Speco 650Line Intensifier3 HTINTB8G User manual

INSTRUCTION
MANUAL
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 6/20/2012
HTINTB8G / HTINTB8GW
HTINTB10G / HTINTB10GW
650Line Intensifier3™

Contents
1
◑
Contents...................................................... 1
◑
Precautions ................................................. 2, 3
◑
Safety Instructions ...................................... 4
◑
Package Contents....................................... 5
◑
Camera Installation ..................................... 6-8
◑
Specications.............................................. 9
◑
Camera Dimension ..................................... 10
◑
Features...................................................... 11,12
◑
OSD Menu Details ...................................... 13-24
◑
Trouble Shooting......................................... 25

2
Precautions
Do not install the camera in
extreme temperature conditions.
Do not touch the front lens of the
camera.
Never keep the camera pointed
directly at strong light.
Do not expose the camera to
radioactivity.
Do not install the camera under
unstable lighting conditions.
Do not drop the camera or subject
it to physical shocks.
Only use the camera under conditions
where temperatures are between
-10°C and +50°C. Be especially careful to provide
ventilation when operating under high
temperatures.
This is one of the most important parts of the
camera. Be careful not to leave
fingerprints on the lens cover.
It can cause malfunctions to occur. If exposed to radioactivity the CCD
will fail.
Severe lighting change or flicker can
cause the camera to work improperly.
Housing damage can compromise
weatherproof ratings.
NOTE
* If the camera is exposed to spotlight or object reflecting strong light,
smear or blooming may occur.
* please check that the power satisfies the normal specification before
connecting the camera.

3
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
their own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
This installation should be made by a qualified service person and
should conform to all local codes.
CAUTION : To prevent electric shock and risk of fire hazards:
☞Do NOT use power sources other than those specified.

4
Safety Instructions
Precautions for use
Please handle this camera carefully :
◑ This camera should be installed by qualied personnel only
◑There are no user serviceable parts inside
◑Do not disassemble this camera other than to make initial adjustments
◑Use a UL approved regulated 24 volt AC or 12 volt DC power supply
◑
Use appropriate low voltage power cable to prevent re or electrical shock
◑
Please insure that your installation area can support the weight of the camera
◑Do not use a strong or abrasive detergent when cleaning the camera
◑Do not install near cooling or heating device

5
Package Contents
Please make sure that the following items are included in the Package:
1) HTINTB8G, HTINTB8GW, HTINTB10G, HTINTB10GW
• 1 Video Test Connector, Power Jack
• 1 Bracket Base
• 2 Wrenches
• Set Screw
- 4 Tapping Screws 4x25
- 4 Hexagon Socket Screws M5x10

6
CAMERA INSTALLATION
jvuulj{Gwv~lyGjhislG
XUG~oluG|zpunGXYG}vs{zGkjGOGG\WWGhPG
YUG~oluG|zpunGY[G}vs{zGhjGO[WG}GhP
ZUGjvuulj{G}pklvGjhislG
Tjvuulj{GiujGjhislG{vG{olGiujGqhjrUG
[UGjvuulj{GhGGOy GP
TjGORGSGjvtPGGwGGGOTUGjvtPGG
uGGGlGhGkGGtG
kGG˄vu˅GGGU
kjGXY}GwGz
wGpGaylk
jGaGORP
ishjraOTP
ylkORP
wGz
hjGY[}
R
T
jvtG
hGvG
wGhGkG
uGhGk

7
CAMERA INSTALLATION
Compatibility
1. HTINTB8G, HTINTB8GW, HTINTB10G, HTINTB10GW
CVCJBB INTJBS INTCM

CAMERA INSTALLATION
8
1. HTINTB8G, HTINTB8GW, HTINTB10G, HTINTB10GW
CAMERA ASSEMBLY
HEXAGON SOCKET SCREW M5X10, 4EA
TAPPING SCREW 4X25, 4EA
BASE ADAPTOR BRACKET

