South Bend Tools Oil Country Series User manual

®
A Tradition of Excellence
South Bend Tools
© December, 2021 by South Bend Tools For Machines Mfd. Since 07/19 (V1.12.21)
BIG BORE LATHE
MODEL SB1065F 34" X 72" MODEL SB1069F 38" X 212"
MODEL SB1066F 34" X 132" MODEL SB1070F 42" X 132"
MODEL SB1067F 34" X 212" MODEL SB1071F 42" X 212"
MODEL SB1068F 38" X 132"
OWNER'S MANUAL
Model SB1065F
Shown with Optional
Accessories

Customer Service
We stand behind our machines. If you have any service questions, parts requests or general questions
about your purchase, feel free to contact us.
South Bend Tools
P.O. Box 2027
Bellingham, WA 98227
Phone: [phone]
Fax: [phone] (International)
Fax: [phone] (USA Only)
Email: [email protected]
Updates
For your convenience, any updates to this manual will be available to download free of charge
through our website at:
www.southbendtools.com
Scope of Manual
This manual helps the reader understand the machine, how to prepare it for operation, how to control
it during operation, and how to keep it in good working condition. We assume the reader has a basic
understanding of how to operate this type of machine, but that the reader is not familiar with the
controls and adjustments of this specific model. As with all machinery of this nature, learning the
nuances of operation is a process that happens through training and experience. If you are not an
experienced operator of this type of machinery, read through this entire manual, then learn more
from an experienced operator, schooling, or research before attempting operations. Following this
advice will help you avoid serious personal injury and get the best results from your work.
Manual Feedback
We've made every effort to be accurate when documenting this machine. However, errors sometimes
happen or the machine design changes after the documentation process—so
the manual may not
exactly match your machine.
If a difference between the manual and machine leaves you in doubt,
contact our
customer service for clarification.
We highly value customer feedback on our manuals. If you have a moment, please share your
experience using this manual. What did you like about it? Is there anything you would change to
make it better? Did it meet your expectations for clarity, professionalism, and ease-of-use?
South Bend Tools
C
/O Technical Documentation Manager
P.O. Box 2027
Bellingham, WA 98227
Email: [email protected]

Table of Contents
INTRODUCTION....................................................2
About This Machine.............................................2
Identification ........................................................3
Description of Controls & Components ..............4
SAFETY................................................................10
Understanding Risks of Machinery ..................10
Additional Metal Lathe Safety.......................... 12
Additional Chuck Safety....................................13
PREPARATION....................................................13
Preparation Overview........................................ 14
Things You'll Need............................................. 14
Power Supply Requirements............................. 15
Unpacking ..........................................................16
Inventory ............................................................16
Cleaning & Protecting ....................................... 17
Location ..............................................................18
Lifting & Moving................................................19
Leveling & Mounting.........................................20
Assembly ............................................................21
Lubricating Lathe ..............................................21
Power Connection ..............................................21
Test Run .............................................................22
Spindle Break-In................................................ 26
Recommended Adjustments ..............................26
OPERATION ........................................................27
Operation Overview........................................... 27
Tailstock .............................................................28
Chucks & Faceplates ......................................... 29
Steady Rest ........................................................29
Spindle Speed..................................................... 30
Manual Feed ......................................................31
Quick Traverse................................................... 32
Power Feed......................................................... 33
Four-Position Apron ..........................................38
Coolant System ..................................................38
ACCESSORIES ...................................................39
MAINTENANCE ...................................................40
Maintenance Schedule....................................... 40
Cleaning & Protecting ....................................... 40
Maintenance Checklist ......................................41
LUBRICATION.....................................................42
Headstock........................................................... 42
Gearbox ..............................................................43
Apron ..................................................................43
Hand-Pump Oiler............................................... 45
Longitudinal Leadscrew ....................................45
Ball Oilers ..........................................................45
End Gears...........................................................46
Tailstock Gearbox ..............................................47
Coolant Service ..................................................48
Machine Storage ................................................49
SERVICE..............................................................50
Backlash Adjustments....................................... 50
Gib Adjustments ................................................51
Half Nut Clamping ............................................53
Leadscrew & Feed Rod End Play .....................53
Brake Service .....................................................54
Adjusting V-Belts............................................... 55
Replacing Shear Pins.........................................56
Removing & Installing Gap Insert.................... 58
TROUBLESHOOTING.........................................60
WARRANTY .........................................................65

