Southwire Elite 300 Series Manual

OPERATING and MAINTENANCE
INSTRUCTIONS
Elite 300 Series Portable Power Station
53251
12 / 21
2021 FUNCIONAMIENTO e INSTRUCCIONES DE INSTALACIÓN
Electricidad Southwire Serie Elite 300
FONCTIONNEMENT et INSTALLATION INSTRUCTIONS
Électrique portativeElite300Series

CHARGE FIRST!
Before reading through the manual, you can
begin by charging your Southwire Elite 300
Series. Just connect it to the power supply cord
provided and plug the unit into a wall socket.
1
TABLE OF CONTENTS
Technical Specifications.............................................................2
Display Features......................................................................3-4
LCD Display.............….……………..........…………….....….…...5
How to Charge Your Elite 300....................................................6
Powering Your Devices.................……....…………..……….......7
What the Southwire Elite 300 Can Charge.................................8
Specifications..........................................……............................9
Troubleshooting..........................................................................9
What`s in the box..........................................….........................10
Safety Instructions...................................……..........................10
FCC Statement.......................................……...........................10
Warranty..............................................................................11-12
2
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
296Wh
[email protected]
L x W x H:
8.46 x 6.3 x 7.56 inch
215 x 160 x 192mm
7.61 pounds/
3.45Kg
DC12-30V 3.78A
USB C Port
PD60W x 1
5V 3A/9V 3A/12V
3A/15V 3A/20V 3A
DC 12V 5A x 2
Total 10A
120V
60Hz 300W
USB A Port:
QC3.0 x 1
5V 2.4A x 2
Lithium-ion
Temperature control
Surge protection
Short circuit protection
Over-current protection
Low-voltage protection
Pure Sine Wave
>1000
32°F to 113°F
0°C to 45°C
14°F to 149°F
-10°C to 65°C
FCC/CE/
PSE/RoHS
24 Months
Capacity
Dimensions
Weight
Input
Input/Output
DC Output
AC Output
USB Output
Battery
Pure Sine Wave
Lifecycles
Operating
Temperature
Storage
Temperature
Certifications
Warranty
Management System
Lb
AUTO POWER-OFF SAFETY FUNCTION
This Product turns off automatically after specified minutes/hours of not being connected.
Model
53251
AC Ports
30-45 Mins
DC Ports
8 Hours
USB Ports
8 Hours

3
DISPLAY FEATURES
4
DISPLAY FEATURES
DISPLAY FEATURES
DC INPUT
LCD Screen
To turn the LCD Screen display on, press any of
the output buttons once (LED/DC/USB/AC).
Press desired output button again to turn the
output power on. An output icon will appear on
the LCD Screen. Ensure you press the output
button again to turn off the power supply (this will
help maintain battery level)
Power Level Percentage
Check the battery level by pressing any of the
input buttons once. The LCD Screen will turn on
and show the battery level. If the battery is below
20%, charge before using.
Power Input & Output (Watts)
If the Elite 300 total output exceeds 300 Watts, it
will automatically shut off. Please ensure the
power consumption is less than 300 Watts, then
press the output button.
Low Power Warning
When the remaining power is less than 10%, the
battery level icon will blink 10 times.
Low & High Temperature Warning
The Elite 200 powers devices at a temperature
range of 0°C - 45°C ( 32°F - 113°F).
If your working temperature is outside this range,
the Southwire Elite 300 Series may work at
reduced efficiency or stop working.
INPUT
OUTPUT
All charging methods use the DC Input port. The exception is when
using PD for charging.
Connect your adapter first then plug it into the DC input of the Elite 300,
this will start charging the unit.

56
USING SOUTHWIRE ELITE 300 SERIES POWER STATIONLCD DISPLAY
DIFFERENT CHARGING METHODS
1. CHARGING WITH AC CHARGER
Using the AC Wall Charger cable (included in box. Assemble two parts together),
plug into a standard wall outlet first and then plug into DC Input on the unit. You
will know the unit is charging when the battery icon on the LCD display starts to
blink. The battery Icon has 5 segments and as the battery charges the segments
will slowly become solid, when the unit is fully charged the battery icon will be
solid. The battery percentage is also shown under the battery icon on the LCD
display it shows what percentage the battery is charged. After the unit is fully
charged, please unplug the AC wall charger from DC Input.