9
650 Line Intensifier3
(Weatherproof Bullet Camera with mount plate)
DC Auto Iris Varifocal Lens 2.8-12mm / 9-22mm
HTINTB8G / HTINTB8GW
(2.8-12mm)
HTINTB10G / HTINTB10GW
(9-22mm)
■
■
SPECIFICATIONS
MODEL HTINTB8G / HTINTB10G
1/3” Sony Super HAD ll CCD
NTSC, PAL
NTSC=811(H) * 508(V) / PAL=795(H) * 596(V)
NTSC=768(H) * 494(V) / PAL=752(H) * 582(V)
NTSC=15.734KHz(H) & 59.94Hz(V) / PAL=15.625KHz(H) & 50.00Hz(V)
2:1 Interlace
Internal
650TV Lines
CDS OFF: 0.15 Lux, CDS ON: 0.00002 Lux
More than 52dB
CVBS: 1.0Vp-p / 75Ω
NTSC=(1/60sec~1/120,000sec) / PAL=(1/50sec~1/120,000sec)
Available
On / Off (Level adjustable)
BLC / HLC / OFF
Color / BW / AUTO
Low / High / Off
ATW / Outdoor / Indoor / Manual / AWC (1,700°K ~ 11,000°K)
Auto / Off (Selectable x2 ~ x512)
On / Off (8 Programmable Zones)
On / Off (12 Programmable Zones)
On / Off (Level adjustable)
On / Off (x1 ~ x16)
On / Off
On / Off (Level adjustable)
On / Off
DC 12V / AC24V(Dual Voltage)
Heater ON (Below 50F) – DC12V 220mA, AC24V 110mA
Heater OFF (Above 50F) – DC12V 160mA, AC24V 85mA
Glacier Heaters – DC12V 740mA, AC24V 375mA
Maximum power consumption – DC12V 800mA, AC24V 400mA (Heaters ON, Glacier Heaters ON)
DC Auto Iris Varifocal Lens 2.8-12mm / 9-22mm
-4ºF~+140ºF RH 95% Max / -40ºF with Glacier Heaters
-4ºF~+140ºF RH 95% Max
3.46"(W) * 4.01"(H) * 11.02"(D)
3 lbs
Image Pick-Up Device
TV System
Total Pixels
Effective Pixels
Scanning Frequency
Scanning System
Synchronization
Resolution
Minimum Illumination
S/N Ratio
Video Output
Electronic Shutter Speed
OSD
WDR
BLC
Day & Night
Gain Control
White Balance
Intensify
Motion Detection
Privacy Masking
SPECO DNR
Digital Zoom
DIS (Digital Image Stabilization)
Sharpness
Flip / Mirror
Power Supply
Power Consumption
Lens
Operational Temp.
Storage Temp.
Dimension
Weight
Automatic Thermostatic Sensor

10
CAMERA DIMENSION
1) HTINTB8G, HTINTB8GW, HTINTB10G, HTINTB10GW
3.46”
4.01”
3.11”
3.89” dia
11.02”
5.90”
5.03”
10.51”

11
FEATURES
Now with “PRESETS”
PRESETS (Outdoor, Indoor, Elevator, Lobby, Hallway & Low Light)
Used for a quick and easy setup for the installation environment.
650TVL Resolution
Horizontal resolution of 650 TV lines is achieved by using a
SONY Super-HAD CCD with 410,000 pixels, and a custom DSP
yielding pictures with a high S/N ratio.
INTENSIFIER 3
More Powerful Performance in low light condition.
High quality Pictures to be captured in very low light condition.
WDR
More Powerful WDR in strong back lighting.
Your camera allows you to get a clear image.
SPECO DNR
The Intensier camera has a DSP chip that can remove image
noise efciently showing clean images in low light conditions.
HLC (High Light Compensation)
This function reverses bright spots in the picture (such as
headlights). This enables the entire system to do a better job of
resolving and displaying grayscale information such as a
license plate.

