OPERATION MANUALOPERATION MANUAL
EP-510HC
EP-510HC: 12 Ton Remote Compression C-Head
Read and understand all of the instructions and safety information
in this manual before operating or servicing this tool.
195 Internationale Blvd
Glendale Heights, IL 60139
Phone [phone]
Fax [phone]
www.spartacogroup.com

www.spartacogroup.com 800-860-6170
2
REGISTRATION/ TABLE OF CONTENTS
THANK YOU...
for purchasing a Huskie Tools product. Our
mission is to supply the finest steel cable
connecting and cutting tools and cable-related
products to the transmission and distribution
markets. Huskie Tools products represents the
state-of-the-art tools and are dependable & safe.
Trust, integrity, teamwork and mutual respect -
these words are something we take to heart here
at Huskie Tools.
Please take the time to read this manual carefully
to learn how to correctly operate and maintain
your tool.
Table of Contents
Registration/ Contents.......................... 2
Warranty................................................. 3
Safety...................................................... 4
Specs/Kit Includes................................. 5
Operating Instructions......................... 6-7
Breakdown.............................................8
Parts List.................................................9

www.spartacogroup.com 800-860-6170
3
WARRANTY
Warranty
Huskie Tools products carry a warranty that makes us a leader in the tool industry. No other manufacturer dares to back
its tools as we do.
All Huskie REC-SERIES battery operated products carry a 5 year warranty. The ECO-SERIES battery operated products
carry a 1 year warranty. The BP-80 & BP-84 batteries carry a 5 year warranty from the date stamped on the battery. The
BP-82 battery carries a 1 year warranty.
PRODUCT WARRANTY
REC-Series battery operated products 5 Years
ECO-Series battery operated products 1 Years
Batteries (BP-80, BP-84) 5 years/ (BP-82) 1 year
Chargers (CH-90, CH-94) 5 Years
The warranty does not cover any damages incurred from a Huskie tool including damages to property, bodily injuries
and lost wages resulting from such injuries. This warranty solely covers the repair or replacement of tools supplied by
Huskie. These remedies are exclusive, and the total liability of Huskie Tools, LLC whether based on contract, warranty,
negligence, indemnification, strict liability or otherwise, shall not exceed the purchase price of the tool. In no event shall
Huskie Tools, LLC be liable for consequential, incidental or special damages.
HUSKIE TOOLS, LLC MAKES NO OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AND ALL IMPLIED
WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
DISCLAIMED.
Huskie reserves the right to determine all warranty claims. Huskie will not warranty tools containing parts or batteries not
originally supplied by Huskie. Failure due to misuse, improper maintenance, misapplication, not following instructions or
warnings, abuse or repairs attempted by anyone other than Huskie Tools, LLC, or an authorized service center renders
this warranty null and void.
Repair and Warranty Claims
All claims must be sent to Huskie for inspection and authorization. A Return Goods Authorization (RGA) is required
before shipping tools to Huskie. Secure the authorization by telephoning or writing to Huskie’s main oce with details
of the claim. Non-warranty repairs are handled using the same procedure. Repairs exceeding 50 percent of the cost of a
new tool will be advised before repairs are made.
Payment Terms
Upon credit approval Huskie’s standard payment terms are net-30 days. Visa, Mastercard, Discover and American
Express are also accepted.
Freight
All Huskie tools are FOB, Glendale Heights, Illinois. Goods will be shipped pre-paid and added, unless otherwise
specified. Freight shipments over $17,000 are pre-paid.
Quotations
Special quantity quotations should be phoned in to discuss the scope of your tool requests.
Complete Support Services
Our customers have direct access to us for training, service, and problem solving. As specialists in tools, we maintain
a trained repair sta and a large stock of parts. This contrasts with many tool suppliers who carry tools as a sideline
without oering support services. Here are some reasons why our customers love to do business with us:
• Quick delivery
• We maintain inventory at our headquarters.
• Training and troubleshooting services.
• Fast repair service.
• Design and engineering service for special tool needs.

www.spartacogroup.com 800-860-6170
4
SAFETY
Safety Alert Symbol:
is safety alert symbol indicates a potential
personal injury hazard; it is not used for messages
related to property damage only.
Wear eye protection:
when operating this tool.
Failure to wear eye
protection could result in
serious eye injury from ying
debris.
Electric Shock hazard:
Use proper personal protective equipment when
using this unit on or near energized electrical lines.
Pinch Point Hazard:
Compression Dies at high
force can cause severe
personal injury. Keep all
body parts away from
moving parts of the tool
while operating.

www.spartacogroup.com 800-860-6170
5
SPECIFICATIONS & KIT INCLUDES
• 1 Manual Tool
• 1 Carrying Case
• Protective Rubber Boot on “C” Head
Specifications
Output 12 Ton
Weight 11 lbs.
Size 12.25”L
Jaw Opening 1.65”
Connector Range
Lugs and Splices Up to 750 MCM Cu
Features
The EP-510HC is a remote C-head that requires an external 10,000 psi pumping source. It
accepts all “U” type dies used with conventional 12 ton compression tools. The larger jaw
opening of 1.65” accepts conductors and mid-span sleeve connections up to 750 MCM.
The EP-510HC is supplied with a screw type, 3/8” male coupler, metal carrying case, and
die tray. We recommend the use of our non-conductive high pressure hose.

