Spectra MobileMapper 50 User manual

Version 1.00
Revision A
July 2016
USER GUIDE
MobileMapper 50 Handheld
with Android operating system

Corporate Office
10368 Westmoor Drive
Westminster, CO 80021
USA
Trimble Mobile Computing Solutions
345 SW Avery Avenue
Corvallis, Oregon 97333
USA
www.trimble.com
Legal Notices
© 2016, Trimble Navigation Limited. All rights reserved.
Trimble and the Globe & Triangle logo are trademarks of
Trimble Navigation Limited, registered in the United States
and in other countries.
The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Trimble
Navigation Limited is under license.
Android is a trademark of Google Inc.
All other trademarks are the property of their respective
owners.
Release Notice
This is the July 2016 release (Revision A) of the MobileMapper
50 handheld documentation. It applies to the Android
operating system 5.1.
Limited Warranty Terms and Conditions
Product Limited Warranty
Subject to the terms and conditions set forth herein, Trimble
Navigation Limited (“Trimble”) warrants that for a period of
three (3) years from date of purchase this Trimble product
(the “Product”) will substantially conform to Trimble's publicly
available specifications for the Product and that the
hardware and any storage media components of the Product
will be substantially free from defects in materials and
workmanship. All accessories and the product battery fall
under a warranty period of one (1) year from the data of
purchase from Trimble.
Product Software
Product software, whether built into hardware circuitry as
firmware, provided as a standalone computer software
product, embedded in flash memory, or stored on magnetic
or other media, is licensed solely for use with or as an integral
part of the Product and is not sold. The terms of the end user
license agreement, as included below, govern the use of the
Product Software, including any differing limited warranty
terms, exclusions and limitations, which shall control over the
terms and conditions set forth in the limited Product
warranty.
Warranty Remedies
If the Trimble Product fails during the warranty period for
reasons covered by this limited warranty and you notify
Trimble of such failure during the warranty period, Trimble will
repair OR replace the nonconforming Product with new,
equivalent to new, or reconditioned parts or Product, OR
refund the Product purchase price paid by you, at Trimble’s
option, upon your return of the Product in accordance with
Trimble's product return procedures then in effect.
How to Obtain Warranty Service
To obtain warranty service for the Product, please contact
your Trimble dealer. Dealers may contact their Trimble
Technical Support group. Please be prepared to provide:
– your name, address, and telephone numbers;
– proof of purchase;
– a copy of this Trimble warranty
– a description of the nonconforming Product including the
model number; and
– an explanation of the problem.
The customer service representative may need additional
information from you depending on the nature of the
problem.
Warranty Exclusions and Disclaimer
This Product limited warranty shall only apply in the event and
to the extent that (i) the Product is properly and correctly
installed, configured, interfaced, maintained, stored, and
operated in accordance with Trimble's applicable operator's
manual and specifications, and; (ii) the Product is not modified
or misused. This Product limited warranty shall not apply to,
and Trimble shall not be responsible for, defects or
performance problems resulting from (i) the combination or
utilization of the Product with hardware or software products,
information, data, systems, interfaces, or devices not made,
supplied, or specified by Trimble; (ii) the operation of the
Product under any specification other than, or in addition to,
Trimble's standard specifications for its products; (iii) the
unauthorized installation, modification, or use of the Product;
(iv) damage caused by: accident, lightning or other electrical
discharge, fresh or salt water immersion or spray (outside of
Product specifications); or exposure to environmental
conditions for which the Product is not intended; (v) normal
wear and tear on consumable parts (e.g., batteries); or (vi)
cosmetic damage. Trimble does not warrant or guarantee
the results obtained through the use of the Product or
Software, or that software components will operate error
free.
Spectra Precision MobileMapper 50 Handheld User Guide | 2

