INST.NO. INE-841B
KL4000/KH4000
(Multi-point type)
Hybrid Recorder
[ Maintenance ]

1. Introduction.........................................................................................................................1
2. Maintenance Mode..............................................................................................................2
2-1. List of Functions ..........................................................................................................................................................2
2-2. How to Enter Maintenance Mode................................................................................................................................3
3. Initialization of Setting Parameters...................................................................................5
3-1. Default value ...............................................................................................................................................................5
3-2. Operation ....................................................................................................................................................................5
4. Hardware Check..................................................................................................................6
4-1. Hardware Check Items and Overview ........................................................................................................................6
4-2. Printer Check ..............................................................................................................................................................7
4-3. Display Check .............................................................................................................................................................8
4-4. Remote Contact Check...............................................................................................................................................9
4-5. Version Check ...........................................................................................................................................................10
4-6. Alarm Output Check..................................................................................................................................................11
5. Scale Adjustment..............................................................................................................12
5-1. Scale Check ..............................................................................................................................................................12
5-2. Zero and Span Adjustment for Trace Printing ...........................................................................................................14
5-3. Zero and Span Adjustment for Digital Recording ......................................................................................................16
5-4. Channel-by-Channel Shift Setting.............................................................................................................................18
Table of contents

- 1 -
1. Introduction
Thank you for purchasing KL4000/KH4000 series (multi-point type).
This instruction manual is provided as a reference guide for the product maintenance such as scale adjustment and
hardware check. Before reading this manual, read and fully understand the contents of instruction manual “General” of the
recorder.
- To the persons doing instrumentation, installation, and sales -
Make sure to provide this instruction manual to the person who uses the unit.
- To the users of this unit -
Store this instruction manual with care until you scrap the unit.
Also, write down the parameter contents set in the product and keep it for your record.
Request
This product is warranted for one year from the date of delivery. If it is damaged during the warranty period, when
used normally based on the cautions in the instruction manual and labels attached to the product, etc., it will be
repaired without any charge (only in Japan). In the case, we are sorry to trouble you, but please contact your
dealer or nearest our sales office.
However, in cases of the followings, it will be repaired at your expense even during warranty period.
1. Failure or damage caused by improper use or connection, or invalid repair or modification.
2. Failure or damage caused by fire, earthquake, wind or flood, thunderbolt, or other extraordinary natural
phenomena, or pollution, salt, harmful gas, abnormal voltage, or use of unspecified power.
3. Replacement of parts or accessories that have reached the end of their life.
Furthermore, the term ‘warranty’ in this sense covers only a CHINO’s product itself. Therefore, we are not
responsible for compensation for whatever the damage that is triggered by failure of our product.
Product warranty scope
1. No part of this manual can be reproduced or copied in any form without permission.
2. The contents of this manual may be altered without prior notice.
3. This manual has been documented by making assurance doubly sure. However, if any question arises or if any
error, an omission, or other deficiencies are found, please contact your nearest our sales office.
4. CHINO is not responsible for any operation results of this software.
Notice

- 2 -
2. Maintenance Mode
2-1. List of Functions
The unit has [Maintenance mode] (the items enclosed by heavy lines). [Maintenance mode] allows users to perform
initialization of setting parameters, hardware check and scale adjustment.
* Alarm value is cleared.
Setting
ENG1
ENG2
Display
Version
Alarm output
Remote contacts
Zero/span
adjustment
for digital recording
Channel-by-
channel
shift setting
Data printing, chart speed, time, periodic
data printing, etc.
Checking unit specifications and
switchin
g
functions
Setting/checking remote contacts ofr
communications when these options are
used
Recovering factory default settings
except for options *
Printing specified characters in different
colors
Displaying all segments one digit at a
time
Displaying version No.
Forcing ON/OFF output
Displaying remote contact ON/OFF
status
A
djusting zero/span lines on a chart
A
pplying correct input with tester to
adjust in the software
Correcting zero point for each channel =
parallel shift
Multi-point sequential
Time
One-point continuous
Initialization
of setting
parameters
Hardware
check
Scale
adjustment
Initialization of
setting
parameters
Printer
Zero/span
adjustment
for trace printing
Operation
Continuous
Indication
Display

