Space-Ray RSTP15C User manual

Form 43206000
Sept 2011
INSTALLATION AND OPERATION INSTRUCTIONS
OWNER / INSTALLER: For yo r safety this man al m st be caref lly and thoro ghly read and
nderstood before installing, operating or servicing this heater.
RSTP SERIES
INFRARED RADIANT TUBE HEATER
Single Stage P ll Thro gh System (Negative Press re)
Models:
RSTP15C
RSTP17C
!
INSTALLER
:
This man al is the property of the owner. Please present this man al to the
owner when yo leave the job site.
▲WARNING: Improper installation, adj stment, alteration, service, or maintenance can
ca se property damage, inj ry or death. Read the installation, operation and maintenance
instr ctions thoro ghly before installing or servicing this eq ipment.
IF YOU SMELL GAS: FOR YOUR SAFETY
FOR YOUR SAFETYFOR YOUR SAFETY
FOR YOUR SAFETY
!
!!
!
DO NOT
DO NOTDO NOT
DO NOT try to light any appliance.
!
!!
!DO NOT
DO NOTDO NOT
DO NOT to ch any electrical switch; DO NOT
DO NOTDO NOT
DO NOT se any
telephone in yo r b ilding.
!
!!
!IMMEDIATELY
IMMEDIATELYIMMEDIATELY
IMMEDIATELY call yo r gas s pplier from a neighbor's
telephone. Follow the gas s pplier's instr ctions. If yo
cannot reach yo r gas s pplier, call the fire department.
DO NOT
DO NOT DO NOT
DO NOT store or se gasoline or other
store or se gasoline or other store or se gasoline or other
store or se gasoline or other
flammable vapors and liq ids in the vicinity of
flammable vapors and liq ids in the vicinity of flammable vapors and liq ids in the vicinity of
flammable vapors and liq ids in the vicinity of
this or any other appliance.
this or any other appliance.this or any other appliance.
this or any other appliance.
!IMPORTANT:
!IMPORTANT:!IMPORTANT:
!IMPORTANT: SAVE THIS MANUAL FOR FUTURE REFERENCE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.SAVE THIS MANUAL FOR FUTURE REFERENCE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
SPACE
SPACESPACE
SPACE-
--
-RAY
RAYRAY
RAY
Post Office Box 36485 (28236) • 305 Doggett Street (28203) • Charlotte, North Carolina
Phone [phone] • Fax [phone] • www.spaceray.com • email: [e-mail]

Form 43206000
Sept 2011 -1-
TABLE OF CONTENTS
SECTION DESCRIPTION PAGE
1.0) Safety ................................................................................................................................................... 2
2.0) Installer Responsibility ...................................................................................................................... 2
3.0) General Information........................................................................................................................... 2
4.0) Minim m Clearances to Comb stibles ........................................................................................... 4
5.0) Specifications...................................................................................................................................... 5
6.0) Packing List ......................................................................................................................................... 5
6.1) Accessory Packages .......................................................................................................................... 5
7.0) Dimensions ......................................................................................................................................... 6
8.0) Heater Assembly Overview ............................................................................................................... 7
9.0) Typical S spension Methods ............................................................................................................ 8
10.0) Heater Assembly .............................................................................................................................. 10
11.0) Gas Connections and Reg lations ................................................................................................. 13
12.0) Instr ctions for Press re Test Ga ge Connection ....................................................................... 15
13.0) Electrical Connections ..................................................................................................................... 16
14.0) Venting ............................................................................................................................................... 19
15.0) Air for Comb stion ........................................................................................................................... 23
15.1) Direct O tside Air for Comb stion ................................................................................................. 23
16.0) Lighting and Sh tdown Instr ctions .............................................................................................. 26
17.0) Seq ence of Operation .................................................................................................................... 26
18.0) Control Component Location .......................................................................................................... 27
19.0) Cleaning and Ann al Maintenance ............................................................................................... 28
20.0) Tro bleshooting G ide..................................................................................................................... 29
21.0) Replacing Parts ................................................................................................................................ 32
21.1) Removal of Spark Electrode and Flame Sensor.......................................................................... 32
21.2) Removing Main B rner and Gas Valve ......................................................................................... 33
21.3) Air Switch Press re Check .............................................................................................................. 33
21.4) Ignition System Checks ................................................................................................................... 34
21.5) Motor and Blower Wheel Check ..................................................................................................... 35
22.0) Installation Data ............................................................................................................................... 35
23.0) Replacement Parts G ide ............................................................................................................... 36
This heater complies with ANSI Z83.20 (c rrent standard) and CSA 2.34. Copies of the National F el Gas Code (ANSI
Z223.1-latest edition) are available from the CSA at 8501 East Pleasant Valley Road, Cleveland, Ohio 44131 or 55 Scarsdale
Road, Don Mills, Ontario M3B 2R3. All NFPA codes are available from the National Fire Protection Association, Batterymarch
Park, Q incy, Massach setts 02269.

Form 43206000
-2- Sept 2011
1.0) SAFETY
This heater is a self-contained infrared radiant t be heater. Safety information req ired d ring installation and
operation of this heater is provided in this man al and the labels on the prod ct. The installation, service and
maintenance of this heater m st be performed by a contractor q alified in the installation and service of gas
fired heating eq ipment.
All personnel in contact with the heater m st read and nderstand all safety information, instr ctions and labels
before operation. The following symbols will be sed in this man al to indicate important safety information.
Warning
WarningWarning
Warning
instr ctions m st be followed to prevent or avoid hazards which
may ca se serio s inj ry, property damage or death.
Ca tion
Ca tionCa tion
Ca tion
instr ctions m st be followed to prevent incorrect operation or
installation of
the heater which may ca se minor inj ry or property
damage.
2.0) INSTALLER RESPONSIBILITY
The installer is responsible for the following:
•
••
•The heater and venting, as well as electrical and gas s pplies m st be installed in accordance with these
installation instr ctions and any applicable codes and reg lations.
•
••
•Every heater shall be located with respect to b ilding constr ction and other eq ipment so as to permit
access to the heater.
•
••
•Each installer m st follow the clearances to comb stible materials for the heaters.
•
••
•Install the heater so that the s pports and hangers are correctly spaced in accordance with these
instr ctions. The heater m st be s pported by materials having a working load limit of at least 115lbs. If a
“trapeze” method is sed, the chain, and t rnb ckle m st have a working load limit of at least 230lbs and
the hooks m st have a working load limit of at least 115lbs. All hooks m st be crimped closed.
•
••
•S pply the owner with a copy of these Installation and Operation Instr ctions.
•
••
•Where nvented heaters are sed, gravity or mechanical means shall be provided to s pply and exha st at
least 4 CFM per 1,000 Bt /hr inp t of installed heaters.
•
••
•Never se the heater as a s pport for a ladder or other access eq ipment. Do not hang anything from the
heater.
•
••
•S pply all installation materials necessary that are not incl ded with the heater.
•
••
•Check the nameplate to make s re that the b rner is correct for the gas type in the b ilding and the
installation altit de.
3.0) GENERAL INFORMATION
This heater is a self-contained infrared radiant t be heater for se in locations where flammable gases or vapors
are not generally present (as defined by OSHA acceptable limits) and is intended for the heating of
nonresidential
nonresidentialnonresidential
nonresidential spaces.
For either indoor or o tdoor installa
For either indoor or o tdoor installaFor either indoor or o tdoor installa
For either indoor or o tdoor installation. Not for se in residential dwellings.
tion. Not for se in residential dwellings.tion. Not for se in residential dwellings.
tion. Not for se in residential dwellings.
INSTALLATION REQUIREMENTS
INSTALLATION REQUIREMENTSINSTALLATION REQUIREMENTS
INSTALLATION REQUIREMENTS
The installation m st conform to local b ilding codes or in the absence of local codes, with the National F el Gas
Code ANSI Z223.1/NFPA54 or the Nat ral Gas and Propane Installation Code CSA B149.1. Heaters shall be
installed by a licensed contractor or licensed installer. Clearances to comb stibles as o tlined in this man al
sho ld always be observed. In areas sed for storage of comb stible materials where they may be stacked
below the heater, NFPA54 req ires that the installer m st post signs that will “specify the maxim m permissible
stacking height to maintain the req ired clearances from the heater to comb stibles.”
Every heater shall be located with respect to b ilding constr ction and other eq ipment so as to permit access
to the heater. Each installer shall se q ality installation practices when locating the heater and m st give
consideration to clearances to comb stible materials, vehicles parked below, lights, overhead doors, storage
areas with stacked materials, sprinkler heads, gas and electrical lines and any other possible obstr ctions or
hazards. Consideration also m st be given to service accessibility.