South Bend Tools
South Bend Tools
-2-
For Machines Mfd. Since 7/19
Model SB1065F–SB1071F INTRODUCTION
About This Machine
Foreword
"The screw cutting engine lathe is the oldest and
most important of machine tools and from it all
other machine tools have been developed. It was
the lathe that made possible the building of the
steamboat, the locomotive, the electric motor, the
automobile and all kinds of machinery used in
industry. Without the lathe our great industrial
progress of the last century would have been
impossible." —How To Run a Lathe, 15th
Edition, South Bend Lathe.
The lathe represented in this manual is a
modern day version of the screw cutting lathes
that trace their roots back to the 1700's, which
were themselves technological improvements of
the bow lathe that can be traced back thousands
of years to the ancient Egyptians.
Now, almost 300 years later, these modern
"screw cutting" lathes are not just a piece of
refined machinery, but a culmination of human
ingenuity and knowledge embodied into the
design and synergy of thousands of interworking
parts—some of which represent the life's work
and dreams of many inventors, mechanical
engineers, and world-class machinists—including
the likes of Leonardo da Vinci, Henry Maudsley,
and the founders of South Bend Lathe, John and
Miles O'Brien.
And now the torch is passed to you—to take
the oldest and most important type of machine
tool—and carry on the tradition. As the operator
of a South Bend Lathe, you now join the ranks
of some very famous and important customers,
such as Henry Ford, who used the machines he
purchased to help him change the world.
Features
Looking down the bore of the Big Bore Lathes is
like looking straight down the barrel of a huge
cannon. With an extra-large 9" spindle bore and
inside/outside spindle noses for mounting chucks
on both sides of the headstock, these lathes can
handle monster-sized workpieces such as large-
diameter oil pipes or hydraulic cylinders. They
are exquisitely built with ultra-tight tolerances,
and the headstocks and gearboxes are assembled
in a laboratory-like environment to ensure
absolutely pristine bearings and fittings for a
lifetime of rugged use. Each lathe is built to
order with chucks precision-fitted onto the lathe
at the factory.
The beds of these lathes are constructed with
Meehanite castings that are hardened and
precision-ground in the traditional three V-way
prismatic design—long used on South Bend
Lathes for its accuracy, durability, and rigidity.
The headstock features gear levers, and the
carriage includes an adjustable clutch that
disables automatic carriage feed when it contacts
the included 4-position apron stop or in the event
of a crash.
To further ensure a high degree of accuracy,
these lathes are equipped with high-quality
spindle bearings and a Fagor DRO. The spindle
nose is A2-15 with an MT#7 taper. The tailstock
has an MT#6 taper and 10" of quill travel. For
easy end drilling of large diameter holes and
chamfers with the tailstock handwheel, a 2-speed
gearbox is incorporated in the tailstock.
Also included is a remote-mounted control panel
on the carriage, and a rapid traverse motor with
controls for moving the cross and longitudinal
feeds for quick tooling positioning and returns.
These lathes are equipped with two types of
brakes: a band-style foot brake and an electric
motor brake.
Capabilities
These Big Bore Lathes are built for daily use
in busy gas and oil field settings. Loaded with
many nice features and high-precision parts,
these lathes excel when long drill pipes, shafts,
and flanges need to be surfaced, chamfered,
or threaded. Thick castings, heavy mass, and
quality construction throughout provide the
necessary brawn for demanding production and
manufacturing tasks.

South Bend Tools
South Bend Tools
For Machines Mfd. Since 7/19 Model SB1065F–SB1071F
-3-
INTRODUCTION
K. Automatic Retracting Chip Curtain
L. Carriage Control Panel
M. Motorized Quick Traverse Control
N. Foot Brake w/Motor Break
O. Oil Filled Apron
P. Four-Position Apron Stop
Q. Removable Gap
R. Headstock Control Panel
S. Gearbox Feed Controls
T. Headstock Spindle Controls
A. Outboard A2-15 Spindle Chuck (Optional)
B. Tool Tray
C. Sliding Chuck Guard w/Safety Switch
D. Inboard A2-15 Spindle Chuck (Optional)
E. Coolant Nozzle & Valve
F. Halogen Work Lamp
G. Fagor DRO Control Panel
H. Four-Way Tool Post (Optional)
I. Steady Rest (Optional)
J. 2-Speed Tailstock w/MT#6 Morse Taper
Quill
Identification
Identification (Model SB1065F shown).Identification (Model SB1065F shown).
TT
DD
AAEE
SS
BBCC
RR
FFGG
HH
QQ
PPOONNMMLLKK
JJ
II

South Bend Tools
South Bend Tools
-4-
For Machines Mfd. Since 7/19
Model SB1065F–SB1071F INTRODUCTION
Description of Controls
& Components
Headstock
A. Spindle Speed Range Hub: Selects one of
four spindle speed ranges.
B. Headstock Feed Direction Lever: Controls
direction of leadscrew and feed rod rotation.
C. Headstock Range Lever: Shifts headstock
into low range, neutral, or high range.
D. Lettered Gearbox Levers: Sets leadscrew and
feed rod cutting pitch in relation to spindle
rotation for threading and feed operations.
E. Feed Mode Lever: Switches gear range in
gearbox between (MP/DP) and (IN/MM)
threading or feeding options.
F. Gearbox Speed Dial: Controls leadscrew and
feed rod speed for the cutting pitch selected
by the lettered gearbox levers.
Figure 2. Headstock controls.Figure 2. Headstock controls.
AA
BB
CC
DD
EE
FF
Refer to Figures 1–11 and the following
descriptions to become familiar with the features
and basic controls of this lathe. This knowledge
will be necessary to properly set up the lathe for
the test run and spindle break-in.
Master Power Switch
The rotary switch shown in Figure 1 toggles
incoming power ON and OFF to lathe controls.
It also prevents the electrical cabinet door from
being opened when the switch is ON.
To reduce the risk of
serious injury when using
this machine, read and
understand this entire
manual before beginning any
lathe operations.
Figure 1. Location of master power switch.Figure 1. Location of master power switch.
Master PowerMaster Power
SwitchSwitch
Turning the master power switch to OFF is not
a safe alternative to completely disconnecting
the machine from power when wiring,
servicing, or making repairs.

