Cairox SOLANO EASY Series Guide

SOLANO EASY TECHNICAL DOCUMENTATION / TECHNISCHE DOCUMENTATIE GEBRUIKSAANWIJZING /
NOTICE D’UTILISATION / DOKUMENTACJA TECHNICZNA / MŰSZAKI LEÍRÁS

1. GENERAL INFORMATION.....................................................................................................................................................2
2. APPLICATION. ........................................................................................................................................................................2
3. DIMENSIONS ...........................................................................................................................................................................3
4. TECHNICAL DATA .................................................................................................................................................................4
5. INSTALLATION.......................................................................................................................................................................4
6. ASSEMBLY INSTRUCTIONS .................................................................................................................................................5
7. UNDER CEILING MOUNTED.................................................................................................................................................6
8. CONNECTING..........................................................................................................................................................................6
8.1. CONNECTION DIAGRAM SOLANO EASY-W ...................................................................................................................7
8.2. CONNECTION DIAGRAM EASY-E .....................................................................................................................................8
8.3. REGULATION S-TOUCH - SOLANO EASY W/N WIRING DIAGRAMS .........................................................................9
8.4. REGULATION S-TOUCH - SOLANO EASY E WIRING DIAGRAMS .............................................................................10
8.5. ELECTRIC SCHEME –CURTAIN CHAINING ..................................................................................................................11
9. START UP AND OPERATION ............................................................................................................................................... 12
10. HEATING CAPACITY ..........................................................................................................................................................57
The SOLANO EASY device group includes the following models:
EASY-W-100 –curtain with water heat exchanger,
EASY-W-150 –curtain with water heat exchanger,
EASY-W-200 –curtain with water heat exchanger,
EASY-E-100 –curtain with electrical heat exchanger,
EASY-E-150 –curtain with electrical heat exchanger,
EASY-E-200 –curtain with electrical heat exchanger.
EASY-W/E (100/150/200) –air curtains in standard version with 3-gear fan and mounting plate.
Air Curtain SOLANO BASIC is to be installed over the door opening, it provides dynamic barrier against
external factors. The devices are designed for indoor use where maximum air dustiness does not exceed
0,3 g/m
3
. Units are built using copper, aluminum and galvanized steel. It is prohibited to install units in the
areas where environment inside can cause corosion.
Thank you for purchasing the SOLANO EASY air curtain.
The manufacturer reserves the right to make revisions and changes in the operation manual at any time and
without notice,and also to make changes in the
device that do not influence its operation. This manual is an
integral part of the device and it must be delivered to the user together with the device. In order to ensure
correct operation of the equipment, get thoroughly acquainted with this manual and
keep it for the future.

EASY-E-100
EASY-E-150
EASY-E-200
Step
1
2
3
1
2
3
1
2
3
Air flow [m
3
/h]
900
1100
1300
1450
1650
1950
2100
2300
2700
Puissance [kW]
6,5 10 13
Temp. increase [°C]
15
15
15
Power supply [V/Hz]
3x400/50 3x400/50 3x400/50
Max current consumption [A]
9,4
14,5
18,7
IP/Insulation class
21 /F 21 /F 21 /F
Max acoustic pressure level [dB(A)]**
44,5
46,5
48,5
46,5
48,5
50,5
48,5
50,5
52,5
Range [m]
3
3
3
Max working temperature [°C]
60
60
60
Device mass[kg]
14,5
19,9
25,1
* Temperature increase at inlet air 10oC and heating agent temperature 90/70oC
** Acoustic pressure level has been measured 3 m from the unit in a 500 m3space with a medium sound absorption coefficient
EASY-W-100
EASY-W-150
EASY-W-200
Step
1
2
3
1
2
3
1
2
3
Air flow [m
3/h]
1050
1250
1400
1600
1850
2100
2300
2600
3000
Heating Capacity [kW]*
14,9 22,8 32,5
Temp. increase [°C]
31 32 32
Power supply [V/Hz]
230/50 230/50 230/50
Max current
consumption [A] 0,65 0,95 1,2
Max power consumption [W]
140 210 260
IP/Insulation class
21 /F 21 /F 21 /F
Max acoustic pressure level [dB(A)]**
44,5
46,5
48,5
46,5
48,5
50,5
48,5
50,5
52,5
Max heating water temperature [°C]
90 90 90
Max operating
pressure [MPa] 1,2 1,2 1,2
Internal thread connection
¾” ¾” ¾”
Range [m]
333
Max working temperature [°C]
60 60 60
Device mass[kg]
19 27,5 35,1
Air curtains can be mounted horizontal. During the montage, the
minimal distances from the
walls and ceiling have to be kept.

1. Unscrew the screws from mounting bracket.
3. Put the curtain on the bracket.
2. Bracket should be mounted to the wall with 4 screws M8.
Hole spacing:
EASY-W/E-100 90x440 mm
EASY-W/E-150/200 90x840 mm
4. After installing the unit on the bracket, tighten
the screws (point 1) then put the plastic cover on
screw hole.