- 3 -
2-2. How to Enter Maintenance Mode
1. Operation procedure
Read the following procedure together with the flow chart given in the next page.
(1) Enter [Maintenance mode]
Turn on the power while pressing the and keys.
(2) Enter passcode
While is displayed on the window, press the / key and enter a passcode.
Pressing the key moves the cursor right.
Functions in maintenance mode Pass code
Initialization of setting parameters 07781
Hardware check 07789
Scale adjustment 07790
Enter a passcode within 20 seconds. The mode changes to [Operation mode] when 20 seconds have passed.
(3) Check display
Press the key after setting the rightmost digit. Decimal points of all digits will flash.
(4) Register passcode
Press the key. A passcode check is performed and the window of the function corresponding to the
passcode will be displayed. The mode will change to [Operation mode] if a wrong passcode is registered.
(5) Function switching in [Maintenance mode]
Functions can be switched in [Maintenance mode].
When the key is pressed on the exit window of each maintenance item, the passcode entry window
() will be returned. Enter a passcode for another item to continue maintenance operation.
(6) Exit [Maintenance mode]
When the key is pressed on the passcode entry window, or 20 seconds have passed, the mode
changes to [Operation mode].
If you exit from [Maintenance mode] accidentally and enter [Operation mode], you will need to go through the
maintenance procedure again from turning on the power.
[Maintenance mode] does not return from [Operation mode]
Note

- 4 -
2. Operation flow chart
Register
p
asscode
NO
Power ON
Enter [Operation mode]
YES
YES
(1)
Scale adjustment Hardware check
End
End
Initialization of setting
parameters
Pass code entry window
Enter [Maintenance mode] corresponding to the passcode
NO
(2)
Enter a password within
20 seconds?
(3)
(4)
(5)
(6)
End
Power on the unit while pressing the and
keys.
Decimal points of all digits flash
key is pressed or 20 seconds have passed.

- 5 -
3. Initialization of Setting Parameters
3-1. Default value
All parameters are returned to factory defaults.
Parameter Factory default
Measuring range Specified measuring range
Scale Specified scale
Chart
speed
KL4000 1: 10 (mm/H) 2: 20 (mm/H) 3: 40 (mm/H)
KH4000 1: 12.5 (mm/H) 2: 25 (mm/H) 3: 50 (mm/H)
Periodic data printing Not set
Skip function No skip channel set
Alarm value Not set
Operation Multi-point sequential display while recording is ON
3-2. Operation
1. Operation procedure
(1) Select item
Press the key and select .
(2) Start
Pressing the key restarts the unit to start initialization.
(3) End
When the initialization process is completed, the mode changes to [Operation mode] and normal operation is
resumed.
2. Operation flow chart
(1) (2) (3)
Initialize setting
Execute
Register passcode “07781”
Initialization starts after
restart Enter [Operation mode]

- 6 -
4. Hardware Check
4-1. Hardware Check Items and Overview
Check the operations of printer, display, remote contacts (when the option is used), version and alarm output (when the
option is used).
Printer
Check mode
Display
Remote contacts
Version
Digital printing: 6-digit printing is performed
(using different colors) for 40
characters (A to Z, 0 to 9).
Trace printing: Dot printing is performed for 11
columns and 6 lines (using
different colors) 10% at a time.
Pressing the .moves one digit to the
right and turns it on.
The display appears only when the optional
remote contact function is used.
You can check if the unit recognizes the remote
contact input status (short/open) correctly.
Each CPU ROM software version number is
displayed.
The display appears only when the optional
alarm function is used.
It forces ON/OFF output to alarm terminals.
Alarm output
End
Register passcode “07789”

