SOYO SY-7VEM User manual

SY-7VEM
Motherboard
Quick Start Guide
Hardware
Installation
Quick BIOS
Setup
Introduction
The SOYO CD

SOYO™
2
SY-7VEM Motherboard
Socket 370 for VIA Cyrix, Intel PIII & Celeron processors
VIA PLE133 AGP/PCI Motherboard
66/100/133 MHz Front Side Bus supported
Micro-ATX Form Factor
Copyright © 2001 bySoyo Computer Inc.
Trademarks:
Soyo is the registered trademark of Soyo Computer Inc. All trademarks are the properties of
their owners.
Product Rights:
All names of the product and corporate mentioned in this publication are used for identification
purposes only. The registered trademarks and copyrights belong to their respective companies.
Copyright Notice:
All rights reserved. This manual has been copyrighted by Soyo Computer Inc. No part of this
manual may be reproduced, transmitted, transcribed, translated into any other language, or
stored in a retrieval system, in any form or by any means, such as by electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without permission in writing from Soyo
Computer Inc.
Disclaimer:
Soyo Computer Inc. makes no representations or warranties regarding the contents of this
manual. We reserve the right to amend the manual or revise the specifications of the product
described in it from time to time without obligation to notify any person of such revision or
amend. The information contained in this manual is provided to our customers for general use.
Customers should be aware that the personal computer field is subject to many patents. All of
our customers should ensure that their use of our products does not infringe upon any patents. It
is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to
infringe upon or to cause others to infringe upon such rights.
Restricted Rights Legend:
Use, duplication, or disclosure by the Government is subject to restrictions set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at
252.277-7013.
About This Guide:
This Quick Start Guide can help system manufacturers and end users in setting up and installing
the Motherboard. Information in this guide has been carefully checked for reliability; however,
to the correctness of the contents there is no guarantee given. The information in this document
is subject to amend without notice.
For further information, please visit our Web Site on the Internet. The address is
"http://www.soyo.com.tw".
7VEM Serial - Version 1.2 - Edition: May 2001
* These specifications are subject to amend without notice

SY-7VEM Quick Start Guide
3
Introduction
1 1 Introduction
Congratulations on your purchase of the
SY-7VEM
Motherboard. This
QuickStartGuide
illustrates the steps for installing and setting up your new Motherboard.
This guide provides all users with the basic steps of Motherboard setting and operation. For
further information, please refer to the
SY-7VEMMotherboard Users’Guide
that came with
your Motherboard.
Unpacking
When unpacking the Motherboard, check for the following items:
u
The SY-7VEM PLE133 AMR/PCI/ISA Motherboard
u
The Quick Start Guide
u
The Installation CD-ROM
u
SOYO Bonus Pack CD-ROM
u
One IDE Device ATA 66 Flat Cable
u
One Floppy Disk Drive Flat Cable
u
One serial port flat cable with a 9-pin connector

SY-7VEM Quick Start Guide
4
Introduction
SY-7VEM Motherboard Layout
(Optional)
PRT
PS/2 KB
Connector
PS/2 Mouse
Connector
ATX Power
AOUT
AIN
AMIC
AGAME
COM1
VGA
USB 1_2
3V
Lithium
Battery
JBAT1
1
3
PCI1
PCI3
SL1
PCI2
FDC
IDE 1
IDE 2
Socket 370
JWOL1
®
VT82C686A
®
VT8601A
CD_IN
AMR
COM 2
MPF
39SF020
VT1611A
1
1
1
3
3
4
J25

SY-7VEM Quick Start Guide
5
Introduction
Key Features
Ø
Supports Intel® processors
- FSB 66MHz: Celeron

