SPARK TITAN USER MANUAL SF-X8 | A1
CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD www.sparkfabrica.com
DISCLAIMER
This product is a professional machine, we do not assume any responsibility for accidents or losses caused by the
use or maintenance of this product by personnel without professional training and permission.
If the information contained in the manual or the product specications are changed, Spark Fabrica will not inform
you further and responsible for any errors or omissions.
Our company reserves the right to modify the user manual at any time.
Please read the manual carefully before installing and using this product. Failure to read or comply with this
manual may result in injury to products and personnel, and Spark Fabrica shall not be responsible for this.
PREFACE
This manual includes warning, caution and notice concerning the safe operation of equipment. These warning,
caution and notice come with the following icons. Please read them carefully!
This warning indicates a dangerous situation that may result in death or serious injury if not
avoided.
This alert indicates a dangerous situation that may result in mild or moderate injury if not
avoided.
This means that you need to be careful.

1. PRODUCT INTRODUCTION
1.1 PRODUCT OVERVIEW
This product belongs to special eects equipment, only for professional use.
This product belongs to the cold reworks simulation special eects equipment, using CST technology, heating
special metal powder, and sparking silver spark fountain which is safer than the traditional cold reworks.It has
three controllable variables: height, density and duration.
This product is widely used in weddings, concerts, sports events, event meetings and so on.Stimulate your interest
and light up your activity.
SPARK TITAN USER MANUAL SF-X8 | A2
CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD
www.sparkfabrica.com
POWER OUT
POWER IN
INSURANCE
DOWN
RIGHT
UP
GRANULE FILLING PORT
BIN BUTTON
DMX IN
LED DISPLAY SCREEN
AIR INLET
AIR OUTLET
LEFT
HANDLE
OUTPUT NOZZLE
HOPPER COVER
DMX OUT
DMX / CAN IN
DMX / CAN OUT

CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD www.sparkfabrica.com
SPARK TITAN USER MANUAL SF-X8 | A3
Open the package carefully and check to make sure the goods are in good condition.
NOTICE
1.2 PRODUCT ACCESSORIES
2 TECHNICAL PARAMETER
1.6 Meter Power Plug
SafetyRope
3 Meters DMX Pair Cable
Safety Ring
3 Meters Power Pair Cable
T-type Wrench
User Manual
Mounting Screw (Four pieces of each set)
Upload Box (Optional)
Only the consumables provided by Spark Fabrica are allowed to be used. Spark Fabrica
shall not be liable for any damage to machines, personnel and property caused by the
use of consumables not provided by the company.
A special metal powder has the characteristics of high content, little residue, belonging to a special consumables
with no smoke, odor and other toxic gas when sparking.
1.3 SPARK FABRICA GRANULE
