Desoutter EPB Series User manual

www.desouttertools.com
Part no 6159920260
Issue no 05
Date 04/2015
Page 1 / 76
EPB/EPBA stand-alone battery nutrunner
Model Part number Series
EPB8-1800-10S 6151659030 C
EPB8-1800-4Q 6151658990 C
EPB14-900-10S 6151659770 C
EPB14-900-4Q 6151659780 C
EPB17-700-10S 6151659010 B
EPB17-700-4Q 6151659050 B
EPBA8-1800-10S 6151659710 C
EPBA8-1800-4Q 6151659720 C
EPBA14-900-10S 6151659730 C
EPBA14-900-4Q 6151659740 C
EPBA17-700-10S 6151659750 B
EPBA17-700-4Q 6151659760 B
WARNING
WARNING
Read all safety warnings (including the ones of the separately provided safety
instructions n° 6159930690) and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.

24
AVERTISSEMENT
Lire l'ensemble des mises en garde de sécurité (y compris celles sur la notice de
sécurité n° 6159930690 fournie à part) ainsi que l'ensemble des consignes. Le non-
respect des mises en garde et des consignes peut entraîner un choc électrique, un
incendie ou des blessures graves.
Conserver l'ensemble des mises en garde et consignes pour pouvoir les consulter
ultérieurement.

26
ADVERTENCIA
Lea todas las advertencias de seguridad (incluyendo las contenidas en las
instrucciones de seguridad n° 6159930690 suministradas por separado) y las
instrucciones. El incumplimiento de las instrucciones y advertencias de seguridad
puede producir descargas eléctricas, incendios y/o lesiones personales graves.
Guarde todas las instrucciones y advertencias para futuras consultas.

28
WARNUNG
Alle Sicherheitshinweise (einschließlich der separat bereitgestellten
Sicherheitsvorschriften Nr. 6159930690) und alle Anweisungen lesen. Eine
Nichtbeachtung der Hinweise und Anweisungen kann zu Stromschlägen, Bränden
und/oder schweren Personenschäden führen.
Bewahren Sie alle Warnhinweise und Anweisungen zur künftigen Verwendung auf.

30
AVVERTENZA
Leggere tutti gli avvisi di sicurezza (inclusi quelli indicati sulle istruzioni di sicurezza
n. 6159930690 fornite separatamente) e tutte le indicazioni di sicurezza. Il mancato
rispetto degli avvisi e delle istruzioni può provocare scosse elettriche, incendi e/o
gravi lesioni.
Conservare tutti gli avvisi e le istruzioni per consultazioni future.

32

6159920260_05_
2 / 76 04/2015
ALERTA
Leia todas as instruções e avisos de segurança (inclusive as que são fornecidas
separadamente, n° 6159930690). A falha em seguir os avisos e instruções pode
resultar em choque elétrico, incêndio e/ou lesão grave.
Guarde todos os alertas e instruções para referência futura.

34
VAROITUS
Lue kaikki turvallisuusvaroitukset (mukaan lukien erikseen painetut
turvallisuusohjeet tiedotteessa nro 6159930690) ja kaikki ohjeet. Varoitusten
ja ohjeiden noudattamatta jättäminen voi johtaa sähköiskuun, tulipaloon ja/tai
vakavaan loukkaantumiseen.
Säilytä kaikki varoitukset ja ohjeet myöhempää tarvetta varten.

36
VARNING
Läs alla säkerhetsvarningar (inklusive dem i de de separata, medföljande
säkerhetsinstruktionerna nr. 6159930690) och alla instruktioner. Underlåtenhet att
följa alla varningar och instruktioner kan leda till en elektrisk stöt, eldsvåda och/eller
svåra personskador.
Spara alla varningar och instruktioner för framtida bruk.

38
ADVARSEL
Les alle sikkerhetsadvarsler (inkludert de i de separate medfølgende
sikkerhetsanvisningene nr. 6159930690) og alle instruksjoner. Om man ikke følger
advarslene eller anvisningene, kan det føre til elektrisk støt, brann og/eller alvorlige
personskader.
Ta vare på alle advarsler og anvisninger for fremtidig bruk.

