Manual Mode Slope Adjustment
UP + DOWN changes Y-Axis slope
Vertical Line Adjust
in Automatic + Manual mode
Standby Mode On/Off
Press and hold for 3 seconds
Red LED flashes every 4 sec.
HV 101 –Quick Card
The unit always powers up in automatic self-leveling mode
(horizontal or vertical) at the last used rotation speed
Manual Mode On/Off
Red Manual LED flashes
once a second
Press quickly => On/Off
Green LED flashes during
self-leveling. When level, the
LED lights solid for the first
five minutes, then flashes
every 4 seconds
Battery Status-/Standby-LED
Flashing 1 x sec. -Batteries low
Solid red –exchange Batteries
Manual Mode Slope
Adjustment
LEFT + RIGHT with RC601
changes slope on X-axis
PN 022507-206

Rotation Speed/Beam Positioning
Selecting Rotation Speed at the
Laser or Remote Control
Press and release to toggle
through the different rotation
speeds 50, 200, 600, 0 rpm
Beam Pointing Mode
Horizontal Setup => UP/DOWN
arrow buttons move the beam
(small line at 0 rpm)
clockwise/counterclockwise
Scan Mode Button -
stops rotation immediately
Beam Pointing Mode
Vertical Setup => UP/DOWN
arrow buttons
move the beam left/right
Beam Pointing Mode –RC601
Use the LEFT and RIGHT arrow
remote buttons to move the small
scanning line cw and ccw regardless
if the unit is set up horizontally or
vertically
Trimble Construction Tools Division
8261 State Route 235
Dayton, Ohio 45424-6383
U.S.A.
[phone] Phone

3°
Zone Scan Mode
Scan Mode
Press and release to toggle
through the 5 different scan
zones 3º, 8º, 45º, 90º, 180º,
and stop
Rotation Button -
stops scan mode immediately
Line Positioning
When the unit is set up
horizontally, the UP/DOWN
buttons move the scan zone
cw/ccw
When set up vertically, these
buttons will move the line to
the left or right
Zone Scan Mode
Pressing the remote’s LEFT/RIGHT
buttons move the scan zone
cw/ccw regardless of the
transmitter setup.
Zone Scan Mode
Pressing the remote’s
UP/DOWN buttons will increase
or decrease the scan zone when
in horizontal automatic mode

Single Axis Slope Mode Y-Axis
Press the Manual button (1 second) after
the UP arrow button at the transmitter or
remote control has been pressed and
released (red and green LEDs flash
simultaneously once every second)
The UP /DOWN arrow buttons change
the slope
Single Axis Slope Mode
Single Axis Slope Mode can only be used when the laser is set up horizontally
One axis remains in automatic horizontal self-leveling mode
Single Axis Slope Mode X-Axis
Press the Manual button (1 second)
after the Right arrow button at the
remote control has been pressed and
released (red and green LEDs flash
simultaneously every 3 seconds)
The LEFT/RIGHT arrow buttons change
the slope
Manual Button
To resume automatic
self-leveling mode, press
the button again