NOTE: The above also applies to charging the unit with an electric generator.
NOTE: The unit allows charging with the PD adapter and AC adapter at the same
time.
2. CHARGING WITH 12V CAR CHARGER
Using the car charger (included in the box), plug into a 12V socket (carport) in your
vehicle, then connect to the unit. You will know the unit is charging when the
battery icon on the LCD display starts to blink. The battery Icon has 5 segments
and as the battery charges the segments will slowly become solid, when the unit is
fully charged the battery icon will be solid. The battery percentage is also shown
under the battery icon on the LCD display it shows what percentage the battery is
charged.
NOTE: To avoid car battery power loss. Charging this unit through your 12V socket
is only recommended when your car engine is started.
3. CHARGING WITH PD CHARGER (CORD NOT INCLUDED)
This power station can support PD60W fast charging. Using the PD charger,
connect into the type-C port marked PD60W on the unit. You will know the unit is
charging when the battery icon on the LCD display starts to blink. The battery Icon
has 5 segments and as the battery charges the segments will slowly become solid,
when the unit is fully charged the battery icon will be solid. The battery percentage
is also shown under the battery icon on the LCD display it shows what percentage
the battery is charged.
NOTE: The unit allows charging with the PD adapter and AC adapter at the same
time.
4. CHARGING WITH SOLAR PANELS (SOLAR PANEL SOLD SEPARATELY)
Use the 4.0mm DC output plug to connect the solar panel to the unit. Ensure the
solar panel is placed in direct sunlight as much as possible. Plug the solar panel
into the input plug (DC 12-30V) on the front of the power station to start charging.
You will know the unit is charging when the battery icon on the LCD display starts
to blink. The battery Icon has 5 segments and as the battery charges the segments
will slowly become solid, when the unit is fully charged the battery icon will be
solid. The battery percentage is also shown under the battery icon on the LCD
display it shows what percentage the battery is charged.
HOW TO CHARGE YOUR ELITE 300:
1. Battery icon will show the remaining power level of the battery. The Battery icon
will blink during the charging process and become solid once it is fully charged.
2. Battery Level is shown in 5 segments, approximating 20%-40%-60%-80% and
100% capacity. As you use your Elite 300, segments will disappear from the
display, indicating the remaining charge. When charging the battery segment
will blink and indicate the current charge status. The battery icon will be solid
once your Elite 300 is fully charged. Don't forget to re-charge the unit when the
remaining power is less than 10%, the battery icon will blink 10 times.
3. LCD Display shows the amount of power (Watts) your devices are using while
plugged into the unit. Icons for all working ports will be shown on the bottom of
the LCD screen. It will also show the hours of charging for the devices plugged
in. If all ports are working at the same time, the Power and Time will be a total
amount.
4. Fan icon will appear on the LCD Display for two reasons:
a. When the AC outlet is selected, the fan automatically turns on as it is
conducting a self-inspection of the unit. It will automatically stop after 2-3
seconds.
b. The fan will turn on automatically if the unit is overheating, and above the
optimal working temperature (refer to technical specifications), it will stop once
the unit cools down.
If you are working in conditions that create a short circuit, an alarm will sound.
Press the input button to re-activate the power station.
NOTE: To charge your unit faster, plug in the AC adapter and PD charger at the
same time. The Elite 300 will be fully charged within 2.5 hours.
Car Charger About 4.5
Hours (Based on
120W DC Adapter)
Wall Charger About
4.5 Hours (Based on
72W AC Adapter)
Solar Panels (Sold Separately)
About 5 Hours (Depending on
Weather, and based on a 100W
Solar Panel)
PD Charger (Cord Not Included)
About 4.9 Hours (Based on a
PD60W Charger )
Generator (Sold Separately)
About 4.5 hours

7 8
USING SOUTHWIRE ELITE 300 SERIES POWER STATION WHAT THE SOUTHWIRE ELITE 300 SERIES CAN CHARGE
WHAT THE SOUTHWIRE ELITE 300 SERIES CAN CHARGE
NOTE: When solar recharging your power station, take note of the voltages of the
solar panels and do not exceed 30V. Individual solar panels, or solar panels
chained in series more than 30V cannot be used with the power station and can
cause serious damage to the unit. We recommend using the Southwire Elite Series
100-Watt Solar Panel with this unit.
