SOYO SY-D6IBA2 User manual

SY-D6IBA2
Motherboard
Quick Start Guide
FC
CTested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
POST CONSUMER
RECYCLED PAPER
100%
Hardware
Installation
Quick BIOS
Setup
Introduction
SCSI Utilities
The SOYO CD

SOYO™
2
SY-D6IBA2 Motherboard
Single or Dual Pentium
®
III & Pentium
®
II processors
supported
82440 BX AGP/PCI Motherboard
66&100MHz Front Side Bus supported
ATX Form Factor
Copyright © 1999 bySoyo Computer Inc.
Trademarks:
Soyo is a registered trademark of Soyo Computer Inc. All trademarks are the property of their
owners.
Product Rights:
Product and corporate names mentioned in this publication are used for identification purposes
only and may be registered trademarks or copyrights of their respective companies.
Copyright Notice:
All rights reserved. This manual is copyrighted by Soyo Computer Inc. You may not reproduce,
transmit, transcribe, store in a retrieval system, or translate into any language, in any form or by
any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, any part of
this publication without express written permission of Soyo Computer Inc.
Disclaimer:
Soyo Computer Inc. makes no representations or warranties regarding the contents of this
manual. We reserve the right to revise the manual or make changes in the specifications of the
product described within it at any time without notice and without obligation to notify any
person of such revision or change. The information contained in this manual is provided for
general use by our customers. Our customers should be aware that the personal computer field is
the subject of many patents. Our customers should ensure that their use of our products does not
infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights
of third parties and not to infringe upon or assist others to infringe upon such rights.
Restricted Rights Legend:
Use, duplication, or disclosure by the Government is subject to restrictions set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at
252.277-7013.
About This Guide:
This Quick Start Guide is for assisting system manufacturers and end users in setting up and
installing the Motherboard. Information in this guide has been carefully checked for reliability;
however, no guarantee is given as to the correctness of the contents. The information in this
document is subject to change without notice.
If you need any further information, please visit our Web Site on the Internet. The address is
"http://www.soyo.com.tw".
D6IBA2 Serial - Version 1.0 - Edition: April 1999
*Thesespecificationsaresubjecttochangewithoutnotice

SY-D6IBA2 Quick Start Guide
3
Introduction
1 1 Introduction
Congratulationsonyourpurchaseofthe SY-D6IBA2 Motherboard.ThisQuickStartGuide
describesthestepsforinstallingandsettingupyournewMotherboard.
ThisguideisdesignedforalluserstoprovidethebasicstepsofMotherboardsettingand
operation.Forfurtherinformation, pleasereferto SY-D6IBA2MotherboardUser'sGuide and
TechnicalReferenceonlinemanualincludedontheCD-ROMpackedwithyour
Motherboard.
Unpacking
*Ifyourboardcomeswithadriverdiscandapapermanual,theQuickStartGuideandtheCD-ROMarenotincludedinthepackage.
WhenunpackingtheMotherboard,checkforthefollowingitems:
u TheSY-D6IBA282440BXAGP/PCIMotherboard
u ThisQuickStartGuide
u TheInstallation CD-ROM
u ThreeSCSIDriverInstallationDiskettes
labeled“7800FamilyManagerSetV3.01”(optional)
u TwoCPURetentionsets
u OneIDEDeviceFlat Cable
u OneFloppyDiskDriveFlatCable
u One50-pin NarrowSCSI Cable (optional)
u One68-pin WideSCSI Cable (optional)
u One68-pin Ultra2SCSICable (optional)