- 7 -
4-2. Printer Check
Perform a test printing for digital and trace printings.
The test printing allows you to check if the printer functions normally.
1. Operation procedure
(1) Preparation
Set a chart paper. Press the key to turn on the “REC” status LED.
(2) Select check item
Pressing the key changes check item. Select .
(3) Start test printing
Press the key to start test printing. To stop it in the middle of the process, press the key.
(4) How to end
Press the key and select , and then press the key.
The mode changes to [Operation mode] when the key is pressed on the passcode entry window
().
2. Operation flow chart
Printer check
Displayed during a
test
Option
Option
Register passcode “07789”
(4)
(2) (3)

- 8 -
4-3. Display Check
Check the 7-segment LEDs used for the display.
1. Operation procedure
(1) Select check item
Pressing the key changes check item. Select .
(2) Start test display
Press the key to change the leftmost digit to . Make sure that all segments are turned on.
(3) Check 7-segment LED of each digit
Pressing the key moves right. Check each digit.
(4) How to end
Press the key and select , and then press the key.
The mode changes to [Operation mode] when the key is pressed on the passcode entry window
().
2. Operation flow chart
Check display
Option
Option
Register passcode “07789”
(1)
(2)
(3)
(4)

- 9 -
4-4. Remote Contact Check
This check is available only on units with remote contacts (option). You can check if the unit recognizes the remote contact input
status (short/open) correctly. Short or open each remote contact terminal and check the input status ON/OFF on the display.
1. Operation procedure
(1) Select check item
Pressing the key changes check item. Select .
(2) Check input signal
When the key is pressed while all remote contact terminals are OFF, is displayed. Then
turn ON (short) each remote contact terminal to see how the display changes. When the ON/OFF status is
recognized correctly, the display value will change depending on the remote contact terminal number.
(3) Complete check
When the above check is completed, press the key.
(4) How to end
Press the key and select , and then press the key.
The mode changes to [Operation mode] when the key is pressed on the passcode entry window
().
2. Operation flow chart
(1) (2)
(3)
(4)
Check remote contacts
A
ll remote contact
terminals are OFF (open)
Option
Option
Example:
Remote contact No. 17
When turned ON
(shorted), the display
changes.
When remote contact terminals are ON (shorted), following
values will be displayed depending on the remote contact No.
providing that the remote contact input is recognized correctly.
Remote
contact No.
Display Remote
contact No.
Display
1 1 11 1024
2 2 12 2048
3 4 13 4096
4 8 14 8192
5 16 15 16384
6 32 16 32768
7 64 17 65536
8 128 18 131072
9 256 19 262144
10 512 20 524288
Display and meaning
Reference
Register passcode “07789”

- 10 -
4-5. Version Check
Display the ROM software version of each CPU.
1. Operation procedure
(1) Select check item
Pressing the key changes check item. Select .
(2) Check version
Pressing the key displays the version of the printer. Press the / key to select each CPU.
(3) How to end
Press the key and select , and then press the key.
The mode changes to [Operation mode] when the key is pressed on the passcode entry window
().
2. Operation flow chart
Check version
Option
Option
Printer
CPU ROM Ver.
Input 1
CPU ROM Ver.
Input 2
CPU ROM Ver.
Alarm/remote contact 1
CPU ROM Ver.
Alarm/remote contact 2
CPU ROM Ver.
Alarm/remote contact 3
CPU ROM Ver.
Alarm/remote contact 4
CPU ROM Ver.
Backup battery voltage
Register passcode “07789”
(1)
(2)
(3)