POWERING YOUR DEVICES:
1. HOW TO POWER DC APPLIANCES WITH THE SOUTHWIRE ELITLE 300
SERIES:
1.1 Connect the power cable plug of the electrical appliance to the USB outlets or
12V port of the unit.
1.2 Press the “DC or USB ” button on the unit once to illuminate the LCD screen.
Press button again to turn output on. You will hear a beep and see the DC or
USB icon on the screen.
1.3 The LED Display will display real-time wattage of the appliance.
1.4 When finished, press “DC or USB” to turn the DC power off. (If there is no DC
power output for 2 hours the DC power will automatically turn off.)
NOTE: If the total output exceeds the wattage output of the DC outlet, the
power station will automatically shut off. Please ensure the power
consumption is less than what the outlet is rated for before using the device.
2. QUICK CHARGE OUTPUT:
This product supports Type-C PD 60W output, compatible with 5 V/3 A, 9 V/3 A,
12 V/3 A ,15 V/3 A and 20 V/3 A smart devices. The actual output voltage and
current depend on the smart device being connected to the unit (please check your
device specifications)
3. HOW TO POWER AC APPLIANCES WITH THE SOUTHWIRE ELITE 300
SERIES:
3.1 Ensure the appliance you are connecting is in the OFF position.
3.2. Connect the power cable plug of the electrical appliance to the AC outlet of
the product.
3.3. Press the “AC” button to turn on the unit once to Illuminate the LCD screen.
Press again to turn AC power output on. You will hear a beep and see the AC
icon on the screen.
3.4. Turn the appliance on.
3.5. The LED Display will display real-time wattage of the appliance and run time.
3.6. When finished, turn off device, remove power cable and press “AC" button to
turn outlets off. (If you leave the AC Power button on it can drain the battery.)
NOTE: If the total output exceeds 300W, the power station will automatically shut
off. Please ensure the power consumption is less than 300W, then press the AC
Power button.
WARNING: The AC outlets, AC voltage, and frequency are different. THIS UNIT
CANNOT SUPPORT DEVICES MORE THAN 300W.
4. HOW TO USE THE FLASHLIGHT
4.1. Press LED button once to turn light on
4.2. Press LED button again to make light brighter
4.3. Press the LED button a third time to turn on the SOS mode.
4.4. Press the LED button a fourth time to turn light off.
WARNING: Do not look directly into the light when turning it on.
Best-Use Strategy:
When charging your device with the Elite 300, pay attention to the LCD battery
display. If you plug in a device with a higher power requirement, the Elite 300
battery level may drop quickly, and you may not get exactly 296Wh of energy.
When using the AC power output, the Elite 300 will convert the DC power from the
battery to the AC power required by your device. The Elite 300 has an efficient
inventor however, there is still some energy loss during the conversion process.
You will not get the full rated capacity of the battery. If you are experiencing shorter
run times, you may want to check the power requirements of your device. If you
have any questions, please refer to TROUBLESHOOTING or contact our customer
service.
Cold Weather Usage:
Cold temperatures (below freezing) can affect the unit’s battery capacity due to
chemical characteristics of the battery. If you’ll be living off-grid in sub-zero
conditions, we recommend you keep your unit in an insulated cooler and
connected to a power source. The natural heat generated by the unit contained in
an insulated cooler will keep battery capacity at its highest.
Mini Fridge (60 W)
Powers for 5 Hours
Laptop (50W)
6 Recharges
Phone (10W)
30 Recharges
CPAP (40W)
Powers for 7 Hours
LED light (5W)
Powers for 60+ Hours
32' LED TV (55W)
Powers for 5 Hours
Speaker (30W)
Powers for 10 Hours
Drone (60W)
5 Recharges

109
TROUBLESHOOTING WHAT’S IN THE BOX
Please note the following:
1. When an output is not in use, please ensure that the port is turned off. Example
press the AC button to turn off the output, the icon will no long show on the LCD
display.
2. Please ensure the power consumption is less than 300W, before plugging into
the unit. If the output exceeds 300W, the Elite 300 will beep twice and a warning
icon will flash on the LCD display, disconnect device to rest.
STORAGE AND MAINTENANCE
Before use or storage, plug your Southwire Elite 300 Series into the wall outlet until
it is fully charged. Store your charged portable power station in a cool dry location
until ready for use.
