Sailor SP3911 User manual

SAILOR, THE GREAT EUROPEAN
SAILOR SP3911
14 HOUR
STANDARD CHARGER

SP3911

SP3911
Indicator
DIM Switch ON/OFF
Battery Holder
the 14 hour timer.
CHAR Switch starts
Front Charging
ON/OFF
Rear Charging
Front Charging
Indicator
the charger and the
Position
CHAR
28582A
ON / OFF
BATTERY CHARGER SP3911

SP3911

Page
Introduction 1
SP3911
Contents

1 SP3911
Introduction
This charger is constructed solely to charge 7.2V
Nickel Cadmium batteries made for the maritime
portable VHF/UHF radio manufactured by ECI.
The charger has two charging position. The front
position is designed for a portable radio mounted
with a battery.
The rear charging position is not normally
connected, and is employed as a storage for a
spare battery or an emergency battery.
1. Connect the charger to a 230V AC source.
2. Switch on the charger by pressing down on the
ON/OFF switch thereby conducting voltage to
the automatic charger.
3. Insert the battery-mounted radio in the front
charging position. The radio must be switched
OFF during the charging time.
4. Press the CHAR switch downwards to start the
charger and the 14 hour timer.

SP3911 2
5. The charger automatically checks the battery
type, which can be either 700mAh or 1200mAh.
6. If the charger accepts the battery, the indicator
for the charging position in use will light up a
constant red.
7. After 14 hours, the battery is fully charged and
the indicator will flash green. By means of a
weak current, the charger subsequently main-
tains the battery’s charge for as long as it re-
mains in the charger. The battery is therefore
always ready for use.
8. The charging process can always be interrupted
by switching off the charger at the ON/OFF
switch or by removing the radio. In such case, it
is necessary to press the CHAR switch in order
to start a new 14-hour charging period.
9. If left in the charger, the battery will not be
damaged as the charger maintains the battery
by means of a trickle charge when the 14 hours
have expired.

3 SP3911
10. By pressing the DIM switch, the charging indica-
tor can be switched on and off alternately. This
has no effect on the charging process, and is
intended solely for use on board vessels where
required.
If the charging indicator does not light up when
a radio is inserted into the charging position and
the CHAR switch is activated, this might be
because the charging indicator has been
switched off by the DIM switch.

Please note
Any responsibility or liability for loss or damage in connection
with the use of this product and the accompanying documen-
tation is disclaimed. The information in this manual is
furnished for informational use only, is subject to change
without notice, may contain errors or inaccuracies, and
represents no commitment whatsoever. This agreement is
governed by the laws of Denmark.
Doc. No.: B3911GB Issue: C/9940
