Sound Sation WF-LM10 User manual

USER MANUAL
Cardioid lavalier Microphone
WF-LM10
WF-LM10
www.soundsationmusic.com Ver 1.0 - Mar. 2023
www.soundsationmusic.com
3
Dear customer,
First of all thanks far purchasing a SOUNDSATION® product. Our mis-
sion is to satisfy all possible needs of musical instrument and profes-
sional audio and lighting users offering a wide range of products using
the latest technologies.
We hope you will be satisfied with this item and, if you want to collab-
orate, we are looking for a feedback from you about the operation of
the product and possible improvements to introduce in the next future.
Go to our website www.soundsationmusic.com and send an e-mail
with your opinion, this will help us to build instruments ever closer to
customer’s real requirements.
One last thing: read this manual before using the instrument, an incor-
rect operation can cause damages to you and to the unit. Take care!
The SOUNDSATION Team
TABLE OF CONTENTS
1. FEATURES...................................................................................................... page 4
2. TECHNICAL SPECIFICATIONS................................................................ page 4
3. FREQUENCY RESPONSE GRAPH.......................................................... page 4
4. POLAR PATTERN GRAPH......................................................................... page 5
5. WF-LM10 RETAIL BOX CONTAINS....................................................... page 5
6. COMPATIBILITY CHART............................................................................ page 5
7. IMPORTANT INSTRUCTIONS................................................................. page 6
8. WARRANTY AND SERVICE ..................................................................... page 7
9. WARNING ..................................................................................................... page 8
4
1. FEATURES
Specifically designed for conferences, presentations and live events
3.5mm TS Screw-lock Jack connector for wireless bodypacks
Electret capsule with cardioid polar pattern
Foam windscreen
Unobtrusive small clip for attaching to clothing
Compact, discreet design
2. TECHNICAL SPECIFICATIONS
Impedance 680Ω± 10%
Sensitivity -37dB ± 2dB
Frequency Response 20Hz - 20kHz
Directivity Uni-directional Cardioid
Working voltage 1.0V - 10V
Connector 3.5mm TS Screw-lock jack
Wire rod 2.3mm / L=1.2M
3. FREQUENCY RESPONSE GRAPH
40 50 60 100 200 300 400 500 1K 2K 3K 4K 5K 6K 10K 20K
Frequency [Hz]
-40.0
-42.0
-44.0
-46.0
-48.0
-50.0
-52.0
-54.0
-56.0
-58.0
-60.0
-62.0
-64.0
-66.0
-68.0
-70.0
-72.0
-74.0
-76.0
-78.0
-80.0
-82.0
-84.0
-85.4
[dB re 1V]

5
4. POLAR PATTERN GRAPH
5. WF-LM10 RETAIL BOX CONTAINS
PLEASE NOTE : Technical specifications and appearance
subject to change without notice. The information contained
herein is correct at the time of printing.
6. COMPATIBILITY CHART
SKU Soundsation Model
E074E WF-U2600HP
E076E WF-U2300HP
E560E WF-U2300PP
I624I WF-U1300P
J243J WF-U216HP
J244J WF-U216PP
WF-LM10
Microphone
Microphone Cable
(3.5mm TS Screw-lock Jack) User manual
USER MANUAL
Cardioid lavalier Microphone
WF-LM10
WF-LM10
www.soundsationmusic.com
6
7. IMPORTANT INSTRUCTIONS
1. Read these instructions. Keep these instructions. Heed all warnings.
Follow all instructions.
2. Pay attention to insert the connector completely into the device to
avoid contact NG (no sound or staccato).
3. If the head of the microphone is covered or brought too close to
the speaker, a howling sound may be generated. To prevent this,
first decrease the volume, then place the microphone so that it is
not pointed too close to the speaker and that there is a sufficient
distance between the microphone and speaker.
4. It is important to keep foreign particles out of the capsule and the
windscreen because they may alter the frequency response of the
microphone.
5. Keep the microphone far from magnetic fields, otherwise per-
manent magnet will lose its magnetism, thus reducing capsule
sensitivity and affect the sound quality.
6. Avoid dropping or hitting.
7. Insert the 3.5mm Screw-lock Jack connector into the bodypack and
screw it until it is firm and stable.
8. Do not pull hard on the cable to prevent it from breaking.
9. Do not place near any heat sources such as radiators, heat regis-
ters, stoves, or other apparatus (including amplifiers) that produce
heat.
10. Only use attachments/accessories specified by the manufacturer.
11. Do not disassemble the microphone or modify the inside to avoid
malfunction. Refer all servicing to qualified service personnel.
Service is required when the device has been damaged in any
way, e.g. by spilled liquids or objects dropped inside the device,
exposure to rain or moisture, device has been dropped or just does
not function normally.
7
8. WARRANTY AND SERVICE
All SOUNDSATION products feature a limited two-year warranty. This
two-year warranty is specific to the date of purchase as shown on your
purchase receipt.
The following cases/components are not covered from the above
warranty:
• Any accessories supplied with the product
• Improper use
• Fault due to wear and tear
• Any modification of the product effected by the user or a third
party
SOUNDSATION shall satisfy the warranty obligations by remedying any
material or manufacturing faults free of charge at SOUNDSATION’s
discretion either by repair or by exchanging individual parts or the en-
tire appliance. Any defective parts removed from a product during the
course of a warranty claim shall become the property of SOUNDSATION.
While under warranty period, defective products may be returned
to your local SOUNDSATION dealer together with original proof of
purchase. To avoid any damages in transit, please use the original
packaging if available. Alternatively you can send the product to
SOUNDSATION SERVICE CENTER – Via Enzo Ferrari , 10 – 62017 Porto
Recanati - Italy . In order to send a product to service center you need
an RMA number. Shipping charges have to be covered by the owner of
the product.
For further information please visit www.soundsationmusic.com
8
9. WARNING
PLEASE READ CAREFULLY – EU and EEA (Norway, Iceland and Liechten-
stein) only
This symbol indicates that this product is not to be disposed of with
your household waste, according to the WEEE Directive (2202/96/EC)
and your national law.
This product should be handed over to a designated collection point,
e.g., on an authorized one-for-one basis when you buy a new similar
product or to an authorized collection site for recycling waste electrical
and electronic equipment (WEEE).
Improper handling of this type of waste could have a possible nega-
tive impact on the environment and human health due to potentially
hazardous substances that are generally associated with EEE. At the
same time, your cooperation in the correct disposal of this product will
contribute to the effective usage of natural resources.
For more information about where you can drop offyour waste equip-
ment for recycling, please contact your local city office, waste authority,
approved WEEE scheme or your household waste disposal service.
This product is imported in EU by
FRENEXPORT SPA – Via Enzo Ferrari, 10 - 62017 Porto Recanati - Italy
Soundsation® is a registered trademark of FRENEXPORT SPA