If the display shows less than 20% capacity, plug the unit into a power source,
such as an AC outlet or a solar panel, as soon as possible to recharge.
Having your power station connected to a power source, between adventures or
while in storage keeps its battery healthy and topped off. This prolongs battery life
and will ensure your power station is charged and ready to go all day, every day.
If you can’t keep your power station plugged into a power source during storage,
fully-charge your power station every 3 months and store it in a cool, dry place.
Failure to maintain your power station by following these steps can result in battery
damage which will void the product warranty.
TROUBLESHOOTING
If your devices are not recharging from your Elite 300, follow the following steps:
1. Make sure the Output buttons (these are the AC/DC or USB buttons) have been
turned on. Once turned on the output type will light up on the LCD screen.
2. Check the LCD Display to see Battery level, if it is less than 20% or below, plug
your unit in to charge.
3. Check the LCD Display for the following warning icons:
* Overload or Short-circuit : The DC icon will be blinking, and the Warning Alarm
will go off twice.
* Temperature: Low & High Temperature Warning icon will appear
The SW Elite 300 Series has a temperature rating ranging from 0 - 40°C (32 - 104
°F). This is the ideal working condition anything outside this can lead to the unit not
working at optimal functionality
4. Make sure the power of devices does not exceed more than 200W, this is the
maximum this station can support. The unit will beep twice with the warning icon
flashing on the LCD display. Unplug the device causing the overload and the
unit will reset.
5. For additional support, please contact us at 1-800-561-4231.
WHAT’S IN THE BOX
Southwire 300 Car Charger Cable AC & AC Cable
(Two Parts)
8 in 1 ConnectorsUser Manual
SAFETY INSTRUCTIONS
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
300
53251
CAUTION
Failure to carefully read the following notes may result in leakage, explosion and
burning of batteries.
Do not put the product into a microwave oven or pressure vessel;
Do not combine the battery with once-for-all batteries (such as dry cells) or the
batteries of different capacities, models or varieties of functions;
Do not use the battery if it is in abnormal conditions such as peculiar smell,
heating, deformation, discolouration or other abnormalities;
Please move the product away from the place close to open flame if its battery is
leaking or giving off peculiar smell;
The leakage of electrolyte may cause fire hazards or explosion.
Do not cover the units air vents. The air vents keep the battery cool and working
efficiently. Covering the air vents while in use can cause over heating.

1211
Warranty Claim Information/How Do You Get Service?
For all warranty, customer service, and product return authorizations and inquiries,
please contact Southwire’s Tools & Assembled Products at:
Southwire Tools & Assembled Products
840 Old Bremen Road
Carrollton, GA, 30117
Phone Number: 1.855.SW.Tools
Repair Your Product When it is Out of Warranty
Southwire is happy to provide information about where a purchaser can send a product for
repair at consumers’ own expense, if available. Please contact 1.855.SW.tools
or visit www.southwiretools.com/tools/resources/repair-centers for more information about
servicing for Southwire Products
WARRANTY ON
SOUTHWIRE CONTRACTOR EQUIPMENT
Limited Warranty
All Southwire Company, LLC products are individually tested and inspected for defects in
material and workmanship before leaving the factory. Should your Southwire
Company, LLC product ever fail due to faulty workmanship or material within one year of the
date of purchase, simply return it to the place of original purchase for replacement. Our
Lifetime Return Policy is limited to the replacement of the original purchase.
NO OTHER LIABILITY, RESPONSIBILITY OR WARRANTY IS EXPRESSED OR IMPLIED
INCLUDING ANY REGARDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
Warranty Period
The warranty period is 24 months. In each case, the warranty period is measured starting on
the date of purchase by the original consumer purchaser. The sales receipt from the first
consumer purchase, or other reasonable documentary proof, is required in order to establish
the start date of the warranty period.
Exclusion of Incidental, Consequential, Indirect, Special and Punitive Damages
SOUTHWIRE MAKES NO WARRANTY THAT SOUTHWIRE CONTRACTOR EQUIPMENT
PRODUCTS WILL BE MERCHANTABLE OR FIT FOR ANY PARTICULAR PURPOSE.