www.spartacogroup.com 800-860-6170
6
OPERATING INSTRUCTIONS
Compression
MAINTENANCE AND INSPECTION
1. Daily maintenance is required to ensure that the tool is kept in good working condition.
2. Do not store the tool in a humid environment.
3. Wipe away any excess oil with a soapy cloth.
4. Provided that maintenance of the tool is carried out regularly, the tool should provide
many years of service.
5. Should you experience any difficulty with the operation and maintenance of this tool,
contact Huskie’s technical support department at 1-800-860-6170.
1. Before connecting the tool head, make sure the pump and hose being used is working
properly, and adjusted to and rated at 10,000 psi. The use of a pump or hose not rated
at 10,000 psi working pressure may cause severe damage and result in personal injury.
2. Connect the tool head to the pump and hose, making sure all coupler connections are
secure. It is important that all connections are tight for tool to function properly.
3. Select appropriate compression die set for the connector and cable being used. The
“U” style Huskie HT-41 series dies are to be used with these tools
4. To insert the dies, depress the die release pin on the ram, and slide die into place. Then
lift release knob on top of “C” head and slide other die half in place. Be sure both die
halves are secure before operating the tool.
5. Position the connector between the dies and operate pump to hold connector in place.
Fully insert cable into the barrel of the connector and operate pump as described
in the pump operations manual until connector is fully crimped. For pumps that are
not equipped with a hold feature, connector and cable must be in alignment before
operating the pump.
6. Always be sure to keep couplers clean and caps in place when the tool is not being
used.

www.spartacogroup.com 800-860-6170
7
OPERATING INSTRUCTIONS
PRECAUTION FOR THE TOOL
1. Always point the tool AWAY from other people.
2. If the tool is stored for an extended period at a temperature of less than 25º F (-5ºC), the tool
should be allowed to return to room temperature to ensure smooth operation Use the tool only
after it has been at room temperature for 1 hour.
3. Do not drop the tool. Dropping the tool may damage the hydraulic circuit and result in the tool
not functioning correctly.
4. Keep the head and ram clean and free of debris. Solvents can be used to clean the head, but
should not be used on the plastic body. Use soap and water to clean the body.
5. Do not use tool for continous use. If any sign of over heating, allow the tool to cool for 15 mins.
6. Do not allow tool to be submerged in water. The tool may be used to in damp or wet
environments. However it is recommended for tool to be air-dried before use.
TROUBLESHOOTING FOR THE TOOL
1. Never operate tools without dies in place. Failure to insert dies before operation will
cause damage to the “C” frame and tool ram.
2. Never attempt to adjust pressure setting without the use of the proper test gauge.
Consult factory for proper adjusting procedure.
3. All manually operated hydraulic compression tools are equipped with our external re-
placeable bypass cartridge. These cartridges should not have to be replaced for 10,000
to 12,000 compressions.
4. Die hang up is common with all types of compression tools. Should this occur, the jaws
can easily be separated by holding the pump handle in the release position while pry-
ing the jaws apart. Never attempt to hit connector or tool jaw withhammer as this will
damage connector and tool.
5. If tool fails to advance upon receipt or after an extended period of storage, invert tool
and rap compression head sharply on ground. The suction valve check ball can become
stuck after extended storage or during shipment, not allowing the tool to advance.
6. Always clean tool after use to keep ram track clear of dirt and debris.

www.spartacogroup.com 800-860-6170
8
BREAKDOWN

www.spartacogroup.com 800-860-6170
9
PARTS LIST
1 2 X 12 Drive Pin (BW) 351-28 1
2 Die Release Knob 510-01B 1
3 Screw (16) 510-02 1
4 Spring (257) 510-03 1
5 Retainer Pin (A) 510-04 1
6 2.5 X 25 Drive Pin (BW) 410-04 1
7 Head 510HC-01B 1
8 Guide Screw 510A-15 1
9 M5 Lock Washer (Small) 510-12 1
10 Key 510A-06 1
11 Stopper 510HC-02 1
12 M4 Lock Washer 410-07 1
13 M4 X 10 Screw 410-06 1
14 Retainer Pin (B) 410-12 1
15 Spring (177) 410-01 1
16 2.5 X 14 Drive Pin (BW) 410-11 1
17 Ram 510HC-03 1
18 Die Release Pin 430-21 1
19 2.5 x 8 Dowel Pin (B) 410-17 1
20 P-42 Back-Up Ring (B.C.) 510-18 1
21 P-42 O-Ring (C.P.) HF-08 1
22 Spring Holder 510HC-04 1
23 Ram Spring (677) 510HC-05 1
24 Ram Spring Support 410-20 1
25 OV-36 Snap Ring 410-21 1
26 SER-48 Scraper 510-23 1
27 Cylinder 510HC-06 1
28 Adapter 3/8 PT-M. 3/8" PT-F." 430H-02 1
29 3/8 "NPT-NPT Nipple NPT-NI 1
30 Male Coupler P.H. Type RD-12 1
32 Grip 430H-03 1
33 Head Insulation 510B-33 1
NO.
DESCRIPTION
CODE
QTY.

www.spartacogroup.com 800-860-6170
10
NOTES

www.spartacogroup.com 800-860-6170
11
NOTES