40
ADVARSEL
Læs alle sikkerhedsadvarsler (også dem i den separate sikkerhedsanvisning nr.
6159930690) og alle anvisninger. Hvis disse advarsler og anvisninger ikke følges,
kan det medføre elektrisk stød, brand og/eller alvorlig tilskadekomst.
Gem alle advarsler og anvisninger til senere brug.

42
WAARSCHUWING
Lees alle veiligheidswaarschuwingen (inclusief de waarschuwingen die afzonderlijk
worden verstrekt in de veiligheidsinstructies met onderdeelnummer 6159930690)
en alle overige instructies. Indien u de de waarschuwingen en de instructies niet
opvolgt, kan dit leiden tot een elektrische schok, brand en/of ernstig lichamelijk
letsel.
Bewaar alle waarschuwingen en instructies, zodat u ze op en later tijdstip kunt
raadplegen.

44
ΠΡΟΕΙΔΟΠΟΙΗΣΗ
Διαβάστε όλες τις προειδοποιήσεις ασφαλείας (συμπεριλαμβανομένων εκείνων των
ξεχωριστά παρεχόμενων οδηγιών ασφαλείας αρ. 6159930690) και όλες τις οδηγίες.
Σε περίπτωση που δεν ακολουθήσετε τις προειδοποιήσεις και τις οδηγίες ενδέχεται
να προκληθεί ηλεκτροπληξία, πυρκαγιά ή/ και σοβαρός τραυματισμός.
Φυλάξτε όλες τις προειδοποιήσεις και τις οδηγίες για να ανατρέξετε μελλοντικά σε
αυτές.

46
警告
阅读所有安全警告（包括那些单独提供的安全说明 n° 6159930690）和所有说明。
未能遵守这些警告和说明可能会导致触电、火灾和/或严重伤害。
妥善保存所有警告和说明，以备将来参考。

48
FIGYELEM
Olvassa el az összes biztonsági (beleértve a különálló, n° 6159930690
számú biztonsági útmutató utasításait) és az összes használati utasítást. A
gyelmeztetések és utasítások gyelmen kívül hagyása áramütést, tűzveszélyt és/
vagy súlyos személyi sérülést okozhat.
Olvassa el és őrizze meg az összes gyelmeztetést és utasítást későbbi
hivatkozásra.

50

6159920260_05_
4 / 76 04/2015
TECHNICAL DATA
Model Part number Ouput
Torque
(18V 2.1Ah minimum) Rotational max. speed Weight
*Voltage
Min. Nominal Max. 36V
battery 18V battery
Nm rpm kg V
EPB8-1800-10S 6151659030 Sq. 3/8” 1.5 7 8 1,800 1,000 1 18/36
EPB8-1800-4Q 6151658990 Hex 1/4” 1.5 7 8 1,800 1000 1 18/36
EPB14-900-10S 6151659770 Sq. 3/8” 4 12 14 900 540 1 18/36
EPB14-900-4Q 6151659780 Hex 1/4” 4 12 14 900 540 1 18/36
EPB17-700-10S 6151659010 Sq. 3/8” 7 15 17 700 400 1 18/36
EPB17-700-4Q 6151659050 Hex 1/4” 7 15 17 700 400 1 18/36
EPBA8-1800-10S 6151659710 Sq. 3/8” 1.5 7 8 1,800 1,000 1 18/36
EPBA8-1800-4Q 6151659720 Hex 1/4” 1.5 7 8 1,800 1,000 1 18/36
EPBA14-900-10S 6151659730 Sq. 3/8” 4 12 14 900 540 1 18/36
EPBA14-900-4Q 6151659740 Hex 1/4” 4 12 14 900 540 1 18/36
EPBA17-700-10S 6151659750 Sq. 3/8” 7 15 17 700 400 1 18/36
EPBA17-700-4Q 6151659760 Hex 1/4” 7 15 17 700 400 1 18/36
* without battery pack
Battery pack 18V 2.1Ah: 385 g
Battery pack 36V 2.1Ah: 645 g
IDENTIFICATION
Serial no.:XXBXXXXX
Product number
Year
Series
B
Tool
part number
Tool model
Manufacturing
date
Tool speed

6159920260_05_
5 / 7604/2015
Find more information and your Desoutter contacts on:
www.desouttertools.com
DIMENSIONING
Model Part number L A B C
mm in. mm in. mm in. mm in.
All models - 227 8.94 32 1.26 206 8.11 38 1.50
C
L
B
A
Software and documentation available at:
http://resource-center.desouttertools.com