SY-D6IBA2 Quick Start Guide
4
Introduction
SY-D6IBA2 Motherboard Layout
Key Features
Ø SupportsIntelPentium
®
III processor (450-
550MHz) & Pentium
®
II processor (233-
450MHz)
Ø EasyCPUsettingsinBIOSwiththe
“SOYOCOMBOSetup”
Ø Auto-detectCPUvoltage
Ø SCSIportonboard (optional)
Ø PC98,APM,UltraDMA/33
Ø Power-onbymodemoralarm
Ø Supportsonboardhardwaremonitoring
andincludes Hardware Doctor™utility
Ø SupportsWake-On-LAN(WOL)
Ø SupportsPower-OnbyPS/2Keyboard
Ø SupportsCreativeSB-LINK™(PC-PCI)
forPCIaudiocard
Ø 1x32-bitAGPslot
Ø 4x32-bitbusmasteringPCIslots
Ø 2xUSBports
Ø 1xIrDAport
Ø Supportsmultiple-bootfunction
Ø ATXpowerconnector
Ø Powerfailureresume
(PC-PCI)
COM 1
COM 2
USB 1
PRT
USB 2
PS/2 KB
Connector
PS/2 Mouse
Connector
ISA Slot #1
ISA Slot #2
Intel
82371EB
Intel
82443 BX
IR1
15
Ultra
I/O Chipset
AGP Slot
ATX
Power
1
FDC
IDE 2
1
DIMM 1
DIMM 2
DIMM 3
DIMM 4
Flash BIOS
W83781D
828AC
SB-LINK
JP5
CMOS Clear
Jumper
3
1
JP4
JP7
3
1
JP1
13
WOL
Header
FAN1
CPUFAN
1
FAN2
CPUFAN
1
FAN3
1
1
IDE 1
PCI Slot #1
PCI Slot #2
PCI Slot #3
PCI Slot #4
1
(Optional)
Slot 1 #2
Slot 1 #1
Narrow SCSI (50-pin)
PWRBT
HDD LED
Turbo
LED
Reset
_
+
_
+
_
+
_
+
Speaker
Keylock
Power
LED
3V
Lithium
Battery
Wide SCSI (68-pin)
1
(Optional)
Ultra2 SCSI (68-pin)
1
(Optional)
JP44
13
adaptec
AQWA741
(Optional)
AIC - 7890AB
Winbond
Adaptec
83977EF-AW
AIC-3860
Hardware Monitoring
Winbond
W83781D
SCSI HDD
LED

SY-D6IBA2 Quick Start Guide
5
Hardware
Installation
2 2 Installation
ToavoiddamagetoyourMotherboard,followthesesimpleruleswhile
handlingthisequipment:
l BeforehandlingtheMotherboard,groundyourselfbygraspinganunpaintedportion
ofthesystem'smetalchassis.
l RemovetheMotherboardfromitsanti-staticpackaging.Holditbytheedgesand
avoidtouchingitscomponents.
l ChecktheMotherboardfordamage.Ifanychipappearsloose,presscarefullytoseat
itfirmlyinitssocket.
Followthedirectionsinthissectiondesignedtoguideyouthroughaquickandcorrect
installationofyournew SY-D6IBA2 Motherboard.Fordetailedinformation,pleasereferto
SY-D6IBA2MotherboardUser'sGuideandTechnical Reference onlinemanualincludedon
theCD-ROMpackedwithyourMotherboard.
PREPARATIONS
Gatherandprepareallthenecessaryhardwareequipmenttocompletetheinstallation
successfully:
u Slot1processorwithbuilt-inCPUcoolingfan(boxedtype)
u SDRAMmodule
u Computercaseandchassiswithadequatepowersupplyunit
u Monitor
u PS/2Keyboard
u PointingDevice(PS/2Mouse)
u VGACard
u SoundCard(optional)
u Speaker(s)(optional)
u DiskDrives:HDD,CD-ROM,Floppydrive…
u ExternalPeripherals:Printer,Plotter,andModem(optional)
u InternalPeripherals:ModemandLANcards(optional)

SY-D6IBA2 Quick Start Guide
6
Hardware
Installation
Install the Motherboard
Followthestepsbelowinordertoperformtheinstallationofyournew SY-D6IBA Motherboard.
Step 1. Install the CPU
: RecordtheworkingfrequencyofyourCPUthatshouldbeclearlymarkedontheCPUcover.
FSB66MHz
266MHz(66 x4.0) 333MHz (66 x 5.0) 400MHz(66 x6.0)
300MHz(66 x4.5) 366MHz (66 x 5.5) 433MHz(66 x6.5)
FSB100MHz
350MHz(100 x 3.5) 450MHz (100 x 4.5) 550MHz (100 x 5.5)
400MHz(100 x4.0) 500MHz (100 x 5.0) 600MHz(100 x6.0)
Notice1: Wheninstallingtwoprocessors,pleasemakesurethefrontsidebusandworking
frequencyareidenticalforbothprocessors.
Notice2: Ifyouareusingasingleprocessor,preferablyinstalltheprocessorinSlot1#1,
leavingSlot1#2emptyforfutureexpansiontodualCPU.
Retention Module Step 1. Open the two sides by folding them up.
Step 2.
Push the locks on top of the CPU
inward. Step 3. Insert the CPU into the retention
module. The CPU fits in the CPU slot in
only ONE way, do not try to force it in.
Step 4. After completely inserting the CPU, push the two locks on
top of the CPU outward. Now your CPU is ready for use.
To remove the CPU, press
the two notches on top of
the CPU inward. Now
press the two slides on the
retention module down and
remove the CPU.

