Soundigital EVOX 800.1 User manual

TECHNOLOGIES
The DTR* is a dynamic thermal recovery system which always maintains a high
efficiency of the amplifier by accelerating the thermal exchange of electronic
components with the heatsink
* Patent. Required
ALUMINIUM
HEATSINK
CONDUCTIVE
COOPER LAYER
ELECTRONIC
COMPONENT
DYNAMIC THERMAL RECOVERY - DTR
An intelligent layout, with great use of the
PCB area and the use of modern
components with reduced structure
guarantee SounDigital products a
compact design, at the same time robust
and with excellent thermal efficiency.
ULTRA COMPACT PCB

TECHNOLOGIES
VIBRATION ABSORPTION DEVICE
*Efficiency measured at power supply only
SounDigital amplifiers are known for their low
consumption of battery, and this feature was
improved on the EVOX Line. The new I-
POWER SUPPLY is even more modern, which
replaces the old toroidal transformers by a new
generation of "E-E" core transformers delivers
efficiency above 90% *,ensuring more hours of
sound without battery recharge.
I - POWER SUPPLY
SounDigital added a new device to the EVO X products which act like shock
absorbers reducing the impact of vibration on the eletronic circuit board, thereby
increasing the life and reliability of the amplifiers.

1 2
21
A
B
DISASSEMBLING OF THE PLASTIC COVER
ASSEMBLING THE PLASTIC COVER
The plastic covers have the function of finishing and hiding the amplifier fixing
screws. To disassembling and assembling them, follow the instructions below.
1. Carefully pull out the top of plastic cover to release the upside latches, as shown in the picture 1.
2. Slide up the plastic cover in a continuous movement to remove it.
1. To fit the plastic cover back, carefully insert the point A of the plastic cover into point B of the
amplifier, slowly sliding it down.
2. Gently press the sides of the top of the plastic cover towards the bottom of the amplifier until
you hear a clicking noise.
EN
ASSEMBLING AND DISASSEMBLING THE PLASTIC COVER

Speaker Output
Connector

1.9" (50mm)
Frequency Response (-3dB)
Low Pass filter (12dB/oct)
High Pass filter (12dB/oct)