12
FEATURES
Motion Detection with Alarm Output
Built in motion detector with adjustable areas of coverage will
Send a signal to an external alarm device when motion is detected.
PRIVACY MASK
It also has the ability to mask up to 8 areas of the picture where
Viewing is not desired. Each zone can be independently
programmed via the OSD
STABILIZER
This function removes image jitter that is caused by vibrations in
the building and reduces the amount of hard drive space.
DIGITAL ZOOM
The picture could be enlarged by this function in digital.
DAY/NIGHT
The Intensier camera can show color pictures in all lighting
conditions, or you can have it automatically switch to a B/W
picture in low light conditions
OSD
All camera functions are menu driven for easy use.
Automatic Thermostatic Sensor

13
●
Menu Setup
●
Lens Setting
1. Press the Function Setup switch.
- Main setup menu is displayed on the monitor screen.
1. Preset :
INDOOR / OUTDOOR / LOW LIGHT / HALLWAY / LOBBY / ELEVATOR.
- Used for a quick and easy setup for the installation environment.
Using this function, you can control the screen brightness.
1. When the SETUP menu screen is displayed, select 'LENS' by using
the Function Setup switch so that the arrow indicates 'LENS'.
2. DC : You can adjust the minimum shutter and maximum value of ESC
shutter mode.
2. Select a desired function using the Function Setup switch.
- Place the cursor over a desired item.
3. Set up a selected item by using the Function Setup switch.
4.
To finish the setting, select 'RETURN' and press the Function Setup switch.
●
Preset Mode
SPECO TECH
1.PRESET MODE
2.MAIN SETUP
3.EXIT
INDOOR
RESET
MAIN SETUP
1.LENS
2.EXPOSURE
3.WHITE BAL
4.WDR
5.BACKLIGHT
6.SPECO DNR
7.DAY/NIGHT
8.SPECIAL
9.RETURN
DC
ATW
OFF
OFF
ON
AUTO
SAVE
☞ NOTE
■ An item with the
◀
icon also has sub menus. To select a sub menu, select an item
with the icon and press the Function Setup switch.
■ An item with the - - - icon is unavailable due to function settings.

14
3. THE Lens mode has sub menu items as listed below.
- BRIGHTNESS : Adjusts the video brightness.
-
FOCUS ADJ : To adjust the DC lens focus correctly, you must activate the
Focus Settings mode under each lens menu. Activate the Focus Settings
mode, adjust the lens focus, and then deactivate the settings mode.
☞ NOTE
■ If color rolling occurs when using a DC lens, set Shutter to Fixed (---).
●
Exposure Setting
1. When the SETUP menu screen is displayed, select 'EXPOSURE' by
using the Function Setup Switch.
2. Select a desired mode using the Function Setup switch.
◆ SHUTTER : You can select either auto or manual shutter.
* --- : Shutter speed is fixed at 1/60sec(1/50sec)
* ESC : Select this to control the shutter speed automatically. If ESC is
selected, the shutter speed is automatically controlled depending
on the ambient illumination of the subject.
* MANUAL : You can control shutter speed manually.
(NTSC MODEL : 1/60~1/120,000, PAL MODEL : 1/50~1/120,000)
* A.FLK : Select this when you see picture flicker, this can happen when the
frequency of the local lighting clashes with the camera.
MAIN SETUP
1.LENS
2.EXPOSURE
3.WHITE BAL
DC
ATW
EXPOSURE SETUP
1.BRIGHTNESS
2.SHUTTER
3.AGC
4.INTENSIFY
5.RETURN
25
- - -
HIGH
OFF
MAIN SETUP
1.LENS
2.EXPOSURE
3.WHITE BAL
DC
ATW

