Sovereign AC60DOWC User manual

Installation and Operating Instructions
AC60DOW C & AC60DOSSC
SC60DOW C & SC60DOSSC
60c m DOUBL E CAVIT Y ELECTRI C CERAMIC
COOKER
Please read these instructions carefully before attempting to install or use this appliance.
It is advisable to keep these instructions in a safe place for future reference

Introduction
Than k yo u fo r choosin g thi s Sovereig n applianc e. It ha s been
designe d to give year s of trou ble -fre e use provide d it is installed
an d maintaine d correctl y.
Pleas e rea d thes e instruction s carefull y be fore installin g or using you r
applianc e. It is ad visa ble to kee p you r purchas e an d installation
receipt s with thes e instruction s in a sa fe plac e for futur e re feren ce.
Include d is som e impo rtan t sa fety in formatio n in additio n to
gu ideline s an d recommendation s tha t will ena ble you to ta ke full
ad vantag e of all th e function s availa ble.
This qualit y applianc e ha s bee n tes ted an d ce rtifie d to mee t all
applica ble UK electrica l an d sa fety standard s.
This applianc e m ust be inst alle d an d connecte d in accordance
with curren t regulation s by a qualifie d elec trician.
After unpa cking the appliance ensure that there is no visi ble
damag e. If the appliance has been damaged du ring transit, do not
use it , contact your retailer immediately.
1

Guarantee
This applianc e is gua rantee d for on e yea r fro m dat e of purchas e.
Kee p you r purchas e receip t with the se instruc tions.
To fulfi ll the condition s of th e gua rante e thi s applianc e m ust have
bee n correctl y installe d by a qualifie d perso n an d ope rate d in
accordanc e with thes e instructions . The applianc e is intende d for
domesti c us e onl y.
If th e applianc e fails to work prope rly durin g th e first yea r period
contac t th e Sovereig n Ser vice Hel p line on 01527 -573010 .
The applianc e will be repaire d or replace d (a t th e ma nufacturer ’s
discretion ) at no cos t to you . If th e gua rante e ha s elapsed , you
will be given a quotatio n for an y repair s or pa rts required.
The mode l an d seria l num be r togethe r with detail s of you r sales
receip t m ust be quote d whe n contactin g th e H elp line .
For Assistance or Service please contact the
Sovereign Service Help line on 01527-573010
2

Description of the Appliance
Four Ceramic Heat
Zones
Digital Clock &
Programmer Oven, Hob & Grill
Control Knobs
Small Oven &
Grill
Large Fan Oven
Levelling Feet
3

CONTENTS:
Sectio n 1 . Inst a llat ion
Section 2. Safety Advice
Section 3. Operating the Appliance
Secti on 4. Maintenance
4

Section 1. Installation
Remove all packing materials and any protective film applied to the
stainless steel surfaces.
Wipe the enamel and glass surfaces with a soft damp cloth
There must be a minimum distance of 650mm between the cooker hob
and a cooker hood positioned directly above (See fig.1 below).
This appliance must be installed by a qualified electrician.
Fig.1.
This appliance has a total power output of 10.0kw and must be ‘hard
wired’ to a separate 45amp cooker circuit with an isolation switch
positioned above the work surface.
Do not connect this appliance to a standard 13amp socket outlet!
Ensure the appliance is situated on a strong firm floor.
The appliance must be level. Adjust the level by screwing the adjustable
feet up or down (use your fingers or a suitable spanner).
Ensure the appliance is upright and the feet are in firm contact with the
floor so that the cooker is stable.
Ensure that the appliance hob is level with the adjacent work surfaces.
Please note that certain parts of this appliance have been protected with
a light film of oil. During initial use you may see light smoke coming from
the oven(s) and grill as the oil is burnt off. This is quite normal.
Section 2. Safety Advice

Neve r allo w childre n to pla y wit h thi s applianc e or operat e the
applianc e unsupervised.

