Speco O4VLD5 User manual

Quick Start Guide
O4VLD5
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

1Warning and Caution
■ If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to disassemble
the camera yourself. Any unauthorized changes or modifications
could void the warranty.
■ Do not allow water or liquid intrusion into the camera.
■ All installation and operation here should conform to local
electrical safety codes. Make sure the device is firmly installed
on the wall or ceiling.
■ Do not use camera beyond specified voltage range.
■ Do not drop the camera or subject it to physical shock.
■ Avoid touching the camera lens.
■ If cleaning is necessary, please use cleaning cloth to wipe it
gently.
■ Do not aim the camera at the sun or extremely bright light
sources.
■ Do not place the camera in extremely hot or cold environments
and dusty and damp locations. Do not expose it to highly
electromagnetic radiation.
■ Do not block any ventilations.
Package
2
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]
Camera 4 tapping screws PA 4×35
Quick start guide
CD Drill template Plastic plug ×4
Rubber plug Junction box Screwdriver
vervie
3
3OOvervieww
1
2
3
4
1 Mounting Base 3 MIC in connector
2 Ethernet connector 4 DC power connector

Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]
Security Cap
DC12V
* 1 It is recommended to install the security cap for outdoor installations.
* 2 DC 12V power supply is not required if a PoE switch or injector is used to power
the camera.
►Connecting Network Cable
12 3
① Loosen the nut from the main element.
② Run the network cable (without RJ 45 connector) through both
elements. Then crimp the cable with RJ 45 connector.
③ Connect the cable to the hermetic connector. Then tighten the nut
and the main cover.

Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]
Low er Dome
4Installation
* Before you start, please make sure that the wall or ceiling is strong enough
to withstand three times the weight of the camera.
① Install junction box onto the wall by using the screws provided.
② Loosen the screws to open the lower dome.

Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]
Rubber Plug
③ Connect the cables, mount the rubber plug to the gap of the
mounting base and fasten the camera onto the junction box.
④ Three-axis Adjustment-Before adjustment, preview the image of the
camera on a monitor and then adjust the camera according to the figure
below to get an optimum angle.
Pan 0°~355°
Tilt 0°~65°
Rotation 0°~355°

⑤Install the lower dome back to the camera and fix it with the screws.
Web Operation and Login
5
IP Scanner can search for the device on the local network.
● Operation
①Make sure that the camera and the PC are connected to the same
local network. The camera is set to DHCP by default.
② Install IP Scanner from the CD and run it after installation.
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

③In the device list, you can view the IP address, model number, and
MAC address of each device. Select the applicable device and double
click to open up the web viewer. You can also manually enter the IP
address in the address bar of the web browser.
The login interface is shown above. Default user name is admin and
password is 1234. After logging in, follow directions to install
applicable plugins.