NOTICE REGARDING PRODUCTS EQUIPPED WITH
TECHNOLOGY CAPABLE OF TRACKING SATELLITE SIGNALS
FROM SATELLITE BASED AUGMENTATION SYSTEMS (SBAS)
(WAAS, EGNOS, AND MSAS), OMNISTAR, GPS, MODERNIZED
GPS OR GLONASS SATELLITES, OR FROM IALA BEACON
SOURCES: TRIMBLE IS NOT RESPONSIBLE FOR THE
OPERATION OR FAILURE OF OPERATION OF ANY SATELLITE
BASED POSITIONING SYSTEM OR THE AVAILABILITY OF ANY
SATELLITE BASED POSITIONING SIGNALS.
THE FOREGOING LIMITED WARRANTY TERMS STATE
TRIMBLE’S ENTIRE LIABILITY, AND YOUR EXCLUSIVE
REMEDIES, RELATING TO THE TRIMBLE PRODUCT. EXCEPT
AS OTHERWISE EXPRESSLY PROVIDED HEREIN, THE
PRODUCT, AND ACCOMPANYING DOCUMENTATION AND
MATERIALS ARE PROVIDED “AS-IS” AND WITHOUT EXPRESS
OR IMPLIED WARRANTY OF ANY KIND, BY EITHER TRIMBLE
OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION,
PRODUCTION, INSTALLATION, OR DISTRIBUTION,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, TITLE, AND NONINFRINGEMENT.
THE STATED EXPRESS WARRANTIES ARE IN LIEU OF ALL
OBLIGATIONS OR LIABILITIES ON THE PART OF TRIMBLE
ARISING OUT OF, OR IN CONNECTION WITH, ANY
PRODUCT. BECAUSE SOME STATES AND JURISDICTIONS
DO NOT ALLOW LIMITATIONS ON DURATION OR THE
EXCLUSION OF AN IMPLIED WARRANTY, THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.
Limitation of Liability
TRIMBLE'S ENTIRE LIABILITY UNDER ANY PROVISION
HEREIN SHALL BE LIMITED TO THE AMOUNT PAID BY YOU
FOR THE PRODUCT. TO THE MAXIMUM EXTENT PERMITTED
BY APPLICABLE LAW, IN NO EVENT SHALL TRIMBLE OR ITS
SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGE WHATSOEVER
UNDER ANY CIRCUMSTANCE OR LEGAL THEORY RELATING
IN ANYWAY TO THE PRODUCTS, SOFTWARE AND
ACCOMPANYING DOCUMENTATION AND MATERIALS,
(INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS
OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF
DATA, OR ANY OTHER PECUNIARY LOSS), REGARDLESS OF
WHETHER TRIMBLE HAS BEEN ADVISED OF THE
POSSIBILITY OF ANY SUCH LOSS AND REGARDLESS OF THE
COURSE OF DEALING WHICH DEVELOPS OR HAS
DEVELOPED BETWEEN YOU AND TRIMBLE. BECAUSE SOME
STATES AND JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.
PLEASE NOTE: THE ABOVE TRIMBLE LIMITED WARRANTY
PROVISIONS WILL NOT APPLY TO PRODUCTS PURCHASED
IN THOSE JURISDICTIONS (E.G., MEMBER STATES OF THE
EUROPEAN ECONOMIC AREA) IN WHICH PRODUCT
WARRANTIES ARE THE RESPONSIBILITY OF THE LOCAL
DEALER FROM WHOM THE PRODUCTS ARE ACQUIRED. IN
SUCH A CASE, PLEASE CONTACT YOUR SPECTRAPRECISION
DEALER FOR APPLICABLE WARRANTY INFORMATION.
Notice to Australian Purchasers - The Australian
Consumer Law
Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Trimble's warranty, as set out in the user manual
accompanying this statement, or as described in the
warranty card accompanying the Product you purchased, is in
addition to any mandatory rights and remedies that you may
have under the Australian Consumer Law.
Official Language
THE OFFICIAL LANGUAGE OF THESE TERMS AND
CONDITIONS IS ENGLISH. IN THE EVENT OF A CONFLICT
BETWEEN ENGLISH AND OTHER LANGUAGE VERSIONS,
THE ENGLISH LANGUAGE SHALL CONTROL
Registration
To receive information regarding updates and new products,
please contact your local dealer or visit the Spectra Precision
website at http://www.spectraprecision.com and create an
account.
Importer of Record
Trimble European Regional Fulfillment Center, Logistics
Manager, Meerheide 45, 5521DZ Eersel, Netherlands.
Notices
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
This device has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
Spectra Precision MobileMapper 50 Handheld User Guide | 3