Thi s applianc e is manufacture d an d intende d fo r DOMESTI C us e only.
Th e guarante e offere d wit h th e applianc e is no t vali d fo r any
installatio n in a commercia l environment.
5


Alway s tur n of f th e electricit y suppl y befor e cleanin g th e interna l or
externa l surface s of th e applianc e or changin g th e ove n ligh t bulb.

Th e hob , oven(s) , gril l an d certai n externa l surface s of thi s ap pliance
ge t ho t durin g use . Tak e car e whe n usin g th e applianc e an d keep
childre n wel l away.

Neve r tur n th e cerami c hea t zone s on unles s yo u hav e firs t positioned
a pa n on th e surface.

Alway s ensur e tha t th e cerami c hea t zone s ar e clean.

D o no t pou r col d wate r ont o a ho t cerami c hea t zone.
Should your cooker develop a fault, call the Sovereign Service
Help line on 01527- 573010.
Section 3. Operating The Appliance
3.1. Operating the Ceramic Heat Zones

Eac h cerami c hea t zon e is operate d by a con tro l kno b (se e diagram
below) . Variou s hea t level s ca n be achieve d b y selectin g th e settings
‘1 ’ to ‘6’.

Settin g ‘0 ’ is OFF . Settin g ‘1 ’ is LO W an d settin g ‘6 ’ is HIGH.

Us e pan s tha t hav e a thick , fla t soli d bas e wit h th e sam e (o r slightly
larger ) diamete r tha n th e heatin g zon e bein g used.
Front Left Zone Back Left Zone Back Right Zone Front Right Zone
3.2. Operating The Top Oven and Grill
Th e fa r righ t han d contro l kno b control s th e to p oven . Th e contro l is clearly
marke d To p Oven . Tur n th e contro l kno b clockwis e to operate.

Th e firs t settin g provide s thermostaticall y controlle d cooking/bakin g via
th e To p an d Botto m heatin g elements . Se t th e contro l kno b to the
require d thermosta t setting.

Th e nex t settin g provide s heatin g fro m th e Botto m heatin g element
only . Th e hea t ou tpu t is pre -se t at 22 0 degree s centigrad e an d is not
thermostaticall y controlled.
6


Th e nex t settin g provide s heatin g fro m th e To p heatin g elemen t only.
Th e hea t outpu t is pre -se t at 22 0 degree s centigrad e an d is not
thermostaticall y controlled.

Th e fina l settin g control s th e G rill . Th e gril l powe r outpu t is pre -se t at
22 0 degree s centigrad e an d is no t thermostaticall y controlled.
A re d indicato r ligh t wil l b e displaye d durin g th e abov e operations.
We recommend that you grill with the oven door closed
. However , if you
do gril l wit h th e doo r ope n yo u shoul d firs t fix th e Hea t Deflecto r plat e in
positio n as show n below . Th e Hea t Deflecto r wil l ensur e tha t hea t risin g from
th e gril l doe s no t caus e th e contro l knob s to overheat.
Th e tw o tab s a t eac h en d of th e Hea t Deflecto r shoul d be inserte d int o the
tw o slot s position ed jus t underneat h th e applianc e contro l panel.
3.3. Operating The Main Oven
The far left control knob controls the main oven. The control is clearly marked
Main Oven. Turn the control knob clockwise to operate.

To operate the oven, set the contr ol knob to the required thermostat
setting. The maximum heat output of the oven is 26 0 degrees
centigrade.
A red indicator light will be displayed whilst the oven is being operated.
7

