Speco O4FT2W User manual

Quick Start Guide
O4FT2W

Welcome
Thank you for purchasing this network camera!
This owner's manual is designed to be a reference tool for your system.
Please read this manual carefully before operating the unit and retain it for future reference.
Should you require any technical assistance, contact Speco Technologies Tech Support at
1-800-645-5516
1. Electrical safety
All installation and operation here should conform to local electrical safety codes.
Use a certified/listed 12VDC Class 2 power supply or adequate PoE switch.
Please note: The product must be grounded to reduce the risk of electric shock.
Improper handling and/or installation could run the risk of fire or electrical shock.
2. Environment
Do not expose the unit to heavy stress, violent vibration or long-term exposure to water
and humidity during transportation, storage, and/or installation.
Do not install near sources of heat.
Only install the product in environments inside the specification operating temperature
and humidity range.
Do not install the camera near power lines, radar equipment or other electromagnetic
radiation.
Do not block any ventilation openings if any.
Use all the weatherproofing hardware requirement to minimize weather intrusion.
3. Operation and Daily Maintenance
Please shut down the device and then unplug the power cable before you begin any
maintenance work.
Do not touch the CMOS sensor optic component. You can use a blower to clean the dust on
the lens surface.
Always use the dry soft cloth to clean the device. If there is too much dust, use a cloth
Important Safeguards and Warning

Warning
Statement
This camera should be installed by qualified personnel only.
All the examination and repair work should be done by qualified personnel.
Any unauthorized changes or modifications could void the warranty.
.
This guide is for reference only.
Product, manuals and specifications may be modified without prior notice. Speco
Technologies reserves the right to modify these without notice and without incurring
any obligation.
Speco Technologies is not liable for any loss caused by improper operation.
Note:
Before installation, check the package and make sure that all components are included.
Contact your rep or Speco customer service department immediately if something is
broken or missing in the package.
dampened with a small quantity of neutral detergent. Finally use the dry cloth to clean
the device.
Please use a professional optical cleaning method to clean the enclosure. Improper enclosure
cleaning (such as using cloth) may result in poor IR functionality and/or IR reflection.
The grounding holes of the product are recommended to be grounded to further enhance
the reliability of the camera.
The lens is an optical device, please don't touch or wipe cover surface directly during
installation and use, please refer to the following methods if dirt is found:
Stained with dirt: Use oil-free soft brush or hair dryer to remove it gently.
Stained with grease or fingerprint: Use oil-free cotton cloth or paper soaked with alcohol
or detergent to wipe from the lens center outward. Change the cloth and wipe several
times if it is not clean enough.
Package
1

Overview
3 Overview
2
Screwdriver
Camera Quick start guide CD Junction box
7 Plastic screw
anchors
7 screws (PA 4×25mm)
3 Screws
(PM 4×10mm)
4 Rubber o-rings
for screws
Drill Template
Audio input connector
3
4Mounting base
Ethernet connector
1
2
Reset
Micro SD card slot
5
6
7
8
Set screw
Microphone
1
2
3
4
5
6
7
8
Power connector

* It is recommended to install the water-proof connector for outdoor installations.
① Loosen the nut from the main element.
② Run the network cable (without RJ 45 connector) through both
elements. Then crimp the cable with RJ 45 connector.
③ Connect the cable to the water-proof connector. Then tighten the
nut and the main cover.
2
13
Water-proof connector
DC12V
External microphone
Connecting Network Cable

Installation
3
* Before you start, please make sure that the wall or ceiling is strong enough
to withstand three times the weight of the camera and the junction box.
① Open the mounting base and the upper cover of the junction box.
② Attach the drill template of the junction box to the place where you
want to install the junction box and then rill the screw hole and calbe
hole on the wall according to the drill template.
③ Install junction box onto the wall by using the screws provided.
Mounting Base
Upper Cover
12mm
6.5×38mm
4×
Rubber o-ring

④ Loosen the set screw to disassemble the camera. Then remove
the cover from the camera unit to insert the SD card. After that, install
the cover back to the camera unit and fix it firmly with the screws.
(Note that the cover should not be installed unevenly .)
⑥ Route the cables through the cable hole and connect the cables.
Then reinstall the upper cover onto the junction box and mount the
camera unit and enclosure to the mounting base.
⑤ Fasten the mounting base of the camera onto the junction box.
PM 4x10mm
6.6mm
3×
Set Screw
Mounting Base
Enclosure
Camera Unit
Cover

⑦ Adjust the camera to obtain an optimum angle. Before adjustment,
preview the image of the camera on a monitor. After that, tighten the
set screw to finish the installation.
Web Operation and Login
4
IP Scanner can search for the device on the local network.
Set screw

③ In the device list, you can view the IP address, model number, and
MAC address of each device. Select the applicable device and double
click to open up the web viewer. You can also manually enter the IP
address in the address bar of the web browser .
The login interface is shown above. Default user name is admin and
password is 1234. After logging in, follow directions to install
applicable plugins if prompted.
● Operation
① Make sure that the camera and the PC are connected to the same
local network. The camera is set to DHCP by default.
② Install IP Scanner from the CD and run it after installation.
O4 FT 2W 5C:F2: 07 :2 4: 68:9A