6159920260_05_
6 / 76 04/2015
ATOOL DESCRIPTION
CB LEDS COLOR CODESCREEN AND BUTTONS
3
4
7
2
1
5
6
1
4
2
3
1 2 3

6159920260_05_
7 / 7604/2015
ACCESSORIES INCLUDED
PROTECTIVE COVER
Part number: 6152110220
1
2
OPTIONAL ACCESSORIES
SIDE HANDLE
Part number: 6153970160
Assy
by Hand

6159920260_05_
8 / 76 04/2015
GENERAL VIEW
A
C
U
T
S
N
B
R
Q
D
C
Loctite 243
A
+/- 15%
50 Nm
A
3 mm³
0.8 Nm
0.35 Nm
15 Nm
Assy
by Hand

6159920260_05_
9 / 7604/2015
GENERAL VIEW
U
F
H
V
G
H
L
E
E
K
I
P
P
Loctite 243
A
+/- 15%
A
9 mm³
2.5 Nm
A
6 mm³
4 Nm
0.8 Nm
0.8 Nm
Assy
by Hand

6159920260_05_
10 / 76 04/2015
Gearbox kits - 4Q
A
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
A Gearbox EPB8 kit 6153984945 1 1 X
A Gearbox EPB14 kit 6153988495 1 1 X
A Gearbox EPB17 kit 6153984965 1 1 X
A1 Gear ring 6154760980 1 1 1 1 1 1 X
A2 Insertion ring kit 6153986220 1 1 1 1 1 1 X
Insertion ring - 2 2 2 2 2 2
Snap ring - 1 1 1 1 1 1
A3
A3
A1
A4
A4
A4
A3
A4
A2
A7
A5
A5
A51
A51
A51
A5
A7
A7
A6

6159920260_05_
11 / 7604/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
A3 Housing front kit 6153986230 1 1 1 1 1 1 X
Housing front - 1 1 1 1 1 1
Spacer 30.6X25.5X3.95 - 1 1 1 1 1 1
O-ring - 111111
A4 Gearbox service kit 6153986240 1 1 1 1 1 1 X
Bearing - 1 1 1 1 1 1
Circlip - 1 1 1 1 1 1
Circlip - 1 1 1 1 1 1
O-ring 25X1 - 222222
Satellite protection ring - 1 1 1 1 1 1
A5 Output stage kit 6153986250 1 1 X
Output shaft R4 - 1 1
Bearing roller - 5 5
A5 Output stage kit 6153986260 1 1 1 1 X
Output shaft R5 - 1 1 1 1
Needle roller - 3 3 3 3
A51 Output planet kit 6154701625 1 1 X
Bearing - 5 5
Planet wheel short 12T - 5 5
A51 Output planet kit 6154701350 1 1 1 1 X
Satellite 14 T - 2nd stage - 3 3 3 3
A6 Quick change kit 6153969685 1 1 1 1 1 1 X
Spring - 1 1 1 1 1 1
Ring - 1 1 1 1 1 1
Locking ring - 1 1 1 1 1 1
Ball - 1 1 1 1 1 1
Sleeve - 1 1 1 1 1 1
A7 1st stage kit 6154752205 1 1 X
Carrier 1st stage - 1 1
Bearing roller - 3 3
Bearing - 3 3
Planet wheel short 12T - 3 3
A7 1st stage kit 6154752195 1 1 X
Carrier 1st stage 1 1
Bearing roller 3 3
Bearing 3 3
Planet wheel short 14T 3 3
A7 1st stage kit 6153986280 1 1 X
1st stage carrier R6.8 - 1 1
Bearing roller - 3 3
Bearing - 3 3
Planet wheel short 16T - 3 3

6159920260_05_
12 / 76 04/2015
Gearbox kit - 10S
A
A3
A3
A1
A4
A4
A4
A3
A4
A2
A7
A5
A5
A51
A52
A7
A5
A51
A52
A7
A51
A52
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
A Gearbox EPB8 kit 6153984935 1 1 X
A Gearbox EPB14 kit 6153988485 1 1 X
A Gearbox EPB17 kit 6153984955 1 1 X
A1 Gear ring 6154760980 1 1 1 1 1 1 X
A2 Insertion ring kit 6153986220 1 1 1 1 1 1 X
Insertion ring - 2 2 2 2 2 2
Snap ring - 1 1 1 1 1 1

