Congratulations and thank you for purchasing Soundstream products. We are confi-
dent you will enjoy your new subwoofer and appreciate the effort involved in bringing
you the best engineered and crafted subwoofer in this category. Harmonic
indulgence...Listen and feel.
We advise you to keep this manual in a safe and dry place. Write down any important
information to reference from in the future, such as all of your enclosure information.
Draw a simple diagram and write all the parameters of the enclosure incase you ever
need to reference from it in the future.
The following enclosure recommendations are only a few in variation of what the
woofer requires. If you need specific information for a design and have questions
regarding it, please contact our Technical Support Department with your details, via
email at [email protected]. We strongly suggest you use or build an
enclosure with in the following parameters for proper function and quality results from
your woofer. Building an enclosure too far from the specified suggestions may cause
undesired performance and/or damage to your woofer and in some cases your
amplifier as well.
Specifications
NOTICE
Sealed Enclosure Recommendations for RW-10
Optimum Enclosure Other Enclosure Recommendations
MAX PowerVolume
Model
Mounting Depth
Outer Diameter
Cutout Diameter
Driver Displacement
Impedance
RMS Power
PEAK Power
Voice Coil
Magnet Weight
Frequency Response
Resonant Frequency
Qts
Qms
Qes
Vas
XMAX
SPL
RW-12
6.5”
12.375”
11.125“
.10 cu. ft.
Dual 4 ohm
600 watts
900 watts
2.5”
120 oz.
30 - 400Hz
24.75Hz
.467
3.905
.530
58.53 ltr
14 mm
84.23 dB
RW-10
6”
10.8125”
9”
.08 cu.ft.
Dual 4 ohm
500 watts
750 watts
2.5”
100 oz
30 - 400Hz
25.94Hz
.418
4.30
.463
27.24 ltr
14 mm
82.1 dB
NET Volume 1 cuft / 28.3 ltrs
Max Power 500 watts
Fill 50% Semi Dense
All volume suggestions are “Net Volume” before any
displacement. Please add accordingly to your design
NET Volume 1.2 cuft / 34 ltrs
Max Power 600 watts
Fill 50% Semi Dense
All volume suggestions are “Net Volume” before any
displacement. Please add accordingly to your design
Smallest .7 cuft / 19.8 ltrs 350 watts
Largest 1.4 cuft / 39.64 ltrs 350 watts
MAX PowerVolume
Smallest .8 cuft / 22.6 ltrs 500 watts
Largest 1.6 cuft / 45.3 ltrs 500 watts
Sealed Enclosure Recommendations for RW-12
Optimum Enclosure Other Enclosure Recommendations
NET Volume 1.25 cuft / 35.4 ltrs
Vent Design 3” X 12.375”
Tuning Freq 32Hz
Max Power 500 watts
All volume suggestions are “Net Volume” before any
displacement. Please add accordingly to your design
Vented Enclosure Recommendations for RW-10
Optimum Enclosure High Output Enclosure
NET Volume 1.75 cuft / 49.5 ltrs
Vent Design 25 sqin X 25”
Tuning Freq 36Hz
Max Power 400 watts
All volume suggestions are “Net Volume” before any
displacement. Please add accordingly to your design
NET Volume 1.75 cuft / 49.5 ltrs
Vent Design 3” X 9.5”
Tuning Freq 30Hz
Max Power 600 watts
All volume suggestions are “Net Volume” before any
displacement. Please add accordingly to your design
Vented Enclosure Recommendations for RW-12
Optimum Enclosure High Output Enclosure
NET Volume 2.25 cuft / 63.2 ltrs
Vent Design 35 sqin X 26”
Tuning Freq 36Hz
Max Power 500 watts
All volume suggestions are “Net Volume” before any
displacement. Please add accordingly to your design
Wiring Configurations
There are a variety of impedance possibilities when using woofers equipped with
multiple coils. It is “EXTREMELY” important that ALL coils are used and none are left as
spares. Always provide the minimum impedance your amplifier requires. If you need
assistance with wiring configurations, please consult a professional installer or
contact our Technical Support Department with your questions.
