Space-Ray Eclipse User manual

®
INSTALLATION MANUAL
Electric zero glow ceramic infrared Heater
Model Eclipse
IPX4
Please note:
Eclipse heaters are predominantly designed and manufactured for indoor use
and should be used in conjuncon with energy saving controls to comply with
EU2015/118.
These heaters may be used outdoors, however it is recommended they are
used in sheltered/semi-enclosed areas.

Content
1. Important 3
2. Introducon 4
3. Specicaon 4
3.1 Dimensions 4
4. Installaon 4
4.1 Mounng 4
4.1.1 Wall mounng 4
4.1.2 Wall mounng bracket dimensions 5
4.2 Chain suspension 5
5. Maintenance 5
5.1 Replacing ceramic emier 5
5.2 Heater failure 7
5.3 Recycling informaon 7
6. Declaraon of conformity 7

1. Important
When using Spaceray electric heaters, basic
precauons should always be followed to reduce the risk
of re, electric shock, and injury to persons, including the
following:
Read all instrucons before using this heater.
• Before using this appliance:
- Check that the voltage indicated on the type
plate corresponds to the mains supply voltage.
- Ensure that the heater has been securely
fastened in its nal mounng posion.
• Do not locate the heater immediately below a
socket outlet.
• This appliance can be used by children aged from
8 years and aboveand persons with reduced
physical, sensory or mental capabilies or lack
of experience and knowledge if they have been
given supervision or instrucon concerning use
of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children of less than 3 years should be kept away
unless connually supervised.
• Children aged from 3 years and less than 8 years
shall only switch on/o the appliance provided
that it has been placed or installed in its intended
normal operang posion and they have been
given supervision or instrucon concerning use
of the appliance in a safe way and understand the
hazards involved. Children aged from 3 years and
less than 8 years shall not plug in, regulate and
clean the appliance or perform user maintenance.
• CAUTION Some parts of the product can become
very hot and cause burns. Parcular aenon has
been given where children and vulnerable people
are present.
• Disconnect pole switch from the hard wired circuit
during installaon, cleaning and/or replacing the
lamp emier and always ensure that the lamp
emier is cool.
• Do not use an extension cord with this product be-
cause the extension cord may overheat and cause
a risk of re.
• Keep the mains supply cord away from the body of
the heater which will get hot during use.
• Arrange the mains supply cord so it cannot be
tripped over or damaged.
• Do not cover or obstruct the heater while it is in
use.
• Do not insert any object through any slot or
opening in the heater.
• Do not use if a guard is not present.
• Do not install less than the minimum mounng
distance from the oor.
• WARNING: This heater should only be installed
indoors with a thermostat device to control the
room temperature and operated by users capable
of using the device. Do not use this heater in small
rooms when they are occupied by persons not
capable of leaving the room on their own, unless
constant supervision is provided.
• Do not touch the heater when it is turned on, as
the body gets hot.
• Do not use the heater in a bathroom, laundry
areas and similar locaons. Never locate the
heater where it may fall into a bathtub or other
water container.
• A heater has hot parts inside. Do not use it in
areas where petrol, paint, or ammable liquids are
used or stored.
• CAUTION: Do not direct a hose or spray water at
the heater or into any of its openings.
• WARNING: If the supply cord becomes damaged, it
must be replaced by the manufacturer, its service
agent or a similar qualied person in order to
avoid a hazard.
• WARNING: This appliance must be connected to a
supply that is earthed!
IMPORTANT:
SAVE THESE INSTRUCTIONS FOR FUTURE USE.
CAUTION!
CAUTION!
WARNING!
WARNING!

CAUTION!
WARNING!
IMPORTANT!
WARNING: RISK OF FIRE
Keep combusble material such as furniture,
papers, clothes and curtains 1.8m (6) from
the front of the heater and away from the
sides and rear.
If the heater is to be used outside, it is
recommend that a waterproof or indoor
socket outlet is used.


The Eclipse range of heaters contain long-life ceram-
ic emiers which are highly ecient and durable. The
Eclipse heaters are designed for indoor use and outdoor
(under cover use) only.
      

      

future reference.

3.1 Dimensions

All Eclipse models are ed with 3m of supply cable and
a 3-pin plug. For permenent connecon it is unnecessary
to open the terminal wiring enclosure, in order to carry
out installaon of this product.
CAUTION: Please observe the minimum safe distance
between the heater body and any inammable surfaces.
CAUTION: Do not mount the heater on plasc sots and
fascia boards and ensure the mounng surface will
suitably withstand the radiant heat from the heater
body.
CAUTION: All installaons must be in accordance with
the latest electrical safety regulaons. 

NOTE: When hard wiring, a large double pole switch with
a 3.0mm contact disconnecon should be ed.
NOTE: When installing the heater indoors it should be
connected to a suitable thermostat device.
NOTE: We recommend using a RCD where applicable.


The Eclipse heater should be wall mounted in a horizon-
tal manner only - see Fig. A.
• Do not posion the heater at an angle more than
70° and less than 45° from the mounng surface as
shown in Fig. A.
• Always allow the heater to cool before aempng
to reposion/move. Never aempt to move the
heater while it is switched on!
• Observe the minimum safe distance between the
heater body and inammable surfaces and objects
when mounng.
• Do not install the heater in a corner.
1. Securely fasten the Eclipse brackets to the mounng
surface using the xing holes in the brackets. See
Fig.s B, C and D for mounng hole centres of the
Model  Triple Quad
 kW 230V N & E 1Ph 50Hz
Power kW 1.5 2.25 3.0
Current A 6.5 9.8 13.0
 IPX4
Weight kg 5.2 7.1 8.9

 Use MCB type 3 or C
CAUTION!
CAUTION!
CAUTION!
NOTE:
NOTE:
NOTE:
CAUTION
Always isolate the heater from the mains supply when
mounng or adjusng the heater posion.
Fig. A


Triple
Quad
45OMax
Minimum clearance to

2m

Floor Level
Fig. A


brackets. Please refer to Table 1 for recommended
posioning of the heater.
2. Fix in the required angular posion by ghtening the
xing bolts on the brackets at the rear of the heater.
3. Arrange the mains supply cord so it cannot be
tripped over or damaged and ensure it is not rest-
ing on the heater body or mounng brackets. Also
ensure it is away from the front of the heater.