SOUTHWIRE MAKES NO OTHER WARRANTY, EXPRESSED OR IMPLIED, OTHER THAN
THE RELEVANT WARRANTY SPECIFICALLY SET FORTH IN THIS WARRANTY SECTION.
SOUTHWIRE WILL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT,
SPECIAL, OR PUNITIVE DAMAGES FOR ANY BREACH OF THIS LIMITED LIFETIME
WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you
1. All warranty claims must be approved by Southwire’s Tools & Assembled Products
Warranty Department prior to return of product. If Southwire determines that a product is
defective, Southwire will, at its option, repair or replace defective products or defective
product components, free of charge.
2. Upon approval, Southwire will issue a Product Return Authorization Form which will
include instructions on how and where to return the product. The product serial number and
the original date of delivery must be set forth on the Product Return Authorization Form.
3. Southwire will cover standard freight charges (Ground Courier Rate) incurred in connection
with products that Southwire ultimately determines to be defective.
4. All defective components and defective products that Southwire replaces under these
Warranties will become Southwire’s property and will be retained by Southwire.
CAUTION
Failure to carefully read the following notes may result in leakage, explosion and
burning of batteries.
Do not put the product into a microwave oven or pressure vessel;
Do not combine the battery with once-for-all batteries (such as dry cells) or the
batteries of different capacities, models or varieties of functions;
Do not use the battery if it is in abnormal conditions such as peculiar smell,
heating, deformation, discolouration or other abnormalities;
Please move the product away from the place close to open flame if its battery is
leaking or giving off peculiar smell;
The leakage of electrolyte may cause fire hazards or explosion.
Do not cover the units air vents. The air vents keep the battery cool and working
efficiently. Covering the air vents while in use can cause over heating.

COMMENCEZ PAR CHARGER!
Avant de lire tout le mode d’emploi, vous pouvez
commencer par charger votre Elite300Series de
Southwire. Il vous suffit de la raccorder au cordon
d’alimentation électrique fourni et de brancher
l’appareil dans une prise murale.
1
TABLE DES MATIÈRES
CARACTÉRISTIQUES TECHNIQUES............................................................2
CARACTÉRISTIQUES D’AFFICHAGE........................................................3-4
AFFICHAGEACL.............….……………..........……...….........................…...5
COMMENT CHARGER VOTRE ELITE300...................................................6
ALIMENTATION ÉLECTRIQUE DE VOS APPAREILS.................…….….......7
CE QUE L’ELITE300SERIES DE SOUTHWIRE PEUT CHARGER...............8
DÉPANNAGE.........................................…….................................................9
ENTREPOSAGE ET ENTRETIEN...................................................................9
CONSIGNES DE SÉCURITÉ..................................……...............................10
DÉCLARATION DE LA FCC......................................……............................10
GARANTIE..............................................................................................11-12
2
CARACTÉRISTIQUES TECHNIQUES
296Wh
80Ah@3,7V
L*l*H:
215*160*192mm
8,46* 6,3*7,56 po
P.N.: 3,45kg
P.N.: 7,61livres
c.c. 12 à 30V 3,78A
PORT USBC
PD60W*1
5V 3A/9V 3A/12V
3A/15V 3A/20V 3A
12V c.c. 5A *2
Total 10A
120V
60Hz 300W
PortUSB A:
QC3.0*1
5V 2,4A*2
Lithium-ion
Contrôle de la
température Protection
contre la surtension
Protection contre les
courts-circuits Protection
contre la surintensité
Protection contre la
basse tension
Onde sinusoïdale pure
>1000
FCC/CE/
PSE/RoHS
24 mois
Capacity
Weight
Input
Input/Output
DC Output
AC Output
USB Output
Battery
Pure Sine Wave
Lifecycles
Operating
Temperature
Storage
Temperature
Certifications
Warranty
Lifecycles
Operating
Management System
CARACTÉRISTIQUES TECHNIQUES
0°C à 45°C
32°F à 113°F
-10°C à 65°C
14°F à 149°F
Dimensions

3
CARACTÉRISTIQUES D’AFFICHAGE
4
CARACTÉRISTIQUES D’AFFICHAGE
CARACTÉRISTIQUES D’AFFICHAGE
ENTRÉEC.C.