South Bend Tools
South Bend Tools
For Machines Mfd. Since 7/19 Model SB1065F–SB1071F
-5-
INTRODUCTION
Control Panels
A. Jog Button: When pressed momentarily
motor rotates spindle for chuck positioning
and shifting gears.
B. EMERGENCY STOP Button: Stops all
machine functions and engages electric
brake in Instant Brake Mode regardless of
what position Brake Mode switch is set at.
Twist EMERGENCY STOP button clockwise
to reset.
C. Power Switch: Toggles power for lathe
controls. Switch illuminates green when
lathe controls receive power.
D. Coolant Pump Switch: Toggles power ON/
OFF for coolant pump motor.
E. Brake Mode Switch: Allows for three
different modes of brake application based
on mass and inertia expected.
Note: No matter what mode position switch is
turned to, the EMERGENCY STOP buttons
bypass all selections to automatically apply
electric brake in Instant Brake Mode.
The three brake modes are as follows:
ABS Brake Mode: When in this mode,
Spindle Switch is used to turn OFF spindle
motor. Next, the electric brake automatically
applies in short, quick cycles.
IMPORTANT: Used when stopping large/long
workpieces that have great amounts of inertia
at high speeds. When in this position, electric
brake on motor applies and releases within
a 6–10 second time period, so not to overheat
pulley belts and electric motor brake.
Note: In this mode, brake may make a heavy
shuttering sound and vibration as brake
applies and releases.
Foot Brake Mode: When in this mode, foot
brake is pressed partially down to turn OFF
spindle motor. Next user presses foot pedal
remaining distance in a sustained manner to
apply band brake.
Figure 3. Headstock control panel.Figure 3. Headstock control panel.
AA
BB
CC
EE
DD

South Bend Tools
South Bend Tools
-6-
For Machines Mfd. Since 7/19
Model SB1065F–SB1071F INTRODUCTION
L. Fagor Digital Readout: Refer to Fagor
Manual for available operations.
Figure 5. Digital readout and keypad.Figure 5. Digital readout and keypad.
LL
IMPORTANT: Used for most normal, slow
lathe operations with lighter objects. If
you feather-foot brake 3–5 times to prevent
overheating band brake, Foot Brake Mode
can also be used to stop a slow turning
spindle that is holding long or heavy objects.
Instant Brake Mode: When in this mode,
either foot brake or EMERGENCY STOP
button turns OFF spindle motor when
pressed. Next, the electric brake fully applies
for 6–10 seconds and then releases.
IMPORTANT: Used for lathe operations that
cut small, short, and lightweight workpieces
that do not have the ability to build high
inertia at fast spindle speeds.
F. Spindle Direction Switch: Selects clockwise
or counterclockwise spindle rotation.
G. Spindle ON Button: Turns lathe spindle ON
and glows green when power is applied.
H. EMERGENCY STOP Button: Stops all
machine functions. Twist clockwise to reset.
I. Jog Button: Turns spindle motor ON while
being pressed and held.
J. Spindle OFF Button: Turns lathe spindle
OFF.
K. Rapid Traverse Direction Switch: Reverses
traverse direction of the selected feed
system.
Figure 4. Carriage control panel.Figure 4. Carriage control panel.
FFGGHH
IIJJKK
Foot Brake
This lathe is equipped with a foot brake (see
Figure 6) to quickly stop the spindle instead of
allowing it to decelerate to a stop on its own.
Figure 6. Foot brake and spindle lever.Figure 6. Foot brake and spindle lever.
Foot BrakeFoot Brake
Pressing the foot brake while the spindle is ON
also cuts power to the motor and can apply the
electric brake in different modes that have been
pre selected by the Brake Mode switch.
Once after brake is used, you must reset or cycle
spindle switches by turning them OFF then back
ON again before spindle rotation can be re-
started.

South Bend Tools
South Bend Tools
For Machines Mfd. Since 7/19 Model SB1065F–SB1071F
-7-
INTRODUCTION
A. Carriage Handwheel: Moves carriage along
bed. Can be disengaged during power feed
operations to prevent an entanglement
hazard.
B. Cross Slide Handwheel: Moves cross slide
toward and away from the workpiece.
C. Feed Selector Knob: Selects cross feed or
longitudinal feed for power feed operations
and quick traverse operations.
D. Feed ON/OFF Lever: Engages and
disengages apron when power feed
operations are being used.
E. Carriage Lock Lever: Locks and unlocks
carriage from bedways.
F. Half Nut Lever: Engages/disengages half nut
for threading operations.
G. Quick Traverse Lever: Engages/disengages
quick traverse system with apron.
H. 4-Position Apron Stop: Contacts adjustable
apron stop lobes, and disengages apron from
feeding operations.
Carriage
EE
Figure 7. Apron controls.Figure 7. Apron controls.
BB
AACC
DD
GG
FF
HH
Figure 8. Feed clutch control knob.Figure 8. Feed clutch control knob.
JJ
KK
LL
II
I. Thread Dial: Depending on how lathe is
ordered (Metric or Standard), thread dial
indicates when to reapply the half nut lever
to resume thread cutting in the same thread
after returning tool tip for next deeper cut.
J. Adjustable Feed Clutch Knob: Serves as a
safety means to adjust how much torsional
load is allowed on feed system before it
disengages auto feed.
K. Oil Flow Knob: Adjusts amount of oil that is
delivered to lubrication locations.
L. Manual Oil Pump: Draws oil from apron
reservoir to lubricate carriage ways through
various oil ports with flow adjusted by apron
oil flow knob.
EE