Triple
Quad
4.2 Chain suspension
Eclipse heaters can be chain hung from a ceiling.
• When ceiling hanging the Eclipse heater, ensure
the minimum distance from the ceiling is adhered
to as shown in Fig. E. and maintain the minimum
distance to the oor.
• Please refer to Table 1 for the recommended
posioning of the heater with regards to minimu
distances.
• Do not install the heater in a corner!
• Always allow the heater to cool before aempng
to reposion/move. Never aempt to move the
heater while it is switched on!
• Observe the minimum safe distance between the
heater body and inammable surfaces and objects
when mounng.
• Keep out of the reach of children.
1. Please refer to Table 1 for
recommended posioning
of the heater. When hanging
from a ceiling, two chains of
equal length and gauge are
required and should be used
with xings that are
adequate to hold the weight
of the heater. If in doubt
contact a professional for
advice!
2. Aach the heater assembly
to the chains via the hole in
the centre of the middle
bracket (remove the
L -shaped wall brackets) as
shown in Fig. E. and ensure
the heater faces directly
down when hanging.
3. Arrange the mains supply
cord so it cannot be tripped
over or damaged and ensure
it is not resng on the heater
body or mounng brackets.
Also ensure it is away from
the front of the heater.



5. Maintenance

1. Disconnect the mains electric power supply to the
heater and ensure the heater and ceramic emiers
are cool.
2. Remove the 4 × Phillips head screws from the
at end plate (opposite end to the permanently
connected mains cord), see Fig. F.
381mm 
4no Holes
Fig. B
531mm 
4no Holes
711mm 
4no Holes
Fig. C
Fig. D
Minimum clearance to ceiling or cover

Floor Level
2m

Fig. E
CAUTION
Disconnect the heater from the mains electric power supply
before any aempts are made to replace the ceramic
emier. Contact your distributor for the correct replacement
ceramic emier quong model type and rang from the
rang label.
It is important that you read through the ceramic emier
replacement procedure before commencing.


3. Slide the front trim piece out of the body nong
which channel it is contained within (for reng).
See Fig. G.
4. Slide the guard out of the body nong it is contained
within the same channel as the front trim piece.
See Fig. H.
5. If mulple ceramic emiers have to be replaced,
connue to slide the front trim pieces and guards
out of the body unl all ceramic emiers are
accessible nong the order in which the trims and
guards go. See Fig. J.
6. Locate the 2 × Phillips screws either side of the
ceramic emier and remove (ideally with a
magnec pped screwdriver which will also aid
reng) and take care to retain the spring/split
washers. See Fig. K.
7. Pull the reector holding the ceramic emier down
to expose the wiring (Fig. L). The ceramic emier
can be disconnected by rst pulling the sleeving
back to reveal the in-line connectors as shown in
Fig. M.

Fig. F
Fig. G
Fig. H
Fig. J
Fig. K
Fig. L
Fig. M


8. Carefully pull the in-line connectors apart to remove
the ceramic emier as shown in Fig. N. Note, when
reng, the connectors must be fully pushed
together and you should feel a dull click and the
sleeving should also be replaced back over the
connectors. Also take note of the emier wire
colours and match.
9. Working on a at surface, slide the ceramic emier
holding U-clip away from the ceramic emier raised
wiring boss as shown in Fig. P. Note. the sleeving
can be removed at this point before proceeding.
Remove the spring clip (note it’s orientaon as
shown in Fig Q) from the reector and li the
reector o the ceramic emier as shown in Fig. R.
10. Ret in reverse order and repeat for any other
ceramic emiers that need to be replaced.
5.2 Heater failure
In the event of heater failure, or for spare parts or
advice, please contact the manufacturer or your service
agent.
• Disconnect from the mains by removing the plug
from the main sockets before commencing any
maintenance procedure including cleaning.
• To ensure opmum heat eecveness, it is recom-
mended that that the guards are removed and the
reectors are wiped with a lint-free cloth should
the reectors show considerable signs of dust or
dirt.

The use of this symbol indicates
that this product may not be
treated as household waste. By
ensuring this product is disposed
of correctly, you will help prevent
potenal negave consequences
for the environment and human
health, which could otherwise be
caused by inappropriate waste
handling of this product.
For more detailed informaon about recycling of this
product, please contact your local council or your
household waste disposal service.

The manufacturer hereby conrms that the Eclipse
heaters comply with the harmonised standards and
spulaons quoted below:
EN 60335-2-30:2009+A11:12
EN 60335-1:2012
EN 62233:2008
LVD 2006/95/EC
EN 61000-3-2, EN 61000-3-3
EMC Direcve 2004/108/EC
WEEE & RoHS Direcves 2002/96/EC & 2002/95/EC
Fig. N
Fig. P
Fig. Q
Fig. R

FACTORIES: IPSWICH, ENGLAND - CHARLOTTE, N.C, U.S.A
Gas Fired Products (UK) Ltd
Chapel Lane
Claydon
Ipswich
Suolk, IP6 0JL
Tel: [phone]
Fax: [phone]
www.spaceray.co.uk
[e-mail]
®
Eclipse Manual December 2022
