SP tools SP61090 User manual

USER MANUAL
IMPORTANT
ALL PERSONS WHO ARE TO USE THIS EQUIPMENT MUST THOROUGHLY READ
AND UNDERSTAND THIS INSTRUCTION MANUAL PRIOR TO OPERATION.
SP61090
SMART CHARGER
8 STAGE 10AMP
MULTI VOLT
RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO
MANUAL FOR FUTURE
REFERENCE
NOTE: Proof of purchase must be retained by
the customer as it will be required in the
event of a claim under warranty.
AFTER SALES SUPPORT:
AUSTRALIA: Visit the website’s contact page to get in
touch with your local service department.
WWW.SPTOOLS.COM
INTERNATIONAL:Use the county selector to get in touch
with your service department in your country or region.

2
CONTENTS
Introduction 3
Intended Use 3
Operating Instructions 4
Safety Precautions & Warnings 6
Technical Features 7
Technical Specification 7
Warranty Details 8

3
INTRODUCTUCTION
This charger is manufactured using the highest quality components, latest manufacturing
processes & systems, along with very strict quality control, to achieve the highest quality
levels in the industry.
Incorporating a unique micro-processor controlled eight stage charging system, This
system intelligently assesses battery condition, state of charge and size, and produces a
charge rate to suit the battery, making battery charging safer, faster and much more effective
in charging and maintaining a battery or small 12v battery banks.
A heavy duty switch to select battery voltage for the microchip controlled automatic eight
stage charging system, provides accurate detection, monitoring and control of the charging
output voltage and current in turn preventing serious over charge or short charging of the
battery. This prevents battery plate oxidization, evens the consistency of the battery
electrolyte, minimizes battery temperature rising while charging recovers the battery
capacity faster and extends battery life.
The “Lead-acid (AGM) / Calcium” or “Gel” selector switch alters the charging stage voltage
parameters allowing all types of batteries to be effectively charged and ready for optimal
use.
The Zero volt start allows the charger to be connected to very flat batteries, and along with
the Desulphation stage give these batteries the best chance possible in recovery.
Temperature compensated voltage adjustment automatically adjusts the charging voltage
according to the environmental ambient temperature. In summer, this function helps
decrease battery heat generated while charging, thus minimizing the loss of battery
electrolyte and preventing battery deformation caused by excessive heat during charging
cycles.
Whilst charging the battery, it is common to see the voltage and percentage of charge LED
display to fluctuate up and down. When a battery is first connected, voltages will climb well
over the selected voltage and later drop back down. This will have an effect on the
percentage of remaining charge display as the on-board software will calculate this figure
based on the battery voltage reading. After the battery charger finishes its bulk and
absorption stages, the charge voltages will slowly settle back down, thus giving an accurate
reading of remaining charge, so please allow appropriate time to gather an accurate reading
of percentage of remaining charge.
Intended Use
The SP61090 - 6,12, 24 Volt Battery Charger is ideal for the home handyman or small
workshop, designed to efficiently charge 6, 12 or 24 Volt lead acid automotive, Motorcycle,
marine and light industrial type batteries, Including Calcium-Calcium (Cal-Cal), Calcium-
Silver (Cal-Ag), Lead Antimony, Absorbed Glass Matt (AGM) and Gel battery types.
These chargers are intended only for use in non-explosive and dry environments.
Never use or put the charger down in any liquid, oil or water.