installation if this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on. The user is encouraged to
try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
Changes and modifications not expressly approved by the
manufacturer or registrant of this equipment can void your
authority to operate this equipment under Federal
Communications Commission rules.
The radios in this device have been designed and
manufactured to not exceed stipulated emission limits for
exposure to radio frequency (RF) energy as required by the
Federal Communications Commission of the U.S.
Government 47 C.F.R. § 2.1091 and 2.1093. The external
antenna connector provided in this device is for GNSS
antennas only.
IC
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference, including interference that may
cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-
003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
This Category II radio communication device complies with
Industry Canada Standard RSS-310.
Ce dispositif de radiocommunication de catégorie II respecte
la norme CNR-310 d’Industrie Canada.
IMPORTANT NOTE:
IC Radiation Exposure Statement
This EUT is compliant with SAR for general
population/uncontrolled exposure limits in IC RSS-102 and
had been tested in accordance with the measurement
methods and procedures specified in IEEE 1528. This
equipment should be installed and operated with minimum
distance 0.5 cm between the radiator & your body.
This device and its antenna(s) must not be co-located or
operating in conjunction with any other antenna or
transmitter. The County Code Selection feature is disabled
for products marketed in the US/Canada.
CE
a. Caution:
• Risk of explosion if battery replaced by an incorrect type.
• Dispose of used batteries according to the instructions.
b. Make sure the temperature for adapter will not be higher
than 40 ˚C.
CE SARCompliance
This device meets the EU requirements (1999/519/EC) on
the limitation of exposure of the general public to
electromagnetic fields by way of health protection.
The limits are part of extensive recommendations for the
protection of the general public. These recommendations
have been developed and checked by independent scientific
organizations through regular and thorough evaluations of
scientific studies. The unit of measurement for the European
Council's recommended limit for mobile devices is the
"Specific Absorption Rate" (SAR), and the SAR limit is 2.0 W/ kg
averaged over 10 gram of body tissue. It meets the
requirements of the International Commission on Non-
Ionizing Radiation Protection (ICNIRP).
For body worn operation, this device has been tested and
meets the ICNIRP exposure guidelines and the European
Standard EN 50360, EN 50566, EN 62209-1 and EN 62209-2,
for use with dedicated accessories. Use of other accessories
which contain metals may not ensure compliance with ICNIRP
exposure guidelines.
RoHS Statement
This device conforms to RoHS (Reduction Of
Hazardous Sub-stances) European Union
regulations that set maximum concentration
limits on hazardous materials used in
electrical and electronic equipment.
CAUTION: RISK OF EXPLOSION IF BATTERY IS DISPOSED OF
INCORRECTLY. DISPOSE OF THE DEVICE AND THE BATTERY
ACCORDING TO INSTRUCTIONS FOR ELECTRONIC WASTE.
Canada
This Class B digital apparatus complies with Canadian ICES-
003.
Cet appareil numérique de classe B est conforme à la norme
NMB-003.
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of the
device.
Spectra Precision MobileMapper 50 Handheld User Guide | 4

