Spectra Precision QuickMark Layout QML800 User manual

QML800 / QML800G QuickMark Layout
User Guide

QuickMark Layout User Guide
p3
p4
p5
p6
p 7
p 8
p9
p 10
p 11
p 12
p 13
p 16
p 17
p 26
p 27
p 28
p 31
p 32
p 33
p 40
p 41
1) Introduction andThank You
2) Laser Safety and General Care
3) System Components
4) Software Updates
5) Wi-Fi Communication overview
6) Tablet introduction
7) Preparation prior tojob site
8) Jobsite set up
9) QML800 set up atjob site
1) Layers
2) Control lines
3) Control points
4) Layout
5) Functions
6) Channel change
10) Dome light symbols
11) Multiple set ups ona single job site
12) Interceptor /Clutter Buster
13) Specifications
14) BuildView Office
15) Calibration andService
16) Warranty
17) FAQ p 42
2
PN 0170-0101 Rev A

Introduction
Thank you for choosing QML800 / QML800G QuickMark Layout for your interior
layout needs. QML will enable you to locate points on your jobsite quickly and
accurately. Before using your QML, read this manual carefully. Included is
information about operation, safety and maintenance.
Consider also, tutorial videos that can be accessed from www.spectralasers.com
Your comments and suggestions are welcome; please contact us at:
Trimble
Construction Tools
5475 Kellenburger Road
Dayton, Ohio 45424 USA
Phone: [phone]
[phone]
Fax: [phone]
Internet: www.spectralasers.com
Introduction
3

Laser Safety Use of this product by people other than those trained on
this product may result in exposure to hazardous laser light.
•Do not remove warning labels from the unit.
•QML800 is a Class 2, 642nm laser product .
•QML800G is a Class 2, 522nm laser product .
• Never look into the laser beam or direct it to the eyes of other people.
•Always operate the unit in a way that prevents the beam from getting
into people‘s eyes.
Laser Safety and General Care
General Care, Safety And Storage General safety rules
1) Check the condition of the tool before use.
2) The user must check the accuracy of the tool after it has been dropped or subjected to other mechanical
stresses.
3) Although the tool is designed for the tough conditions of jobsite use, as with other measuring instruments it
should be treated with care.
Cleaning and drying
1. Blow dust off the windows.
2.Use only a clean, soft cloth for cleaning. If necessary, moisten the cloth slightly with pure alcohol or a little
water.
NOTE Do not use any other liquids as these may damage the plastic components.
Storage
The temperature limits for storage of your equipment must be observed, especially in winter / summer.
Remove the tool from its pouch if it has become wet. The tool, its carrying case and accessories should be
cleaned and dried (at maximum40°C). Repack the equipment only once it is completely dry. Check the
accuracy of the equipment before it is used after a long period of storage or transportation.
Transport
Use the original packaging or packaging of equivalent quality for transporting or shipping your equipment.
4

QML800G includes:
•2 laser transmitters
•Tablet controller with rubber protector
•2 tripods,
•Green and white interceptors with a
LP20G green plum pointer
•Laser glasses
•Chargers
•Clutter Buster
•BuildView QuickMark Layout 2.0 Android
Contoller software
•BuildView Office – free computer
download to review architectural files
Product Configurations
5
QML800 includes:
•2 laser transmitters
•Tablet controller with rubber protector
•2 tripods,
•Red and white interceptors with a LP30
red plumb pointer
•Laser glasses
•Chargers
•BuildView QuickMark Layout 2.0 Android
Contoller software
•BuildView Office – free computer
download to review architectural files

Software Updates
QML800 controller uses an Android application called BuildView. This software is
what allows you to see the architectural drawings on the controller.
It is recommended that you check for updates occasionally (once per quarter)
Connect Controller Tablet to the internet
Find a hot spot (work office, Starbucks, etc.)
Go to settings, select Wi-Fi
Select appropriate Wi-Fi network to connect (you may need username
and/or password if network is secure)
Go to app store (Google Playstore) – Search “QuickMark Layout 2.0”
If an upgrade is available, it will be indicated.
6