(400-700MHz)
- FSB 100MHz: Pentium® III (500-
850MHz)
- FSB 133MHz: Pentium® III (533MHz-
933MHz)
Supports Via Cyrix processors
- FSB 100MHz: Cyrix III (500MHz-
600MHz)
- FSB 133MHz: Cyrix III (533MHz-
600MHz)
Ø
Supports 66/100/133 MHz Front Side
Bus Frequency
Ø
Auto-detect CPU voltage
Ø
PC99, ACPI
Ø
Ultra DMA33/66 (ATA 33/66)
Ø
Supports Wake-On-LAN (WOL)
Ø
Power-on by modem and alarm
Ø
Support onboard VGA
Ø
Supports onboard hardware monitoring
Ø
Supports 5 sets of voltage monitoring
Ø
Supports multiple-boot function
Ø
Supports Audio Modem Riser slot (AMR
1.0 compliant) *
Ø
3 x 32-bit bus master PCI slots
Ø
1 x 16-bit ISA slot.
Ø
4 x USB ports onboard
Ø
ATX power connector
*Becausethis boardcomes withsoftware Audio(AC97) onboard, theAudio functionin AMRis notrelevant.
Iftheuser wantsto useaModem Risercard (MR)makesure tousea Secondary modeMR, PRIMARY
modeMRs are NOT Supported.
TheCPUFan willnotturn off duringstandbymode.

SY-7VEM Quick Start Guide
6
Hardware
Installation
2 2 Installation
To avoid damage to your Motherboard, please follow these simple rules while
handling this equipment:
l
Before handling the Motherboard, ground yourself by touching on to an unpainted
portion of the system's metal chassis.
l
Remove the Motherboard from its anti-static packaging. Hold the motherboard by the
edges and avoid touching its components.
l
Check the Motherboard for damage. If any chip appears to be loose, press carefully
to seat it firmly in its socket.
Follow the directions in this section which is designed to guide you through a quick and
correct method to install your new
SY-7VEM
Motherboard. For detailed information, please
refer to the
SY-7VEMMotherboardUser'sguideandTechnical Reference
online manual on
in the CD-ROM package that came with your Motherboard.
Gather and prepare all necessary components to complete the installation successfully:
u Socket370 processor with built-in CPU cooling fan (boxed type)
u SDRAM module(s)
u Computer case with adequate power supply unit
u Monitor
u PS/2 Keyboard
u Pointing Device (PS/2 Mouse)
u Speaker(s) (optional)
u Disk Drives: HDD, CD-ROM, Floppy drive…
u External Peripherals: Printer, Plotter, and Modem (optional)
u Internal Peripherals: Modem and LAN cards (optional)
Note: 1.
If you want to use an external speaker connected to "Line-out" port, please make
sure to use an "amplified speaker" that can generate proper output sound volume.

SY-7VEM Quick Start Guide
7
Hardware
Installation
Install the Motherboard
To perform the installation of your new
SY-7VEM
Motherboard, follow the steps below:
Step 1. CPU Installation
Mark your CPU Frequency:
RecordtheworkingfrequencyofyourCPUthat
shouldbeclearlymarkedontheCPUcover.
FSB66MHz
400MHz(66x6.0) 466MHz(66x7.0) 533MHz(66x8.0) 600MHz(66x9.0) 667MHz(66x10.0)
433MHz(66x6.5) 500MHz(66x7.5) 566MHz(66x8.5) 633MHz(66x9.5) 700MHz(66x10.5)
FSB100MHz
500MHz(100x5.0) 600MHz(100x6.0) 700MHz(100x7.0) 800MHz(100x8.0)
550MHz(100x5.5) 650MHz(100x6.5) 750MHz(100x7.5) 850MHz(100x8.5)
FSB133MHz
533MHz(133x4.0) 667MHz(133x5.0) 800MHz(133x6.0) 933MHz(133x7.0)
600MHz(133x4.5) 733MHz(133x5.5) 866MHz(133x6.5)
CPU Mount Procedure:
To mount the Pentium® & Celeron
TM
processor & VIA
Cyrix processor that you have purchased separately, follow these instructions.
1. Lift the socket handle up to a vertical position.
2. Align the blunt edge of the CPU with the matching pinhole edge on the socket.
3. Seat the processor in the socket completely and without forcing.
4. Then close the socket handle to secure the CPU in place.
Remember to connect the CPU Cooling Fan to the appropriate power
connector on the Motherboard.
Thefanisakeycomponentthatstabilizesthe
system.Itpreventstheequipmentfromoverheatingandprolongsthelifeof
yourCPU.
12
34
S
o
cket370
S
o
cket370
S
o
cket370
S
o
cket370