4
Operation
How to use:
1) Check the battery is suitable for this charger.
2) Select the correct battery voltage by rotating the Voltage selection switch.
3) Connect the charger Positive (Red) Lead to the Positive of the battery.
4) Connect the charger Negative (Black) Lead to the Negative of the battery.
5) Plug the charger into the power socket & turn on the charger.
6) Select the battery type by repeatedly pressing the battery type selector until the
correct type is illuminated on the display.
Gel = Gel Batteries, Lead Acid = Lead Antimony & AGM Batteries, Calcium =
Calcium (Ca-Ca or Ca-Ag)
7) Charging is now taking place.
8) When the battery capacity bar graph is fully lit up, the battery is fully charged & the
charger has gone into its maintenance stage. You can disconnect the charger, or
leave the charger connected, if left connected the charger will maintain the battery in
a fully charged state without causing any damage to the battery or charger.
Note: The charger will remember the last battery type selected, even after disconnection
from the power, and will only change when changed manually by the user. This is very
useful if you are charging a lot of batteries, or the unit is permanently connected to a
battery bank and the 240V power may be frequently disconnected and reconnected.
LED Display:
•Battery Type Selected – “GEL”, “LEAD
ACID”, “CALCIUM”
•Charging Voltage – Shows the Voltage
of the battery while charging.
•All bars on battery will flash if the
charger has determined that the battery
may be faulty.
The battery bar graph will display the percentage of charge in the battery, when all bars
are illuminated the battery is fully charged.
Charge
100%
50%
10%
As well the red & white terminals
on battery bar graph display will
flash, if the charger is connected
to the battery with reverse
polarity.

5
Charging Stages:
Stage 1 – “Desulphation”
In this initial start-up stage, a high frequency voltage pulse (0.5 sec) is to assist in “waking
up” a deeply discharged battery. This method of pulse charging can also help to reduce
build-up of sulphate crystals that may have formed on the battery plates during the time it
was discharged. This stage will last as long as it takes the battery to reach approximately
10 volts. If the connected battery is only slightly discharged, this stage may only be
activated for a short time before automatically switching to the next “soft start” stage.
Stage2 – “Soft Start”
Most conventional Battery Chargers will immediately apply a high charging voltage and
current output. This creates a large amount of gas and heat from the battery, and when
the consistency of the battery electrolyte / state of cell charge is uneven and a full load
charging characteristic can result in a period of potentially damaging overcharging.
The Soft Start function eliminates this situation by starting the charging process slowly and
softly, battery electrolyte and cell charge is able to even out, before receiving the main bulk
charge. This significantly improves the battery charging capability and reception.
Stage 3 – “Bulk”
This is the main hard charging stage, where the charger will operate at the maximum rated
current output, until the battery reaches a pre-set voltage determined by the battery type
selection. Charging time period is determined by the capacity and charge state of the
battery.
Stage 4 – “Absorption”
After the Bulk stage, the charger will automatically begin to reduce its current output
depending on the charge acceptance of the battery, while maintaining a constant voltage
(determined by the battery type selection). When the current reduces to a predetermined
threshold level charging will automatically halt, allowing the analysis stage to be performed
Stage 5 - “Analysis” (Testing the battery while charging)
After the Absorption charging state, the battery charger will start the “Analysis” stage and
will stop charging the battery for approximately 2 minutes. At this point, if the battery
voltage is sensed at below 12.6V, the battery alarm and faulty battery indicators and alarm
will sound. If the battery voltage is equal to or above 12.6V, the next Boost stage will start.
Stage 6 – “Boost”
After successfully analysing the battery condition, the charger will enter the Boost charge
stage, which will charge at a slightly higher voltage ensuring the battery attains a 100% full
charge. The current output is limited at 25% of the maximum rated charger output. When
the current drops to the pre-set level or a maximum of 15 minutes is reached the charger
will enter the last float charge stage.
Stage 7 – “Float”
This stage will “even out” the voltage between all cells maintaining a constant voltage with
a reduced current, thus prolonging the battery service time. If a load is applied to the
battery and the battery voltage drops below 6.2 volts (6 Volt Setting), 12.4 volts (12 Volt
Setting) or 24.4 volts (24 Volt Setting), the charger will restart from the absorption stage.

