Speco O5DH Reference guide

SPECO 5MP IP HDMI DOME O5DH Brief Manual
1
CONTENTS
1. Introduction of 5MP IP HDMI Dome Camera O5DH--------------------------------------2
2. Interfaces of 5MP IP HDMI Dome Camera O5DH-----------------------------------------3
3. IP Tool for 5MP IP HDMI Dome Camera O5DH--------------------------------------------4
3.1 IP Tool Installation
3.2 IPC Default Information
4. 5MP IP HDMI Dome Camera O5DH Operation Guiding-----------------------------5-14
4.1 Web Login----------------------------------------------------------------------------------------5
4.2 Preview Page------------------------------------------------------------------------------------6
4.3 Backup--------------------------------------------------------------------------------------------6
4.4 Settings----------------------------------------------------------------------------------------7-14
4.4.1 Config Media----------------------------------------------------------------------------------7
4.4.2 Network-----------------------------------------------------------------------------------------8
4.4.3 Alarm Config-----------------------------------------------------------------------------------9
4.4.4 Record-----------------------------------------------------------------------------------------10
4.4.5 System-----------------------------------------------------------------------------------------11
4.4.6 Intelligence-----------------------------------------------------------------------------------12
4.4.7 PVM Function-----------------------------------------------------------------------------13-14

SPECO 5MP IP HDMI DOME O5DH Brief Manual
2
1. Introduction of 5MP IP HDMI Dome Camera O5DH
5MP IP HDMI dome camera is mainly designed for retail environment loss prevention.
With HDMI output, users can connect to TV/monitors to have no-latency IP video for
active deterrence.
Besides, the camera supports “Banner” function, allow users to upload their brand image
to show on the IP video (PIP).
And when faces are continuously detected about 3s, a deterrence picture like
“RECORDING IN PROGRESS” will pop-up. Users can upload their own picture to pop-
up when faces detected.
SPECO IP HDMI dome camera supports 1TB Max TF card for remote recording, it can
ensure longer time recording.

SPECO 5MP IP HDMI DOME O5DH Brief Manual
3
2. Interfaces of 5MP IP HDMI Dome Camera O5DH

SPECO 5MP IP HDMI DOME O5DH Brief Manual
4
3. IP Tool for 5MP IP HDMI Dome O5DH
3.1 IP Tool Installation
Customers can use our IP Config Tool to search/modify/factory reset/FW upgrading, etc
3.2 IPC Default Information
Default address: 192.168.0.66 (DHCP default enabled)
Default username and PW: admin (PW is required to modify when you log in Web at the first time)
Please note:
1. Ensure your PC & Camera are in same network segment, so you can enter into the IPC web without
issue;
2. Use Non-IE browsers to login IPC Web, we prefer to suggest Chrome.

SPECO 5MP IP HDMI DOME O5DH Brief Manual
5
4. 5MP IP HDMI Camera O5DH Operation Guiding
4.1 Web Login
Please type in correct IP address of your camera on browser, and:
1. Type in default PW “admin”;
2. Enter into PW change page and change your PW (PW is forced to change to ensure safety).

SPECO 5MP IP HDMI DOME O5DH Brief Manual
6
4.2 Preview Page (Main Stream)
4.3 Backup
Record Files: Alarm/Timed/Manual/Face Detection
Download Format: IVD/MP4/JPG

SPECO 5MP IP HDMI DOME O5DH Brief Manual
7
4.4 Settings
Including: Config Media/Network/Alarm Config/Record/System/Intelligence/PVM Function
4.4.1 Config Media
Please note:
1. If you use camera in corridor environment, you can adjust “camera angle”;

SPECO 5MP IP HDMI DOME O5DH Brief Manual
8
4.4.2 Network
Including: TCP/IP, Email, FTP, UPNP, RTSP.
Please note:
1. HTTP Port: 80
2. Onvif Port: 80
3. RTSP Port: 554, and instruction is below:
rtsp://192.168.0.66:554/H264?channel=1&subtype=0&unicast=true&proto=Onvif/video
Note: subtype=0 (main stream) ; subtype=1 (sub stream)

SPECO 5MP IP HDMI DOME O5DH Brief Manual
9
4.4.3 Alarm Config
Including: Motion Detection/Video Blind/Alarm
Please note:
1. To set motion detection region/sensitivity/threshold, please enter “Regional Edit”.

SPECO 5MP IP HDMI DOME O5DH Brief Manual
10
4.4.4 Record
Including: Schedule/SD Storage/Snapshot/Destination/NAS//System Log
Please note:
1. Ensure your camera is powered off before you insert TF card for remote recording;
2. After power up, please format your TF card;

SPECO 5MP IP HDMI DOME O5DH Brief Manual
11
4.4.5 System
Including: Maintenance/Device Info/Set Time/User Admin
Please note:
1. You can do factory default for your camera on this page, after default, please use our IP tool to
search and find out new IP address and login;
2. You can do FW upgrading on this Web page too;
3. Time zone, our default is GMT+08:00.

SPECO 5MP IP HDMI DOME O5DH Brief Manual
12
4.4.6 Intelligence
Our AI function is face detection. This category includes Face Comparison & Face Parameters.
Please note:
1. We have face detection alarm out interface, so when face alarm output is needed in application, you
can enable “Alarm output”;
2. In “Face Parameters”, you can also set face sizes and clarity.

SPECO 5MP IP HDMI DOME O5DH Brief Manual
13
4.4.7 PVM Function (Banner)
Including: Screen/Brand Image/Deterrence Message.
Screen: You can set screen direction with Normal/Corridor mode 90/Corridor mode 270/Invert.
.
Brand Image: You can upload a picture and show on the IP video (PIP)
Please note:
1.You can define the logo’s position and size on the monitor;
2. Logo picture format is PNG and not more than 1MB.

SPECO 5MP IP HDMI DOME O5DH Brief Manual
14
Deterrence Message: You can upload a deterrence message (picture type), so when faces detected,
the message will pop-up.
Please note:
1. The deterrence picture must be PNG format and not more than 1MB.
