O2D5M User’s Manual
Network Camera Manual
(O2D5M)

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
2
Note
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into and outlet on a circuit different from that to which the receiver is
connected
Consult the dealer or an experienced radio/TV technician for help.
Directions
DirectionsDirections
Directions
Be careful not to cause any physical damage by dropping or throwing the camera. Especially keep the
device out of reach from children.
Do not disassemble the camera. No after service is assumed when disassembled.
Use only the power adapter provided with the camera.
Be careful to prevent moisture or water penetration into the unit. Attention is needed when installing the
camera. The screw holes for the installation screws and pipe should be maintained water tight during the
whole life time of the product.
All of the electrical connection wires running into the unit should be prepared so that water from the outside
cannot flow into the unit through the surface of the wires. Penetration of moisture through the wire for an
extended period can cause malfunction of the unit or deteriorated image.

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
3
Revision History
Date Revision Details
Aug 18, 2015 1.0 First manual re ision creation.
Caution
Any changes or modifications in construction of this device which are not explicitly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
4
Contents
Contents ........................................................................................................................ 4
1. Introduction ............................................................................................................. 5
1.1. O er iew ............................................................................................................................... 5
1.2. Specifications ......................................................................................................................... 6
1.3. Applications of O2D5M .......................................................................................................... 7
2. Product Description ................................................................................................. 8
2.1. Contents ................................................................................................................................ 8
2.2. Product Pre iew .................................................................................................................... 8
2.3. Physical description ............................................................................................................... 9
2.4. Functional Description .......................................................................................................... 11
2.5. Accessories for installation ................................................................................................... 12
3. On Site Installation ................................................................................................. 13
3.1. Installation ............................................................................................................................ 13
4. Getting Started ...................................................................................................... 14
4.1. PC System Requirements ...................................................................................................... 14
4.2. Quick Installation Guide ........................................................................................................ 15
5. Troubleshooting ..................................................................................................... 19
5.1. No power is applied .............................................................................................................. 19
5.2. Cannot connect to the camera .............................................................................................. 20
5.3. Technical Assistance .............................................................................................................. 21

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
5
1. Introduction
1.1. Overview
The O2D5M is a state-of-the-art mega-pixel, dual-codec (H.264, MJPEG) IP/network camera built with embedded software
and hardware technology. It enables real time transmission of synchronized ideo of up to 1080p and audio data. Remote
clients can connect to O2D5M for real time ideo/audio data through arious client solutions running on PCs and
smartphones. Real time 2-way communication is a ailable through the bidirectional audio communication feature.
Designed to be a stand-alone streaming audio & ideo transmission de ice, O2D5M can be applied to arious applications
such as ideo security, remote ideo monitoring, remote education, ideo conference or internet broadcasting system.
Vandal proof and weather proof housing will extend the application area to harsh en ironments of wide temperature
ranges.
Integrated PoE (Power o er Ethernet, IEEE 802.3af) will reduce the total cost of ownership by reducing on-site wiring for
installation.

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
6
1.2. Specifications
LENS
Lens Type 3.3~10mm Motorized Focus Lens
Lens Iris Control DC Auto Iris
C MER
Image Sensor 1/2.8” 2 Mega Pixel Sony CMOS
Minimum Illumination IR LED Off : 0.5Lux, IR LED On : 0Lux
Scanning Mode Progressi e Scan
Dynamic Range (D-WDR) 74.7dB or Higher (90dB or higher)
Electronic Shutter Auto
IR LED 24pcs (850nm)
VIDEO
Compression Algorithm H.264, MJPEG
Compression Resolution 352X240, 704X480, 1280X720, 1920X1080
Bitrate Control H.264-CBR /VBR (up to 12Mbps)
Maximum Frame Rate 30fps @ 1920X1080 + 30fps @ 4CIF
Multi Stream Primary, Secondary, Tertiary
UDIO
Compression Algorithm G.726 (16KHz), G.711 μ – Law (8KHz)
INPUTS/OUTPUTS
Video Output 1 Composite, 1 Vp-p
Audio Input 1 line in
Audio Output 1 line out
Alarm Input 1 TTL, NC/NO programmable, 4.3V (NC) or 0.3V (NO) threshold, 5 VDC
Alarm Output 1 relay out, NO only, 0.3A @ 125 VAC, 1A @ 30 VDC
Network Connecti ity 10/100 Mbps Ethernet
CONNECTORS
Video Output BNC
Audio In/Out Φ 3.5 audio jack
Alarm In Wires
Alarm Out Wires
Ethernet Port RJ-45
GENER L
Dimensions (Ø x H) 5.1”(W)X3.9”(H)X5.1”(D)
Unit Weight 2lbs

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
7
Operating Temperature 14°F to 122°F (-10°C to 50°C)
Operating Humidity 0% to 90%
Power Supply 12 VDC, PoE (Power o er Ethernet) (IEEE 802.3af, Class 3)
Power Consumption Max. 4.8W
Appro al FCC, CE, IP66
Specifications are subject to change without notice.
1.3. pplications of O2D5M
 Security sur eillance (buildings, stores, manufacturing facilities, parking lots, banks, go ernment facilities, military, etc.)
 Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)
 Teleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting
 Weather and en ironmental obser ation