SY-D6IBA2 Quick Start Guide
7
Hardware
Installation
Note: Installing a heat sink and cooling fan on top of your CPU is necessary for
proper heat dissipation. Failing to install these items may result in overheating
and possible burn-out of your CPU.
Step 2. Make Connections to the Motherboard
ThissectiontellshowtoconnectinternalperipheralsandpowersupplytotheMotherboard.
InternalperipheralsincludeIDEdevices(HDD,CD-ROM),FloppyDiskDrive,ChassisFan,
FrontPanelDevices(TurboLED,InternalSpeaker,ResetButton,IDELED,andKeyLock
Switch.),Wake-On-LANcard,VGAcard,SoundCard,andotherdevices.
FormoredetailsonhowtoconnectinternalandexternalperipheralstoyournewSY-
D6IBA2Motherboard,pleasereferto SY-D6IBA2MotherboardUser'sGuideandTechnical
ReferenceonlinemanualonCD-ROM.
Connectors and Plug-ins
PCI Audio Card Header: SB-Link™(PC-PCI) Wake-On-LAN Header: JP44
Pin1 Pin2 Pin3
Connect the SB-Link™(PC-PCI) cable from your PCI audio
card to this header. 5VSB GND MP-Wakeup
Slot 1 #1 CPU
Cooling Fan: FAN 1 Slot 1 #2 CPU Cooling Fan: FAN 2 Chassis Fan: FAN 3
Pin1 Pin2 Pin3 Pin1 Pin2 Pin3 Pin1 Pin2 Pin3
GND 12V SENSOR GND 12V SENSOR GND 12V SENSOR
Power LED Keylock
Pin1 Pin2 Pin3 Pin1 Pin2
5V NC GND Control Pin GND
Speaker
Pin1 Pin2 Pin3 Pin4
5V NC NC Speaker out
HDD LED Turbo LED PWRBT RESET
Pine1 Pin2 Pin1 Pin2 Pin1 Pin2 Pin1 Pin2
LED Anode LED
Cathode LED Cathode GND Power On/Off GND Power Good GND
IrDA (Infrared Device Header): IR1
Pin1 Pin2 Pin3 Pin4 Pin5
VCC None IRRX GND IRTX
ATX Power On/Off: PWRBT ATX Power Supply: ATX PW
Connect your power switch to this
header (momentary switch type).
To turn off the system,
please press this switch and hold
down for longer than
4 seconds.
Attach the ATX Power cable to this connector.
When using the Power-On by PS/2 Keyboard
function, please make sure the ATX power supply
can take at least 720mA load on the 5V Standby lead
(5VSB) to meet the standard ATX specifications.
Power LED
Key Lock
Speaker
Reset
PWRBT
Turbo LED
HDD LED
+
+
++
__
_
_

SY-D6IBA2 Quick Start Guide
8
Hardware
Installation
Step 3. Configure Memory
YourboardcomeswithfourDIMMsockets,providingsupportforupto1GBofmainmemory
usingDIMMmodulesfrom8MBto256MB.For66MHzfrontsidebusCPUsuse12nsorfaster
memory;for100MHzfrontsidebusCPUsuse8ns(100MHz,PC100compliant)memory.
Memory Configuration Table
Number of
Memory Modules DIMM 1 DIMM 2 DIMM 3 DIMM 4
11st
21st 2nd
31st2nd 3rd
41st 2nd 3rd 4th
RAM Type SDRAM
Memory Module
Size (MB) 8/16/32/64/128/256 Mbytes
Notice 1: 256 MB memory modules only available on PC registered DIMM.
Notice 2: Always install memory modules in the order prescribed in this table.
Notice 3: Do not install unbuffered and registered memory modules together.
Important: ItisofprimeimportancethatyouinstallDIMMmodulesasoutlinedinthetable
aboveinordertopreservesignalintegrityon100MHzfrontsidebussystems.
Step 4. Set the CPU Frequency
YoudonotneedtosetanyjumperfortheCPUfrequency.Instead,CPUsettingsare
changedthroughtheBIOS [SOYOCOMBO SETUP]. PleaserefertoChapter3-Quick
BIOSSetupfordetailsonhowtosetthePentium
®
IIprocessorfrequency.
Step 5. Enable/Disable Power-On by PS/2 Keyboard (JP1)
YoucanchoosetoenablethePower-OnbyPS/2Keyboardfunctionbyshortingpin2-3on
jumperJP1,otherwise,shortpin1-2todisablethisfunction.
Support Power-On
by Keyboard Enable Disable
JP1 Setting Enable Power-On by PS/2 Keyboard
(short pin 2-3)
Disable Power-On
by PS/2 Keyboard
(short pin 1-2)
Important: When using the Power-On by PS/2 Keyboard function, please make sure
the ATX power supply can take at least 720mA load on the 5V Standby lead (5VSB)
to meet the standard ATX specifications.
3
2
1
3
2
1

