Soundance S1 User manual

1
Soundance Bluetooth Speaker User Manual
Model S1
Thank you for purchasing the Model S1 Bluetooth speaker. Please read this
manual carefully and keep it for future reference.
Features of the speaker
1. New Bluetooth Technology supports wireless control through a Bluetooth device
2. Large Screen display of Time, Alarm, Temperature, Battery level and Mode
3. Built-in FM radio with automatic channel searching
4. Plays MP3, WAV, WMA, APE, FLAC format audio files from a Micro SD card / TF
card and USB. Shuffle function when playing from a USB or Micro SD / TF card
5. 3.5mm line-in jack for wired devices
6. Built-in 2000mAh rechargeable battery
7. Two 45mm speaker drivers deliver 6W deep and rich sound
8. Built-in microphone for phone calls
9. Alarm setting for FM radio and music from a USB / Micro SD card. Repeat alarm
and snooze function
10. Built-in white noise and nature sound to aid sleeping

2
Operating Instructions
1. Charging
Connect the Micro-USB connector of the charging cable to the DC5V input socket
at the rear side of the speaker and plug the USB connector of the charging cable to
an external USB power supply socket with a minimum supply current of 1A
(recommended charge current is 2A).
The external USB power supply can be the USB wall charger included in the
package, the USB socket in your computer / laptop, the USB adaptor of most cell
phone USB chargers with DC5V output, or the 5V USB port of a power socket etc.
When charging, the charge indicator on the charge port will be on and it will turn off
when charging is complete.
2. On / Off
Slide the ON / OFF switch at the rear side to turn on / off the speaker. The speaker
will enter Time mode after turning on.
3. Bluetooth
Press the “ ” button to enter Bluetooth mode, press the “ ” button again will
exit to Time mode.
Paring - When the speaker is in Bluetooth mode, turn on your Bluetooth device
and search for Bluetooth equipment “S1”, and then pair up with the speaker.

3
Bluetooth phone call - When paired to your phone, press the “ ” button to
answer incoming calls, press “ ” again to end the call. Hold the “ ” button to
reject the call. Pressing the “ ” button twice will call the last incoming call number.
(Note: Microphone is on top of the speaker, please talk into the microphone when
making phone calls.)
Track selection - When playing music in Bluetooth mode, press the “ ” or “ ”
button to jump to the previous track or next track. Track selection can also be done
from your Bluetooth device.
4. FM Radio
Press the “ ” button to enter FM mode. Press the “ ” button again will exit to
Time mode.
FM channel search - When in FM mode, press and hold the “ ” button to start
automatic channel searching. The speaker will save the channels it finds and
automatically assign channel number.
Channel selection - After channels have been saved, press the “ ” or “ ”
button to move to the next or previous channel.
Delete channel - Press and hold the “ ” button while the radio is playing the
channel you want to delete.

4
5. USB / Micro SD Card
The speaker supports a USB / Micro SD card. Just plug your USB Flash Drive or
Micro SD Card into the speaker’s USB port or Card slot and the speaker will play
the music files automatically.
Note - USB / Micro SD card is not supported when in FM mode. If the speaker is in
FM mode, press the “ ” or “ ” button to exit FM mode and insert the USB /
Micro SD card.)
Shuffle - When playing music from a USB / Micro SD card, press and hold the “ ”
button to switch between shuffle and sequence playing. “-R-”on the screen means
Random play.
6. Setting the Time
Press and hold the “ ” button and the hour number will start flashing, press “ ”
or “ ”to adjust the hour. Press “ ” again to confirm the hour setting, and the
minute number will start flashing. Press “ ” or “” to adjust the minute. Press
“ ” again to confirm the minute setting
Pressing “ ” in time mode will switch between 12H and 24H display format.
7. Alarm
Alarm can only be set in Time mode, press “ ” button to enter Time mode before
setting alarm.