SY-7VEM Quick Start Guide
8
Hardware
Installation
Step 2. Connections to the Motherboard
This section tells how to connect internal peripherals and the power supply to the Motherboard.
The internal peripherals consist of IDE devices (HDD, CD-ROM), Floppy Disk Drive, Chassis
Fan, Front Panel Devices (Internal Speaker, Reset Button and IDE LED Switch.), Wake-On-
LAN card, VGA card, Sound Card, and other devices.
For more details on connecting internal and external peripherals to your new SY-7VEM
Motherboard, please refer to
SY-7VEMMotherboardUser'sGuideandTechnical Reference
online manual on the CD-ROM.
Connectors and Plug-ins
Wake-On-LANHeader: JWOL1 StandardIrDA (Infrared Device Header): J1
Pin1 Pin2 Pin3 Pin1 Pin2 Pin3 Pin4 Pin5
5V-SB GND Ring VCC NC IRRX GND IRTX
JUSB1_#1 JUSB1_#2
Pin1 Pin3 Pin5 Pin7 Pin9 Pin2 Pin4 Pin6 Pin8 Pin10
+5V Data(-) Data(+) GND GND +5V Data(-) Data(+) GND GND
CPU Cooling Fan: JFAN1 ChassisFan:JFAN2
Pin1 Pin2 Pin3 Pin1 Pin2 Pin3
SENSOR 12V GND SENSOR 12V GND
CD -IN: CD_IN Pin1 Pin2 Pin3 Pin4
Connect the CD Line-in cord from the CR-ROM device to the
matching connector CD_IN LG G R
PowerLED
Pin1 Pin2 Pin3
5V NCGND
Speaker
Pin1 Pin2 Pin3 Pin4
5V NC NC Speakerout
HDDLED PWRBT RESET
Pin1 Pin2 Pin1 Pin2 Pin1 Pin2
LEDAnode LEDCathode Power On/Off GND ControlPIN GND
ATXPowerOn/Off:PWRBT
Connectyourpowerswitchtothisheader(momentaryswitchtype).
Toturnoff the system, press this switch andholddownforlongerthan4seconds.
ATXPowerSupply:ATXPW
AttachtheATXPowercabletothisconnector.(ThismotherboardrequiresanATXpowersupply,anAT
powersupplycan NOT beused.)
WhenusingthePower-OnbyPS/2Keyboardfunction,pleasemakesuretheATXpower supply isableto
provideatleast720mAonthe5VStandbylead(5VSB)inordertomeet the standardATXspecifications.
Power LED
Speaker
Reset
PWRBT
HDD LED
++
+
_
_
_
1 1

SY-7VEM Quick Start Guide
9
Hardware
Installation
Step 3. Configure Memory
Your board comes with two DIMM sockets, providing support for up to 512MB of main
memory using unbuffered and registered DIMM modules from 8MB to 256MB. On this
motherboard, DRAM speed can be set independent from the CPU front side bus speed.
Depending on the DRAM clock speed setting in the BIOS setup, appropriate memory
modules must be used. For 66MHz DRAM speed, use PC66 memory; for 100MHz DRAM
speed, use PC100 memory; for 133MHz DRAM speed, use PC133 memory.
Memory Configuration Table
Number of Memory
Modules DIMM 1 DIMM 2
RAM Type SDRAM
Memory Module Size (MB) 8/16/32/64/128/256 MB
Note:Always install memory modules in the order prescribed in this table.
CMOS Clear (JBAT1)
In some cases the CMOS memory may contain wrong data, follow the steps below to clear
CMOS memory.
1. Clear the CMOS memory by momentarily shorting pin 2-3 on jumper JBAT1. This
jumper can be easily identified by its white colored cap.
2. Then put the jumper back to 1-2 to allow writing of new data into the CMOS memory.
CMOS Clearing Clear CMOS Data Retain CMOS Data
JBAT1Setting Shortpin2-3for
atleast5secondsto
clearthe CMOS
Shortpin1-2to
retain new settings
Note: You must unplug the ATX power cable from the ATX power connector when
performing the CMOS Clear operation.
123
123