South Bend Tools
South Bend Tools
-8-
For Machines Mfd. Since 7/19
Model SB1065F–SB1071F INTRODUCTION
A. Compound Rest Handcrank: Moves tool
toward and away from workpiece at preset
angle of compound rest.
B. 4-Way Tool Post Lock Lever: Mounts up
to four cutting tools at once that can be
individually rotated and indexed to the
workpiece, then locked in place with lever.
C. Compound Thumb Lock: One of two thumb
locks that help hold slide in place and
improve rigidity of cut.
D. Compound Locking Capscrews: One of four
cap screws that hold compound at angled
positions indicated by rosette scale.
E. Compound Rosette: The scale indicates at
which angle compound is set to move.
Figure 9. Compound rest and tool holder.Figure 9. Compound rest and tool holder.
AA
BB
CC
DD
EE
Compound Rest & Tool Holder Tailstock
A. Quill: An MT#6 Morse taper, metric and inch
scale, and a drift slot to remove tight-fitting
tooling are used.
B. Quill Lock Lever: This lever secures quill in
position and ensures rigidity.
C. Tailstock Lock Nuts: Two lock nuts at the end
of studs secure tailstock in position along
bedway by pulling upward on locking plates
underneath the ways.
D. Tailstock Hi-Lo Lever: This lever allows for
1:1 movement between handwheel and quill.
When lever is in gear reduction position,
handwheel operation is made easier for large
diameter end drilling operations.
E. Tailstock Handwheel: A cast-iron handwheel
moves quill toward or away from spindle.
Figure 10 Tailstock controls.Figure 10 Tailstock controls.
AA
BB
DD
CC
EE

South Bend Tools
South Bend Tools
For Machines Mfd. Since 7/19 Model SB1065F–SB1071F
-9-
INTRODUCTION
F. Tailstock Clamp Nut: Two nuts adjust
clamping pressure of tailstock to bedways.
G. Offset Scale: Indicates relative distance of
tailstock offset from spindle centerline.
H. Offset Lock: Two cap screws clamp together
upper and lower halves of tailstock after
offset is adjusted.
I. Tailstock Stop: Prevents tailstock from
sliding off of ways.
Figure 11. Tailstock rear controls.Figure 11. Tailstock rear controls.
FF
GG
HH
II

South Bend Tools
South Bend Tools
-10-
For Machines Mfd. Since 7/19
Model SB1065F–SB1071F SAFETY
Understanding Risks of Machinery
Operating all machinery and machining equipment can be dangerous or relatively safe depending
on how it is installed and maintained, and the operator's experience, common sense, risk awareness,
working conditions, and use of personal protective equipment (safety glasses, respirators, etc.).
The owner of this machinery or equipment is ultimately responsible for its safe use. This
responsibility includes proper installation in a safe environment, personnel training and usage
authorization, regular inspection and maintenance, manual availability and comprehension,
application of safety devices, integrity of cutting tools or accessories, and the usage of approved
personal protective equipment by all operators and bystanders.
The manufacturer of this machinery or equipment will not be held liable for injury or property
damage from negligence, improper training, machine modifications, or misuse. Failure to read,
understand, and follow the manual and safety labels may result in serious personal injury, including
amputation, broken bones, electrocution, or death.
The signals used in this manual to identify hazard levels are as follows:
Death or catastrophic
harm WILL occur.
Moderate injury or fire
MAY occur.
Death or catastrophic
harm COULD occur.
Machine or property
damage may occur.
Basic Machine Safety
Owner’s Manual: All machinery and machining
equipment presents serious injury hazards
to untrained users. To reduce the risk of
injury, anyone who uses THIS item MUST
read and understand this entire manual
before starting.
Personal Protective Equipment: Operating or
servicing this item may expose the user
to flying debris, dust, smoke, dangerous
chemicals, or loud noises. These hazards
can result in eye injury, blindness, long-
term respiratory damage, poisoning,
cancer, reproductive harm or hearing loss.
Reduce your risks from these hazards
by wearing approved eye protection,
respirator, gloves, or hearing protection.
Trained/Supervised Operators Only: Untrained
users can seriously injure themselves
or bystanders. Only allow trained and
properly supervised personnel to operate
this item. Make sure safe operation
instructions are clearly understood. If
electrically powered, use padlocks and
master switches, and remove start switch
keys to prevent unauthorized use or
accidental starting.
Guards/Covers: Accidental contact with
moving parts during operation may cause
severe entanglement, impact, cutting,
or crushing injuries. Reduce this risk by
keeping any included guards/covers/doors
installed, fully functional, and positioned
for maximum protection.