- 11 -
4-6. Alarm Output Check
This check is available only on units with alarm output (option). As alarm output, contact signals (ON/OFF) are output to
alarm terminals. This function forces the unit to send the ON/OFF signals to alarm output terminals.
1. Operation procedure
(1) Select check item
Pressing the key changes check item. Select .
(2) Start output signal display
Pressing the key brings the output number display.
(3) Select output number
Pressing the / key advances/reverses the output number. Select a number to be checked.
(4) Turn output ON/OFF
Pressing the key switches output ON and OFF (display shows “0” for OFF and “1” for ON).
(5) How to end
Press the key and select , and then press the key.
The mode changes to the operation mode when the key is pressed on the passcode entry window
().
2. Operation flow chart
(1)
(2)
(3)
(4)
(5)
Check alarm output
Option
Option
Output
Display and meaning
Reference
* This is the case of 6-point alarm output.
The number can be advanced up to 24 depending
on the number of output points.
*
Register passcode “07789”
0: OFF
1: ON
Output

- 12 -
5. Scale Adjustment
When you perform a trace printing (dot printing) position adjustment only, refer to “5-2. Zero and Span Adjustment for
Trace Printing”.
5-1. Scale Check
The check is performed on a channel to channel basis. Even if all channels use the same measuring range, an error in
measured value may occur between channels.
The rated accuracy varies between digital display and
analog indication.
Use a tester with the accuracy equal to or higher than the
specified rated accuracy.
1. Preparation
(1) Turn OFF the power switch and perform the wiring depending on the input signal (see figure below).
Connect to the input terminal of the check target channel.
(2) Attach the terminal cover.
(3) Turn ON the power switch and change to [Continuous indication mode]. For details of [Continuous indication
mode], refer to “9. Continuous Indication Mode” in instruction manual “General”.
(4) Display the check target channel.
(5) Energize the unit for at least 30 minutes (an hour or more is ideal) and then perform checking.
Digital display: Temperature input ······· ±0.2%
DC voltage input ········ ±0.1%
Analog indication: ±0.5% of scale range
The accuracy of the unit is ±0.1%. Therefore, you
need to use a tester having higher degree of
accuracy to perform proper checking. Also, attention
should be paid to the thermocouple error.
Note that a tester requires time to ensure its stability
and accuracy.
Tester accuracy
Note 1
Make sure that the reference junction temperature is
0°C. When using an electronic reference junction
temperature compensator, read its instruction
manual. Also, the compensation accuracy should be
checked.
Reference junction compensator
Note 2

- 13 -
2. How to check
(1) Set a tester (standard DC voltage generator or precision variable resistor) to an input value equivalent to the
check target value.
(2) At this time, read the digital display and check if the error is within the specified accuracy range.
(3) Next, change to the check target channel and check it likewise.
(4) Check also the analog indication/dot printing position.
* The accuracy of the unit is rated at an ambient temperature of 23°C ±2°C. Ensure safety of the surrounding
environment.
* When you changed the wiring with the terminal cover removed, energize the unit for at least 30 minutes
after attaching the terminal cover and then perform checking.

- 14 -
5-2. Zero and Span Adjustment for Trace Printing
Adjust the trace printing (dot printing) position on a chart. The adjustment does not affect digital display/recording.
Note that the default position cannot be recovered after performing this adjustment.
1. Adjustment procedure
(1) Preparation
1) Set a chart paper. Press the key to
turn on the “REC” status LED.
2) Pressing the key changes
adjustment item. Select .
(2) Adjusting zero position of chart
1) Press the key. The display shows
and dotting is performed at
the initial position (left side) while feeding
the chart.
2) Pressing the / key moves the
position right/left slightly (about 0.05mm at
one time). Align the position with the zero
line of the chart.
3) Press the key to register the zero
position in the memory.
(3) Adjusting span position of chart
1) Press the key when you complete
the zero adjustment. The display shows
and dotting is performed at
the initial position (left side of span line)
while feeding the chart.
2) Pressing the / key moves the
position right/left slightly (about 0.05mm at
one time). Align the position with the span
line of the chart.
3) Press the key to register the span
position in the memory.
(4) How to end
Press the key and select ,
and then press the key.
The mode changes to [Operation mode] when the
key is pressed on the passcode entry
window ( ).
Chart zero position adjustment
Chart feed direction
Zero line
Pressing the / key
moves the position right/left a little
at a time.
Initial position
Chart span position adjustment
Span line
Chart feed direction
Pressing the / key
moves the position right/left a little at
a time.
Initial position

- 15 -
2. Adjustment flow chart
(1)
(2)
(3)
(4)
Zero/span adjustment
for trace printing
Press / to align dotting
position with zero line of chart.
Save current dotting position as
span position with above zero
position in the memory.
Press / to align dotting
position with span line of chart.
Register passcode “07790”
Save current dotting position as
zero position tentatively.