SY-D6IBA2 Quick Start Guide
9
Hardware
Installation
Step 6. Power Button Enable (JP7)
Yoursystemcanbepoweronbyeitherpressingapowerbuttonortypinginapassword,
whichcanbesetintheBIOSSOYOCOMBOSetup.Toavoidbeingunabletopowerupthe
systemduetoofforgettingthepassword,youcanplaceajumpercaptoshortJP7.Thiswill
alwaysenablethePowerButton.
Power Button
Enable Power Button always enabled Power Button according to BIOS setting
JP7 Setting
Shortpintoalways
enablethePower
Button.
OpenpinforaPower
Buttonfunctionaccording
totheBIOSsetting.
Step 7. Clear CMOS Data (JP5)
CleartheCMOSmemorybymomentarilyshortingpin2-3onjumperJP5foratleast5
seconds,andthenbyshortingpin1-2toretainnewsettings. Thisjumpercanbeeasily
identifiedbyitswhitecoloredcap.
CMOS Clearing Retain CMOS Data Clear CMOS Data
JP5 Setting Short pin 1-2 to retain
the new settings. Short pin 2-3 for
at least 5 seconds
to clear the CMOS.
Note: You must unplug the ATX power cable from the ATX power connector when
performing the CMOS Clear operation.
3
2
1
3
2
1

SY-D6IBA2 Quick Start Guide
10
Hardware
Installation
Note on Over-clocking Capability
TheSY-D6IBA2Motherboardprovidesover-clockingcapability.Duetotheover-clocking
settingyoursystemmayfailtobootuporhangduringruntime.Ifthisoccurs,pleaseperform
thefollowingstepstorecoveryoursystemfromtheabnormalsituation:
1. Turnoffsystempower.(IfyouuseanATXpowersupply,anddependingonyour
system,youmayhavetopressthepowerbuttonformorethan4secondstoshut
downthesystem.)
2. Pressandholddownthe<Insert>keywhileturningonthesystempower.Keep
holdingdownthe<Insert>keyuntilyouseethemessageoftheCPUtypeand
frequency(133MHzor200MHz)appearonscreen.
3. Pressthe<Del>keyduringthesystemdiagnosticcheckstoentertheAwardBIOS
Setupprogram.
4. FromtheBIOSmainmenu,select[SOYOCOMBOSETUP]andmovethecursorto
the[CPUFrequency]fieldtosettheproperworkingfrequency.
5. Select[Save&ExitSETUP]andpress<Enter>tosavetheconfigurationtothe
CMOSmemory,andcontinuethebootsequence.
Note : SOYOdoesnotguaranteesystemstabilityiftheuseroverclocksthesystem.
Anymalfunctions dueto over-clocking arenot coveredbythewarranty.

SY-D6IBA2 Quick Start Guide
11
Quick BIOS
Setup
3 3 Quick BIOS Setup
ThisMotherboarddoesnotuseanyhardwarejumperstosettheCPUfrequency.Instead,
CPUsettingsaresoftwareconfigurablewiththeBIOS [SOYO COMBO SETUP]. The
[SOYOCOMBOSETUP]menucombinesthemainCPUparametersthatyouneedto
configure,allinonemenu,foraquicksetupinBIOS.
Afterthehardwareinstallationiscomplete,turnthepowerswitchon, thenpress the <DEL> key
duringthesystemdiagnostic checksto entertheAwardBIOSSetupprogram.The CMOS
SETUPUTILITYwilldisplayonscreen.Then,followthesestepsto configurethe CPUsettings.
Step 1. Select [LOAD SETUP DEFAULT]
Selectthe“LOADSETUPDEFAULT”menuandtype“Y”attheprompttoloadtheBIOS
optimalsetup.
Step 2. Select [STANDARD CMOS SETUP]
Set[Date/Time]and[Floppydrivetype],andthenset[HardDiskType]to “Auto”.
Step 3. Select [SOYO COMBO SETUP]
Movethecursortothe [CPUSpeed] fieldtosettheCPUworkingfrequency.
Available[CPUSpeed]settingsonyourSY-D6IBA2Motherboardaredetailedinthe
followingtable.Ifyousetthisfieldto[Manual],youarethenrequiredtofillinthenexttwo
consecutivefields:(1)theCPUHostClock,and(2)theCPURatio.
CPU Frequency
233MHz (66 x 3.5) 350MHz (100 x 3.5)
266MHz (66 x 4.0) 400MHz (100 x 4.0)
300MHz (66 x 4.5) 450MHz (100 x 4.5)
333MHz (66 x 5.0) 500MHz (100 x 5.0)
366MHz (66 x 5.5) 550MHz (100 x 5.5)
400MHz (66 x 6.0) 600MHz (100 x 6.0)
433MHz (66 x 6.5)
Select the working frequency of
your Pentium® III, Pentium® II
processor among these preset
values.
Note: Mark the checkbox that
corresponds to the working
frequency of your Pentium® III,
Pentium® II processor in case the
CMOS configuration should be lost.
Step 4. Select [SAVE & EXIT SETUP]
Press <Enter> tosavethenewconfigurationtotheCMOSmemory,andcontinuetheboot
sequence.