South Bend Tools
South Bend Tools
For Machines Mfd. Since 7/19 Model SB1065F–SB1071F
-11-
SAFETY
Entanglement: Loose clothing, gloves, neckties,
jewelry or long hair may get caught in
moving parts, causing entanglement,
amputation, crushing, or strangulation.
Reduce this risk by removing/securing
these items so they cannot contact moving
parts.
Mental Alertness: Operating this item with
reduced mental alertness increases the
risk of accidental injury. Do not let a
temporary influence or distraction lead to a
permanent disability! Never operate when
under the influence of drugs/alcohol, when
tired, or otherwise distracted.
Safe Environment: Operating electrically
powered equipment in a wet environment
may result in electrocution; operating near
highly flammable materials may result in a
fire or explosion. Only operate this item in
a dry location that is free from flammable
materials.
Electrical Connection: With electically powered
equipment, improper connections to the
power source may result in electrocution
or fire. Always adhere to all electrical
requirements and applicable codes when
connecting to the power source. Have all
work inspected by a qualified electrician to
minimize risk.
Disconnect Power: Adjusting or servicing
electrically powered equipment while it
is connected to the power source greatly
increases the risk of injury from accidental
startup. Always disconnect power
BEFORE any service or adjustments,
including changing blades or other tooling.
Secure Workpiece/Tooling: Loose workpieces,
cutting tools, or rotating spindles can
become dangerous projectiles if not
secured or if they hit another object during
operation. Reduce the risk of this hazard
by verifying that all fastening devices are
properly secured and items attached to
spindles have enough clearance to safely
rotate.
Chuck Keys or Adjusting Tools: Tools used to
adjust spindles, chucks, or any moving/
rotating parts will become dangerous
projectiles if left in place when the machine
is started. Reduce this risk by developing
the habit of always removing these tools
immediately after using them.
Work Area: Clutter and dark shadows increase
the risks of accidental injury. Only operate
this item in a clean, non-glaring, and well-
lighted work area.
Properly Functioning Equipment: Poorly
maintained, damaged, or malfunctioning
equipment has higher risks of causing
serious personal injury compared to
those that are properly maintained.
To reduce this risk, always maintain
this item to the highest standards and
promptly repair/service a damaged or
malfunctioning component. Always follow
the maintenance instructions included in
this documentation.
Unattended Operation: Electrically powered
equipment that is left unattended while
running cannot be controlled and is
dangerous to bystanders. Always turn the
power OFF before walking away.
Health Hazards: Certain cutting fluids and
lubricants, or dust/smoke created when
cutting, may contain chemicals known to
the State of California to cause cancer,
respiratory problems, birth defects,
or other reproductive harm. Minimize
exposure to these chemicals by wearing
approved personal protective equipment
and operating in a well ventilated area.
Difficult Operations: Attempting difficult
operations with which you are unfamiliar
increases the risk of injury. If you
experience difficulties performing the
intended operation, STOP! Seek an
alternative method to accomplish the
same task, ask a qualified expert how the
operation should be performed, or contact
our Technical Support for assistance.

South Bend Tools
South Bend Tools
-12-
For Machines Mfd. Since 7/19
Model SB1065F–SB1071F SAFETY
Additional Metal Lathe Safety
Rotating Parts. Always keep hands and body
at a safe distance from rotating parts—
especially those with projecting surfaces.
Never hold anything against rotating
workpiece, such as emery cloth, that can
pull you into lathe.
Guarding. Guards and covers protect against
entanglement or flying objects. Always
ensure they are properly installed while
machine is running.
Adjustment Tools. Remove all chuck keys,
wrenches, and adjustment tools before
turning lathe ON. A tool left on the lathe
can become a deadly projectile when
spindle is started.
Safe Clearances. Before starting spindle, verify
workpiece has adequate clearance by
hand-rotating it through its entire range of
motion.
New Setups. Test each new setup by starting
spindle rotation at the lowest speed and
standing to the side of the lathe until
workpiece reaches full speed and you can
verify safe rotation.
Spindle Speeds. Using spindle speeds that
are too fast for the workpiece or clamping
equipment can cause rotating parts to come
loose and strike nearby people with deadly
force. Always use slow spindle speeds with
large or non-concentric workpieces. Never
exceed rated RPM of the chuck.
Long Stock Safety. Long stock can whip
violently if not properly supported. Always
support any stock that extends from the
chuck/headstock more than three times its
own diameter.
Clearing Chips. Metal chips can be razor sharp.
Avoid clearing them by hand or with a rag.
Use a brush or vacuum instead.
Chucks. Chucks can be heavy and difficult to
hold. During installation and removal,
protect your hands and precision bed ways
by using a chuck cradle or piece of plywood
over the bed ways. Use lifting equipment,
as necessary, for large chucks.
Stopping Spindle. Always allow spindle to
completely stop on its own, or use a brake,
if provided. Never put hands or another
object on a spinning workpiece to make it
stop faster.
Crashing. A serious explosion of metal parts
can occur if cutting tool or other lathe
component hits rotating chuck or a
projecting part of workpiece. Resulting
metal fragments can strike nearby people
and lathe will be seriously damaged.
To reduce risk of crashing, ALWAYS
release automatic feeds after use, NEVER
leave lathe unattended, and CHECK all
clearances before starting lathe.
Coolant Safety. Coolant can become very toxic
through prolonged use and aging. To
minimize toxicity, change coolant regularly.
When using, position nozzle properly to
avoid splashing operator or causing a
slipping hazard on floor.
Tool Selection. Cutting with incorrect or dull
tooling increases risk of injury from broken
or dislodged components, or as a result of
extra force required for operation. Always
use sharp tooling that is right for the job.
Sanding/Polishing. To reduce entanglement
risk, never wrap emery cloth around
rotating workpiece. Instead, use emery
cloth with the aid of a tool or backing
board.
Measuring Workpiece. To reduce risk of
entanglement, never measure rotating
workpieces.
Serious injury or death can occur from getting entangled in, crushed between, or struck
by rotating parts on a lathe! Unsecured tools or workpieces can eject from the chuck and
strike nearby operators with deadly force. To minimize the risk of getting hurt or killed,
anyone operating this lathe MUST follow the hazards and warnings below.