- 16 -
5-3. Zero and Span Adjustment for Digital Recording
When the rated accuracy still cannot be achieved after performing the scale check, perform a channel-by-channel
adjustment.
1. Adjustment procedure
(1) Preparation
1) Connect a tester (standard DC voltage generator or precision variable resistor) to an adjustment target
channel number.
2) Pressing the key changes adjustment item. Select .
(2) Select channel number
Pressing the / key advances/reverses channel number. Select a desired channel number.
(3) Zero adjustment
Obtain zero correction data
Apply an input equivalent to zero value
(minimum value of measuring range).
→
The span adjustment display appears
several seconds after pressing the
key.
The display shows a channel number and
zero value (minimum value).
When the minimum value input and the
correction data registration to the memory
are completed, the display changes to the
span adjustment display.
(4) Span adjustment
Obtain span correction data
Apply an input equivalent to span value
(maximum value of measuring range).
→
The zero adjustment display appears several
seconds after pressing the key.
The display shows a channel number and
span value (maximum value).
When the maximum value input and the
correction data registration to the memory
are completed, the display changes to the
zero adjustment display.
(5) How to end
Press the key and select , and then press the key.
The mode changes to [Operation mode] when the key is pressed on the passcode entry window
().
Example display in zero adjustment
Ref 1
Minimum value of
measuring range
Channel No.
Example display in span adjustment
Ref 2
Maximum value of
measuring range
Channel No.
●Press the key to cancel the adjustment.
How to cancel
Ref 3

- 17 -
2. Adjustment flow chart
(1)
(2)
(3)
(4)
(5)
Minimum value input
Correction value registered
Zero/span adjustment
for digital printing
*
Minimum value input
Correction value registered
* This is the case of 6-point input.
The number can be advanced up to 24 depending
on the number of input points.
Maximum value input
Correction value registered
Minimum value input
Correction value registered
Maximum value input
Correction value registered
Minimum value input
Correction value registered
Maximum value input
Correction value registered
Maximum value input
Correction value registered
Register passcode “07790”

- 18 -
5-4. Channel-by-Channel Shift Setting
This function is used to shift (parallel shift) the measured value of digital display/recording.
The amount of shift is set on a channel to channel basis.
1. Setting procedure
(1) Select shift setting
Pressing the key changes adjustment item. Select .
(2) Select channel number
Pressing the / key advances/reverses channel number. Select a desired channel number by
pressing the key.
(3) Start setting
Pressing the / key displays the cursor (flashing decimal point).
(4) Move cursor
Press the key to move the cursor right.
(5) Set numeric value
Pressing the / key increases/decreases numeric value.
(6) Set (change) desired measured value
Repeat above steps (4) and (5) to set a desired value.
(7) Check display
Press the key after the rightmost digit is set. Decimal points of all digits will flash.
(8) When set value is correct
Press the key. An error judgment is made and the set value is registered if no error is found. After that,
go back to step (2).
(9) Error judgment display
If the display shows or , it indicates that the set value is out of the setting range or a format error
occurs. In this case, press the key to reset.
(10) How to end
Press the key and select , and then press the key.
The mode changes to the operation mode when the key is pressed on the passcode entry window
().
A shift value should be within 2% of the scale width
(maximum value – minimum value).
Setting range of shift
Note 1
You cannot view a reflected shift set value.
Check of set value
Note 2