SY-D6IBA2 Quick Start Guide
12
The SOYO CD
4 4 The SOYO CD
YourSY-D6IBA2MotherboardcomeswithaCD-ROMlabeled"SOYOCD."TheSOYOCD
containstheuser'smanualfileforyournewMotherboard,the driverssoftwareavailablefor
installation,andadatabaseinHTMLformatwithinformationonSOYOMotherboardsand
otherproducts.
Step 1. Insert the SOYO CD into the CD-ROM drive
TheSOYOCDwillauto-run,andtheSOYOCDStartUpMenuwilldisplayasshownbelow.
(SOYOCD Start UpProgram Menu)
TheSOYOCDStartUpProgramautomaticallydetectswhichSOYOMotherboardyouown
anddisplaysthecorrespondingmodelname.
Step 2. Read SOYO [D6IBA2] Manual
Clickthe Read Manual buttontoopentheuser'smanualfileofyourMotherboard.

SY-D6IBA2 Quick Start Guide
13
The SOYO CD
PleasenotethatiftheStartUpprogramwasunabletodeterminewhichSOYOMotherboard
youown,themanualselectionmenuwillpopup,asshownbelow.Thenselecttheuser's
manualfilethatcorrespondstoyourMotherboardmodelnameandclick OK.
(ManualSelection Menu)
Theuser'smanualfilesincludedontheSOYOCDcanbereadinPDF(Postscript
Document)format.InordertoreadaPDFfile,theappropriateAcrobatReadersoftware
mustbeinstalledinyoursystem.
Note: TheStartUpprogramautomaticallydetectsiftheAcrobatReaderutilityisalready
presentinyoursystem,andotherwisepromptsyouonwhetherornotyouwanttoinstallit.
YoumustinstalltheAcrobatReaderutilitytobeabletoreadtheuser'smanualfile.Follow
theinstructionsonyourscreenduringinstallation,thenoncetheinstallationiscompleted,
restartyoursystemandre-runtheSOYOCD.
Step 3. Install Drivers
Clickthe Install Drivers buttontodisplaythelistof driverssoftwarethatcanbeinstalledwith
yourMotherboard.TheStartUpprogramdisplaysthedriversavailablefortheparticular
modelofMotherboardyouown.Werecommendthatyouonlyinstallthosedrivers.
SOYO CD Manuals
Please select your manual in the box below
and click OK.
686 boards:586 boards:
OKBack
D6IBA2

SY-D6IBA2 Quick Start Guide
14
The SOYO CD
Thefollowing drivers areavailable forWindows95
(DriverInstallationMenu)
Thefollowing drivers areavailable forWindows98
(DriverInstallation Menu)
However,todisplaythe listofall driverssoftwareavailablewithSOYOMotherboards,click
the DisplayalldriversontheSOYO CD button.Pleasemakesuretoinstallonlythe
driversadaptedtoyoursystem,orotherwisethiscausesystemmalfunctions.
Please select the driver you want to install and click OK, You will have to
restart your system after installation. Only the drivers that are relevant
to your board are displayed initially.
Intel Southbridge Drivers
Intel BusMaster Drivers for Win95
SOYO Speedpro BusMaster Driver for win 95/98
Intel BusMaster Drivers for Win NT
Intel BusMaster Drivers for OS/2
Winbond hardware doctor for win 95/98
SOYO CD Xpress utility
CancelDisplay all drivers
on the SOYO CDOK
Driver Installation
Please select the driver you want to install and click OK, You will have to
restart your system after installation. Only the drivers that are relevant
to your board are displayed initially.
SOYO Speedpro BusMaster Driver for win 95/98
Intel BusMaster Drivers for Win NT
Intel BusMaster Drivers for OS/2
Winbond hardware doctor for win 95/98
SOYO CD Xpress utility
CancelDisplay all drivers
on the SOYO CDOK
Driver Installation