South Bend Tools
South Bend Tools
For Machines Mfd. Since 7/19 Model SB1065F–SB1071F
-13-
SAFETY
Additional Chuck Safety
Entanglement. Entanglement with a rotating
chuck can lead to death, amputation,
broken bones, or other serious injury.
Never attempt to slow or stop the lathe
chuck by hand, and always roll up long
sleeves, tie back long hair, and remove
any jewelry or loose apparel BEFORE
operating.
Chuck Speed Rating. Excessive spindle speeds
greatly increase the risk of the workpiece
or chuck being thrown from the machine
with deadly force. Never use spindle speeds
faster than the chuck RPM rating or the
safe limits of your workpiece.
Using Correct Equipment. Many workpieces can
only be safely turned in a lathe if additional
support equipment, such as a tailstock or
steady/follow rest, is used. If the operation
is too hazardous to be completed with the
lathe or existing equipment, the operator
must have enough experience to know
when to use a different machine or find a
safer way.
Trained Operators Only. Using a chuck
incorrectly can result in workpieces coming
loose at high speeds and striking the
operator or bystanders with deadly force.
To reduce the risk of this hazard, read
and understand this document and seek
additional training from an experienced
chuck user before using a chuck.
Chuck Capacity. Avoid exceeding the capacity
of the chuck by clamping an oversized
workpiece. If the workpiece is too large to
safely clamp with the chuck, use a faceplate
or a larger chuck if possible. Otherwise,
the workpiece could be thrown from the
lathe during operation, resulting in serious
impact injury or death.
Clamping Force. Inadequate clamping force
can lead to the workpiece being thrown
from the chuck and striking the operator
or bystanders. Maximum clamping force
is achieved when the chuck is properly
maintained and lubricated, all jaws are
fully engaged with the workpiece, and the
maximum chuck clamping diameter is not
exceeded.
Proper Maintenance. All chucks must be
properly maintained and lubricated to
achieve maximum clamping force and
withstand the rigors of centrifugal force.
To reduce the risk of a thrown workpiece,
follow all maintenance intervals and
instructions in this document.
Disconnect Power. Serious entanglement or
impact injuries could occur if the lathe is
started while you are adjusting, servicing,
or installing the chuck. Always disconnect
the lathe from power before performing
these procedures.

PREPARATION
South Bend Tools
South Bend Tools
-14-
For Machines Mfd. Since 7/19
Model SB1065F–SB1071F PREPARATION
Preparation Overview Required for Setup
To complete the preparation process, you will
need the following items:
For Lifting and Moving
• A forklift or other power lifting device rated
for at least 25% more than the shipping
weight of the lathe (see Product Data
Sheet).
• Lifting straps, each rated for at least 25%
more than the shipping weight of the lathe.
• Guide rods for steading the load when lifting.
• Two other people for assistance when moving
machine.
• Hardwood blocks (refer to Page 19).
• Two solid-steel bar stock that are 21⁄2" dia x
4' long to serve as lifting bars.
For Power Connection
• A power source that meets the minimum
circuit requirements for this machine (review
the Power Supply Requirements section
on the next Page for details).
• An electrician or qualified service personnel
to ensure a safe and code-compliant
connection to the power source.
For Cleaning & Assembly
• Precision level 12"
• Cotton rags
• Cleaner/Degreaser (refer to Page 17)
• Quality metal protectant oil
• Safety glasses for each person
• Basic hand tools
• Floor mounting hardware (refer to Page 20)
The purpose of the preparation section is to help
you prepare your machine for operation. The list
below outlines this basic process. Specific steps
for each of these points will be covered in detail
later in this section.
The typical preparation process is as follows:
1. Unpack lathe and inventory contents of box/
crate.
2. Clean lathe and its components.
3. Prepare location where lathe will be installed.
4. Move lathe to the operation location.
5. Level lathe and either bolt it to the floor or
place it on mounts.
6. Assemble loose components and make any
necessary adjustments or inspections to
ensure lathe is ready for operation.
7. Lubricate lathe and verify oil levels are full.
8. Connect lathe to power source.
9. Test run lathe to make sure it functions
properly.
10. Prepare lathe for full operation.