Form 43206000
Sept 2011 -3-
The heater, when installed in aircraft hangars and p blic garages, m st be installed in accordance with
ANSI/NFPA 409-latest edition (Standard for Aircraft Hangars), ANSI/NFPA 88a-latest edition (Standard for
Parking Str ct res), and ANSI/NFPA 88b-latest edition (Standard for Repair Garages) with the following
clearances:
a. At least 10 feet above the pper s rfaces of wings or engine enclos res of the highest aircraft that may be
ho sed in the hangar and at least 8 feet above the floor in shops, offices, and other sections of hangars
comm nicating with aircraft storage or service areas.
b. At least 8 feet above the floor in p blic garages. ▲
▲▲
▲WARNING:
WARNING:WARNING:
WARNING: Minim m clearances marked on the heater
m st be maintained from vehicles parked below the heater.
(FOR CANADA ONLY)
a.
Installation of this appliance is to be in accordance with latest edition of C
SA B149.1 (Nat ral Gas and
Propane Installation Code).
b. For installation in p blic garages or aircraft hangars, the minim m clearances from the bottom of the
infrared heater to the pper s rface of the highest aircraft or vehicle shall be 50 percent greater than the
certified minim m clearance, b t the clearance shall not be less than 8 feet.
Altho gh these heaters may be sed in many applications other than space heating (e.g., process heating),
Space-Ray will not recognize the warranty for any se other than space heating.
This heater is for Indoor or O tdoor Installation and can be sed in either Vented or Unvented mode. The term
Unvented act ally means Indirect Vented. While the prod cts of comb stion are expelled into the b ilding,
national codes req ire ventilation in the b ilding to dil te these prod cts of comb stion. This ventilation may be
provided by gravity or mechanical means.
This heater is not an explosion proof heater.
This heater is not an explosion proof heater.This heater is not an explosion proof heater.
This heater is not an explosion proof heater. Where the possibility of expos re to volatile and low flash point
materials exists, it co ld res lt in property damage or death. This heater m st not be installed in a spray booth
where the heater can operate d ring the spraying process. Cons lt yo r local fire marshal or ins rance company.
High Altit de:
High Altit de:High Altit de:
High Altit de:
Appliances are s pplied as standard for altit des of O to 2,000 feet (0-610 m). High-altit de ratings are obtained
by a change in the orifice size. When ordered for high altit de installations, b rners are s pplied by the factory
ready for high altit de installation. Check the nameplate for altit de before proceeding with the installation. In
Canada the adj stment for altit de is made in accordance with Standard CGA 2.17, Gas-Fired Appliances for Use
at High Altit des.

Form 43206000
-4- Sept 2011
4.0) MINIMUM CLEARANCES TO COMBUSTIBLES
Failure to do so may result in death, serious injury or
property damage.
Combustible material must be located outside the
clearance dimensions listed.
Minim m clearances to comb stibles shall be meas red from the o ter s rfaces as shown in the following
diagram:
file: RSTP17C Clearances
60
(152 cm)
*14
(36 cm)
60
(152 cm)
84
(213 cm)
Horizontal
60
(152 cm)
60
(152 cm)
24
(61 cm)
60
(152 cm)
**90 Deg Angle (Max.)
24
(61 cm)
84
(213 cm)
60
(152 cm)
36
(91 cm)
**60 Deg Angle
24
(61 cm)
84
(213 cm)
60
(152 cm)
36
(91 cm)
30 Deg Angle
60
(152 cm) 60
(152 cm)
* Clearance is 30 when installed
UNVENTED in Canada.
** Maximum mounting angle is 45 deg
when used outdoors.
▲WARNING:
▲WARNING:▲WARNING:
▲WARNING: Certain materials or objects, when stored nder the heater, will be s bjected to radiant heat and
Certain materials or objects, when stored nder the heater, will be s bjected to radiant heat and Certain materials or objects, when stored nder the heater, will be s bjected to radiant heat and
Certain materials or objects, when stored nder the heater, will be s bjected to radiant heat and
co ld be serio sly damaged.
co ld be serio sly damaged.co ld be serio sly damaged.
co ld be serio sly damaged. Observe the Minim m Clearances to Comb stibles listed in the man al and on the
Observe the Minim m Clearances to Comb stibles listed in the man al and on the Observe the Minim m Clearances to Comb stibles listed in the man al and on the
Observe the Minim m Clearances to Comb stibles listed in the man al and on the
heater at all times.
heater at all times.heater at all times.
heater at all times.
NOTE:
NOTE:NOTE:
NOTE:
1.
1. 1.
1. The clearan
The clearanThe clearan
The clearances specified above m st be maintained to comb stibles and other materials that may be
ces specified above m st be maintained to comb stibles and other materials that may be ces specified above m st be maintained to comb stibles and other materials that may be
ces specified above m st be maintained to comb stibles and other materials that may be
damaged by temperat res 90ºF above ambient temperat re.
damaged by temperat res 90ºF above ambient temperat re.damaged by temperat res 90ºF above ambient temperat re.
damaged by temperat res 90ºF above ambient temperat re. Clearances to comb stibles are posted on the
Clearances to comb stibles are posted on the Clearances to comb stibles are posted on the
Clearances to comb stibles are posted on the
control box.
control box.control box.
control box. In areas sed for storage of comb stible materials wher
In areas sed for storage of comb stible materials wherIn areas sed for storage of comb stible materials wher
In areas sed for storage of comb stible materials where they may be stacked below the heater,
e they may be stacked below the heater, e they may be stacked below the heater,
e they may be stacked below the heater,
NFPA54 req ires that the installer m st post signs that will “specify the maxim m permissible stacking height
NFPA54 req ires that the installer m st post signs that will “specify the maxim m permissible stacking height NFPA54 req ires that the installer m st post signs that will “specify the maxim m permissible stacking height
NFPA54 req ires that the installer m st post signs that will “specify the maxim m permissible stacking height
to maintain the req ired clearances from the heater to comb stibles.”
to maintain the req ired clearances from the heater to comb stibles.”to maintain the req ired clearances from the heater to comb stibles.”
to maintain the req ired clearances from the heater to comb stibles.” Space
SpaceSpace
Space-
--
-Ray recommends posting these
Ray recommends posting these Ray recommends posting these
Ray recommends posting these
s
ss
signs adjacent to the heater thermostat or other s itable location that will provide enhanced visibility.
igns adjacent to the heater thermostat or other s itable location that will provide enhanced visibility.igns adjacent to the heater thermostat or other s itable location that will provide enhanced visibility.
igns adjacent to the heater thermostat or other s itable location that will provide enhanced visibility.
2. The stated clearance to comb stibles represents a s rface temperat re of 90
2. The stated clearance to comb stibles represents a s rface temperat re of 902. The stated clearance to comb stibles represents a s rface temperat re of 90
2. The stated clearance to comb stibles represents a s rface temperat re of 90 ºF
ºFºF
ºF (32
(32(32
(32 ºC) above room
ºC) above room ºC) above room
ºC) above room
temperat re. B ilding materials with a low heat to
temperat re. B ilding materials with a low heat totemperat re. B ilding materials with a low heat to
temperat re. B ilding materials with a low heat tolerance (s ch as plastics, vinyle siding, canvas, tri
lerance (s ch as plastics, vinyle siding, canvas, trilerance (s ch as plastics, vinyle siding, canvas, tri
lerance (s ch as plastics, vinyle siding, canvas, tri-
--
-ply, etc.)
ply, etc.) ply, etc.)
ply, etc.)
may be s bject to degradation at lower temperat res. It is the installer’s responsibility to ass re that adjacent
may be s bject to degradation at lower temperat res. It is the installer’s responsibility to ass re that adjacent may be s bject to degradation at lower temperat res. It is the installer’s responsibility to ass re that adjacent
may be s bject to degradation at lower temperat res. It is the installer’s responsibility to ass re that adjacent
materials are protected from degradation.
materials are protected from degradation.materials are protected from degradation.
materials are protected from degradation.