SY-D6IBA2 Quick Start Guide
15
The SOYO CD
Ashortdescriptionofallavailabledriversfollows:
ØIntel Southbridge Drivers
BecauseWindows95 doesnotrecognizethe SouthbridgeofthenewerIntelchipsets(TX,
BX,ZXetc)thisutilityhastoberun,itwillupdatethenecessaryWindowsfiles.(Onlyfor
Windows95)
ØSOYO SpeedPro Busmaster Driver for Win 95/98
WithoutthebusmasterdriverstheCPUwillneedtobeinvolvedeverytimedataisreadfrom
orwrittentotheHarddisk.ThebusmasterdriversmakeuseofDMA(DirectMemoryAccess)
torelievetheCPUofthisburden,thusspeedingupthesystem.
TheSOYOSpeedProdrivermakesuseofanadvancedcachingalgorithm,whichgivesitan
advantageoverother busmasterdrivers.
ØIntel Busmaster Drivers for Windows 95
ØIntel Busmaster Drivers for Win NT
ØIntel Busmaster Drivers for OS/2
Thesearetheofficial busmasterdriversassuppliedbyIntel.
Note:DoNEVER installtwo typesof busmaster drivers onyoursystem, thiswill
leadtoconflicts andsysteminstability. Therefore, ifyou install theSOYO
SpeedProBusmasterdriveryou canNOTinstall theIntel Busmasterdrivers.
Beforeinstallinganewbusmaster driverfirst UNINSTALLtheold busmaster
driver.
ØSOYO CD Xpress Utility
ThisutilitywillenhanceyourCD-ROMDrivedata-thoughputbyusingspaceonthe Harddisk
ascache.Thiswayapplicationprogramscanaccessdatafaster.Thisutilityissuitablefor
Windows95/98.
ØWinbond hardware doctor for Windows xx
YourmotherboardcomeswithahardwaremonitoringIC.ByinstallingthisutilityTemperature,
FanspeedandVoltagescanbemonitored.Itisalsopossibletosetalarmswhencurrent
systemvaluesexceedorfallbelowpre-setvalues.
ThisutilitycomeswithapresetmonitoringragefortheCPUvoltage.However,thecorevoltage
oftheprocessoryoupurchasedmayfalloutofthispresetrange,soyoumayneedtoadjustthe
pre-setvalue.PleaserefertotheSY-D6IBA2Motherboard’sCDmanualforthedetails.
Select which driver you want to install and click OK, or click Cancel to abort the driver
installationandreturntothemainmenu.
Note1: Onceyouhaveselectedadriver,thesystemwillautomaticallyexittheSOYOCDto
beginthedriverinstallationprogram.Whentheinstallationiscomplete,mostdriversrequire
torestartyoursystembeforetheycanbecomeactive.

SY-D6IBA2 Quick Start Guide
16
The SOYO CD
Note2:EZ-SCSIUtility: TheSCSIutilityforusewiththeonboardAdaptec
®
SCSIchipis
locatedinthe \drivers\EZ-SCSIdirectory.EZ-SCSIissuitableforDOSorWindows3.1
environmentonly.ThemanualfileinPDFformatcanbefoundatthefollowinglocation:
\Manual\EZ-SCSI.pdf.
Step 4. Check the Latest Releases
Clickthe'CheckthelatestReleases'buttontogotheSOYO Websitetoautomaticallyfind
thelatestBIOS,manualanddriverreleasesforyourmotherboard.Thisbuttonwillonlywork
ifyourcomputeris connectedto the internetthroughanetworkormodemconnection.Make
suretogetyourmodemconnectionupbeforeclickingthisbutton.
Step 5. Enter the SOYO CD
Clickthe EnterSOYO CD buttontoentertheSOYOHTMLdatabase.TheStartUp
programwillactivatethedefaultHTMLbrowserinstalledonyoursystem(forexample,
InternetExplorerorNetscape)tovisualizethecontentsoftheSOYOCD.
TheSOYOCDcontainsusefulinformationaboutyourMotherboardandotherSOYO
productsavailable.Foryourconvenience,thisinformationisavailableinHTMLformat,
similartotheformatwidelyusedontheInternet.
(SOYOCD HTMLDatabase inEnglish*)
Note: IfnoHTMLbrowserisinstalledonyoursystem,theStartUpprogramwillpromptyou
onwhetherornotyouwouldliketoinstalltheInternetExplorer*browser.ClickYEStoinstall
theHTMLbrowser.Aftertheinstallationiscomplete,pleaserestartyoursystem.Thenre-run
theSOYOCDandyouwillbeabletobrowsetheSOYOHTMLdatabase.
(*InternetExplorerisaMicrosoftTrademark)