ÉcranACL
Pour allumer l’écran d’affichageACL, appuyez une
fois sur n’importe quel bouton de sortie
(LED/DC/USB/AC [DEL/c.c./USB/c.a.]). Appuyez
encore une fois sur le bouton de sortie souhaité
pour activer la puissance de sortie. Une icône de
sortie apparaîtra sur l’écranACL. Veillez à appuyer
encore une fois sur le bouton de sortie pour couper
l’alimentation électrique (ceci permettra de mainte-
nir le niveau de la batterie).
Pourcentage de charge
Vérifiez le niveau de charge de la batterie en
appuyant une fois sur n’importe quel bouton
d’entrée. L’écranACL s’allumera et affichera le
niveau de charge de la batterie. Si le niveau de
charge de la batterie tombe en-dessous de 20%,
chargez-la avant l’utilisation.
Puissance d’entrée et de sortie (en watts)
Si la sortie totale de l’Elite300 dépasse 300watts,
l’Elite300 s’éteindra automatiquement. Veuillez
vous assurer que la consommation électrique est
inférieure à 300watts, puis appuyez sur le bouton
de sortie.
Avertissement de batterie faible
Quand le niveau de charge restant est inférieur à 10
%, l’icône de charge de batterie clignotera 10fois.
Avertissement en cas de température élevée ou
basse
L’Elite300 alimente les appareils fonctionnant dans
une plage de température comprise entre -0°C et 45
°C (32°F et 1134°F).
Si votre température de travail sort de cette plage,
l’Elite300Series de Southwire peut fonctionner
moins efficacement ou cesser de fonctionner.
If your working temperature is outside this range,
the Southwire Elite 300 Series may work at reduced
efficiency or stop working.
INPUT
OUTPUT
Toutes les méthodes de charge utilisent le port d’entréec.c. L’exception
est l’utilisation de PD pour charger.
Raccordez tout d’abord votre adaptateur, puis branchez-le dans l’entrée
c.c. de l’Elite300 pour démarrer la charge de l’unité.

56
COMMENT CHARGER VOTRE ELITE300AFFICHAGEACL
DIVERSES MÉTHODES DE CHARGE
1. CHARGER AVEC UN CHARGEURC.A.
En utilisant le câble de chargeur muralc.a. (compris dans la boîte. Assemblez les
deux pièces ensemble), branchez tout d’abord dans une prise murale standard,
puis dans l’entrée c.c. de l’unité. Vous saurez que l’unité est en cours de charge
quand l’icône de batterie de l’affichageACL commence à clignoter. L’icône de
batterie a 5segments et au fur et à mesure que la batterie est chargée, les
segments deviennent lentement pleins et fixes, de sorte que l’icône de batterie est
entièrement pleine et fixe une fois que la batterie est complètement chargée. Le
pourcentage de batterie est également affiché sous l’icône de batterie de
l’affichageACL; il indique le pourcentage de batterie chargé. Une fois que l’unité
est complètement chargée, veuillez débrancher le chargeur mural c.a. de l’entrée
c.c.
REMARQUE: Les consignes ci-dessus sont également applicables si vous chargez
l’unité avec un générateur électrique.
REMARQUE: L’unité permet de charger avec l’adaptateurPD et l’adaptateurc.a.
en même temps.
2. CHARGER AVEC UN CHARGEUR POUR VOITURE DE 12V
En vous servant du chargeur pour voiture (compris dans la boîte), branchez dans
une prise de 12volts (abri d’auto) de votre véhicule, puis raccordez à l’unité. Vous
saurez que l’unité est en cours de charge quand l’icône de batterie de l’affichage
ACL commence à clignoter. L’icône de batterie a 5segments et au fur et à mesure
que la batterie est chargée, les segments deviennent lentement pleins et fixes, de
sorte que l’icône de batterie est entièrement pleine et fixe une fois que la batterie
est complètement chargée. Le pourcentage de batterie est également affiché sous
l’icône de batterie de l’affichageACL; il indique le pourcentage de batterie chargé.
REMARQUE: Pour éviter la perte de charge de la batterie de la voiture. Charger
cette unité avec la prise de 12V de votre voiture est uniquement recommandé
quand le moteur de votre voiture est en marche.
