Soundance SDY019 User manual

1
Soundance
Bluetooth Speaker User Manual
Thank you for purchasing Soundance bluetooth speaker. Please read this manual
carefully and keep it for future reference.
Features of the speaker:
1. New Bluetooth Technology, support wireless control through Bluetooth device
. LED display with Time and Alarm clock function (in 4 hour format only).
3. Built-in FM radio with automatic channel searching and fine tune function
4. Support plug and play for Micro SD card/TF card and USB
5. 3.5mm line-in jack for wired devices
6. Built-in rechargeable battery supports up to 8 hours playback (medium volume)
7. Two 40MM drivers deliver deep and rich sound
8. Built-in Microphone for phone Calls
9. Support MP3, WAV, WMA, APE, FLAC format of audio file Micro SD card/TF
card, USB storage device
-

2
Button illustration:

3
Operating Instructions:
1. Charging
With the speaker turned off, connect the Micro-USB connector of the charging
cable to the DC5V input socket at the rear side of the speaker, and plug the USB
connector of the charging cable to an external USB power supply socket with a
minimum supply current of 1A. The external USB power supply can be the USB
socket in your computer/laptop, the USB adaptor of most cellphone USB chargers
with DC5V output, or the 5V USB port of a power socket etc.
When charging, this will be indicated on the LCD screen.
2. On/Off
The On/Off slide button is at the rear side of the speaker. Slide to the on or off
position to turn the speaker on or off.
. Bluetooth
Paring – 1. Press the button to enter Bluetooth mode. The LCD screen will
display “bt” to show that the speaker is in Bluetooth mode. Turn on your Bluetooth
device (such as a mobile phone, laptop, PDA etc) , search for bluetooth equipment
“SDY-019”, and then pair up with the speaker. There will be a sound from the
speaker when Bluetooth connection is established.
Bluetooth phone call - When paired to your phone, press the “ ” button to
answer incoming calls, and press the “ ” button again to end the call. Press the
“ ” button twice will call back to the last incoming call number.
Note: Microphone is on top of the speaker, please talk close to the microphone
when making phone calls.
Volume adjustment – When playing music and when making a phone call under
Bluetooth mode, the volume can be adjusted by keep pressing and holding the
“ /
/ /
/ / ”button. The volume can also be controlled from your Bluetooth
device (cellphone, laptop, PDA etc.)
Track selection – When playing music in Bluetooth mode, a short press of /
/ /
/
/ ”button will jump to the previous track or next track. Track selection can
also be done from your Bluetooth device.

4
4. FM radio
Press the “ ” button to enter FM mode.
FM Channel Search – When in FM mode, press and hold the “ ” button to start
automatic channel searching. The speaker will save the channels it finds and
automatically assign them a channel number.
Channel Selection – After channels have been saved, press the button to
move to next channel.
Fine Tune - Under FM mode, press the “ / ”button to fine tune the FM
frequency.
5. USB / Micro SD Card
The speaker supports plug and play for USB/Micro SD card. Just plug in your USB
Flash Drive or Micro SD Card into the speaker’s USB port or Card slot and the
speaker will play the music files automatically. Refer to item 9 Technical data below
for acceptable music formats.
6. Time setting
The speaker can only display the time in a 4 hour format. To set the time, first
press and hold the button until the digits on the LCD screen keep flashing.
Press the button to switch between the hour and minute setting. Press the
/ button to adjust the time accordingly.
7. Alarm
1.) Under Alarm/Clock mode, press the alarm button to the alarm on or off.
When alarm is on, the bell shape indicator on the LCD screen will be on.
.) To set the alarm time, first press and hold the alarm button. Press the alarm

5
button to switch between the hour and minute setting. Press /
button to adjust the alarm time accordingly.
3) Setting alarm music: Insert an USB or TF card, when playing the music you
want to set for the alarm, press the alarm button. The screen will display” -AL- ”,
then the alarm music is set. Please note that the music setting will be cleared
when the USB or TF card is removed from the speaker. If no music is set as
alarm music, the default alarm sound will be used.
8. Reset – If the speaker is not working normally, press and hold the
button for 5 seconds to reset the speaker.
9. Technical Data
Power
Built-in high capacity Li battery
External USB 5V supply
Power input: 500-1000mA
Technical
Frequency 80HZ- 0KHZ
FM radio 87.5-108MHz
SNR ≥
≥≥
≥90db (line out)
Sensitivity Rate 80db
THD 0.3% (line out)
Output power 5W*
Speaker Φ45mm 3Ω 3w *
Music format MP3、WMA、WAV,、APE、FLAC
Impedance 3 Ohm
Speaker size 40 x55x 61.5mm

6
Trouble shooting:
1. Can’t turn the speaker on:
Check if the battery is in low. Recharge and then try to turn on again.
2. Can’t charge the speaker:
Check the power supply is working and that the output of the power supply to the
charge cable is 5V and > 1A.
Check that the charge cable and connectors of the cable are not damaged.
. No sound:
Check the speaker is paired with the right Bluetooth device. If not, disconnect
the Bluetooth connection and pair again to the right device.
Check the music format in the USB or TF/card.
4. No FM radio
Check if there is any electronic equipment interfering with the signal.
Adjust the direction or position of the speaker or move to an open area for a
better signal reception.
Warning:
1. Do not use the product in high temperatures. Always keep the product away
from fire. For your own safety, never throw the product into a fire which may
cause an explosion and personal injury.
. Do not use the product close to high-voltage wires or electronic equipment.
3. Keep the speaker away from water, and avoid using the speaker in
high-humidity environments.
4. Keep the speaker away from any strong magnetic fields.
Support:
If you have any questions or problems in using the speaker, please feel free to write
to: Victormobile@1 6.com