Cet appareil est conforme avec Industrie Canada RSS
standard exempts de licence (s). Son fonctionnement est
soumis aux deux conditions suivantes:
(1) cet appareil ne peut pas provoquer d'interférences et
(2) cet appareil doit accepter toute interférence, y compris les
interférences pouvant entraîner un mauvais fonctionnement
de la appareil.
RF Radiation Exposure Statement:
For body worn operation, this phone has been tested and
meets RF exposure guidelines when used with an accessory
that contains no metal and that positions the handset a
minimum of 1.5 cm from the body.
Use of other accessories may not ensure compliance with RF
exposure guidelines.
Déclaration de l'exposition aux radiations RF:
Pour le fonctionnement du corps, ce téléphone a été testé et
répond aux directives d'exposition RF lorsqu'il est utilisé avec
un accessoire qui ne contient pas de métal et qui place le
combiné d'un minimum de 1.5 cm du corps.
Utilisation d'autres accessoires peut ne pas assurer le
respect des directives d'exposition RF.
Europe / EUConformance
The following CE compliance information is
applicable to this device that carry the following CE mark:
This product has been tested and found to comply with all
requirements for CE Marking and sale within the European
Economic Area (EEA).
The Spectra Precision MobileMapper 50 handheld has
Bluetooth wireless technology approval in most EU countries
and satisfies the requirements for Radio and
Telecommunication Terminal Equipment specified by
European Council Directive 1999/5/EC. These requirements
provide reasonable protection against harmful interference
when the equipment is operated appropriately in a
residential or commercial environment.
Spectra Precision MobileMapper 50 handhelds equipped with
wireless cellular modem radios are intended for connection to
European Networks operating with GSM 900, or GSM 1800.
European Conformity Statement
Declaration of Conformity with Regard to the R&TTE
1999/5/EC and EMC 89/336/ EEC directives.
According to ISO / IEC Guide 22 and EN 450 14
- Manufacturer’s Name: Trimble Europe B.V.
- Manufacturer’s Address: European Regional Fulfilment Centre,
Meerheide, 45, 5521DZ Eersel, The Netherlands.
- Declares, under our sole responsibility, that the product:
- Product Name: MobileMapper 50 WiFi and 4G
- Model Number: MobileMapper 50 WiFi and 4G
- Regulatory Name: MobileMapper 50 WiFi and 4G
- Product Options: ALL
Conforms to the following Product Specifications:
All versions
- ETSI EN 301 489-1 : 2011 V1.9.2 ; ETSI EN 301 489-3 : 2013
V1.6.1 ; ETSI EN 301 489- 17 : 2009 V2.2.1
- ETSI EN 300 440-1 : 1.6.1 ; ETSI EN 300 440-2 : 1.4.1
- ETSI EN 301 328 : V1.8.1
- LVD directive 2006/95/EC EN 60950-1 :2006 + A11 :2009 +
A1 :2010+A12 :2011+A2 :2013 ; EN50360 :2001 A1
:2012/EN62209-1 :2006/ EN 50566 :2013 AC : 2014/EN
62209-2 :2010/EN62479 :2010
4G version only
- ETSI EN 301 489- 7 : 2002 V1.3.1 , ETSI EN 301 489- 24: 2009
V1.5.1
- ETSI EN 301 908-1 : V6.2.1 ( 2013-04 ); ETSI EN 301 908-2 :
V6.2.1 , ETSI EN 301 908-13 : V6.2.1
- ETSI EN 300 330-1 : 1.7.1 ; ETSI EN 300 330-2 : 1.5.1
- ETSI EN 301 511-2 : V9.0.2
European Union Customers:(WEEE)
For product recycling instructions and more information,
please go to www.trimble.com/Corporate/Environmental_
Compliance.aspx.
Recycling in Europe: To recycle Trimble WEEE (Waste
Electrical and Electronic Equipment, products that run on
electrical power.), Call [phone], and ask for the
"WEEE Associate". Or, mail a request for recycling instructions
to:
Trimble Europe BV
c/o Menlo Worldwide Logistics
Meerheide 45
5521 DZ Eersel, NL
Spectra Precision MobileMapper 50 Handheld User Guide | 5

