Speco OS103T User manual

Quick Start Guide
OS103T
IP Encoder

1Warnings
■ If the product does not work properly, please contact the dealer or
where the product was purchased. Speco Technologies is not
responsible for any problems caused by improper operation or repair.
■ Keep away from liquid while in use.
■ All installation and operation here should conform to local
electrical safety codes.
■ Do not use the device beyond specified voltage range.
■ Do not drop it or subject it to physical shock.
■ Do not place it in extremely hot or cold (the operating temperature
shall be -20˚C~55˚C), dusty and damp locations. D o not exp ose
it to high ly electromagnetic radiation.
■ To avoid heat accumulation, good ventilation is required for
operating environment.
Package
2
1

Overview
3 Overview
3
● Front Panel
1 2 3 4 5 6 7 8
2
TF
RESET
VIDEO IN
Audio
PWR
+ -
IN
OUT
DC12V OUT
Device Quick Start Guide CD
Plastic plug ×4
4 tapping screws PA 4×25

1
2
3
4
5
6
7
8
Micro SD card slot
Reset
Video input (TVI/Analog)
Ground
Audio input
Audio output
Power indicator
DC12V power output
● Rear Panel
1
1
2
2
3
3
4
4
5
5
6
6
PoE network interface
Analog video output
Alarm output
Alarm input
RS 485 interface
DC12V power input
3

TVI /Analog camera
Sound pickup
DC12V
Loudspeaker
PTZ
Monitor
Sensor Alarm out
LAN/
WAN
Web Operation and Login
5
● Operation
IP Scanner can search for the device on the local network.
① Make sure that the IP encoder and the PC are connected to the
same local network. The IP encoder is set to DHCP by default.
② Install IP Scanner from the CD and run it after installation.
4

③ In the device list, you can view the IP address, model number, and
MAC address of each device. Select the applicable device and double
click to open up the web viewer. You can also manually enter the IP
address in the address bar of the web browser.
The login interface is shown above. Default user name is admin and
password is 1234. After logging in, follow directions to install
applicable plugins.
5
OS 10 3 T