3. CHARGER AVEC UN CHARGEURPD (CORDON D’ALIMENTATION NON
COMPRIS)
Cette centrale électrique ne convient pas aux charges rapides des chargeursPD60
W. En vous servant du chargeur PD, raccordez au port de typeC portant la
mention PD60W de l’unité. Vous saurez que l’unité est en cours de charge quand
l’icône de batterie de l’affichageACL commence à clignoter. L’icône de batterie a
5segments et au fur et à mesure que la batterie est chargée, les segments devien-
nent lentement pleins et fixes, de sorte que l’icône de batterie est entièrement
pleine et fixe une fois que la batterie est complètement chargée. Le pourcentage
de batterie est également affiché sous l’icône de batterie de l’affichageACL; il
indique le pourcentage de batterie chargé.
REMARQUE: L’unité permet de charger avec l’adaptateurPD et l’adaptateurc.a.
en même temps.
4. CHARGER AVEC DES PANNEAUX SOLAIRES (VENDUS SÉPARÉMENT)
Utilisez la fiche de sortiec.c. de 4,0mm pour connecter le panneau solaire à l’unité.
Assurez-vous que le panneau solaire est placé de façon à être exposé le plus
possible à la lumière solaire directe. Branchez le panneau solaire dans la fiche
d’entrée (C.C. 12-30V ) située sur la face frontale de la centrale électrique afin de
lancer la charge. Vous saurez que l’unité est en cours de charge quand l’icône de
batterie de l’affichageACL commence à clignoter. L’icône de batterie a 5
segments et au fur et à mesure que la batterie est chargée, les segments devien-
nent lentement pleins et fixes, de sorte que l’icône de batterie est entièrement
pleine et fixe une fois que la batterie est complètement chargée. Le pourcentage
de batterie est également affiché sous l’icône de batterie de l’affichageACL;
COMMENT CHARGER VOTRE ELITE300:
1. L’icône de batterie indiquera la charge restante de la batterie. L’icône de
batterie clignotera pendant la charge et deviendra pleine et fixe une fois que la
batterie est complètement chargée.
2. Le niveau de charge de la batterie est affiché en 5segments, représentant une
capacité approximative de 20%, 40%, 60%, 80% et 100%. Au fur et à
mesure que vous utilisez votre Elite300, les segments disparaîtront de
l’affichage pour indiquer la charge restante. Au cours de la charge, un segment
de batterie clignotera pour indiquer le niveau de charge actuel. L’icône de
batterie sera fixe une fois que votre Elite300 est entièrement chargée. N’oubliez
pas de recharger l’unité quand la charge restante est inférieure à 10%, l’icône
de batterie clignotera 10fois pour vous le rappeler.
3. L’affichage ACL indique la puissance (en watts) consommée par vos appareils
quand ils sont branchés dans l’unité. Les icônes de tous les ports en marche
apparaîtront en bas de l’écranACL. Les heures de charge des appareils
branchés seront également affichées. Si tous les ports fonctionnent en même
temps, la puissance et la durée correspondront au total.
4. L’icône de ventilateur apparaîtra sur l’écranACL pour deux raisons:
a. Une fois que la prise c.a. est choisie, le ventilateur se mettra automatique
ment en marche, tandis qu’il effectue une autovérification de l’unité. Il
s’arrêtera automatiquement au bout de 2 à 3secondes.
b. Le ventilateur se mettra automatiquement en marche si l’unité surchauffe et
monte au-delà de la température de travail optimale (veuillez consulter les
caractéristiques techniques), il s’arrêtera une fois que l’unité refroidit.
Si vous travaillez dans des conditions qui produisent un court-circuit, une alerte
retentira. Appuyez sur le bouton d’entrée pour réactiver la centrale électrique.
REMARQUE: Pour charger votre unité plus rapidement, branchez l’adaptateur
c.a. et le chargeurPD en même temps. L’Elite300 sera complètement chargée
en 2,5heure.
Chargeur pour voiture
Environ 4,5heures (en
fonction d’un adaptateur
c.c. de 120W)
Chargeur mural Environ
4,5heures (en fonction
d’un adaptateur c.a.
de 72W)
Panneaux solaires (vendus
séparément) Environ 5heures
(selon les conditions climatiques
et en fonction d’un panneau
solaire de 100W)
ChargeurPD (cordon d’alimentation
non compris) Environ 4,9heures (en
fonction d’un chargeurPD de 60W)
Générateur (vendu
séparément)
Environ 4,5heure