Australia and New Zealand
This product conforms with the regulatory requirements of
the Australian Communications Authority (ACA) EMC and
Radiocommunications framework, thus satisfying the
requirements for C-Tick Marking and sale within Australia and
New Zealand.
Additionally, Spectra Precision MobileMapper 50 4G
products that incorporate a modem also comply with
the requirements for A-Tick Marking and sale in Australia.
Taiwan
低功率電波輻射性電機管理辦法
第十二條： 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者
均不得擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條： 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有
干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。低功率射頻電機需
忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
SAR 標準值2.0W/Kg，送測產品實測值為0.545w/Kg
Taiwan – Battery Recycling Requirements
The product contains a removable Lithium-ion battery.
Taiwanese regulations require that waste batteries are
recycled.
廢電池請回收
Spectra Precision MobileMapper 50 Handheld User Guide | 6

Contents
Safety information 10
Radio use 10
Exposure to Radio Frequency (RF) Signals 11
Exposure to radio frequency radiation from Bluetooth and WLAN
transmitters 11
Exposure to radio frequency radiation from cellular wireless transmitters 12
Telecommunications & Internet Association (TIA) information 12
ACadaptor safety 13
Battery safety 13
Electrostatic discharge 14
Storage card use 15
Exposure to loud audio 15
Environmental Hazards 16
1 Getting started 17
Introduction 17
Technical assistance 18
Additional help 18
Use and care of the handheld 18
Parts of the MobileMapper 50 handheld 21
Accessories 22
Powering the handheld 22
Charging the battery 22
Turning the handheld on and off 23
Checking the level of battery power 23
Conserving power 23
Assigning apps to the programmable buttons 24
Resetting the handheld 24
Storing data 24
Memory cards 25
Inserting and removing a SIM card (4Gmodel only) 26
Connecting to an office computer 27
2 Using the Android operating system 29
Using the Home screen 29
Interacting with the handheld 30
Using the Android buttons on the MobileMapper 50 handheld 32
Entering information 32
Using the menus 32
Spectra Precision MobileMapper 50 Handheld User Guide | 7

Contents
Using the on-screen keyboard 33
Editing text 33
Managing notifications 34
Select the language 35
Set the time and date 35
Using the clock to set alarms 35
Display settings 36
Sounds and notifications 36
Locking the device 36
Sending and receiving email 37
3 Using the WLAN and Bluetooth radios 38
Turning on and turning off the WLANand Bluetooth radios 38
Connecting to a WLAN access point 39
Adding a WLAN network 39
Forgetting a WLAN network 40
Advanced WLAN settings 40
Connecting to a Bluetooth-enabled device 41
Working with paired Bluetooth-enabled devices 41
Unpairing a Bluetooth device 42
Accessing a corporate network 42
4 Using the cellular modem (4Gmodelonly) 44
Manually connecting to a cellular network from the modem 44
Using the Smartphone 45
Using the Call History log 46
Messaging 47
Sending a text or a multimedia message 47
Deleting message threads 48
Replying to messages 48
Changing Messaging settings 48
5 Using the GNSS receiver 49
Receiving signals from GNSSsatellites 49
Supported software 50
Using an external GNSS antenna 51
Using an external GNSS receiver 51
6 Using the camera 52
Starting and closing the Camera app 52
Using the camera in Still mode 52
Using the camera in Panorama mode 53
Spectra Precision MobileMapper 50 Handheld User Guide | 8

Contents
Using the camera in Video mode 54
Camera setting options 55
Working with photos and videos in the Android Photos app 56
Spectra Precision MobileMapper 50 Handheld User Guide | 9