6159920260_05_
13 / 7604/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
A3 Housing fro nt kit 6153986230 1 1 1 1 1 1 X
Housing front - 1 1 1 1 1 1
Spacer 30.6X25.5X3.95 - 1 1 1 1 1 1
O-ring - 111111
A4 Gearbox service kit 6153986240 1 1 1 1 1 1 X
Bearing - 1 1 1 1 1 1
Circlip - 1 1 1 1 1 1
Circlip - 1 1 1 1 1 1
O-ring 25X1 - 222222
Satellite protection ring - 1 1 1 1 1 1
A5 Output stage kit 6153986290 1 1 1 1 X
Output shaft 3/8 R4 - 1 1 1 1
Bearing roller - 5 5 5 5
A5 Output stage kit 6153986300 1 1 1 1 X
Output shaft 3/8 R5 - 1 1 1 1
Needle roller - 3 3 3 3
A52 Socket retention kit 6153976610 1 1 1 1 1 1 X
Retaining pin spring - 1 1 1 1 1 1
Retaining pin - 1 1 1 1 1 1
Pin - 1 1 1 1 1 1
A51 Output planet kit 6154701625 1 1 X
Bearing - 5 5
Planet wheel short 12T - 5 5
A51 Output planet kit 6154701350 1 1 1 1 X
Satellite 14 T - 2nd stage - 3 3 3 3
A7 1st stage kit 6154752205 1 1 X
Carrier 1st stage - 1 1
Bearing roller - 3 3
Bearing - 3 3
Planet wheel short 12T - 3 3
A7 1st stage kit 6154752195 1 1 X
Carrier 1st stage 1 1
Bearing roller 3 3
Bearing 3 3
Planet wheel short 14T 3 3
A7 1st stage kit 6153986280 1 1 X
1st stage carrier R6.8 - 1 1
Bearing roller - 3 3
Bearing - 3 3
Planet wheel short 16T - 3 3

6159920260_05_
14 / 76 04/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
B Display kit 6153984435 1 1 1 1 1 1 1 1 1 1 1 1 X
Display and buttons module - 1 1 1 1 1 1 1 1 1 1 1 1
Screw - 444444444444
B1 Housing display kit 6153986310 1 1 1 1 1 1 1 1 1 1 1 1
Housing display - 1 1 1 1 1 1 1 1 1 1 1 1
Screen protection - 1 1 1 1 1 1 1 1 1 1 1 1
Sticker protection - 1 1 1 1 1 1 1 1 1 1 1 1
B2 Display service kit 6153986320 1 1 1 1 1 1 1 1 1 1 1 1 X
Screw TORX M2 - 555555555555
B3 Buttons with screen seal
kit 6153100750 1 1 1 1 1 1 1 1 1 1 1 1 X
Buttons with screen seal - 1 1 1 1 1 1 1 1 1 1 1 1
B4 Display board kit 6159190175 1 1 1 1 1 1 1 1 1 1 1 1 X
Display board - 1 1 1 1 1 1 1 1 1 1 1 1
Display kit
B
B2
B1
B4
B3
B

6159920260_05_
15 / 7604/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
D Front LED PCB kit 6153986340 1 1 1 1 1 1 1 1 1 1 1 1 X
Board - 111111111111
Housing module - 1 1 1 1 1 1 1 1 1 1 1 1
Screw TORX M2 - 111111111111
Front LED PCB kit
D
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
C Cover plate kit 6153986330 1 1 1 1 1 1 1 1 1 1 1 1 X
Guide light - 2 2 2 2 2 2 2 2 2 2 2 2
Cover plate - 2 2 2 2 2 2 2 2 2 2 2 2
Cover plate kit
C