SY-7VEM Quick Start Guide
10
Quick BIOS
Setup
3 3 Quick BIOS Setup
This Motherboard does not require any hardware jumpers to set the CPU operating
frequency.
Aftercompletionofhardwareinstallation,turnthepowerswitchon,thenpressthe <DEL> keywhile
thesystemdiagnosticischeckingtoenter theAwardBIOSSetupprogram.TheCMOSSETUP
UTILITYwillbedisplayedonscreen.Thenfollow these steps toconfiguretheCPUsettings.
Step 1. Select [STANDARD CMOS SETUP]
Set [Date/Time] and [Floppy drive type], then set [Hard Disk Type] to “Auto”.
Step 2. Select [LOAD SETUP DEFAULT]
Select the “LOAD SETUP DEFAULT”menu and type “Y”at the prompt to load the BIOS
optimal setup.
Step 3. Select [SAVE & EXIT SETUP]
Press
<Enter>
to save the new configuration to the CMOS memory, and continue with the
boot sequence.

SY-7VEM Quick Start Guide
11
The SOYO CD
4 4 The SOYO CD
The SOYO-CD will NOT autorunifyou use it on anOperatingSystemother
thanWindows9xorNT.
Your SY-7VEM Motherboard comes with a CD-ROM labeled "SOYO CD." The SOYO
CD contains (1) the user's manual file for your new Motherboard, (2) the drivers software
available for installation, and (3) a database in HTML format with information on SOYO
Motherboards and other products.
Step 1. Insert the SOYO CD into the CD-ROM drive
The SOYO CD will auto-run, and the SOYO CD Start Up Menu will be as shown.
If you use Windows NT, the SOYO-CD will not detect your motherboard type. In that case
the following dialog will pop up, please choose your motherboard and press OK. Now the
SOYO-CD Start Up Menu will be shown.
(SOYOCDStartUpProgramMenu)
If you use Windows 95 or 98, the SOYO CD Start Up Program automatically detects
which SOYO Motherboard you own and displays the corresponding model name.
7IWA-F
7IWA-F V1.0
6IWM/L
6IWM
6IWA
LI-7000
7IWB
7IWB V1.0
7IWM
7IWM/L V1
Please Select Your Board
OKCancel
X

SY-7VEM Quick Start Guide
12
The SOYO CD
The user's manual files included on the SOYO CD are in PDF (Postscript Document)
format. In order to read a PDF file, the appropriate Acrobat Reader software must be
installed in your system.
Note:
The Start Up program automatically detects if the Acrobat Reader utility is already
present in your system, and otherwise prompts you on whether or not you want to install it.
You must install the Acrobat Reader utility to be able to read the user's manual file. Follow
the instructions on your screen during installation, then once the installation is completed,
restart your system and re-run the SOYO CD.
Step 2. Install Drivers and Utilities
Click the
Install Drivers
button to display the list of drivers software that can be installed
with your Motherboard. The Start Up program displays the drivers available for the
particular model of Motherboard you own. We recommend that you only install those
drivers.

SY-7VEM Quick Start Guide
13
The SOYO CD
(DriverInstallationMenu)
A short description of all available drivers follows:
ØVIA 4in1 Driver Package for Win 9x/NT/2000
The 4 in 1 Driver Package includes all drivers your motherboard needs. After selecting this
Driver Package, one driver will be installed automatically (the IRQ remapping utility), the
other three are installed if selected. By default all three drivers are selected. A description of
the 4 drivers follows:
 Bus Master PCI IDE Driver
This driver will speed up the data-transfer rate to and from the harddisk.
 AGPVxD Driver
This driver must be installed in order to be able to make use of the on-board AGP
Video functionality.
 VIAChipset Functions Registry
This driver will make the necessary changes to the Windows registry, in order to
make sure that Windows has no problems recognizing your VIA chipset.
 IRQremappingutility(Thisdriveris installed automatically)
This utility will remap the IRQ lines to make sure that everything functions properly
under Windows.
ØVIA 8601 ProSavage Display Driver for Win 98
In order to be able to make use of the integrated VGA function in your VIA 8601 chipset,
you will need to install this driver first. For Win 98 only.
ØVIA 8601 ProSavage Display Driver for Win ME
In order to be able to make use of the integrated VGA function in your VIA 8601 chipset,
you will need to install this driver first. For Win ME only.
driverrevision:
VIA 4 in 1 Driver Package for Win 9x/NT/2000
VIA8601 Onboard Display Driver for Win 98/ME
VIA8601 Onboard Display Driver for Win 2000
VIA8601 Onboard Display Driver for Win NT4.0
VIA Onboard Audio Driver for Win 9x/ME/NT/2000
VIA hardware(R) monitor for (Win 95/98)
CancelOK