SY-D6IBA2 Quick Start Guide
17
SCSI Utilities
5 5 SCSI Utilities
Ultra2 SCSI I/O Subsystem
Yournew SYD6IBA2 high-performanceMotherboardisequippedwiththeonboard
Adaptec
®
AIC-7890Ultra2SCSIhostadapterforyourhighbandwidthapplications,providing
datatransferratesofupto80Mbytespersecond.TheUltra2SCSIisaninput/outputbus
interfacethatprovidesapowerfulmultitaskinginterfacebetweenyourcomputer’sPCIbus
andyourSCSIdevices.
WithSCSI,youcanconnectavarietyofdevicesonyourcomputer(Hard/FloppyDiskDrives,
CD-ROMDrives,Scanners,TapeDrives,RemovableMediaDrives,etc.)inadaisy-chain
topologytoacommonhostadapter.Daisy-chainingSCSIdevicesallowsthemto
communicatewitheachotherbysendingcommandsanddataviatheSCSIbus.
TheAIC-7890Ultra2SCSIprovidesmaximumdatatransferratesof20Mbytes/secinthe
narrow8-bitmode(FastSCSI)and40Mbytes/secinthewide16-bitmode(UltraSCSI),and
80Mbytes/secintheLVDmode(Ultra2SCSI)
Installing SCSI Devices
YourMotherboardfeaturestwointernalSCSIconnectorsonboard,andcomeswithone50-
pinflatcable,one68-pinflatcable,andone68-pin Ultra2cable.
50-pin Fast SCSI Connector
NarrowSCSIallowsdatatransferratesofupto20Mbytes/sec.WithNarrowSCSI,youcan
connectupto7internalFastSCSIdevicestothe50-pinFastSCSIconnectoronthe
Motherboard.UsetheenclosedNarrowSCSIcabletoconnectupto2internalSCSI
devices.
Ifyouareconnectingmorethan2internalSCSIdevices,youmustuseaninternalSCSI
cablewithenoughconnectorstoaccommodateallyourdevices.Contactyourdealerfor
specialcableservice.
WhenFastSCSIdevicesareconnectedtothebus,thetotallengthofallcablesisnotto
exceed3meters(9.8ft.)toensurereliableoperation.
50-pin internal connector
Fast SCSI

SY-D6IBA2 Quick Start Guide
18
SCSI Utilities
68-pin Ultra-Wide SCSI Connector
Ultra-WideSCSIallowsyoutoconnectupto15devices(7Narrowinternaland8 Wide
internalorexternalSCSIdevices,or15WideinternalorexternalSCSIdevices)tothe68-pin
Ultra-WideSCSIconnectorontheMotherboard.Devicesthatconnecttothe16-bitWide
SCSIbuscantransferdataatthemaximumrateof40Mbytes/sec.
68-pin Ultra2 SCSI Connector
Ultra2SCSIallowsyoutoconnectupto15devices(LVD/SEmode)tothe68-pinUltra2
SCSIconnectorontheMotherboard.Devicesthatconnecttothe16-bitUltra2SCSIbuscan
transferdataatthemaximumrateof80Mbytes/sec.
ConnectingInternalSCSI Devices
IfyouareconnectingseveralinternalSCSIdevices(morethan2SCSIdevices),makesure
youhaveaninternalSCSIcablewithenoughconnectorstoaccommodateallofyour
devices.TheenclosedSCSIflatcablescanserveupto2SCSIdevices.
FollowthesestepstoensureaproperinstallationofyourinternalSCSIdevices:
1. PrepareeachSCSIdevicesforinstallation;configurethedevice SCSIID and
terminators( terminate thelastinternaldeviceattachedtothecablebysettingits
terminationtotheONposition;allotherinternaldevicesontheSCSIbusmusthave
theirterminationsettoOFF).
2. InstalltheSCSIdevicesinyourcomputer.
3. PlugtheconnectoratoneendoftheinternalSCSIcableintothehostadapter’sSCSI
connectorontheMotherboard.
Note: Makesurethecable’scoloredstripeisalignedwithpin-1ofthehostadapter’s
connector.Pin-1oftheSCSIconnectorisusuallydesignatedbyasmalltriangle( 5 ),ora
“1”atonecorneroftheconnector.
4. ConnecttheremainingconnectorsonthecabletotheSCSIdevices(CD-ROMdrives,
etc.).
Note: Makesurethecable’scoloredstripeisalignedwithpin-1oftheSCSIdevice’s
connector.
5. ConnectaDCpowercable(fromyourcomputer’spowersupply)tothepower
connectoroneachSCSIdevice.
68-pin internal connector
Ultra-Wide SCSI
68-pin internal connector
Ultra2 SCSI

