SpaceLift 5200-S Series User manual

Page 1 SpaceLift 5200-S Series Attic Lift Manual (9/19-R)
SpaceLift 5200-S Series Attic Lift
Operating Instructions
Step 2 Step 3
Operation: Step 1
WARNING: Before any operation of the SpaceLift 5200-S Series attic lift,
inspect the platform operating area to verify no persons, animals or objects
are within 5 feet of the platform.
To avoid injury in loading and unloading operations, make sure to use proper
lifting practices. Secure objects in the lift platform to prevent them from
shifting or falling off while the platform is in motion.
Maximum load limit is 200 pounds. Exercise caution when loading heavier
items. Avoid dropping on lift platform.
The 5200-S Series attic lift system automatically performs a variety of checks
before each operation.
SAVE THESE INSTRUCTIONS
Figure shown
operating optional
remote control unit.
Manufacured by Redco Home
SPACELIFT INSTALLATION VIDEOS
We have 7 YouTube videos to compliment the site selection, installation and operations manuals:
https://www.youtube.com/playlist?list=PL64o5GKvoOih2lYcdQkBEfJzRYz4ZOv7u

READ THIS FIRST:
NORMAL SEQUENCE OF OPERATION
With lift in the fully stowed Up position the Unit
Control will display only a Down Button. When
stowed, pressing the Up Button will do nothing.
NOTE: It is the responsibility of the operator to
insure an overloaded condition does not occur.
Pressing and holding the Down Button will start
the following sequence:
•The tray will slowly lower while the microprocessor
monitors the speed. If the tray has an overload of
more than 200 pounds the speed will become
excessive, causing an overspeed error and the
microprocessor will halt the motion. The Down
Button will FLASH Red and the Up Button will
display STEADY Red.
•When the load is less than 200 pounds the tray will
continue moving downward as long as the Down
Button is continuously pressed. The tray will con-
tinue traveling downward and accelerate to the
normal run speed. The tray will continue down until
it approaches the bottom limit where it will decel-
erate and automatically slowly settle onto the floor
(provided bottom limit is set correctly).
•With tray on the floor only the Up Button will be
illuminated green indicating only upward travel is
possible. Pressing the Down Button will do nothing.
Pressing and holding the Up Button starts the
following sequence:
•Tray will slowly lift off the floor and accelerate
while the microprocessor continuously monitors
the overload. If the load exceeds 200 pounds the
tray will stop and the UP Button will FLASH Red
while the DOWN Button displays STEADY Red.
•Provided load is 200 pounds or less, the tray will
continue going up until tray is near the top where
it will decelerate and continue slowly up to the
stow position. When stowed the Control Unit will
display one GREEN Down Button indicating only
downward motion possible.
While traveling Up or Down:
•If the tray is stopped by the operator releasing a
travel button at any point between the “stowed”
and “on floor” positions, both Control Unit Buttons
will show GREEN indicating travel is possible either
Down or Up.
•While tray is moving upward or downward the load
management system continuously monitors the
load and drive motor in order to detect an over-
load, over speed or slack Poly-Web Straps. If any
of these errors occur the Control Unit will display a
unique illumination pattern for each. See indicator
table below.
After a few seconds, arrow indicators will revert to
green indicating travel may resume.
NOTE: It is up to the operator to determine whether or
not any condition still exists that would generate another
error (i.e. an overload or slack Poly-Web Straps).
Page 2 SpaceLift 5200-S Series Attic Lift Manual (9/19-R)
INDICATOR TABLE
Normal operation (no errors)
Stowed ........................DOWN green, UP no illumination
Traveling .....................UP/DOWN no illumination
Stopped in middle ...UP/DOWN green
On floor........................UP green, DOWN no illumination
Errors
Slack .............................DOWN red flashing, UP green
Persistent Slack ..........DOWN and UP flashing red ---
........................................no movement allowed until fault
is cleared.
Overload .....................UP red flashing, DOWN red steady
Over speed ................DOWN red flashing, UP red steady
Top Safety....................DOWN red steady, UP red steady