SY-7VEM Quick Start Guide
14
The SOYO CD
ØVIA 8601 ProSavage Display Driver for Win 2000
In order to be able to make use of the integrated VGA function in your VIA 8601 chipset,
you will need to install this driver first. For Win 2000 only.
ØVIA 8601 ProSavage Display Driver for Win NT4.0
In order to be able to make use of the integrated VGA function in your VIA 8601 chipset,
you will need to install this driver first. For Win NT4.0 only.
ØVIA Onboard Audio Driver for Win 9x/ME/NT/2000
You have to install the drivers before installing any application for the Onboard Audio.
ØVIA hardware(R) monitor for (Win 95/98)
Your motherboard comes with a hardware monitoring IC. By installing this utility
Temperature, Fan speed and Voltages can be monitored. It is also possible to set alarms
when current system values exceed or fall below pre-set values.
Select which driver you want to install and click
OK,
or click
Cancel
to abort the driver
installation and return to the main menu.
Note:
Once you have selected a driver, the system will automatically exit the SOYO CD to
begin the driver installation program. When the installation is complete, most drivers
require to restart your system before they can become active.
Step 3. Check the Latest Releases
Click the 'Check the latest Releases' button to go the SOYO Website to automatically find
the latest BIOS, manual and driver releases for your motherboard. This button will only
work if your computer is connected to the internet through a network or modem
connection. Make sure to get your modem connection up before clicking this button.
(*InternetExplorerisaMicrosoftTrademark)

SY-7VEM Quick Start Guide
15
Quick Trouble shoot tips
Video (no display) related issues
I built a new computer system using a Soyo board and nothing happens when
turning it on, no video and no beeps from the PC speaker. What is happening
and how can it be fixed?
No screen and no beeps mean that your CPU and motherboard do not work at all. It
could be that the CPU is not seated correctly or that a component on the M/B is
grounded (shorted) with the case. Also make sure to check the voltage setting
switch (110V/220V) on the back of the power supply. To isolate the problem do
the following:
1. Press and hold down on the “Ins”(insert) key while turning on the computer
until you get video. If you do not get video then,
2. Double-check jumpers setting on you motherboard and remove all add-on
cards, unplug all hard-disk and floppy-disk drive cables and see if you can hear
some beeps. If you still do not get any beeps, then try putting the motherboard on
the table (to isolate it from the case) with the CPU and speaker only, and give it one
more try.
I get distorted video right after I save my bios. Why is that?
To fix this, please clear the CMOS via JBAT1 and if it still does not work, please
upgrade your motherboard bios to the latest version.
BIOS Issues
Where can I find the BIOS revision of my mainboard?
It will be displayed on the up-left corner on the screen during boot-up. It will show
as your board type followed by the revision number, such as 5EH_2CA1 (meaning
revision 2CA1 for the SY-5EH board) or 6BA+ IV_2AA2 which means SY-6BA+
IV motherboard with 2AA2 bios.
Where can I find the latest BIOS of my motherboard?
Please go to the technical support page of one of the SOYO websites (Taiwan:
www.soyo.com.tw), and look up your motherboard to find the latest BIOS
revision.
Hard disk, floppy drive, CD-ROM etc
When I boot up my new computer I got "floppy boot failure" and the LED on