SY-D6IBA2 Quick Start Guide
19
SCSI Utilities
SCSI Driver Installation
Windows®95 Users
Thischapterexplainshowtoinstallthe Adaptec7800FamilyManagerSetaic78xx.mpdandaic78u2.mpd
driversforWindows95.Theaic78xx.mpddriversupportsallAdaptec7800FamilyUltra2SCSI(andearlier)
hostadapters,andtheaic78u2.mpddriversupports allUltra2SCSIadapters.Refertothelist.
IfyouareperformingafirsttimeWindows95installation,seeInstallingtheDriverWhenInstallingWindows
95IfWindows95isalreadyinstalledinyoursystem,seeInstallingtheDriverWhenWindows95isAlready
Installed.
Note:When Windows 95 starts, if a New Hardware Found dialog is displayed after your
7800 Family Manager Set host adapter has been installed, you must select the Driver from
Disk Provided by Hardware Manufacturer option. Insert your Adaptec 7800 Family
Manager Set v. 3.01 diskette into the floppy drive and type a:\win95 as the path. Then,
followtheonscreeninstructions.
Installing the Driver When Installing Windows 95
Aversionoftheaic78xx.mpd(Ultra2SCSI)driverisembedded(included)intheWindows95installation
CD-ROM.DuringanormalWindows95installation,the7800Familyhost adapter(Ultra2 SCSIor earlier)is
detectedinyoursystemandtheembeddedaic78xx.mpddriverisautomaticallyinstalled.
Note: If the Windows 95 installation cannot detect the 7800 Family host adapter(Ultra2
SCSI or earlier) installed in your computer, or you are installing the aic78u2.mpd driver for
an Ultra2 SCSI host adapter, you must install the driver manually after Windows 95 is
complete. Follow the procedures in the section Installing the Driver When Windows 95 is
AlreadyInstalled,below
Installing the Driver When Windows 95 is Already Installed
Toupdateorinstalltheaic78xx.mpdoraic78u2.mpdifWindows95is alreadyinstalled,followthese
instructions:

SY-D6IBA2 Quick Start Guide
20
SCSI Utilities
Note: All Adaptec 7800 Family Ultra2 SCSI (and earlier) host adapters use the
aic78xx.mpd driver. Ultra2 SCSI adapters use the aic78u2.mpd driver. Once the correct
driver is updated, it is not necessary to update it again for each 7800 Family host adapter
installedinyoursystem.
1. StartWindows 95.
2. Clickthe[Start]buttonontheWindows95taskbar,andthenpointtoSettings.
3. Click[ControlPanel].
4. Double-clickthe[System]icon.
5. OntheDeviceManagertab,clicktheplussign(+)nexttotheSCSIcontrollericon.
Note: If Windows 95 cannot determine the type of host adapter installed in your
computer, a yellow question mark labeled Other devices appears instead of the JSCSI
controller icon. To continue, click the plus sign (+) next to the question mark; a yellow
questionmarklabeledPCISCSIBusControllerthenappears.
6. Double-clickthe7800Familyhostadapteryouwishtoupdate,orifayellowquestionmarklabeled
PCISCSIBusControllerisdisplayed,double-clickthequestionmark.
7. InserttheAdaptec7800FamilyManagerSetv.3.01disketteintodriveA.
8. SelecttheDrivestab
Note: If the version of Windows 95 you are using displays an Update Drivers button
instead of a [Change Driver] button, follow the procedures in the section Updating the
Driverfor Windows95(VersionOSR2).
9. Click[ChangeDriver].Ifyouarepromptedtoselectthehardwaretype,select[SCSIController].
10. Clickthe[HaveDisk]buttonandentera:\win95asthepath.
11. Click[OK]
12. Selectthe7800Familyhostadapter,andclick[OK].
13. Click[OK].Thedriveriscopiedandscanned.
14. Youmustrestartyourcomputerforthechangestotakeeffect.Click[Yes]torestartyourcomputer.
Click[No]toreturntothesystempropertieswindow.