South Bend Tools
South Bend Tools
For Machines Mfd. Since 7/19 Model SB1065F–SB1071F
-15-
PREPARATION
Power Supply
Requirements
Availability
Before installing the machine, consider the
availability and proximity of the required power
supply circuit. If an existing circuit does not meet
the requirements for this machine, a new circuit
must be installed.
To minimize the risk of electrocution, fire,
or equipment damage, installation work and
electrical wiring must be done by an electrician
or qualified service personnel in accordance with
all applicable codes.
Circuit Information
For your own safety and protection of property,
consult an electrician if you are unsure about
wiring practices or applicable electrical codes.
A power supply circuit includes all electrical
equipment between the main breaker box or fuse
panel in your building and the incoming power
connections inside the machine. This circuit
must be safely sized to handle the full-load
current that may be drawn from the machine for
an extended period of time. (If this machine is
connected to a circuit protected by fuses, use a
time delay fuse marked D.)
Circuit Requirements 230V/460V
This machine is pre-wired to operate on a 230V
power supply circuit. With the SB460VSB1065F
conversion kit installed, the machine will operate
on 460V. Under both options, this machine must
have a power supply circuit that has a verified
ground and meets the following requirements:
Nominal Voltage ............................... 230V/460V
Cycle .............................................................60 Hz
Phase ....................................................... 3-Phase
Minimum Circuit Rating .............. 90/50 Amps
Connection ........Hardwire w/Locking Switch
Note: The circuit requirements in this manual
are for
a dedicated circuit—where only one
machine will be running at a time. If this
machine will be connected to a shared circuit
where multiple machines will be running at
the same time, consult a qualified electrician to
ensure the circuit is properly sized.
Electrocution or fire may
occur if machine is not
correctly grounded and
attached to the power
supply. Use a qualified
electrician to ensure a safe
power connection.
The full-load current is not the maximum
amount of amps that the machine will draw. If
the machine is overloaded, it will draw additional
amps beyond the full-load rating.
If the machine is overloaded for a sufficient
length of time, damage, overheating, or fire may
result—especially if connected to an undersized
circuit. To reduce the risk of these hazards,
avoid overloading the machine during operation
and make sure it is connected to a power supply
circuit that meets the requirements in the
following section.
The full-load current rating is the amperage
a machine draws at 100% of the rated output
power. On machines with multiple motors, this is
the amperage drawn by the largest motor or sum
of all motors and electrical devices that might
operate at one time during normal operations.
Full-Load Current Rating
Full-Load Rating at 230V 3-PH......71.6 Amps
Full-Load Rating at 460V 3-PH......35.8 Amps

South Bend Tools
South Bend Tools
-16 -
For Machines Mfd. Since 7/19
Model SB1065F–SB1071F PREPARATION
Grounding Requirements
This machine must be grounded! In the event
of
certain types of malfunctions or breakdowns,
grounding provides a path of least resistance
for electric current
in order to reduce the risk of
electric shock.
Improper connection of the equipment-grounding
wire can result in a risk of electric shock. The
wire with green insulation (with or without
yellow stripes) is the equipment-grounding wire.
If power cord repair or replacement is necessary,
do not connect the equipment-grounding wire to
a live (current carrying) terminal.
Check with a qualified electrician or service
personnel if you do not understand these
grounding requirements, or if you are in doubt
about whether the machine is properly grounded.
If you ever notice that a cord is damaged or
worn, disconnect it from power, and immediately
replace it with a new one.
Figure 12. Typical hardwire setup with a lockingFigure 12. Typical hardwire setup with a locking
disconnect switch.disconnect switch.
Power Source
LOCKING
DISCONNECT SWITCH
Machine
Conduit
Ground Ground
Conduit
Electrocution or fire may
occur if machine is grounded
incorrectly and attached
to the power supply. Have
electrician or qualified
service person ensure safe
power connection.
Unpacking
This item was carefully packaged to prevent
damage during transport. If you discover any
damage, please immediately call Customer
Service at
[phone] for advice. You may
need to file a freight claim, so save the containers
and all packing materials for possible inspection
by the carrier or its agent.
Inventory
This class of lathes is built specifically to order.
To verify that your shipment is complete, please
compare your order with the bill of materials
sheet from the crate.
Note: Additional documentation pertaining to
the electrical system is shipped inside of the lathe
electrical cabinet.
IMPORTANT: DO NOT use a static phase
converter to create 3-phase power—it can quickly
decrease the life of electrical components on this
machine. If you must use a phase converter, only
use a rotary phase converter.
When connected to a rotary phase converter,
power from the manufactured power
leg (sometimes called 'the wild wire' or
'manufactured leg') can fluctuate. Make sure that
when you connect the lathe to the phase converter
you connect the wild wire to the lathe input
lead L2, and that L1 and L3 incoming power
do not fluctuate. Fluctuation of power to the
transformer may cause magnetic switch chatter
and transformer damage and prevent the lathe
from starting correctly.
Phase Converter
As specified in the Circuit Requirements
section on the previous Page, this machine must
be hardwired to the power source, using a locking
switch (see Figure 12).
This machine must also be connected to a
grounded metal permanent wiring system; or to a
system with an equipment-grounding conductor.
Due to the complexity and high voltage involved,
this type of installation MUST be done by an
electrician or qualified service personnel.
Connection Type

