Soundance SDY033 User manual

1
Soundance®
®®
®
Bluetooth Speaker User Manual
-----------------------------------------------
Model SDY033
Thank you for purchasing Soundance bluetooth speaker. Please read this manual
carefully and keep it for future reference.
Features of the speaker:
1. New Bluetooth Technology, support wireless control through Bluetooth device
. LED time display (in 4 hour format only).
3. Built-in FM radio with automatic channel searching function
4. Support plug and play for Micro SD card/TF card and USB
5. 3.5mm line-in jack for wired devices
6. Built-in rechargeable battery supports up to 8 hours playback (medium volume)
7. 5W speaker with enhanced bass resonator deliver deep and rich sound
8. Built-in Microphone for phone Calls
9. Support MP3, WAV, WMA, APE, FLAC format of audio file Micro SD card/TF
card, USB storage device

2
Button illustration schematic diagram:
Previous / Fast backward Next / Fast forward VOL+
Power / Pause / Play MODE VOL-
USB port TF card slot Aux Reset DC charging 5V

3
Operating nstructions:
1. Charging
With the speaker turned off, connect the Micro-USB connector of the charging
cable to the DC5V input socket at the rear side of the speaker, and plug the USB
connector of the charging cable to an external USB power supply socket with a
minimum supply current of 1A. The external USB power supply can be the USB
socket in your computer/laptop, the USB adaptor of most cellphone USB chargers
with DC5V output, or the 5V USB port of a power socket etc.
When charging, this will be indicated on the LCD screen.
2. On/Off
Press and hold the button to turn on or turn off the speaker.
3. Mode Selection
Short press button Bluetooth to switch between Bluetooth/ Line in / FM /
USB / TF card / time mode.
4. Bluetooth
Paring – 1. Press the button to enter Bluetooth mode. The LCD screen
will display “bt” to show that the speaker is in Bluetooth mode. Turn on your

4
Bluetooth device (such as a mobile phone, laptop, PDA etc) , search for bluetooth
equipment “SDY033”, and then pair up with the speaker. There will be a sound
from the speaker when Bluetooth connection is established.
Bluetooth phone call - When paired to your phone, press the button to
answer incoming calls, and press the button again to end the call. Press
the button twice will call back to the last incoming call number.
Note: Microphone is on top of the speaker, please talk close to the microphone
when making phone calls.
Volume adjustment – When playing music and when making a phone call under
Bluetooth mode, the volume can be adjusted by pressing the button.
The volume can also be controlled from your Bluetooth device (cellphone, laptop,
PDA etc.)
Track selection – When playing music in Bluetooth mode, a short press of
button will jump to the previous track or next track. Track selection can
also be done from your Bluetooth device.
5. FM radio
Press button to enter FM mode.
FM Channel Search – When in FM mode, press and hold the button to
start automatic channel searching. The speaker will save the channels it finds
and automatically assign them a channel number.
Channel Selection – After channels have been saved, press the button

5
to select channels. The LCD screen will display the frequency of the FM channel.
6. AUX / Line in
Insert the audio cable into the 3.5mm jack of speaker and connect the other side to
your laptop / mobile phone / mp3 / mp4/CD player etc to play music file from
AUX/Line in.
7. USB / Micro SD Card
The speaker supports plug and play for USB/Micro SD card. Just plug in your
USB Flash Drive or Micro SD Card into the speaker’s USB port or Card slot and
the speaker will play the music files automatically. Refer to item 10 Technical
data below for acceptable music formats.
8. Time setting
Press button to enter time mode, short press the button to
switch between the hour and minute, then short press button to adjust
the time accordingly. After finished setting, short press button to save
the time setting.
9. Reset
If the speaker is not working normally, please use a thin wire to touch the reset
hole and then machine will turn off and reset.

6
10. Technical Data
Note: When machine is in low power, machine will decrease the volume and then
lock the volume, please charge the speaker and then volume can be unlocked.
Trouble shooting:
1. Can’t turn the speaker on:
Check if the battery is in low. Recharge and then try to turn on again. The
2. Can’t charge the speaker:
Check the power supply is working and that the output of the power supply to the
charge cable is 5V and > 1A.
Check that the charge cable and connectors of the cable are not damaged.
Check if the battery is damaged or need to be replaced.
3. No sound:
Check the speaker is paired with the right Bluetooth device. If not, disconnect
Power
Built-in high capacity Li battery
External USB 5V supply
Working voltage : 3.3V-4. V
Charging voltage: 5V 1000mA
Technical
Frequency 80HZ- 0KHZ
FM radio 87.5-108MHz
SNR ≥
≥≥
≥90db
Sensitivity Rate 80db
THD 0.3%
Speaker Φ5 mm 4Ω 5w
Music format MP3、WMA、WAV,、APE、FLAC
Speaker size 00 x55x 8 mm

7
the Bluetooth connection and pair again to the right device.
Check the music format in the USB or TF/card.
4. No FM radio
Check if there is any electronic equipment interfering with the signal.
Adjust the direction or position of the speaker or move to an open area for a
better signal reception.
Warning:
1. Do not use the product in high temperatures. Always keep the product away
from fire. For your own safety, never throw the product into a fire which may
cause an explosion and personal injury.
. Do not use the product close to high-voltage wires or electronic equipment.
3. Keep the speaker away from water, and avoid using the speaker in
high-humidity environments.
4. Keep the speaker away from any strong magnetic fields.
Support:
If you have any questions or problems in using the speaker, please feel free to write
to: Victormobile@1 6.com