6159920260_05_
16 / 76 04/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
E Reverse button kit 6153986350 1 1 1 1 1 1 1 1 1 1 1 1 X
Spacer reverse - 1 1 1 1 1 1 1 1 1 1 1 1
Washer - 111111111111
Reverse female magnet
assy - 111111111111
Reverse male - 1 1 1 1 1 1 1 1 1 1 1 1
Reverse button kit
E
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
F Feature button kit 6153985265 1 1 1 1 1 1 1 1 1 1 1 1 X
Button function magnet
assy - 111111111111
Spring cylindrical - 1 1 1 1 1 1 1 1 1 1 1 1
Bearing needle - 1 1 1 1 1 1 1 1 1 1 1 1
Feature button kit
F

6159920260_05_
17 / 7604/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
G Connector kit 6153986360 1 1 1 1 1 1 1 1 1 1 1 1 X
Cover - 111111111111
Housing - 111111111111
Screw TORX M3 - 222222222222
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
H Footprint kit 6153986370 1 1 1 1 1 1 1 1 1 1 1 1 X
Footprint - 1 1 1 1 1 1 1 1 1 1 1 1
Spacer - 444444444444
Screw TORX M4 - 444444444444
Threaded insert - 2 2 2 2 2 2 2 2 2 2 2 2
Connector kit
Footprint kit
G
H

6159920260_05_
18 / 76 04/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
I Handle kit 6153986380 1 1 1 1 1 1 1 1 1 1 1 1 X
Handle magnet assy - 1 1 1 1 1 1 1 1 1 1 1 1
Warning label - 1 1 1 1 1 1 1 1 1 1 1 1
Screw HEX M4 - 6 6 6 6 6 6 6 6 6 6 6 6
Spacer - 666666666666
Spacer - 444444444444
Threaded insert - 2 2 2 2 2 2 2 2 2 2 2 2
Handle kit
I
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
K Trigger kit 6153984995 1 1 1 1 1 1 1 1 1 1 1 1 X
Trigger assy - 1 1 1 1 1 1 1 1 1 1 1 1
Pin - 222222222222
Trigger kit
K

6159920260_05_
19 / 7604/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
LPCB main to display
cable kit 6159175790 1 1 1 1 1 1 1 1 1 1 1 1 X
Cable - 111111111111
Cable tie - 1 1 1 1 1 1 1 1 1 1 1 1
PCB main to display cable kit
L
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
N Speaker kit 6153984975 1 1 1 1 X
Speaker assy - 1 1 1 1
O-ring - 1111
Cable tie - 1 1 1 1
Speaker kit
N

6159920260_05_
20 / 76 04/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
P EPB PCB tool module kit 6153987210 1 1 1 1 1 1 X
PCB main & cover assy - 1 1 1 1 1 1
Cable tie - 1 1 1 1 1 1
O-ring - 222222
Firmware - 1 1 1 1 1 1
PEPBA PCB tool module
kit 6153988280 1 1 1 1 1 1 X
PCB main & cover assy - 1 1 1 1 1 1
Cable tie - 1 1 1 1 1 1
O-ring - 222222
Firmware - 1 1 1 1 1 1
P1 Bumpers kit 6153986400 1 1 1 1 1 1 1 1 1 1 1 1 X
Bumper top - 1 1 1 1 1 1 1 1 1 1 1 1
Bumper bottom - 1 1 1 1 1 1 1 1 1 1 1 1
O-ring - 111111111111
PCB main kit
P
P1
P
P1

6159920260_05_
21 / 7604/2015
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
Q Transducer kit 6155961815 1 1 1 1 X
Transducer - 1 1 1 1
Q Transducer kit 6155680225 1 1 1 1 1 1 1 1 X
Transducer - 1 1 1 1 1 1 1 1
Transducer kit
Q
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
R Motor coupling sleeve kit 6153977265 1 1 1 1 X
R Motor coupling sleeve kit 6153977275 1 1 1 1 X
R Motor coupling sleeve kit 6153977255 1 1 1 1 X
Motor coupling sleeve kit
R
EPB8-1800-10S EPB8-1800-4Q EPB14-900-10S EPB14-900-4Q EPB17-700-10S EPB17-700-4Q EPBA8-1800-10S EPBA8-1800-4Q EPBA14-900-10S EPBA14-900-4Q EPBA17-700-10S EPBA17-700-4Q
High Medium Low
Item Description Part number Qty Wear
S Motor board kit 6159190975 1 1 1 1 1 1 1 1 1 1 1 1 X
Board - 111111111111
Screw TORX M2 - 222111111111
Motor board kit
S
