual

Sony

Sony SLV-750HF - Hi Fi Stereo Vhs Vcr User manual

Sony

Sony UVW-1800 User manual

Sony

Sony SLV-788HF - Video Cassette Recorder User manual

Sony

Sony SLV-E580EE User manual

Sony

Sony SLV-P58EE User manual

Sony

Sony SLV-E730EX/UX User manual

Sony

Sony SLV-685HF User manual

Popular VCR System manuals by other brands

Toshiba

Toshiba M-662 owner's manual

JVC

JVC HR-J282EU Service manual

Panasonic

Panasonic AGDTL1P - TIME LAPSE RECORDER operating instructions

RCA

RCA VR678HF user guide

Sylvania

Sylvania SRV196 owner's manual

Akai

Akai VS-606EA Operator's manual

Fisher

Fisher FVH-8300 operating instructions

Zenith

Zenith VRL4270HF Operating guide & warranty

Panasonic

Panasonic Omnivision PV-4661 operating instructions

Panasonic

Panasonic Omnivision PV-V4601 user guide

GE VG2050 user guide

Sanyo

Sanyo TLS-9072 instruction manual

Philips

Philips VR969/05 operating manual

Memorex

Memorex MVR4041 Service manual

Arm Electronics

Arm Electronics VCR800 instruction manual

Panasonic

Panasonic NV-SD200BA operating instructions

Sanyo

Sanyo VHR-230 series instruction manual

Panasonic

Panasonic NV-SJ412EE operating instructions

Sony SLV-ED333 User manual

Popular VCR System manuals by other brands