5
7.1 Press and hold the “ ” button to start alarm setting -
◇Press the “ ” or “” button to set the hour and press the “ ” button to
confirm, and then press the “ ” or “” button to set the minute and then press
the “ ” button to move to alarm ring setting.
◇Press the “ ” button to select from the 3 default rings and press “ ” to
confirm.
◇Press the “ ” button to turn on or off repeat alarm, when repeat alarm is on,
the repeat symbol will be displayed on the screen.
◇Note: In Time mode, press the “ ” button to turn the alarm on or off. When
the alarm is on, the alarm indicator will be displayed on the screen.
7.2 Setting Radio or music in USB / Micro SD as alarm -
◇When the alarm is turned on, play the radio station or music from a USB / Micro
SD which you want to set as the alarm, and press the “ ” button. The screen will
display “-AL-”, and the radio station or music playing will be set as the alarm ring.
◇Please note that the USB / Micro SD alarm ring setting will change to a default
ring when the USB / Micro SD card is removed from the speaker.
7.3 Turn off the alarm - The alarm will sound for 10 minutes, press any buttons
except the “ ” or “ ” to turn off the alarm.
7.4 Snooze - When the alarm is ringing, press the “ ” or “” button and the
alarm will ring again after 5 minutes.
7.5 Set the alarm volume - Press “ ” to go to time mode fist and then press and
hold “ ” or “ ” button to set alarm volume.

6
8. Aid Sleeping
Press the “ ” button to aid sleeping sound setting. Press “ ” or “ ” button
to select from the 6 default nature sounds. Press and hold “ ” or “ ” button to
set the aid sleeping sound volume. If you want to stop the aid sleeping sound,
please press the “ ” button.
9. Sleep Timer
When playing from Aid sleeping, FM radio, Bluetooth, USB, Micro SD card or Aux
audio cable, press and hold “ ” button move to shut-off time setting, and press
“ ” or “ ” button to set 30min, 45min or 60min shut-off time. And when the
screen display “CONt”, the speaker will play continuously.
10. Screen and Display
◇Press the “ ” button to select from the 3-brightness level of the screen.
◇In time mode, press the “ ” button to switch between 12H and 24H time
display format.
◇Press the C/F button on the rear side of the speaker to switch the temperature
display between Degrees Celsius and Fahrenheit.
◇When speaker is switched to Bluetooth, FM radio, USB / Micro SD card or AUX,
the screen will display time after 10 seconds.
◇If battery is exhausted completely, the user setting will be cleared.

7
11. Reset
If the speaker is not working normally, insert the reset pink or a thin wire into the “R”
hole on the rear side to reset.
Technical Data
Power
Built-in high capacity Lithium Ion battery
External USB 5V supply
Power input: 1~2A
Technical
Frequency
80Hz~18kHz
FM radio
87.5~108MHz
SNR
≥85db (line out)
Sensitivity rate
80db
THD
0.3% (line out)
Bluetooth version
4.2 + ERD
Output power
3W x 2
Speaker
Φ45mm, 4Ω, 3W x 2
Music format
MP3, WMA, WAV,APE, FLAC
Speaker size
194 x 80 x 58 mm (7.6 x 3.1 x 2.3 inch)
Speaker weight
169.5 g (0.37 lb)

8
Troubleshooting
◇Cannot turn the speaker on - Check if the battery is low. Charge the speaker
and turn on again.
◇Cannot charge the speaker - Check the power supply is working and that the
output of the power supply to the charging cable is 5V and 1~2A. Check that the
charging cable and connectors of the cable are not damaged.
◇Buttons not working - Reset the speaker by inserting the reset pink or a thin
wire into the “R”hole on the rear side.
◇No FM radio - Check if any electronic equipment is interfering with the signal.
Adjust the direction or position of the speaker or move to an open area for a better
signal reception.
Warning
◇Do not use the product in high temperatures. Always keep the product away
from fire. For your own safety, never throw the product into a fire, as this may
cause an explosion and personal injury.
◇Do not use the product close to high-voltage wires or electronic equipment.
Keep the speaker away from water and avoid using the speaker in high-humidity
environments.
◇Keep the speaker away from any strong magnetic fields.

9
◇Charge the speaker regularly to avoid damage of battery result from low battery
level. It’s recommended to charge the speaker from 5V 2A USB input.
Tips
When you use it as a clock or alarm clock, please keep the speaker connected to a
charger to maintain adequate electricity.
Support
If you have any questions or problems in using the speaker, please feel free to
write to:
[email protected]