15
◆
AGC(AUTO GAIN CONTROL) : The higher the gain level, the brighter the screen
- but the higher the noise.
* OFF : Deactivates the AGC function.
* LOW : Allows automatic gain control from 5.3dB to 32dB.
* HIGH : Allows automatic gain control from 5.3dB to 37dB.
◆
INTENSIFY : When it is night or dark, the camera automatically detects the
light level and maintains a clear picture if this mode is activated.
* OFF : Deactivates the INTENSIFY function.
* AUTO : Activates the INTENSIFY function.
◆
RETURN : Select this to save the changes in the EXPOSURE menu and return
to the SETUP menu.
☞ NOTE
■ If you press the Function Setup switch to ‘AUTO’ mode, you can adjust brightness by
increasing or decreasing the shutter speed. (x2 ~ x512)
■ Note that the higher the zoom level, the brighter the screen, but the more likely there
will be a ghosting effect.
■ It is normal for Noise, Spots and Whitish symptoms to appear in INTENSIFY mode
when the D-ZOOM level is increased.
●
White Balance (White Bal) Setting
Use the White Balance function to adjust the screen color.
1. When the SETUP menu screen is displayed, select 'White Bal' by using the
Function Setup switch so that the arrow indicates 'White Bal'.
2. Select a desired mode using the Function Setup switch.
MAIN SETUP
1.LENS
2.EXPOSURE
3.WHITE BAL
DC
ATW
☞ NOTE
■ When the SHUTTER is set to MANUAL or A.FLK mode, INTENSIFY will be disabled.

16
※ Select one of the following 5 modes, as appropriate for your purpose.
◆
ATW : Select this when the color temperature is between 1,700˚K and 11,000˚K.
◆
OUTDOOR : Select this when the color temperature is between 1,700˚K and 11,000˚K.
(sodium light inclusion)
◆
INDOOR : Select this when the color temperature is between 4,500˚K and 8,500˚K.
◆
MANUAL : Select this to fine-tune White Balance manually. Set White Balance first
by using the ATW or AWC mode. After that switch to MANUAL mode,
fine-tune the White Balance and then press the Function Setup switch.
◆
AWC→SET : To find the optimal luminance level for the current environment, point
the camera towards a sheet of white paper and press the Function
Setup switch. If the environment changes, readjust it.
☞ NOTE
■ White Balance may not work properly under the following conditions. In this case
select the AWC mode.
① When the color temperature of the environment surrounding the subject is out of the
control range (e.g. clear sky or sunset).
② When the ambient illumination of the subject is dim.
③ If the camera is directed towards a uorescent light or is installed in a place where
illumination changes dramatically, the White Balance operation may become unstable.
●
WDR Setting
WDR illuminates darker spots of an image while retaining the same light
level for brighter spots to even out the overall brightness of images with
high contrast between bright and dark spots.
MAIN SETUP
1.LENS
2.EXPOSURE
3.WHITE BAL
4.WDR
DC
ATW
OFF
1. When the SETUP menu screen is displayed, select 'WDR' by using the
switch so that the arrow indicates 'WDR'.
2. Use the switch to change the WDR level according to the contrast
between bright and dark areas.

17
●
Backlight Setting
Unlike conventional cameras, the 650Line Intensifier3™ Series are designed to
deliver a distinctive subject and background at the same time, even when the
subject is backlight, by using the features of the proprietary W-V DSP chip.
1. When the SETUP menu screen is displayed, select 'BACKLIGHT' by using
the Function Setup switch so that the arrow indicates 'BACKLIGHT'.
2. Select a desired mode using the Function Setup switch.
◆
BLC : Enables a user to directly select a desired area from a picture, and to view
the area more clearly.
◆
HLC (High Light Compensation) : If the scene contains extremely bright light areas
such as; from car headlights, the light can mask out much of the on-screen detail
-
LEVEL : Adjust level of the HLC function.
-
LIMIT : Enable to change the operating condition.
-
MASK COLOR/TONE : Change the color / transparency of the masking area.
(Black, Red, Blue, Cyan, Magenta)
-
TOP/BOTTOM/LEFT/RIGHT : Adjust the area to be enhanced
◆
OFF : Not being used
3.
Select a desired mode using the Function Setup switch and press the Function Setup switch.
◆
Select 'BLC' to adjust the area to be enhanced then adjust the level.
MAIN SETUP
1.LENS
2.EXPOSURE
3.WHITE BAL
4.WDR
5.BACKLIGHT
6.SPECO DNR
7.DAY/NIGHT
8.SPECIAL
9.RETURN
DC
ATW
OFF
OFF
ON
AUTO
SAVE