4 pcs. of pins M8 should be screwed into the curtain min. at a length of 20 mm
Model
AxB [mm]
EASY-W-100
181x948
EASY -W-150
181x1448
EASY -W-200
181x1958
EASY -E-100
80x948
EASY -E-150
80x1448
EASY -E-200
80x1958
To connect the control system and power supply to the SOLANO EASY curtain, remove the cover (unscrew 2
screws) located at the top of the unit.
GUIDE
MOUNTED

Power supply 230V/50Hz (OMY 3x1,0 mm2)
!Air curtain step switch with thermostat S-C (OMY 5x0,5 mm2)
FAN AUTO –fan operating depending on room thermostat signal
FAN CONT –fan operating continuously (deactivated thermostat signal)
HEAT –heating mode
FAN –room thermostat deactivated for FAN CONT
COOL –cooling mode
"Door switch S-DS-RMAG/S-DS-MEC (OMY 2x0,5 mm2) (door opened –closed switch)
#Valve with actuator S-V-3-3/4 (OMY 3x0,75 mm2) / S-V-2-3/4 (OMY 3x0,75 mm2)
A –Exchanger water supply
AB –Valve water supply
B –Return pipe water supply

8
!Power supply 3x400V/50Hz
EASY-E-100 (5x2,5 mm2); Overcurrent breaker B16
EASY-E-150 (5x2,5 mm2); Overcurrent breaker B20
EASY-E-200 (5x4,0 mm2); Overcurrent breaker B25
"Air curtain step switch with thermostat S-C (OMY 7x0,5 mm2)
FAN AUTO* –fan operating depending on room thermostat signal
FAN CONT –fan operating continuously (deactivated thermostat signal)
HEAT –heating mode
FAN –room thermostat deactivated for FAN CONT
COOL –cooling mode
#Door switch S-DS-RMAG/S-DS-MEC (OMY 2x0,5 mm2) (door opened –closed switch)
*To set AUTO MODE, it is required to connect the cable with connectors 3 and 4 in the curtain parallel to the
connector 3 in the controller S-C















Power supply 230V/50Hz (OMY 3x1 mm2)
!S-TOUCH (LIYCY 2x2x0,5 mm2)
"Door contact S-DS-MAG / S-DS-MEC (door closed –contacts opened;
door opened contacts closed) (OMY 2x0,5 mm2)
•Valve with actuator S-V-2 (OMY 3x0,75 mm2) or S-V-3 (OMY 3x0,75 mm2)
A –Exchanger water supply
AB –Valve water supply
B –Return pipe water supply
•EASY- W/N
NOTE: In last DRV in line, dipswitch SW2 has to be switched to the right –T120.





 






10
















Power supply 3x400V/50Hz
• EASY-E-100 (min. 5x2,5 mm2) (Overcurrent B16)
• EASY-E-150 (min. 5x4,0 mm2) (Overcurrent B20)
• EASY-E-200 (min. 5x4,0 mm2) (Overcurrent B25)
S-TOUCH (LIYCY 2x2x0,5 mm2)
!Door contact S-DS-MAG / S-DS-MEC (door closed –contacts opened; door opened –contacts closed)
(OMY 2x0,5 mm2)
•EASY E
ATTENTION:
Switch 4 on SW3 to the position “E” and then restart the system switching it off for 5 seconds. Each time the device
is switched off the heaters are being cooled for next 30 seconds











Single S-C controller can run with up to 2 EASY air curtains. Larger number of EASY air curtains need to be
connected via S-SPLIT splitter.


































ŒPower supply 230V/50Hz
(OMY 3x1,omm
2)
Power supply 3x400V/50Hz:
EASY
C-E-100 (5x2,5 mm2) Overcurrent
breaker B16
EASY
C-E-150 (5x2,5 mm2) Overcurrent
breaker B20
EASY
C-E-200 (5x4,0 mm2) Overcurrent
breaker B25
ŽDoor contact S-DS-RMAG / S-DS-
MEC
(door closed
- opened contacts;
door opened
-
closed contats). Use DC jumper
between connectors NC and NC if door contact
not used (OMY 2x1,0 mm
2)
•Air curtain step switch with thermostat S
-C
(OMY
5x1,0 mm2)
FAN AUTO
- Fan auto - fan operating
depending on room thermostat signal
FAN CONT
- fan operating continuously
(deactivated
thermostat signal)
HEAT
- heating mode
FAN
- room thermostat deactivated
COOL
- cooling mode
In curtain connected with drivers, replace fuse
on
F6,3A
C-W
C-E

12
GUIDELINES FOR SYSTEM CONNECTION
• The connection should be executed in a way which does not induce stresses. It is recommended to use flex pipes
to connect the stubs.
• It is recommended to install vent valves at the highest point of the system.
• The system should be executed so that, in the case of a failure, it is possible to disassemble the device. For this
purpose it is best to use shut-off valves just by the device.
• The system with the heating medium must be protected against an increase of the heating medium pressure above
the permissible value (1.2 MPa).
• While screwing exchanger to pipeline - connecting stubs has to be hold by wrench.
START UP
• Before connecting the power supply check the correctness of connection of the fan motor and the controllers.
These connections should be executed in accordance with their technical documentation.
• Before connecting the power supply check whether the mains voltage is in accordance with the voltage on the
device data plate.
• Before starting the device check the correctness of connection of the heating medium conduits and the tightness
of the system.
• Starting the device without connecting the ground conductor is forbidden.
OPERATION
• The device is designed for operation inside buildings, at temperatures above 0oC. In low temperatures
(below 0oC) there is a danger of freezing of the medium. The manufacturer bears no responsibility for damage
of the heat exchanger resulting from freezing of the medium in the exchanger. If operation of the device is
expected at temperatures lower than 0o, then glycol solution should be used as the heating medium, or special
automatic systems should be used for protecting against freezing of the medium in the exchanger.
• It is forbidden to place any objects on the heater or to hang any objects on the connecting stubs.
• The device must be inspected periodically. In the case of incorrect operation of the device it should be switched
off immediately. It is forbidden to use a damaged device. The manufacturer bears no responsibility for damage
resulting from the use of a damaged device.
• If it is necessary to clean the exchanger, be careful not to damage the aluminium lamellas.
• For the time of performing inspection or cleaning the device, the electrical power supply should be disconnected.
• In case water is drained from the device for a longer period of time, the exchanger tubes should be emptied
withcompressed air.
•It is not allowed to make any modification in the unit. Any modification causes in warranty loss.