3.4. Operating The Electronic Timer
Your appliance is fitted with an electronic clock/timer and programmer.
Please note that the correct time must be set before you can operate your oven
correctly.
How To Set The Correct Time
Connect the power to the appliance, the display will flash. Now press the
button and use the ‘+’ and ‘-‘ buttons to set the correct time of day.
How To Set The Minute Minder
Press and hold the button whilst using the ‘+’ and ‘-‘ buttons to set the
desired period of time, i.e. 30 minutes. When the set time has elapsed, an alarm
will sound. To stop the alarm press the or button and the display will
revert to the pre-set time of day.
How To Set The Automatic Timer
The auto -timer can be used to operate the Top Oven, Main Oven or both ovens
simultaneously as follows:
Ensure that the correct time of day is displayed.
Press and hold the button whilst pressing the ‘+’ and ‘-‘ buttons to
set the required length of time for cooking, i.e. if you want your meal to
cook for 2 hours, set the cook time to 2.00 hours.
8


Then press and hold the whilst pressing the ‘+’ and ‘-‘ buttons to
set the finish time, i.e. if you want your meal to be ready at 6.00pm you
must set the finish time to read 18.00 hours.
Turn the appropriate oven control knob to the required heat setting. The
oven will turn itself on at the correct start time and turn off at the correct
finish time.
When the auto-cook period ends, the alarm will sound. To turn the alarm
off press the button and turn the oven control knob to zero.
During the auto-mode, you can check the remaining cooking time by
simply pressing the button – the display will revert to the clock
setting after approximately 5 seconds.
Please note: You will not be able to use your oven in ‘manual’ mode if you do
not cancel the auto mode by pressing the button first.
How To Set The Semi-Automatic Timer
The auto -timer can be set to automatically switch off the oven at a pre -set time
if you have already started the cooking process.
To operate the appliance in this mode, procee d as follows:

Ensure that the correct time of day is displayed.

Turn the appropriate oven control knob to the required heat setting. The
oven will start operating as nor m al.

Now press and hold the button whilst pressing the ‘+’ and ‘-‘
buttons to set the required length of time for cooking, i.e. if you want the
meal to cook for 2 hours, set the cook time to 2.00 hours.

At the end of the set cook time the oven will automatically turn itself off.

Press the
button to turn the auto-mode off.
Turn the control knob back to zero.
Section 4. Maintenance
4.1. Changing the Oven Light Bulb

S w itch off the electricity supply to the oven.

Turn the lam p fixing glass anti -cloc kw ise to remo ve it.

Re m ove the bulb and insta ll an appro ved repla cem ent.

Re -fit the gla ss cover.
9

4.2. General Maintenance

Clean the ceramic heat zones with warm soapy water or a specialist
ceramic hob cleaner. Ensure that the hob surface is cool before
proceeding.

Clean the interior of the oven(s) with warm soapy water or a specialist
oven cleaner. Ensure that the oven(s) is cool before proceeding.

Clean the glass doors with warm soapy water or glass cleaner. Ensure
that the glass surface is cool before proceeding.

Clean the exterior enamel pane ls with warm soapy water.
10

Important Note:
Th is appliance is m arke d accordin g to th e E uropea n directi ve 2002/96/ E C
on W ast e E lect rical and E lectroni c E quip m en t (WEEE) . B y ensu rin g this
produc t is dispose d of co rrect ly, you will hel p prev en t potentia l negati ve
consequence s for th e environ m en t an d hu m an health , which could
othe rwis e be cause d by inapprop riat e wast e handling of this product.
Th e sym bo l on th e product , or on th e docu m ent s acco m pa nying the
pro duct , th e Crosse d Out W heelie Bin, indicates tha t this applianc e m ay
no t be treate d as househol d was te. Ins tead it shall be hande d ov er to
th e applicable collection poin t for th e recycling of elect rica l an d electronic
equip m ent.
Disposa l mus t be ca rried ou t in accordanc e with local environ m ental
regulation s for wast e disposal. Fo r m ore detailed inform ation
abou t treat m ent , rec ov ery an d recycling of thi s product , please
contac t you r local autho rity, you r househol d wast e disposa l se rvice
or th e retailer w he re you purchase d th e product.
W e continuou sly try to im pr ove ou r products for the benefit of ou r custom er s.
For this rea son w e re serve the righ t to m ak e change s to any produ ct at any tim e,
withou t noti ce
11