Form 43206000
Sept 2011 -5-
5.0) SPECIFICATIONS
Model No.
Model No.Model No.
Model No.
Bt /hr
Bt /hrBt /hr
Bt /hr
In
InIn
Inp t
p tp t
p t
Orifice Size
Orifice SizeOrifice Size
Orifice Size Weight (lbs.)
Weight (lbs.)Weight (lbs.)
Weight (lbs.)
Minim m *
Minim m *Minim m *
Minim m *
Mo nting Height
Mo nting HeightMo nting Height
Mo nting Height
Nat ral Gas
Nat ral GasNat ral Gas
Nat ral Gas Propane Gas
Propane GasPropane Gas
Propane Gas Shipping
ShippingShipping
Shipping Unit
UnitUnit
Unit
@
@@
@
Horizontal
HorizontalHorizontal
Horizontal
@
@@
@
45º Angle
45º Angle45º Angle
45º Angle
RSTP15C
-
N5D
150
,000
#1 (0.220)
n/a
256
216
1
4
ft.
12
ft.
RSTP17C
-
N5D
175
,000
“D” (0.246)
n/a
256
216
16
ft.
1
4
ft.
RSTP17C
-
L5D
175
,000
n/a
#26 (0.147)
256
216
1
6
ft.
1
4
ft.
* MOUNT HEATERS AS HIGH AS POSSIBLE. Minim ms are shown as a g ideline for h man comfort and niform
energy distrib tion for complete b ilding heating applications. Cons lt yo r Space-Ray representative for the
partic lars of yo r installation req irements.
Type
TypeType
Type
Gas
GasGas
Gas
Gas Pipe
Gas PipeGas Pipe
Gas Pipe
Connection
Connection Connection
Connection
T be
T beT be
T be
Diameter
DiameterDiameter
Diameter
Fl e
Fl eFl e
Fl e
Connection
ConnectionConnection
Connection
Fresh Air
Fresh Air Fresh Air
Fresh Air
Connection
ConnectionConnection
Connection
Electrical
ElectricalElectrical
Electrical
S pply
S pplyS pply
S pply
C rrent
C rrentC rrent
C rrent
Rating
RatingRating
Rating
Nat ral
or Propane
½” MPT
(Male) 4” 6” Ro nd 6” Ro nd
120 Volt,
60Hz,
1 Phase 2.6 Amp
F se
F seF se
F se
R
RR
R
ating:
ating:ating:
ating:
Ignition System (direct spark):
Ignition System (direct spark):Ignition System (direct spark):
Ignition System (direct spark):
Spark Mod le: 3 Amp 250V (for 24V Circ it) 30 second pre-p rge period
6.0) PACKING LIST
A.
A.A.
A. RSTP15C & RSTP17C
RSTP15C & RSTP17C RSTP15C & RSTP17C
RSTP15C & RSTP17C Package
PackagePackage
Package
Part Description
Part DescriptionPart Description
Part Description
QTY
QTYQTY
QTY
Heater
Assembly
................................
................................
................................
................................
.......
1
O tlet Fl e
Collar (#
42
377000
)
................................
................................
................................
............
1
Note, Lit. & Parts in Cabi
net
(#42
799000
)
................................
................................
.........................
1
Gas connector
,
5/8” OD x 36” (#30302360)
................................
................................
.....................
1
Installation & Operation Instr ctions
(#4
3206000
)
................................
................................
..........
1
HEATER ASSEMBLY
HEATER ASSEMBLYHEATER ASSEMBLY
HEATER ASSEMBLY PACKAGE NUMB
PACKAGE NUMBPACKAGE NUMB
PACKAGE NUMBERS
ERSERS
ERS
NATURAL GAS
NATURAL GASNATURAL GAS
NATURAL GAS PROPANE GAS
PROPANE GASPROPANE GAS
PROPANE GAS
MODEL NO.
MODEL NO. MODEL NO.
MODEL NO. PART NO.
PART NO.PART NO.
PART NO. MODEL NO.
MODEL NO. MODEL NO.
MODEL NO. PART NO.
PART NO.PART NO.
PART NO.
RSTP15C-N5D #42363011 RSTP17C-L5D #42363020
RSTP17C-N5D #42363010
6.1) ACCESSORY PACKAGES
A.
A.A.
A.
Indoor Unvented Kit, Part #42406000
Indoor Unvented Kit, Part #42406000Indoor Unvented Kit, Part #42406000
Indoor Unvented Kit, Part #42406000
Contains:
Exha st Hood, #42401000……QTY–1
#10-24 x 3/8 Screws, #02168010……QTY–2
Form, #42407000……QTY–1
Exha st Hood
Exha st HoodExha st Hood
Exha st Hood
B.
B.B.
B.
O tdoor Kit, Part #42411000
O tdoor Kit, Part #42411000O tdoor Kit, Part #42411000
O tdoor Kit, Part #42411000
Contains:
Exha st Hood, #42401000……QTY–1
Inlet Air Hood, #42408000……QTY–1
Foam Strip, #42001040……QTY–1
#10-24 x 3/8 Screws, #02168010……QTY–4
Form, #42412000……QTY–1
Inlet Air Hood
Inlet Air HoodInlet Air Hood
Inlet Air Hood
C.
C.C.
C. “L” Bracket Kit
“L” Bracket Kit“L” Bracket Kit
“L” Bracket Kit for 90
for 90for 90
for 90
°
°°
°
mo nting
mo ntingmo nting
mo nting, Part #42929000
, Part #42929000, Part #42929000
, Part #42929000
Contains:
“L” Bracket, #42400000……QTY–4
“L” Bracket
“L” Bracket“L” Bracket
“L” Bracket