SpaceLiftProducts.com
© 2019 SpaceLift Products, Inc. All rights reserved (9/19-R)
WARNING: Before any operation of the SpaceLift
5200-S Series attic lift system inspect the platform
operating area to verify no persons, animals or
objects are within 5 feet of the platform.
To avoid injury in loading and unloading operations,
make sure to use proper lifting practices. Secure
objects in the lift platform to prevent them from
shifting or falling off while the platform is in motion.
The 5200-S Series attic lift system automatically
performs a variety of checks before each operation.
NOTE: Maximum load limit is 200 pounds. Be
careful, especially when loading heavier items, not
to drop them on the lift platform.
STEP 1. Turn on Remote Control Unit with Key.
•Up/Down Buttons – Arrows display GREEN to
indicate directions possible (i.e. stowed lift will
only go down).
•Obstacle Detection – If lift hits obstruction,
remote will display RED. (See Indicator Table
for all possible error codes)
STEP 2. Use the Down Button to lower the cargo lift
platform to the lower level landing position.
STEP 3. Load the lift platform with items to be trans-
ported. Weight of items should be centered in tray.
Maximum load must be limited to 200 pounds per trip.
Be sure objects are secured to prevent load shifting
during lift operations.
STEP 4. Depress and hold the Up Button until the lift
cycle is complete. To halt operation, release the
button any time during the lift cycle.
STEP 5. Unload lift platform.
STEP 6. Turn Key OFF when lift operations are
complete.
NOTE: If power is lost during operation the lift will stop.
When power is restored, depress the Up Button and
return the lift to the fully stowed position. This enables
the system to maintain consistent operation.
WARNING: When using the cargo lift system
Remote Control Unit, keep the lift platform in sight
until completely stopped in either the bottom or
top position. DO NOT allow children to play under
or near the lift platform.
WARNING: The lift platform moves rapidly. Keep
path clear.
Contacting Redco Home
If your product fails during the warranty period and the
product documentation does not solve the problem,
you may receive support by:
1. Check Model 5200-S Series FAQ on the SpaceLift
website.
2. Contact the dealer from whom you purchased.
3. Use SpaceLift website Contact form for inquiry.
Before contacting your dealer or Redco Home, have
the following:
•Product serial number (found on the motor
housing label)
•Product model name and model number
•Detailed notes for questions
SpaceLift 5200-S Series Attic Lift
Operating Instructions
Step 4
Step 5
Page 3 SpaceLift 5200-S Series Attic Lift Manual (9/19-R)
Step 2 Step 3
Operation:
Step 1
Figure shown
operating optional
remote control unit.
Manufacured by Redco Home

Extent of Limited Warranty
SpaceLift Products, Inc. warrants that the cargo lift
product will be free from defects in material and
workmanship for two years. SpaceLift Products does
not warrant that the operation of the product will be
uninterrupted or error free.
This limited warranty covers only those defects that
arise as a result of normal use of the product and
does not cover any other problems, including those
that arise as a result of: (i) improper maintenance or
modification; (ii) operation outside the product’s spec-
ifications; or (iii) unauthorized modification or misuse.
If SpaceLift Products receives, during the applicable
warranty period, notice of a defect in any product,
which is covered by this warranty, SpaceLift Products
shall either repair or replace the product at its sole
discretion and option.
Limitations of Warranty
TO THE EXTENT ALLOWED BY LOCAL LAW,
NEITHER SPACELIFT PRODUCTS NOR ITS THIRD
PARTY SUPPLIERS MAKES ANY OTHER WARRANTY
OR CONDITION OF ANY KIND, WHETHER EXPRESS
OR IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY, SATISFACTORY QUALITY, AND
FITNESS FOR A PARTICULAR PURPOSE.
Limitations of Liability
To the extent allowed by local law, the remedies
provided in this Limited Warranty Statement are the
customer’s sole and exclusive remedies.
TO THE EXTENT ALLOWED BY LOCAL LAW, EXCEPT
FOR THE OBLIGATIONS SPECIFICALLY SET FORTH
IN THIS WARRANTY STATEMENT, IN NO EVENT
SHALL SPACELIFT PRODUCTS OR ITS THIRD PARTY
SUPPLIERSBELIABLEFORDIRECT,INDIRECT,SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES,
WHETHER BASED ON CONTRACT, TORT, OR ANY
OTHER LEGAL THEORY AND WHETHER ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES.
Local Law
This Limited Warranty Statement gives the customer
specific legal rights. The customer may also have
other rights, which vary from state to state in the
United States, from province to province in Canada,
and from country to country elsewhere in the world.
To the extent that this Limited Warranty Statement
is inconsistent with local law, this Statement shall be
deemed modified to be consistent with such local
law. Under such local law, certain disclaimers and
limitations of this Warranty Statement may not apply
to the customer. For example, some states in the
United States, as well as some governments outside
the united States (including provinces in Canada),
may: (i) preclude the disclaimers and limitations in this
Warranty Statement from limiting the statutory rights
of a consumer (e.g., United Kingdom); (ii) otherwise
restrict the ability of a manufacturer to enforce such
disclaimers or limitations; or (iii) grant the customer
additional warranty rights, specify the duration of
implied warranties which the manufacturer cannot dis-
claim, or allow limitations on the duration of implied
warranties.
THE TERMS IN THIS WARRANTY STATEMENT,
EXCEPT TO THE EXTENT LAWFULLY PERMITTED, DO
NOT EXCLUDE, RESTRICT, OR MODIFY, AND ARE
IN ADDITION TO, THE MANDATORY STATUTORY
RIGHTS APPLICABLETO THESALE OF THESPACELIFT
PRODUCTS TO SUCH CUSTOMERS.
Register Online to Initiate Your Warranty:
SpaceLiftProducts.com/Products
Protected by U.S. Patents No. 8,292,031 and
9,120,645 B2.
SpaceLiftProducts.com
Limited Warranty
SpaceLift Products Model 5200-S Series Lift System
© 2019 SpaceLift Products, Inc. All rights reservedPage 4 SpaceLift 5200-S Series Attic Lift Manual (9/19-R)