Safety information
Safety information
Radio use
Telecommunications & Internet Association (TIA) information
Battery safety
ACadaptor safety
Electrostatic discharge
Storage card use
Exposure to loud audio
Environmental Hazards
Radio use
Depending on the model, the MobileMapper 50 handheld contains a Bluetooth® radio, a
WLAN radio, and a cellular modem radio. In some situations, you may be required to turn
off the radios. For example, aviation authority regulations restrict the use of wireless
transmission devices on board aircraft.
To prevent the handheld from emitting radio signals, do one of the following:
lTo put the handheld in airplane mode, press and hold the Power button for two
seconds to display the Power options menu, then tap Airplane mode. This mode turns
off all wireless connections.
lTo turn off the handheld, press and hold the Power button for two seconds to display
the Power options menu, then tap Power off.
lTo turn off the Bluetooth, WLAN, and wireless cellular modem radios only:
a. On the Apps screen, tap Settings.
b. Under Wireless &Networks, tap each radio type and make sure it is OFF. If any
radio is ON, flick the ON/OFFslider to turn it off.
NOTE – You may need to deactivate the WLAN and/or Bluetooth radio in the handheld if
the country in which you are working does not approve the use of WLAN and/or Bluetooth
wireless technology. If you are unsure about whether the handheld’s radios are approved
for use in your country, check with your Spectra Precision reseller.
Spectra Precision MobileMapper 50 Handheld User Guide | 10

Safety information
Exposure to Radio Frequency (RF) Signals
Your device contains a radio transmitter and receiver. The radiated output power is far
below the international radio frequency exposure limits. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on the safety standards previously set by
international standards bodies:
lAmerican National Standards Institute (ANSI) IEEE. C95.1-1992.
lNational Council on Radiation Protection and Measurement (NCRP). Report 86. 1986.
lInt’l Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996.
lMinistry of Health (Canada), Safety Code 6. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health.
SAR: 0.545w/kg
Use of unauthorized or modified antennas may impair call quality and damage the device,
causing loss of performance. To assure optimal performance and ensure human
exposure to RF energy is within the guidelines set forth in the relevant standards; always
use your device only in its normal-use position.
Avoiding contact with the antenna area when the device is IN USE optimizes the antenna
performance.
Exposure to radio frequency radiation from Bluetooth and WLAN
transmitters
This device is approved as a portable device with respect to Radio Frequency (RF) exposure
compliance. The radiated output power of the internal wireless radio transmitters is less
than 100 milliwatt, which results in exposure levels far below the FCC radio frequency
exposure limits, even when operated in close proximity to the body. The internal wireless
radios operate within guidelines found in international radio frequency safety standards
and recommendations, which reflect the consensus of the international scientific
community. Spectra Precision therefore believes the internal wireless radios are safe for
use by users. The level of electromagnetic energy emitted is hundreds of times lower than
the electromagnetic energy emitted by wireless devices such as mobile phones. However,
the use of wireless radios may be restricted in some situations or environments, such as
on aircraft. If you are unsure of restrictions, you are encouraged to ask for authorization
before turning on the wireless radios.
Spectra Precision MobileMapper 50 Handheld User Guide | 11

Safety information
Exposure to radio frequency radiation from cellular wireless
transmitters
Devices equipped with wireless cellular modem radios have been designed and
manufactured to meet safety requirements for limiting exposure to radio waves. When
used in accordance with the instructions set forth in this manual, the equipment has been
independently verified to not exceed the emission limits for safe exposure to radio
frequency (RF) energy as specified by the Federal Communications Commission of the U.S.
Government in 47 CFR §2.1093. These limits are part of comprehensive guidelines and
establish permitted levels of RF energy for the general population. The guidelines are
based on standards that were developed by independent scientific organization through
periodic and thorough evaluation of scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons, regardless of age and health.
Telecommunications & Internet Association (TIA)
information
Hearing Aids: Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your wireless service provider, or call
customer service to discuss alternatives.
Pacemakers and Other Medical Devices: The Health Industry Manufacturers Association
recommends a minimum separation of six inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the pacemaker.
These recommendations are consistent with the independent research by and
recommendations of Wireless Technology Research. Persons with pacemakers should use
the ear opposite the pacemaker to minimize the potential for interference. Persons with
pacemakers should exercise great caution if using a hands-free device such as a headset,
as these persons may be at greater risk of the device not maintaining the recommended
minimum six inches of separation from the pacemaker. If you have any reason to suspect
that interference is taking place, turn the device OFF immediately.
If you use any other personal medical device, consult the manufacturer of your device to
determine if they are adequately shielded from external RF energy. Your physician may be
able to assist you in obtaining this information.
Turn the device OFF in health care facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities may be using equipment that could
be sensitive to external RF energy.
Spectra Precision MobileMapper 50 Handheld User Guide | 12