Form 43206000
-6- Sept 2011
7.0) DIMENSIONS
Top View Bottom View 18
161-5/16 exhaust outlet
perforated panel
tube exchanger
Side View
36 109-1/2 15-13/16
suspension bracket
suspension bracket
suspension bracket
32
(outside brackets)
9-1/2
End View
rivets

Form 43206000
Sept 2011 -7-
8.0) HEATER ASSEMBLY OVERVIEW
109-1/2
suspension chain and
turnbuckle rated @230lbs
S hooks rated @ 115 lbs
long axis of heater
must be level
min.
36
109-1/2
suspension chain with
S hooks rated @ 115 lbs 32
Typically, 2/0 chain, 3/8
eye&eye turnbuckle and #80
S hooks meet the capacity
requirements.

Form 43206000
-8- Sept 2011
9.0) TYPICAL SUSPENSION METHODS
All materials used to suspend the heater must have a minimum working load
of 115 lbs. All S Hooks must be crimped closed.
If a Trapeze method of hanging is used, the chain and turnbuckle used to
suspend the heater must have a minimum working load of 230 lbs. S hooks
must have a minimum working load of 120 lbs.
Never use the heater to support a ladder or other access equipment.
Failure to do so may result in death, serious injury or property damage.
SUSPENSION HAZARD
Vario s means of s spending the heater can be sed. The following sho ld be observed:
1. Use only noncomb stible materials for s spending hangers and brackets.
2. Heaters m st not be s pported by gas or electric s pply lines and m st be s spended from a permanent
str ct re with adeq ate load capacity.
3. Heaters s bject to vibration m st be provided with vibration isolating hangers.
4. A minim m No. 2 chain with a working load limit of 115 lbs. is req ired when sing fo r (4) separate chains.
If a “trapeze” method of hanging is desired, yo m st se a chain with a load limit of at least 230 lbs, a
t rnb ckle (if necessary) with a load limit of at least 230 lbs, and “S” hooks with a load limit of at least 115
lbs. Typically, 2/0 chain and 3/8” eye & eye t rnb ckle have a minim m working load of 230 lbs; #80 “S”
hooks have a minim m working load of 115 lbs.
5. T rnb ckles can be sed with chains to allow leveling of the heater. All “S” hooks and eye bolts m st be
man ally crimped closed by the installer.
6. When sing rigid means for heater s spension (rod, flat bar, etc.) provide s fficient lengths or swing joints to
compensate for expansion. See Fig res b and c.
7. The heater can be mo nted horizontally or at angles of 30º, 60º, or 90º indoors. The maxim m mo nting
angle is 45º when installed o tdoors. The long axis of the heater sho ld be level whether i
The long axis of the heater sho ld be level whether iThe long axis of the heater sho ld be level whether i
The long axis of the heater sho ld be level whether it
tt
t i
ii
is
ss
s mo nted
mo nted mo nted
mo nted
horizontally or angled.
horizontally or angled.horizontally or angled.
horizontally or angled.
8. If the heater is to be mo nted horizontally or at an angle p to 60º, se the hanging brackets installed on
the heater. See Fig re 1 on Page 9.
9. If the heater is to be mo nted at a 90º angle, remove the existing hanging brackets from each end of the
heater and replace with “L” shaped brackets. See Fig re 2 on Page 9. (Note:
Note:Note:
Note: “L” shaped brackets are
s pplied as an accessory item. Order Kit No. 42929000.)
10. IMPORTANT:
IMPORTANT:IMPORTANT:
IMPORTANT: When the heater is angle mo nted, the exha st side sho ld be p.
If a “trapeze” method is sed for t be s pport/hanger brackets (shown below), the minim m chain length for the
two connecting chains is 36” to minimize any vibration that might be generated by the draft ind cer assembly. If
these chains m st be less than 36”, then do not se the trapeze method and, instead, se individ al chains on
each t be s pport/hanger bracket.

Form 43206000
Sept 2011 -9-
d.
Eyebolt
Turnbuckle*
Minimum
No. 2 Chain*
Eyebolt
c.
Threaded
Rod
Turnbuckle
Eyebolt
b.
3/16 x 1 wide
Flat Bar
Minimum
No. 2 Chain*
a.
S-Hook*
(typical)
Hanger Bracket
* Minimum 2/0 chain, 3/8 eye & eye turnbuckle and #80 S hook should be used if a trapeze suspension method is desired.
Bracket
Lockwasher
Flat Washer
Cap Screw
Bracket
(L shaped)
Lockwasher
Flat Washer
Cap Screw
36(91cm)Minimum
36(91cm)Minimum
Figure 1 Figure 2

Form 43206000
-10- Sept 2011
10.0) HEATER ASSEMBLY
Sheet metal parts, particularly reflectors and vent have sharp
edges. Always use gloves when handling.
Failure to do so may result in death, serious injury or property
damage.
CUT HAZARD
The heater is completely factory assembled. The gas manifold t bing req ires field assembly; the recommended
proced re is as follows:
1. Add the manifold t be and fittings. The req ired components are packaged inside the control box.
a. Remove the access panel. Apply pipe joint compo nd to the 5/8” t be x 1/2” Male NPT compression
nion and screw it into the valve. The pipe joint compo nd sho ld be resistant to the action of liq efied
petrole m gases.
b. Assemble the 5/8” t be x 1/2” Female NPT compression nion to the opposite end of the manifold t be,
then slide the manifold t be thro gh the hole on control box.
c. Connect the manifold t be to the valve at the compression fitting. When connecting, se a wrench to hold
the compression nion on the valve.
d. Leak check the gas line p to the gas valve sing soap sol tion method at a press re of 14” w.c. Replace
the access panel.
5/8 Tube x 1/2 Male NPT
Compression Fitting Manifold Tube 5/8 Tube x 1/2 Female NPT Compression Fitting
Note: Components packaged in control box.
ab
c
Pipe Joint
Hold with
Wrench
Tighten Compression
Fittings