18
BLC SETUP HLC SETUP
Press Set to Return
Press Set to Return
LEVEL
TOP
BOTTOM
LEFT
RIGHT
LEVEL
LIMITS
MASK COLOR
MASK TONE
TOP
BOTTOM
LEFT
RIGHT
LOW
38
109
54
121
MIDDLE
NIGHT ONLY
BLACK
1
5
120
5
172
☞ NOTE
■
Because there can be a difference in the effectiveness of HLC according to the amount
of light area in the screen, optimize the installation angle for the best HLC performance.
■
When dark, the HLC is only activated when a bright light exceeding a specic size in
NIGHT ONLY mode.
■
The HLC is not activated in day light or when bright light is not present at night in NIGHT
ONLY mode.
■
BLC Function doesn't work in the B/W mode of the DAY/NIGHT menu.
●
SPECO DNR Setting
This function reduces the background noise in a low luminance environment.
1. When the SETUP menu screen is displayed, select 'SPECO DNR' by using the
Function Setup switch so that the arrow indicates 'SPECO DNR'.
2. Select a desired mode using the Function Setup switch.
◆
OFF : Deactivates SPECO DNR. Noise is not reduced.
◆
ON : Activates SPECO DNR so that noise is reduced.
MAIN SETUP
1.LENS
2.EXPOSURE
3.WHITE BAL
4.WDR
5.BACKLIGHT
6.SPECO DNR
7.DAY/NIGHT
8.SPECIAL
9.RETURN
DC
ATW
OFF
OFF
ON
AUTO
SAVE

19
3. Set the SPECO DNR mode to 'ON' and press the Function Setup switch. Then
you can adjust the noise reduction level.
☞ NOTE
■
You cannot set the SPECO DNR to ‘ON’ or ‘OFF’ when the AGC mode of the EXPOSURE menu is ‘OFF’.
■
When adjusting the noise reduction level in the SPECO DNR mode, remember that the higher
the level set, the more the noise level will be reduced, as will the brightness of the image.
●
Day/Night Setting
You can display pictures in color or black and white.
1. When the SETUP menu screen is displayed, select 'DAY/NIGHT'by using the
Function Setup switch so that the arrow indicates 'DAY/NIGHT'.
MAIN SETUP
1.LENS
2.EXPOSURE
3.WHITE BAL
4.WDR
5.BACKLIGHT
6.SPECO DNR
7.DAY/NIGHT
8.SPECIAL
9.RETURN
DC
ATW
OFF
OFF
ON
AUTO
SAVE
2. Select a desired mode using the Function Setup Switch according to the
picture display you want.
◆
COLOR : The picture is always displayed in color.
◆
B/W : The picture is always displayed in black and white.
- BURST MODE : You can turn on or off the burst
signal on B/W mode.
B/W MODE SETUP
1.BURST MODE
2.RETURN
OFF
This manual suits for next models
7
Table of contents
Other Speco Security Camera manuals

Speco
Speco HT65010XS User manual

Speco
Speco Bullet2 HT-INTB4 User manual

Speco
Speco O4FB1M User manual

Speco
Speco O4BLP2M User manual

Speco
Speco INTENSIFIER3 CVC6246IHR User manual

Speco
Speco CVC71HRB User manual

Speco
Speco H8D7M User manual

Speco
Speco VL-64TP User manual

Speco
Speco O2VB1 User manual

Speco
Speco HTB10X Operating and maintenance instructions
