St r a t o St e a m
3 and 5 Pan, Electric Countertop Steamer
Standard Features
- Increased productivity in a space-saving design
- Single operating switch for easy operation
- Minimal side clearance required
- 5 minute cold start-up
- Constantwaterow-minimizeswatercontaminationbuildup
- Self-contained (steam is generated within the cavity without
thecostofexpensiveboilermaintenance)
- No elements in water
- No hood needed
- Efcientdesignallowsfor100%sideserviceableandeasy
cleaning
- Larger 3/4” “clog-free” drain capacity
- Side mount water resistant controls
- Stackable-nostandrequired
Printed in USA
STRE-3D; STRE-5D
FormSTRERev2(01/08)
STANDARD CONSTRUCTION SPECIFICATIONS
(shown on optional
stainless cabinet)
Exterior :Type304stainlesssteel,#3sanitarynish.
Interior: Type304stainlesssteel.
Legs: 4”stainlesssteellegsstandard.Optionalcabinetbase
available.
Fully insulated cooking compartment.
Power Source: Electric.Onepowersourceforcontrolsand
elementsaswellasonegroundwire.Apositivegroundcon-
nectionisessential.
Controls:
-ON/OFFLever:Singleswitchforoperation.Whentheamber
Powerlightisilluminatedthisindicatestheunitison.
-60MinuteTimer:Timecanbesetbetween1and60minutes.
Whentimeexpires,buzzersounds.Buzzercanbedisabled
by turningknobtomanualposition.Timerhasnoeffecton
theoperationofthesteamer.
WATER QUALITY STATEMENT
Waterqualityisthemajorfactoraffectingtheperformanceofyourappliance.Ifyouareunsureofwaterquality,consultalocal
watertreatmentspecialistandhavethewateranalyzed.Yourwatersupplymustbewithinthesegeneralguidelines:
 Totaldissolvedsolids-lessthan60PPM
 Totalalkalinity-lessthan20PPM
 Silica-lessthan13PPM
 Chlorine-lessthan1.5PPM
 pHFactor-7.0-8.5
Waterwhichfailstomeetthesestandardsshouldbetreatedbyinstallationofwaterconditioner.
FAILURE OR MALFUNCTION OF THIS APPLIANCE DUE TO POOR WATER QUALITY IS NOT COVERED UNDER WARRANTY

1100 Old Honeycutt Road, Fuquay-Varina, NC 27526
[phone] www.southbendnc.com
Models:
www.yatesgd.com www.yatesgraphicdesign.com
 STRE-3D  STRE-5D
INTENDED FOR COMMERCIAL USE ONLY.
NOT FOR HOUSEHOLD USE.
FormSTRERev2(01/08)
Models: STRE-3D; STRE-5D
ELECTRIC:
OneElectricalconnectionperunitisrequired.STRE-3(9kw);STRE-5(11kw)
* All units shipped per customer order three phase or single phase if necessary to
changeseemanualforconversioninformation.
WATER USAGE:
0.12gallonsperminuteat45p.s.i.waterpressureincavity.0.34gallonsperminute
at45p.s.i.waterpressureincondenser.0.46totalgallonsperminuteat45p.s.i.
MISCELLANEOUS
UTILITY INFORMATION
-Forinstallationoncombustibleoors(with4”high
legs)andadjacenttocombustiblewalls,allow6”
clearance.
-Checklocalcodesforre,installationandsanitary
regulations.
NOTICE:
Southbendhasapolicyofcontinuousproduct
researchandimprovement.Wereservethe
righttochangespecicationsandproductdesign
withoutnotice.Suchrevisionsdonotentitlethe
buyertocorrespondingchanges,improvements,
additions or replacements for previously
purchasedequipment.
OPTIONS AND ACCESSORIES
 Stainlesssteelcabinetbasewithrackpanguides
 208Vor240V
 220VAC50Hz3Phase
 240VAC50Hz3Phase
 480VAC60Hz3Phase
Di m e n s i o n s & We i g h t
mo D e l
Cr a t e D
Wi D t h
Cr a t e D
De p t h
Cr a t e D
he i g h t
Cr a t e D
Vo l u m e
Cr a t e D
We i g h t
STRE-3D 52”
(1322)
43”
(1093)
40”
(1017)
51cu.ft.
(1.47)
216lbs
(98kg)
STRE-5D 52”
(1322)
43”
(1093)
40”
(1017)
51cu.ft.
(1.47)
238lbs
(108kg)
si n g l e un i t to t a l
Co n n e C t e D am p s
stre-3D stre-5D
1 ph a s e 3 ph a s e 1 ph a s e 3 ph a s e
208V60Hz 46 27 57 33
220V50/60Hz 44 26 54 31
240V60Hz 40 24 49 29
480V60Hz 19 11 25 15