Form 43206000
Sept 2011 -11-
2. Install the s spension chains (according to Section 7.0) sing proper s spension method (see Section 9.0).
chains for suspension
109-1/2
Hooks rated
@ 115lbs min.
Turnbuckle rated
@ 230lbs min.
Chain rated
@ 230lbs min.
109-1/2
Suspension
Chain
32
32
Chain rated
@ 115lbs min.
Hooks rated
@ 115lbs min.
Trapeze Method
Trapeze MethodTrapeze Method
Trapeze Method Individ al S spension Method
Individ al S spension MethodIndivid al S spension Method
Individ al S spension Method
3. Lift the heater and s spend it into place. When lifting, ca tion sho ld be sed to avoid damaging the
assembly. Make s re that the long axis of heater is level.
Level indicator
The long axis of heater
Side View
4. If the heater is to be sed Indoors and Vented
Indoors and VentedIndoors and Vented
Indoors and Vented to the o tside, install the fl e collar s pplied with the heater
by placing the collar directly over the gasket. Sec re the collar flange with clamps. See Fig re 4 on next
page.
5. Attach a 6” diameter fl e pipe to the fl e collar. Place an approved vent cap to the o tside end of the fl e
pipe. See Section 14.0) for fl e vent req irements.
6. If the heater is to be sed Indo
IndoIndo
Indoors and Unvented
ors and Unventedors and Unvented
ors and Unvented, order the Indoor Unvented Kit (Part #42406000). Remove
the clamps and install the Exha st Hood directly over the gasket. See Fig re 5 on next page.
7. If the heater is to be sed O tdoors
O tdoorsO tdoors
O tdoors, order the O tdoor Kit (Part #42411000). Install the Exha st Hood as
instr cted above in #4. Remove the solid cover panel from the side and install the Inlet Air Hood. Remove
the perforated cover panel from the top and replace it with the solid cover panel. See Fig re 5 on next page.
After completing the assembly, silicone sealant sho ld be tilized to seal the access panel openings. If the
installation site is s bject to excessive wind conditions, it might be necessary to tilize pop rivets to sec re
the reflectors to the heater body.

Form 43206000
-12- Sept 2011
NOTE:
NOTE:NOTE:
NOTE: EXHAUST HOODS AND
EXHAUST HOODS ANDEXHAUST HOODS AND
EXHAUST HOODS AND INLET AIR HOODS ARE SUPPLIED AS ACCESSORY ITEMS. REFER TO THE PART
INLET AIR HOODS ARE SUPPLIED AS ACCESSORY ITEMS. REFER TO THE PART INLET AIR HOODS ARE SUPPLIED AS ACCESSORY ITEMS. REFER TO THE PART
INLET AIR HOODS ARE SUPPLIED AS ACCESSORY ITEMS. REFER TO THE PART
NUMBERS BELOW TO ORDER THE KIT YOUR APPLICATION MAY REQUIRE.
NUMBERS BELOW TO ORDER THE KIT YOUR APPLICATION MAY REQUIRE.NUMBERS BELOW TO ORDER THE KIT YOUR APPLICATION MAY REQUIRE.
NUMBERS BELOW TO ORDER THE KIT YOUR APPLICATION MAY REQUIRE.
P
PP
PART
ARTART
ART N
NN
NO
OO
O.
..
. DESCRIPTION
DESCRIPTIONDESCRIPTION
DESCRIPTION
42406000 Indoor Unvented Kit (incl des Exha st Hood)
42411000 O tdoor Kit (incl des Exha st Hood and Inlet Air Hood)
Flue Collar
Clamp
Gasket
Perforated
Cover Panel
as Fresh Air Inlet
(DO NOT obstruct
opening) Solid Cover
Panel
Access Panel
Burner
Sight Glass
Figure 4 Indoor Installation Vented
Exhaust
Hood
(Unvented, Indoor/Outdoor
installation)
Figure 5
Solid Cover
Panel
Inlet Air Hood
(Outdoor Installation Only)
Note: When the heater is angle mo nted, the exha ster side sho ld be p.
Note: When the heater is angle mo nted, the exha ster side sho ld be p.Note: When the heater is angle mo nted, the exha ster side sho ld be p.
Note: When the heater is angle mo nted, the exha ster side sho ld be p.

Form 43206000
Sept 2011 -13-
11.0) GAS CONNECTIONS AND REGULATIONS
Tighten flexible gas hose and components securely.
Flexible metal gas hoses must be installed without any twists or
kinks in them. The hose will move during operation of the heater
and it can crack if it is twisted.
Failure to do so may result in death, serious injury or property
damage.
IMPORTANT BEFORE CONNECTING THE GAS TO THE HEATER
IMPORTANT BEFORE CONNECTING THE GAS TO THE HEATERIMPORTANT BEFORE CONNECTING THE GAS TO THE HEATER
IMPORTANT BEFORE CONNECTING THE GAS TO THE HEATER
1. Connect to the s pply tank or manifold in accordance with the latest edition of National F el Gas Code (ANSI
Z223.1), and local b ilding codes. A thorities having j risdiction sho ld be cons lted before the installation
is made. (In Canada, refer to the latest edition of CSA B149.1, Nat ral Gas and Propane Installation Code.)
2. Check that the gas f el on the b rner rating plate matches the f el for the application.
3. Check that the gas s pply piping has the capacity for the total gas cons mption of the heaters and any other
eq ipment connected to the line.
4. Check that the calc lated s pply press re with all gas appliances and heaters operating will not drop below
the minim m s pply press re req ired for these heaters. Check inlet s pply press res on Section 12.0).
5. All gas s pply lines m st be located in accordance with the req ired clearances to comb stibles from the
heater as listed on the clearances label of the heater and Section 4.0) of this man al.
6. Pipe joint compo nds m st be resistant to the action of liq efied petrole m gases.
7. Where local codes do not prohibit, a CSA or U.L. approved flexible connector s pplied with this heater is
req ired for connections between the rigid piping and the heater. A nion sho ld be installed before the
control box inlet. An approved sh t off valve sho ld be installed within 6 feet of the nion.
8. The gas pipe, flexible hose and connections m st be self s pporting. The gas pipe work m st not bear any of
the weight of the heater or any other s spended assembly.
9. This appliance is eq ipped with a step-opening, combination gas valve. The maxim m s pply press re to the
The maxim m s pply press re to the The maxim m s pply press re to the
The maxim m s pply press re to the
appliance is 14” W.C. or 1/2 P.S.I.
appliance is 14” W.C. or 1/2 P.S.I.appliance is 14” W.C. or 1/2 P.S.I.
appliance is 14” W.C. or 1/2 P.S.I. If the line press re is more than the maxim m s pply press re, then a
second stage reg lator which corresponds to the s pply press re m st be sed.
10. After all gas connections have been made, make s re the heater and all gas o tlets are t rned off before
the main gas s pply is t rned on slowly. T rn the gas s pply on and check for leaks. To check for leaks,
check by one of the methods listed in Appendix D of the National F el Gas Code.
11. All field installed gas connections MUST be checked for leakage along the gas line p to the gas valve.
12. If a 2nd stage reg lator is sed, the ball valve down stream in the s pply line m st be closed when p rging
the gas lines to prevent gas seeping thro gh it. If initial gas press re is higher than 14” w.c. the red ndant
combination gas valve is designed to lock o t. Press re b ild- p in the s pply lines prior to the heater m st
be released before proper heater operation.
DO
DO DO
DO not
notnot
not se an open flame of any kind to test for leaks.
se an open flame of any kind to test for leaks.se an open flame of any kind to test for leaks.
se an open flame of any kind to test for leaks.