Safety information
ACadaptor safety
To charge the handheld’s battery, use the power cable and adaptor kit provided with the
handheld (see Powering the handheld, page 22).
WARNING – To use ACadaptors safely:
lUse only the AC adaptor intended for the handheld. Using any other AC adaptor
can damage the handheld and may void your warranty. Do not use the AC adaptor
with any other product.
lMake certain that the input voltage on the adaptor matches the voltage and fre-
quency in your location.
lMake certain that the adaptor has prongs compatible with your outlets.
lDo not use the AC adaptor in wet outdoor areas; it is designed for indoor use only.
lUnplug the AC adaptor from power when not in use.
Battery safety
The rechargeable Lithium-ion battery is supplied partially charged. Charge the battery
completely before using it for the first time (see Powering the handheld, page 22). If the
battery has been stored for longer than six months, charge it before use.
WARNING – Use only the battery intended for the product. Using any other battery
can damage the handheld and may void your warranty. If the battery becomes
damaged or stops charging fully, replace it with a new battery.
WARNING – Charge and use the rechargeable Lithium-ion battery only in strict
accordance with the instructions. Charging or using the battery in unauthorized
equipment can cause an explosion or fire, and can result in personal injury and/or
equipment damage. To prevent injury or damage:
lDo not charge or use the battery if it appears to be damaged or leaking.
lCharge the Lithium-ion battery only in a product that is specified to charge it. Be
sure to follow all instructions that are provided with the battery charger.
lDiscontinue charging a battery that gives off extreme heat or a burning odor.
lUse the battery only in equipment that is specified to use it.
lUse the battery only for its intended use and according to the instructions in the
product documentation.
Spectra Precision MobileMapper 50 Handheld User Guide | 13

Safety information
WARNING – Avoid contact with the rechargeable Lithium-ion battery if it appears to
be leaking. Battery fluid is corrosive, and contact with it can result in personal injury
and/or property damage. To prevent injury or damage:
lIf the battery leaks, avoid contact with the battery fluid.
lIf battery fluid gets into your eyes, immediately rinse your eyes with clean water and
seek medical attention. Do not rub your eyes!
lIf battery fluid gets onto your skin or clothing, immediately use clean water to wash
off the battery fluid.
WARNING – Do not damage the rechargeable Lithium-ion battery. A damaged
battery can cause an explosion or fire, and can result in personal injury and/or
property damage. To prevent injury or damage:
lDo not use or charge the battery if it appears to be damaged. Signs of damage
include, but are not limited to, discoloration, warping, and leaking battery fluid.
lDo not store or leave your device near a heat source such as near a fireplace or
other heat-generating appliance, or otherwise expose it to temperatures in excess
of 70 °C (158 °F) such as on a vehicle dashboard. When heated to excessive tem-
peratures, battery cells could explode or vent, posing a risk of fire.
lDo not leave the battery immersed in water.
lDo not use or store the battery inside a vehicle during hot weather.
lDo not drop or puncture the battery.
lDo not open the battery or short-circuit its contacts.
CAUTION – Safe temperature ranges are:
lOperating temperature range: -20 °C to +60 °C (-4 °F to +140 °F).
lStorage temperature range: -30 °C to +70 °C (-13 °F to +158 °F).
Electrostatic discharge
WARNING – Static electricity can harm electronic components inside your
handheld. To prevent static damage, discharge static electricity from your body before
you touch any of the electronic components inside your device, such as a memory
module. You can do so by touching an unpainted metal surface.
The handheld is designed for outdoor conditions; however under conditions of low
humidity extremely high voltage discharge events are possible. Users are advised that the
Spectra Precision MobileMapper 50 Handheld User Guide | 14