South Bend Tools
South Bend Tools
For Machines Mfd. Since 7/19 Model SB1065F–SB1071F
-17-
PREPARATION
The unpainted surfaces are coated
at the factory
with a heavy-duty rust preventative that
prevents corrosion during shipment and
storage.
The benefit of this rust preventative is that it
works very well. The downside is that it
can be
time-consuming
to thoroughly remove.
Be patient and do a careful job when
cleaning
and removing the rust preventative
. The time
you spend doing this will reward you with
smooth
-sliding parts and a better appreciation
for the proper care of
the unpainted surfaces.
Although there are many ways to successfully
remove the rust preventative, the
following
process works well in most situations
.
Before cleaning, gather the following:
• Disposable
rags
• Cleaner/degreaser
(certain citrus-based
degreasers work extremely well and they
have non-toxic fumes)
• Safety
glasses&disposablegloves
Note:
Automotive degreasers, mineral spirits, or
WD•40
canbeusedtoremoverustpreventative.
Before using these products, though, test them
on an inconspicuous area of a painted surface to
make sure they will not damage it.
Basic steps for removing rust preventative:
1. Put on safety glasses and disposable gloves.
2. Coatallsurfacesthathaverustpreventative

with a liberal amount of your cleaner or
degreaser and let them soak for a few
minutes.
3. Wipe off the surfaces. If your cleaner or
degreaser is effective, the rust preventative
will wipe off easily.
Note:
To clean off thick coats of rust preventative
on flat surfaces, such as beds or tables, use
aPLASTICpaintscrapertoscrapeoffthe
majority of the coating before wiping it off
withyourrag.(Donotuseametalscraperor

it may scratch the surface.)
4. Repeat Steps 2–3 as necessary until clean,
then coat all unpainted surfaces with a
quality metal protectant or light oil to
prevent rust.
GAS
Gasoline and petroleum
products have low flash
points and can explode
or cause fire if used for
cleaning. Avoid using these
products to remove rust
preventative.
Many cleaning solvents are
toxic if inhaled. Minimize
your risk by only using
these products in a well
ventilated area.
Avoid chlorine-based solvents, such as
acetone or brake parts cleaner that may
damage painted surfaces. Always follow the
manufacturer’s instructions when using any
type of cleaning product.
Cleaning & Protecting
Open the end gear cover and clean the end
gears using a stiff brush with mineral spirits.
DO NOT get any cleaner or rust preventative
on the V-belts or the brake band lining, as it
could damage them or make them slip during
operations.

South Bend Tools
South Bend Tools
-18-
For Machines Mfd. Since 7/19
Model SB1065F–SB1071F PREPARATION
Physical Environment
Electrical Installation
Lighting
Weight Load
Space Allocation
Location
Weight Load
Refer to the Machine Specifications for the
weight of your machine. Make sure that the
surface upon which the machine is placed will
bear the weight of the machine, additional
equipment that may be installed on the machine,
and the heaviest workpiece that will be used.
Additionally, consider the weight of the operator
and any dynamic loading that may occur when
operating the machine.
Space Allocation
Consider the largest size of workpiece that will
be processed through this machine and provide
enough space around the machine for adequate
operator material handling or the installation
of auxiliary equipment. With permanent
installations, leave enough space around
the machine to open or remove doors/covers
as required by the maintenance and service
described in this manual.
Physical Environment
The physical environment where your machine
is operated is important for safe operation and
longevity of
parts. For best results, operate this
machine in a dry environment that is free from
excessive moisture, hazardous
or flammable
chemicals, airborne abrasives, or extreme
conditions. Extreme conditions for this type
of machinery are generally those where the
ambient temperature
is outside the range of 41°–
104°F; the relative humidity
is outside the range
of
20–95% (non-condensing); or the environment
is subject to vibration, shocks, or bumps.
Electrical Installation
Place this machine near an existing power
source. Make sure all power cords are protected
from traffic, material handling, moisture,
chemicals, or other hazards. Make sure to leave
access to a means of disconnecting the power
source or engaging a lockout/tagout device.
Lighting
Lighting around the machine must be adequate
enough to perform operations safely. Shadows,
glare, or strobe effects that may distract or
impede the operator must be eliminated.
Children or untrained
people may be seriously
injured by this machine.
Only install in an access
restricted location.
Lathe
Electrical
Access Door
= Power Connection Location
Min. 32"
Wall
Keep
Workpiece
Loading Area
Unobstructed
Wall
32"
Note: Drawing Not to Scale
Min.
Minimum Working Clearances - Add 32" at the Shown Locations for the Lathe Purchased.
Refer to Applicable Data Sheet for Overall Dimensions of Your Lathe Model.
FigureFigure 13. Minimum working clearances (All models).13. Minimum working clearances (All models).