SY-7VEM Quick Start Guide
16
the floppy stays on
Make sure the red wire of floppy ribbon cable goes to Pin1 on the floppy drive side
(don't trust the "key lock" or "notch") and use the end-connector of the cable (don't
use middle one).
Modem issues
I get an "I/O Conflict" message when I turn on my system and I can not get
my modem to work
What you need to do is to disable 'COM2' (or UART2 or serial port 2) in the bios
under integrated peripheral setup.
I have installed my modem drivers several times and I still cannot get my
modem to work. Why?
If you are sure that the modem driver has been installed correctly, then you need to
install the via 4 in 1 driver from the SOYO CD, this is because Windows does not
properly recognize relatively new chipsets.
Audio Issues
I do not get any sound from my sound card. What could be wrong?
Please make sure the speaker is connected to the speaker out port on your sound card.
In Device Manager, I keep getting yellow exclamation signs on my sound port
even though I have installed my sound driver several times and I could not get
my sound card to work. What is wrong?
It is likely that you did not have the correct driver installed. If you are sure that the
correct sound driver has been installed, then please install the 'via 4 in 1' driver for
the motherboard.
The sound is working in my system, but when I play CD music from the CD-
ROM, I do not get any sound. What is wrong?
This is because the 3-wire audio cable from the CD-ROM to the sound card is not
connected or it is loose.
The sound from my sound card is distorted when Windows starts. What is
wrong?
First, if you are using an ISA sound card, please make sure the IRQ needed for the
sound card is set to 'Legacy ISA' in the bios. In other words, if your ISA sound card
takes IRQ5, then set IRQ5 to 'Legacy ISA'. Next, install the 'via 4 in 1' driver for the
motherboard.

SY-7VEM Quick Start Guide
17
The sound and everything else works fine except that the recorder and
microphone do not work. What is wrong?
This is because the recorder and microphone in the Windows are not enabled.
Please go to sound properties and enable them.
Lock up (freeze)
When I boot up my system, everything works fine. It sees my CPU and
memory, detects my hard drive, floppy drive and CD-ROM but locks up at
"Verify DMI pool data... ", and it won’t go any further. What should I do?
Please clear the CMOS via JBAT1 then choose 'load optimized default' in the bios
and save the bios and exit. Next, unplug all other add-on cards except the video
card and floppy drive controller, and see if it can boot from floppy. Then put back
the peripherals one by one to identify which one causes the lockup.
I can not get my board to run properly.
Please make sure you have the latest bios and driver from the SOYO web site at:
http://www.soyo.com

SY-7VEM Quick Start Guide
18
How to contact us:
nIf you are interested in our products, please contact the SOYO sales
department in the region you live.
nIf you require Technical Assistance, please contact our Technical Support in
the region you live.
SOYO prefers Email as communication medium, remember to always add to the
email the country that you live in.
TAIWAN
SOYO COMPUTER INC.
No. 21 Wu-Kung 5 Rd., Hsin Chuang
City, Taipei Hsien, Taiwan, R.O.C
TEL: [phone]
FAX: [phone]
http://www.soyo.com/
Email:[email protected]
USA
SOYO INC.
41484 Christy Street, Fremont, CA
94538, USA
TEL: [phone]
FAX: [phone]
http://www.soyousa.com/
Email : [email protected]
GM
SOYO Deutschland GmbH
(SAAT Technology GmbH)
August-Wilhelm-Kuhnholz-Str. 15
D-26135 Oldenburg (Oldb), Germay
TEL: [phone]
FAX: [phone]
http://www.soyo.de/
Email: [email protected]
JAPAN
SOYO COMPUTER
SOYO BLDG, 1-23-14, Hyakunincho,
Shinjyuku-ku, Tokyo Japan 169-0073
TEL: [phone]
FAX: [phone]
http://www.soyo.co.jp/
Email: [email protected]
CHINA
GING MEI JEI LTD
Room 304, Phoenix Mansion, No. 165
Haidian Road, Haidian Distnct, Beijing
100080, China
TEL: [phone]
FAX: [phone]
http://www.soyo.com.cn/
Email: [email protected]
KOREA
SOYO TECHNOLOGY CO., LTD.
3 rd, F1, Wonhyo Bldg, 46-1,
Wonhyoro 3 Ga, yongsan Ku, Seoul
Korea
TEL: [phone]
FAX: [phone]
http://www.soyo.co.kr/
Email: [email protected]

SY-7VEM Quick Start Guide
19
Hong Kong
Soyo (H.K.) Ltd.
5C, Big Star Centre, 8 Wang Kwong
Road, Kowloon Bay, Kowloon, HK
TEL: [phone]
FAX: [phone]
http://www.soyo.com.hk/
Email: [email protected]

Edition: May 2001
Version 1.2
SY-7VEM
SERIAL