6
Stage 8 – “Maintain”
This final stage regulates the fully charged battery. A small pulse charge is applied at
0.5Hz to maintain the battery at its fully charged state and ready to be used at any time. If
a load is applied to the battery and the battery voltage drops below 6.2 volts (6 Volt
Setting), 12.4 volts (12 Volt Setting) or 24.4 volts (24 Volt Setting), the charger will restart
from the absorption stage.
Safety Instructions for Charger & Battery
1. Do not use a damaged appliance. If the
electrical cord is damaged have it
repaired or replaced by a qualified
electrician immediately.
2. Explosive gases may escape from the
battery during charging.
3. Do not charge inside a box or container of any kind. The battery must be placed in a
well-ventilated area during charging.
4. Prevent flames and sparks - ensure the area is well ventilated.
5. Do not short the battery or touch the terminals with any conductive materials.
6. Do not expose battery charger to water or rain, make sure you have dry hands when
operating the charger.
7. Before charging ensure you have read the instruction manual in full.
8. This charger is for use indoors, do not expose to rain or excessive dust.
9. Be careful not to drop, shake or strike the charger or battery.
10. Disconnect from 240Volt supply before making or disconnecting connections to the
battery.
11. This charger is for charging 6, 12 or 24volt batteries only
12. This appliance is not for use with non-rechargeable batteries.
13. Never charge a frozen battery.
14. This charger is intended for use by responsible persons and should not be operated
by children or untrained persons without supervision.
15. Always check battery manufacturer’s specifications on charge rates and voltage prior
to charging.
△!
△
!WARNING

7
Technical Features:
Multi volt; 6, 12, or 24 Volt Battery Charger.
Built-in microchip charging control and monitoring system.
Zero-volt minimum start – can charge a completely flat battery.
Optimally designed charging cycle designed for Lead Acid / AGM, Gel, and Calcium, Starting and
Deep cycle batteries.
Comprehensive eight stage charging cycle including: Desulphation, soft start, bulk, absorption,
analysis, boost, float and maintenance stages.
Automatic adjustment of charging voltages according to environmental temperature.
Overcharge protection, protecting the battery from damage due to overcharging.
Reverse polarity, short circuit, overload and high temperature protection.
LED display simultaneously showing charging voltage, percentage of battery charge
Battery Testing function while charging (faulty batteries cause the Full Battery Bar display to flash).
Technical Specifications:
Model No:
SP61090
Output Current
10 Amp
Output Voltage
Selectable
6Volt / 12Volt / 24Volt
Input Voltage
175-255VAC / 50-60Hz
Battery Type Selectable
Gel / Calcium / Lead Acid - AGM
Charge stages
8 Stages
Desulphation
High Frequency Pulse
Soft Start Slowly start the charging process
Bulk Charge
Maximum Current until pre-set voltage reached
Absorption Constant voltage with automatic amperage control
Analysis
Analyse the battery condition
Boost Higher voltage charge at limited current
Float
Constant Voltage at required Current
Maintain Pulse to maintain maximum charge
6 Volt
12 Volt
24 Volt
Output Voltage (Bulk)
7.1V Gel / 7.8V Cal / 7.35V LA
& AGM
14.2V Gel / 15.6V Cal /
14.7V LA & AGM
28.4V Gel / 31.2V Cal /
29.4V LA & AGM
Output Voltage
(Absorption)
7.1V Gel / 7.8V Cal / 7.35V LA
& AGM
14.2V Gel / 15.6V Cal /
14.7V LA & AGM
28.4V Gel / 31.2V Cal /
29.4V LA & AGM
Output Voltage (Float)
6.65V Gel / 6.85V Cal / 6.85V
LA & AGM
13.3V Gel / 13.7V Cal /
13.7V LA & AGM
26.6V Gel / 27.4V Cal /
27.4V LA & AGM
Output Voltage
(Maintain)
6.65V Gel / 6.85V Cal / 6.85V
LA & AGM
13.3V Gel / 13.7V Cal /
13.7V LA & AGM
26.6V Gel / 27.4V Cal /
27.4V LA & AGM
Working Temperature
-15 °C to +40°C
Safety Protection
Short Circuit, Reverse Polarity, Zero-volt start & High Temperature
Dimensions
(L x W x H)
275 x 205 x 90