Form 43206000
-14- Sept 2011
KEY DIMENSIONS AND COMPONENTS OF THE GAS CONNECTIONS
END VIEW
Gas Pressure
= 2 PSIG
Gas Supply
Piping
Sediment Trap
(Drip Leg)
*Manual Gas
Shut Off Valve
*Second Stage Regulator with
Vent Leak Limiter to reduce the
Supply Pressure below 14 W.C.
* Available as Accessories
14 to 17
(36 to 43cm)
2 (5cm) Max.
Displacement
Approved
Flexible Connector
Adaptor 1/2 NPT female
Adaptor 1/2 NPT male
Alternate Supply
Locations
SIDE VIEW
Control Box
END VIEW
INCORRECT POSITIONS
WRONG WRONG WRONG
WRONG
US ONLY:
US ONLY:US ONLY:
US ONLY: CONNECTOR MUST BE INSTALLED IN “
CONNECTOR MUST BE INSTALLED IN “CONNECTOR MUST BE INSTALLED IN “
CONNECTOR MUST BE INSTALLED IN “⊃
⊃⊃
⊃
” CONFIGURATION.
” CONFIGURATION. ” CONFIGURATION.
” CONFIGURATION.
USE ONLY THE 36” LONG CONNECTOR THAT WAS FURNISHED WITH
USE ONLY THE 36” LONG CONNECTOR THAT WAS FURNISHED WITH USE ONLY THE 36” LONG CONNECTOR THAT WAS FURNISHED WITH
USE ONLY THE 36” LONG CONNECTOR THAT WAS FURNISHED WITH
THIS HEATER.
THIS HEATER.THIS HEATER.
THIS HEATER.
US ONLY: A gas connector certified for se on a t b lar type
A gas connector certified for se on a t b lar typeA gas connector certified for se on a t b lar type
A gas connector certified for se on a t b lar type infrared heater per the standard for Connectors
infrared heater per the standard for Connectors infrared heater per the standard for Connectors
infrared heater per the standard for Connectors
for Gas Appliances, ANSI Z21.24/CSA 6.10 is s pplied for installation in US only. The gas connector is 36” long
for Gas Appliances, ANSI Z21.24/CSA 6.10 is s pplied for installation in US only. The gas connector is 36” long for Gas Appliances, ANSI Z21.24/CSA 6.10 is s pplied for installation in US only. The gas connector is 36” long
for Gas Appliances, ANSI Z21.24/CSA 6.10 is s pplied for installation in US only. The gas connector is 36” long
and
and and
and 1
11
1/
//
/2
22
2” nominal ID, and m st be installed as shown above, in
” nominal ID, and m st be installed as shown above, in” nominal ID, and m st be installed as shown above, in
” nominal ID, and m st be installed as shown above, in one plane, and witho t sharp bend
one plane, and witho t sharp bendone plane, and witho t sharp bend
one plane, and witho t sharp bends, kinks or
s, kinks or s, kinks or
s, kinks or
twists.
twists.twists.
twists.
CANADA ONLY: A Type I hose connector sho ld be sed that is certified as being in compliance with the
A Type I hose connector sho ld be sed that is certified as being in compliance with the A Type I hose connector sho ld be sed that is certified as being in compliance with the
A Type I hose connector sho ld be sed that is certified as being in compliance with the
Standard for Elastomeric Composite Hose and Hose Co plings for Cond cting Propane and Nat ral Gas
Standard for Elastomeric Composite Hose and Hose Co plings for Cond cting Propane and Nat ral Gas Standard for Elastomeric Composite Hose and Hose Co plings for Cond cting Propane and Nat ral Gas
Standard for Elastomeric Composite Hose and Hose Co plings for Cond cting Propane and Nat ral Gas
(CAN/CGA 8.1) and is of length of
(CAN/CGA 8.1) and is of length of (CAN/CGA 8.1) and is of length of
(CAN/CGA 8.1) and is of length of 36+/
36+/36+/
36+/-
--
- 6 in (90+/
6 in (90+/6 in (90+/
6 in (90+/-
--
- 15 cm).
15 cm).15 cm).
15 cm). The gas connector
The gas connector The gas connector
The gas connector m st be installed as shown
m st be installed as shownm st be installed as shown
m st be installed as shown
above
aboveabove
above, in one plane, and witho t sharp bends, kinks or twists.
, in one plane, and witho t sharp bends, kinks or twists., in one plane, and witho t sharp bends, kinks or twists.
, in one plane, and witho t sharp bends, kinks or twists.

Form 43206000
Sept 2011 -15-
12.0) INSTRUCTIONS FOR PRESSURE TEST GAUGE CONNECTION
Failure to do so may result in death, serious injury or property
damage.
The access panel must be closed tightly during operation.
Never operate the heater with the access panel open or removed.
SUPPLY PRESSURE
SUPPLY PRESSURESUPPLY PRESSURE
SUPPLY PRESSURE
1. The installer will provide a 1/8” N.P.T. tapped pl g, accessible for test ga ge connection immediately
pstream of the gas s pply connection to the heater.
MANIFOLD PRESSURE
MANIFOLD PRESSURE MANIFOLD PRESSURE
MANIFOLD PRESSURE –
––
– COMBINATION GAS VALVE IS FACTORY SET
COMBINATION GAS VALVE IS FACTORY SETCOMBINATION GAS VALVE IS FACTORY SET
COMBINATION GAS VALVE IS FACTORY SET
1. T rn the gas valve to the “OFF” position. Remove the 1/8” pl g from the combination gas valve at the O tlet
O tlet O tlet
O tlet
Press re T
Press re TPress re T
Press re Tap
apap
ap shown below and connect a 1/8” nipple to the tapped hole. Connect the test ga ge to the
nipple. T rn on the gas s pply.
Pressure Regulator Adjustment
(under cap screw)
1/8 NPT
Inlet Pressure
Tap with 3/16 Hex
Allen Wrench Plug
1/8NPT
Outlet Pressure
Tap with 3/16 Hex
Allen Wrench Plug
Gas Control
Knob
Wiring
Terminals (2)
Ground
Terminals (2)
OUTLET
INLET
CAUTION
Never jumper these terminals. This
shorts out valve coil and may burn
out heat anticipator in thermostat.
STEP-OPENING
GAS CONTROL VALVE
ON
OFF
MV
MV
2. With the main b rner operating, check the b rner manifold press re sing a water col mn manometer.
Ga ges that meas re press re in po nds per sq are inch are not acc rate eno gh to meas re or set the
manifold press re. All meas rements MUST BE
MUST BEMUST BE
MUST BE made when this heater and all other gas b rning eq ipment
that is connected to the gas s pply system are operating at maxim m capacity.
3. The combination gas valve is factory set and sho ld not req ire adj stment.
The combination gas valve is factory set and sho ld not req ire adj stment.The combination gas valve is factory set and sho ld not req ire adj stment.
The combination gas valve is factory set and sho ld not req ire adj stment. If f ll rate adj stment is
req ired, remove the cover screw. Using a small screwdriver, t rn the adj stment screw clockwise  to
increase or co nterclockwise  to decrease the gas press re to the b rner. Replace the cover screw. NOTE:
NOTE: NOTE:
NOTE:
The step opening press re of this gas valve is not adj stable.
The step opening press re of this gas valve is not adj stable.The step opening press re of this gas valve is not adj stable.
The step opening press re of this gas valve is not adj stable.
4. Check the b rner at step press re, observing b rner ignition and flame characteristics. The b rner sho ld
ignite properly and witho t flashback to the orifice, and sho ld remain lit.
GAS PRESSURE TABLE
GAS PRESSURE TABLEGAS PRESSURE TABLE
GAS PRESSURE TABLE
GAS TYPE
GAS TYPEGAS TYPE
GAS TYPE MANIFOLD PRESSURE
MANIFOLD PRESSUREMANIFOLD PRESSURE
MANIFOLD PRESSURE
SUPPLY PRESSURE
SUPPLY PRESSURESUPPLY PRESSURE
SUPPLY PRESSURE
Minim m*
Minim m*Minim m*
Minim m* Maxim m
Maxim mMaxim m
Maxim m
Nat ral Gas 3.5” W.C. 7” W.C. 14” W.C.
Propane Gas 10.0” W.C. 11” W.C. 14” W.C.
* Minim m permissible gas s pply press re for p rpose of inp t adj stment.

