Speco O2VD2 User manual

Quick Start Guide
O2VD2

Welcome
Thank you for purchasing this network camera!
This owner's manual is designed to be a reference tool for your system.
Please read this manual carefully before operating the unit and retain it for future reference.
Should you require any technical assistance, contact Speco Technologies Tech Support at
1-800-645-5516
1. Electrical safety
All installation and operation here should conform to local electrical safety codes.
Use a certified/listed 12VDC Class 2 power supply or adequate PoE switch.
Please note: The product must be grounded to reduce the risk of electric shock.
Improper handling and/or installation could run the risk of fire or electrical shock.
2. Environment
Do not expose the unit to heavy stress, violent vibration or long-term exposure to water
and humidity during transportation, storage, and/or installation.
Do not install near sources of heat.
Only install the product in environments inside the specification operating temperature
and humidity range.
Do not install the camera near power lines, radar equipment or other electromagnetic
radiation.
Do not block any ventilation openings if any.
Use all the weatherproofing hardware requirement to minimize weather intrusion.
3. Operation and Daily Maintenance
Please shut down the device and then unplug the power cable before you begin any
maintenance work.
Do not touch the CMOS sensor optic component. You can use a blower to clean the dust on
the lens surface.
Always use the dry soft cloth to clean the device. If there is too much dust, use a cloth
Important Safeguards and Warning

Warning
Statement
This camera should be installed by qualified personnel only.
All the examination and repair work should be done by qualified personnel.
Any unauthorized changes or modifications could void the warranty.
.
This guide is for reference only.
Product, manuals and specifications may be modified without prior notice. Speco
Technologies reserves the right to modify these without notice and without incurring
any obligation.
Speco Technologies is not liable for any loss caused by improper operation.
Note:
Before installation, check the package and make sure that all components are included.
Contact your rep or Speco customer service department immediately if something is
broken or missing in the package.
dampened with a small quantity of neutral detergent. Finally use the dry cloth to clean
the device.
Please use a professional optical cleaning method to clean the enclosure. Improper enclosure
cleaning (such as using cloth) may result in poor IR functionality and/or IR reflection.
The grounding holes of the product are recommended to be grounded to further enhance
the reliability of the camera.
Dome cover is an optical device, please don't touch or wipe cover surface directly during
installation and use, please refer to the following methods if dirt is found:
Stained with dirt: Use oil-free soft brush or hair dryer to remove it gently.
Stained with grease or fingerprint: Use oil-free cotton cloth or paper soaked with alcohol
or detergent to wipe from the lens center outward. Change the cloth and wipe several
times if it is not clean enough.
Package
1

Overview
3
Camera Quick start guide CD
Overview
2
Screwdriver
3 Plastic screw
anchors
3 Screws (PA 4×25mm) Drill template
Overview
3
Camera Quick start guide
CD Plastic screw anchor ×3
Screwdriver
Tapping screw × 3
Ethernet connector (PoE)
(3.5mm) audio input connector
Power connector
Micro SD Card Slot
1
2
3
4
* 1 It is recommended to install the weather-resistant connector for outdoor installation.
* 2 This series can be powered by DC 12V/PoE power supply. If the PoE switch is
used to power the camera, DC 12V power supply is not required.
1
2
3
4

* It is recommended to install the water-proof connector for outdoor installations.
① Loosen the nut from the main element.
② Run the network cable (without RJ 45 connector) through both
elements. Then crimp the cable with RJ 45 connector.
③ Connect the cable to the water-proof connector. Then tighten the
nut and the main cover.
2
13
DC12V
Water-proof connector
External microphone
Connecting Network Cable

Installation
3
* Before you start, please make sure that the wall or ceiling is strong enough
to withstand three times the weight of the camera.
① Attach the drill template to the place where you want to fix the camera
and then drill the screw holes and the cable hole on the wall according
to the drill template.
69.46mm
76.28mm
Ø4.5 Ø110
84mm
② Loosen the screws to remove the lower dome from the camera.
Lower Dome

④ Three-axis adjustment. Before adjustment, view the image of the camera
on a monitor and then adjust the camera according to the figure below to get
③ Route and connect the cables. Then secure the camera to the ceiling
or wall with the screws provided.
of the camera on a monitor and then adjust the camera according to
the figure below to get an optimum angle.
Network Connection
5
MENU
IPC
Network Cable Network Cable
Switch
Router Computer
● Access Through IP-Tool
① Make sure that the camera and the PC are connected to the local
network.
② Install the IP-Tool from the CD and run it after installation.
Here we take accessing IP camera via LAN for example.
Pan 0°~355°
Tilt 0°~70°
Rotate: 0°~355°
PA 4×25mm
3×

Web Operation and Login
4
● Operation
IP Scanner can search for the device on the local network.
① Make sure that the camera and the PC are connected to the same local
network. The camera is set to DHCP by default.
② Install IP Scanner from the CD and run it after installation. Or
download from https://www.specotech.com/ip-scanner/
⑤ Install the lower dome back to the camera and fasten it with screws.
Finally, remove the protection film softly.

③ In the device list, you can view the IP address, model number, and
MAC address of each device. Select the applicable device and double
click to open up the web viewer. You can also manually enter the IP
address in the address bar of the web browser.
The login interface is shown above. Default user name is admin and
password is 1234. After logging in, follow directions to install
applicable plugins if prompted.
O2 VD 2
5C :F 2:07:24 :5 8: 9A