O2D5M User’s Manual
2. Product Description
2.1. Contents
The product package contains
the following
Contents
Main Body
Tools and Mounting
Screws
Screw
M4X25 4EA
L Wrench 1EA
CD
Software & User’s Guide
Quick Reference Guide
Quick installation guide
GPL License
Open Source Guide
2.2. Product Preview
O2D5M
Vandal Dome IP Camera
PC software to
network and assign IP addresses
the following
:
Description Image
O2D5M
M4X25 4EA
, Screw M4X8 3EA
L Wrench 1EA
, Core 1EA
Software & User’s Guide
Quick installation guide
Open Source Guide
IP Scanner
SecureGuard™ Plus VMS
PC software to
locate IP cameras on the
network and assign IP addresses
PC software to iew and record
ideo from the IP camera.
Remarks
SecureGuard™ Plus VMS
PC software to iew and record
ideo from the IP camera.

O2D5M User’s Manual
2.3. Physical description
2.3.1. External View
Figure 2-1. External view of O2D5M
2.3.2. Dimensions
Figure 2-2. Dimensions

O2D5M User’s Manual
2.3.3. Connector information
1. Network Port 2. BNC Video Out 3. Power In
4. Ground 5. udio In/Out 6. larm In/Out
Figure 2-3. Connector information
①
②
④
③
⑤
⑥

O2D5M User’s Manual
2.4. Functional Description
 Power
Power input for supplying 12V 1
A DC power.
Caution: If O2D5M
is powered by PoE, do not plug in DC Jack with active DC power into DC
connector.


 udio (MIC/LINE) IN
Connect external audio source or microphone.


 udio (Line) In
Connect speakers with built in amplifier. Audio from remote site is output through Line out in bi
mode.


 RJ-45 Ethernet (100Base-T) /
PoE (IEEE802.3af)
100Mbps Ethernet connector (RJ-
45) with standard PoE (802.3af).


 SENSOR IN
Connect external alarm sensor. Examples of sensing de ices are infrared sensor, motion sensor, heat/smoke sensor,
magnetic sensor, etc. Connect th
e two wires of the sensors to “Sensor In”. The sensor type (NC/NO) can be set
in the
admin page. Multiple sensor de ices can be connected in parallel.
+ 12V
+ 12V+ 12V
+ 12V G N D
G N DG N D
G N D
P hoto C o upler
Figure 2-
4. SENSOR input and connection of the sensor
A DC power.
is powered by PoE, do not plug in DC Jack with active DC power into DC
Connect external audio source or microphone.
Connect speakers with built in amplifier. Audio from remote site is output through Line out in bi
PoE (IEEE802.3af)
45) with standard PoE (802.3af).
Connect external alarm sensor. Examples of sensing de ices are infrared sensor, motion sensor, heat/smoke sensor,
e two wires of the sensors to “Sensor In”. The sensor type (NC/NO) can be set
admin page. Multiple sensor de ices can be connected in parallel.
S en sor
S en sorS en sor
S en sor
D evice
D eviceD evice
D evice
S en sor
S en sorS en sor
S en sor
P o w er
P o w erP o w er
P o w er
S up ply
S up plyS up ply
S up ply
N O /N C Type
N O /N C TypeN O /N C Type
N O /N C Type
S en sor1 -
S en sor1 -S en sor1 -
S en sor1 -
S en so r1+
S en so r1+S en so r1+
S en so r1+
4. SENSOR input and connection of the sensor
is powered by PoE, do not plug in DC Jack with active DC power into DC
power
Connect speakers with built in amplifier. Audio from remote site is output through Line out in bi
-directional audio
Connect external alarm sensor. Examples of sensing de ices are infrared sensor, motion sensor, heat/smoke sensor,
e two wires of the sensors to “Sensor In”. The sensor type (NC/NO) can be set
Sensor
Sensor Sensor
Sensor
D evice
D evice D evice
D evice
S ensor
S ensorS ensor
S ensor
P o w er
P o w erP o w er
P o w er
S up ply
S up plyS up ply
S up ply
O pen C ollectorType
O pen C ollectorTypeO pen C ollectorType
O pen C ollectorType

O2D5M User’s Manual


 Factory Default Switch
A switch pro ided for returning the IP camera to factory default state. Unscrew the co er to access the switch.
Press the switch about 5 seconds while power is applied.
Figure 2-5. Factory Default Switch
2.5. ccessories for installation
Figure 2-6. ccessories for installation of O2D5M
Factory default switch

O2D5M User’s Manual
3. On Site Installation
Use cables and conduits that are suitable for the installation. Close attention should be paid to the installation so that no
moisture is allowed to penetrate into the unit through the cables or conduits during the lifetime of the product. Products
that ha e internal parts exposed to moisture due to improper installation are not co ered by warranty.
3.1. Installation
1. Screw the bottom co er to the wall or ceiling by using the mounting screws pro ided with the camera. Use the
mounting template pro ided with the camera.
2. Connect the external de ices, network and power adapter.
3. Adjust the angle of the lens for the proper iew angle.
4. Focus and zoom can be adjusted remotely.
5. Tighten the tilt adjustment screw.
6. Screw the dome co er to the bottom co er by using the set screw pro ided with the camera.
7. Apply power.
W RNING: You might need to reinforce the wall or ceiling. If the wall or ceiling is not strong enough to support the
camera, the camera might fall damaging the camera or causing injuries.