Power ON one Laser Unit (LU) at a time- waiting 3 to 5 seconds between powering laser units. The first LU
powered on becomes the Wi-Fi Host and shows a green 360 sensor. The second LU powered on becomes
the Client and shows a blue 360 sensor. If powered on at the same time, they may both become hosts with
green lights. If this happens power off one laser unit and then power on again.
After the Laser Units are powered on, launch the QML application on the controller. It will search for a QML
network and join it. If the Laser Units are not powered on, you can only work off-line.
QML Wi-Fi network
How the QML800 WiFi network operates.
Green laser
unit -HOST Blue laser
unit - CLIENT
Controller unit (CU)
Green 360⁰ sensor
Blue 360⁰ sensor
7

Other Functions including:
•Change Channel
•Screen rotate lock
Tablet – useful settings
Back arrow. Also = undo
Go to home screen Navigate to other open
applications
The controller is an off-the-shelf
tablet. YouTube videos and other
useful control information is
available on the internet.
8
QuickMark Layout 2.0 app
Instructional Videos

1
2
Obtain Architectural File
Move File to Tablet (QML800 Folder)
Option 1: Via USB cable
Option 2: Set up Email account on tablet.
Move file on to “Internal Storage” drive on
the tablet
You may also wish to review architectural
drawings on your computer using BuildView
Office. You can review details, confirm
completeness, manage layers, discuss with
architect, etc.
See Section 14.
BuildView Office (computer program)
dwg or dxf
9
Preparation Prior to Job Site

Lasers minimum 20 ft (7m)
Reference Points minimum 20 ft (7m)
1 Place control lines and reference
points on jobsite floor
2 Place lasers 20 – 60 ft (7 -20m)
Power on lasers one at a time
10
Set Up – At Job Site Floor

Manage File Layers
Start QML App, Choose and Open Job File, Select Layers
Manage Open Layers
Select layers of interest
Tip. File will open faster
with fewer layers open
11
Set Up QML800 at Job Site Floor

Control Lines
Create control lines in the job file – in the same location as control lines are on the floor.
A) Input Offset Distance
C) Select which Side to Offset
B) Tap Entity to offset (often column line)
12
Set Up QML800 at Job Site Floor
Create Control Lines
D) Create Control Line

Create Control Points
Place Control Points at the same locations as on the job site. Minimum 2 Control Points
Tap intersection. To create points, zoom in and tap on the control line intersection. Then tap on the
check mark.
Alternatively, you can create control points after laser alignment.
13
Set Up QML800 at Job Site Floor

Locate Control Points with QML800 System
When laser alignment is complete, go to benching.
Locate control points with both lasers.
Fast
Medium
Slow Nudge – tap for
incremental
Small
movement
Laser on / off
Slow
Medium
Fast
“Start Layout” This begins Laser Alignment
Tap “Found Unit” or “Reflection”
14
Set Up QML800 at Job Site Floor
Tap and hold
appropriate shade

Verify setup •Recommendation - do not skip this step.
•Drive laser X to 2 points and mark the points
•Measure the distance between the points
•Compare QML calculations to your
measurement
•If with in your tolerance, proceed.
•If difference exceeds 1/8” (3mm) start laser
alignment again
15
Set Up QML800 at Job Site Floor

Begin Staking Out Points
Tap intersection. Choose:
16
Layout Points
Note. The program keeps all points created or staked.
create point
create point
and stake
point cancel

•Point / Layers
•Place Control lines
•Point size
•“Snap” manage
•Measure Distance
•Survey Mode
•Column Buster
•Flash Lasers
17
CONTROLLER FUNCTIONS
See Following Pages for Explanations

Layer Management
Tap Layers
All Layers On / Off
Individual layer
On / Off
Job files will load faster if many layers are off
Points are placed in “QML Points 1” layer by default. You can create a new layers for
point management.
18

Point List
Tap Points
Scroll to points to
find one quickly.
Or search for
point number.
Tap on Point to
bring up Options:
Edit Point
Delete Point
Stake Point
19

Point Size
Select Point Size
Icon on tablet
20