Form 43206000
-16- Sept 2011
13.0) ELECTRICAL CONNECTIONS
Failure to do so may result in death or serious injury.
This appliance must be connected to a properly grounded electrical source.
Disconnect electrical power and gas supply before servicing.
ELECTRIC SHOCK HAZARD
1. All electric wiring shall conform to the latest edition of the National Electrical Code (ANSI/NFPA No. 70), or
the code legally a thorized in the locality where the installation is made.
2. The nit m st be electrically gro nded in accordance with the National Electrical Code (ANSI/NFPA No.
70-latest edition). In Canada, refer to c rrent standard C22.1 Canadian Electrical Code Part 1.
3. The wiring providing power to the heater shall be connected to a permanently live electrical circ it, one that
is not controlled by a light switch.
4. The power s pply to the nit sho ld be protected with a f sed disconnect switch or circ it breaker. A service
switch, as req ired by local codes, shall be located in the vicinity of the heater (check local codes for
allowable distances) and sho ld be identified as Heater Service Switch. All electrical wiring m st be located
in accordance with the req ired Clearances to Comb stibles from the heater as listed on the nameplate on
the heater.
5. When connecting the s pply circ it
s pply circ its pply circ it
s pply circ it to the heater, wiring material having a minim m size of 14 AWG and a
temperat re rating of at least 90°C shall be sed.
INTERNAL CONNECTION WIRING DIAGRAM
INTERNAL CONNECTION WIRING DIAGRAM INTERNAL CONNECTION WIRING DIAGRAM
INTERNAL CONNECTION WIRING DIAGRAM
—
——
—
Direct Spark Ignition
Direct Spark IgnitionDirect Spark Ignition
Direct Spark Ignition
FLAME
SENSOR
v
G
BL BL
BKBK
R
W
BK
BK
R
BK
W
BK
BK
BK
W
DRAFT
INDUCER
MOTOR
GAS VALVE
AIR SWITCH
25V
(GND) 25V GND (BURNER)
VALVE VALVE
TRANSFORMER
120V PRIMARY
24V SECONDARY
A
G
R
IGNITION MODULE
HIGH VOLTAGE
CABLE
ELECTRODE
GAP 3/16
CONTINUE TO
ADDITIONAL
HEATERS
NEUTRAL
120V THERMOSTAT
GROUND
L1
L2
TERMINAL
BLOCK
FACTORY WIRING
FIELD WIRING CONTROL CABINET
MONITORING LIGHTS
Circuit d'origine
Connexions client Lampes témoins
Neutre
Terre
Vers les autres
radiateurs
Plaque à
bornes
Transformateur
bobine primaire 120ÊV
bobine secondaire 24ÊV
pressostat
Robinet à gaz
Écartement
d'électrode
4,7Êmm
Haute tension
Armoire de commande
Bloc d'allumage
Moteur
d'amorce
d'aspiration
NOTES:
NOTES:NOTES:
NOTES:
1. If any of the original wire as s pplied with the appliance m st be replaced, it m st be replaced with wiring
material having a temperat re rating of at least 105ºC. (18 Ga. CSA 600V Type TEW)
2. When connecting the s pply circ it to the heater, wiring material having a minim m size of 14 AWG and a
temperat re rating of at least 90ºC shall be sed.
3. A replaceable 3-amp f se (1-1/4” long) is fitted to the Ignition Control Mod le.

Form 43206000
Sept 2011 -17-
SCHEMATIC
SCHEMATICSCHEMATIC
SCHEMATIC
WIRING DIAGRAM
WIRING DIAGRAM WIRING DIAGRAM
WIRING DIAGRAM
—
——
—
Direct Spark Ignition
Direct Spark IgnitionDirect Spark Ignition
Direct Spark Ignition
SCHEMATIC WIRING DIAGRAM
MOT Motor Moteur
GL Green Light Témoin vert
TRANS 24V Transformer Transformateur 24ÊV
RL Red Light Témoin rouge
AS Air Switch pressostat
SM Ignition Module Bloc d'allumage
IG/S Ignitor / Sensor électrode
V Gas Valve Robinet à gaz
AL Amber Light Témoin ambre
MOT
120V
GL
TRANS
RL
AS
IG/S
AL
V
SM
42785000 Rev. C 10/04
25V GND25V
FIELD CONNECTION
FIELD CONNECTION FIELD CONNECTION
FIELD CONNECTION AN
ANAN
AND THERMOSTAT
D THERMOSTAT D THERMOSTAT
D THERMOSTAT WIRING DIAGRAMS
WIRING DIAGRAMSWIRING DIAGRAMS
WIRING DIAGRAMS
A.
A.A.
A. LINE VOLTAGE (120V) THERMOSTAT CONNECTIONS
LINE VOLTAGE (120V) THERMOSTAT CONNECTIONS LINE VOLTAGE (120V) THERMOSTAT CONNECTIONS
LINE VOLTAGE (120V) THERMOSTAT CONNECTIONS –
––
– SINGLE HEATER
SINGLE HEATERSINGLE HEATER
SINGLE HEATER PER THERMOSTAT
PER THERMOSTATPER THERMOSTAT
PER THERMOSTAT
Ground
Neutral
Hot (120VAC)
Fused
Disconnect
Switch
Thermostat Service
Switch
Heater 1
Continue To
Additional
Heaters
Thermostat Service
Switch
Heater 2
B.
B.B.
B. LINE VOLTAGE (120V) THERMOSTAT CONNECTIONS
LINE VOLTAGE (120V) THERMOSTAT CONNECTIONS LINE VOLTAGE (120V) THERMOSTAT CONNECTIONS
LINE VOLTAGE (120V) THERMOSTAT CONNECTIONS –
––
– MULTIPLE HEATERS
MULTIPLE HEATERSMULTIPLE HEATERS
MULTIPLE HEATERS PER THERMOSTAT
PER THERMOSTATPER THERMOSTAT
PER THERMOSTAT
Ground
Neutral
Hot (120VAC)
Fused
Disconnect
Switch
Thermostat Service
Switch
Heater 1
Continue To
Additional
Heaters
Service
Switch
Heater 2