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
14
4. Getting Started
Brief information for the initial operation of O2D5M is pro ided in this chapter.
4.1. PC System Requirements
Audio/Video streaming data recei ed from O2D5M can be displayed or stored in a PC running client programs. Minimum
requirements of the PC are described below:
Minimum Requirements Recommended Specifications
CPU Intel Core i3 Intel Core i5
Main Memory 2GB 4GB
Operating System
*
Windows XP Windows 7,8 (64bit)
Web Browser Internet Explorer 8 Internet Explorer 8 or higher
Graphic Card Video RAM 256MB or more
Resolution 1920x1080
Video RAM 1GB
Resolution 1920x1080
Network 100 Base-T Ethernet 100 Base-T Ethernet
* Operating Systems supported: Windows XP / Vista / 7 / 8

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
15
4.2. Quick Installation Guide
1. Connect PC and O2D5M to network.
1) Prepare a PC to run programs for the installation and ideo connection
2) In the case of using PoE, connect the PC and O2D5M to the network using one of the following ways.
If your LAN Switch does not support standard PoE, connect O2D5M as shown in dotted line in Figure 4-1. The DC
power is applied through DC adapter.
Figure 4-1. Power and network connection
LAN switch with
standard POE
(802.3af)
LAN switch
DC adapter

O2D5M User’s Manual
2. Install IP Scanner
IP Scanner is a utility to disco er IP cameras on the local network.
Follow the sequence be
low to access the
i)
Install IP Scanner on the PC that will be used on the same local network as the IP camera. IP Scanner can
be found on the CD included in the package or downloaded from specotech.com.
ii) Run IP Scanner
iii)
The a ailable cameras on the local
i ) Highlight and double-
click on the applicable model to launch the camera web iewer
be set to Internet Explorer to iew ideo)
IP Scanner is a utility to disco er IP cameras on the local network.
The camera is set to DHCP mode out of the box.
low to access the
camera settings
Install IP Scanner on the PC that will be used on the same local network as the IP camera. IP Scanner can
be found on the CD included in the package or downloaded from specotech.com.
The a ailable cameras on the local
network will show automatically
click on the applicable model to launch the camera web iewer
(default browser must
be set to Internet Explorer to iew ideo)
The camera is set to DHCP mode out of the box.
Install IP Scanner on the PC that will be used on the same local network as the IP camera. IP Scanner can
(default browser must

O2D5M User’s Manual
3. Remote video connection to O2D5M
1) Connection through Web Viewer
The web iewer offers the
simplest way
O2D5M in the
Internet Explorer address bar
Note :
When prompted, install and allow the Acti e X controls
The default login ID and password are admin
, 1234
4. dditional settings
All parameters of the camera are set to
factory default out of the box. For a more sophisticated target application,
parameters can be changed through the
settings
web iewer.
[e.g.] Port 8080
[e.g.] Port 80
simplest way
to connect to the O2D5M.
For ideo connection, enter the IP address of
Internet Explorer address bar
as:
When prompted, install and allow the Acti e X controls
as needed
, 1234
.
factory default out of the box. For a more sophisticated target application,
settings
page. The settings page can be
accessed by clicking on “Setup” in the
Port 80 (default) can be
omitted
For ideo connection, enter the IP address of
factory default out of the box. For a more sophisticated target application,
accessed by clicking on “Setup” in the
Port 80 (default) can be

O2D5M User’s Manual

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
19
5. Troubleshooting
5.1. No power is applied
 In case of Standard PoE (Power o er Ethernet)
Power supply through standard PoE is possible only when the following conditions are met.
1. Standard PoE is supported on the product.
2. The LAN switch supports standard PoE.
Make sure that both the IP camera and the LAN switch support standard PoE (IEEE 802.3af)
 In case of DC adapter
If PoE is not applied, the power and network connection should be made through separate cables. Use the
DC adapter recommended by the pro ider. In case of replacing the DC power supply, make sure that the
power supply meets the power requirement of the IP camera to pre ent damage or malfunction.

O2D5M User’s Manual
Rev 1.0 (Aug. 2015)
20
5.2. Cannot connect to the camera
Check the status of the network connection through PING test.
Try the following on your PC:
-Start > Run > Cmd > Ping IP address (Ex : Ping 172.16.42.51)
-If “Reply from ~” message is returned ( in the figure below), the network connection is in normal state. Try
connection to the ideo again. If the problem persists, or refer to other trouble shooting notes.
- If “Request timed out” message is returned. ( in the figure below), the network connection or network
setting is not in normal state. Check the network cable and settings.
1
2
2
1