8
LIMITED WARRANTY
This Limited Warranty applies only to new products* distributed by SP Tools Pty Ltd (“SP Tools”). It is a condition of this Limited
Warranty Policy that the purchaser read the owner’s manual for the product and only use the product to the extent or for the
purposes stated therein. The purchaser must also ensure that all servicing requirements are completed as listed in the owner’s
manual (said servicing is at the owner’s expense). We recommend that all servicing is completed by an authorised service agent and
that records of said servicing are retained by the purchaser as proof in the event of a warranty claim.
Whilst the owner’s manual, packaging, and/or other documentation supplied with SP Tools’ products may provide details in respect
of a Limited Warranty, the terms set out herein supersede these matters, and this Limited Warranty applies in their place. This
warranty is no less advantageous than otherwise described in such other documentation.
SP Tools agrees, subject to the terms and conditions specified below, to repair or replace at SP Tools’ cost, the product purchased by
you when the product does not perform in accordance with its specifications during the limited warranty period, due to any fault in
manufacturing, materials and/or workmanship. SP Tools is not liable to repair or replace products that the purchaser uses in a
manner that is inconsistent with the owner’s manual or in the circumstances set out in paragraphs 1.1 – 1.7 below.
The benefits to the purchaser under this warranty are in addition to other rights and remedies under the Competition and Consumer
Act 2010 (Cth). The limited warranty period, within which a defect in the product must appear, commences from the date of
purchase and ceases on expiration of the specified term below.
THE LIMITED WARRANTY PERIOD
• SP Speciality Tools – 12 Months
THE PURCHASERS ATTENTION IS DRAWN TO THE FOLLOWING
To the extent permitted by law and subject to this Limited Warranty, and as part of the terms of the sale of the equipment or part
thereof: SP Tools shall not be liable for any form of loss, damage, cost, injury or harm of any kind (whether direct, indirect, special
or consequential) howsoever arising from the use or supply of the equipment to the purchaser.
EXCLUSIONS TO LIMITED WARRANTY POILICY
This Limited Warranty will not apply where the equipment or any part thereof:
1.1 Fails due to an accident (including liquid spillage), abuse, misuse, neglect or normal wear and tear;
1.2 Has been used in a manner other than for which it was originally designed;
1.3 Has been tampered with or is otherwise than as supplied by SP Tools;
1.4 Where any damage, malfunction or other failure of the equipment or any part thereof resulted directly or indirectly from
unauthorized persons, adjusting or failing to adjust any part requiring normal maintenance and service (examples include
adjustment of tappets, air filter maintenance, lubrication and tightening of screws nuts and bolts);
1.5 Malfunctions due to the use of defective or incompatible accessories;
1.6 Is damaged by lightning or thunderstorm activity; or
1.7 Has been transported to a country where no authorised Service Agents exist.
CLAIMING WARRANTY
This Limited Warranty may be claimed on in the following manner:
2.1 In order to make a claim under this Limited Warranty, the purchaser must deliver the equipment or any part thereof to an
SP Tools authorised repair agent and pay all costs of transportation and all costs incidental to making a claim under
this Limited Warranty. The purchaser must first contact SP Tools (contact details described above) and request the
delivery address of an SP Tools authorised repair agent.
2.2 The purchaser must deliver to the repair agent written reasons why the purchaser considers that the purchaser has a claim
under this Limited Warranty and must provide all necessary details, including:
• The place, date and from whom the unit or part was purchased.
• The unit or part involved, Model and Serial Number.
• The defect, malfunction or failure in respect of which the claim is being made.
• Proof of service of the unit or part (if applicable)
• Proof of purchase in respect of the unit or part.
2.3 If the Limited Warranty claim is valid, the repair agent will carry out repairs and return the product at no charge to the
purchaser. These repairs are limited to the Limited Warranty fault identified and as such will not include any other faults due to
misuse, abuse, failure to maintain, fair wear and tear or the replacement of serviceable items such as oil, spark plugs, air filters,
fuel etc.
Our goods come with guarantees that cannot be excluded under Consumer Law. You are entitled to a replacement or refund for a
major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Note: Units which are failing to perform in accordance with specifications due to non-warrantable causes will be subject to freight,
repair and or quote charge