Form 43206000
-18- Sept 2011
C.
C.C.
C. LOW
LOWLOW
LOW VOLTAGE (
VOLTAGE (VOLTAGE (
VOLTAGE (24
2424
24V) THERMOSTAT CONNECTIONS
V) THERMOSTAT CONNECTIONS V) THERMOSTAT CONNECTIONS
V) THERMOSTAT CONNECTIONS –
––
– SINGLE HEATER PE
SINGLE HEATER PESINGLE HEATER PE
SINGLE HEATER PER THERMOSTAT
R THERMOSTATR THERMOSTAT
R THERMOSTAT
G
BL BL
BKBK
R
W
BK
BK
W
BKBK
BK
W
DRAFT
INDUCER
MOTOR
GAS VALVE
AIR SWITCH
25V
(GND) 25V GND (BURNER)
VALVE VALVE
TRANSFORMER
120V PRIMARY
24V SECONDARY
A
G
R
IGNITION MODULE
HIGH VOLTAGE
CABLE
ELECTRODE
GAP 3/16
CONTINUE TO
ADDITIONAL
HEATERS
NEUTRAL
120V
GROUND
L1
L2
TERMINAL
BLOCK
FACTORY WIRING
FIELD WIRING
CONTROL CABINET
MONITORING
LIGHT
3 4 5
1
LOW VOLTAGE
THERMOSTAT (24V)
BK
BK
BK
W
R
FIELD INSTALLED
RELAY KIT
PART NO.
43274000
R
FLAME
SENSOR
v
Order 24V Relay Kit (Part No. 432740
Order 24V Relay Kit (Part No. 432740Order 24V Relay Kit (Part No. 432740
Order 24V Relay Kit (Part No. 4327400
00
00) for Low Voltage (24V) thermostat connection.
0) for Low Voltage (24V) thermostat connection.0) for Low Voltage (24V) thermostat connection.
0) for Low Voltage (24V) thermostat connection.
NOTES:
NOTES:NOTES:
NOTES:
1. If any of the original wire as s pplied with the appliance m st be replaced, it m st be replaced with wiring
material having a temperat re rating of at least 105ºC. (18 Ga. CSA 600V Type TEW)
2. When connecting the s pply circ it to the heater, wiring material having a minim m size of 14 AWG and a
temperat re rating of at least 90ºC shall be sed.
3. A replaceable 3-amp f se (1-1/4” long) is fitted to the Ignition Control Mod le.
D.
D.D.
D. L
LL
LOW
OWOW
OW VOLTAGE (
VOLTAGE (VOLTAGE (
VOLTAGE (24
2424
24V) THERMOSTAT CONNECTIONS
V) THERMOSTAT CONNECTIONS V) THERMOSTAT CONNECTIONS
V) THERMOSTAT CONNECTIONS –
––
– MULTIPLE HEATERS
MULTIPLE HEATERSMULTIPLE HEATERS
MULTIPLE HEATERS PER THERMOSTAT
PER THERMOSTATPER THERMOSTAT
PER THERMOSTAT
Ground
Neutral
Hot (120VAC)
Fused
Disconnect
Switch
Service
Switch
Heater 1
Continue To
Additional
Heaters
Service
Switch
Heater 2
Low Voltage
Thermostat (24V)
coil
C
RG
NO
Fan Center Relay Part No. 30169000
Contact Rating: 120V, 40VA, 12A
(maximum of 6 heaters per relay)

Form 43206000
Sept 2011 -19-
14.0) VENTING
Failure to do so may result in death, serious injury, property damage or illness
from Carbon Monoxide poisoning.
Heaters installed in an unvented mode require a minimum ventilation flow of
4 CFM per 1,000 Btu/hr of total installed capacity.
In buildings with airborne contamination the heater must be installed with
fresh air for combustion.
CARBON MONOXIDE HAZARD
A.
A.A.
A. BASIC FLUE VENTING
BASIC FLUE VENTINGBASIC FLUE VENTING
BASIC FLUE VENTING — Venting m st comply with the latest edition of the National F el Gas Code (ANSI
Z223.1-latest edition) or the a thority having j risdiction. Other venting references are in the eq ipment
vol me of the ASHRAE Handbook.
SINGLE HEATER VENTING (VERTICAL THROUGH THE ROOF)
SINGLE HEATER VENTING (VERTICAL THROUGH THE ROOF)SINGLE HEATER VENTING (VERTICAL THROUGH THE ROOF)
SINGLE HEATER VENTING (VERTICAL THROUGH THE ROOF)
1. When venting the heater to o tside of b ilding thro gh a roof, se single-wall metal pipe. This is to be
constr cted of galvanized sheet metal or other approved noncomb stible corrosion-resistant material as
allowed by state or local codes.
2. A vent passing thro gh a comb stible roof shall extend thro gh an approved clearance roof thimble. Do ble-
wall, Type B vent m st be sed for the portion of the vent system which passes thro gh the comb stible roof.
An approved vent cap m st be attached to end of the fl e.
3. The maxim m eq ivalent length of vent pipe sho ld be caref lly observed. A safety switch in the heater is
designed to sh t the heater off before excessive fl e restriction ca ses bad comb stion. Refer to the Vent
Sizing Table for vent pipe diameter.
•Minim m Eq ivalent Length = 5 ft. of pipe
•Maxim m Eq ivalent Length = 100 ft. of pipe
Use the following correction factors to obtain the eq ivalent length:
•S btract 15 ft. if the r n is horizontal.
•S btract 10 ft. for an approved vent cap.
•S btract 10 ft. for each elbow beyond 15 ft. from the heater.
•S btract 15 ft. for each elbow within 15 ft. of the heater.
4. Joints between sections of piping shall be fastened by sheet metal screws or other approved means and
sho ld be sealed to prevent leakage of fl e gas into b ilding. Al min m or Teflon tape s itable for 550ºF
(3M Company tapes 433 or 363) or silicone sealant is recommended.
5. Avoid locating elbows in the first 5’ of vent pipe whenever possible. Limit to (2) 90° elbows. When vent pipe
is in a horizontal r n, it m st have 1/4 inch per foot rise.
6. All portions of the vent pipe shall be s pported to prevent from sagging (6’ spacing is recommended).
7. When the vent pipe passes thro gh areas where the ambient temperat re is likely to ind ce condensation
of the fl e gases, the vent pipe sho ld be ins lated and a condensation drain sho ld be provided.
8. Minim m clearance for single-wall fl e pipe to comb stible material shall be 6 inches. This may be red ced
when the comb stible material is protected as specified in the National F el Gas Code or the a thority
having j risdiction.
9. Single-wall metal pipe shall not originate in any nocc pied attic or concealed space and shall not pass
thro gh any attic, inside wall or concealed space, or thro gh any floor. For the installation of a single-wall
metal pipe thro gh an exterior comb stible wall, refer to latest edition of the National F el Gas Code or the
a thority having j risdiction.
10. A venting system shall terminate at least 3 ft. above any forced air inlet located within 10 ft.