Safety information
risk of causing discharge to sensitive electronics can be minimized by avoiding finger
contact to the recessed connectors on the unit.
Storage card use
The handheld provides a storage card slot, providing an alternative storage location to the
storage memory in the handheld.
WARNING – Static electricity can harm electronic components inside your
handheld. To prevent static damage, discharge static electricity from your body before
you touch any of the electronic components inside your device, such as a memory
module. You can do so by touching an unpainted metal surface.
Exposure to loud audio
To prevent possible hearing damage, do not listen at high volume levels for
long periods.
Spectra Precision MobileMapper 50 Handheld User Guide | 15

Safety information
Environmental Hazards
The product complies with international RoHS regulations.
Toxic and Hazardous Substances and Elements
Part name Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr6+)
Poly-brom-
inated
biphenyls
(PBB)
Poly-brom-
inated
diphenyl
ethers
(PBDE)

Display X O O O O O
Keypad  O O O O O
Housing O O O O O O 
Hardware O O O O O O
Product Period does not include these items
Battery X O O O O O
Power supply X O O O O O
Cable O O O O O O 
Manual O O O O O O 
Hand strap O O O O O O 
Stylus Package O O O O O O 
Spectra Precision MobileMapper 50 Handheld User Guide | 16

Getting started
Introduction
Technical assistance
Use and care of the handheld
Parts of the MobileMapper 50 handheld
Accessories
Powering the handheld
Resetting the handheld
Storing data
Inserting and removing a SIM card (4Gmodel only)
Connecting to an office computer
Introduction
This user guide describes how to set up and use the MobileMapper 50 handheld. The
information in this guide supplements the information in the MobileMapper 50 Quick Start
Guide, which you received with the handheld.
There are two models of the MobileMapper 50 handheld—a WLAN-only model, and a 4G/
WLAN model. Both models:
lare powered by the Android™ 5.1 “Lollipop” mobile operating system
lhave Wireless LAN technology
lhave Bluetooth® wireless technology
lhave a high-sensitivity GNSS receiver, supporting GPS, GPS plus GLONASS, or GPS plus
Beidou, with 1 to 2 meter positioning accuracy in real time (using SBAS)
lare rated IP67 (see Use and care of the handheld for more information)
1
Spectra Precision MobileMapper 50 Handheld User Guide | 17

1 Getting started
lcontain a MicroSD/SDHC storage slot
lhave a replaceable Li-ion battery
The MobileMapper 50 Wi-Fi only handheld has a built-in 8 megapixel digital camera with
geotagging, 8 GB of storage. and a 3100 mAh removable battery.
The MobileMapper 50 4G handheld contains a 4G cellular modem for data transfer and
voice call capability, a 13 megapixel digital camera with geotagging, 16 GB of storage, NFC
(Near Field Communication)capabilities, and a 4800mAh removable battery.
The handheld's battery is partially charged when shipped new from the factory.
The SIM card and Micro SD card slots are below the battery; to access the slots, turn off the
handheld and remove the battery.
Your warranty is invalidated if you open or tamper with the outer casing of the device.
Unapproved modifications or operations beyond or in conflict with these instructions for
use may void authorization by the authorities to operate the equipment.
Only approved accessories may be used with the device. In general, all cables must be high
quality, shielded, correctly terminated and normally restricted to two meters in length. The
power supply approved for this product employs special provisions to avoid radio
interference and should not be altered or substituted.
Technical assistance
Go to the MobileMapper 50 handheld webpage on the Spectra Precision website
www.spectraprecision.com for the latest support information, including:
lsupport notes detailing support issues
ldocumentation
lthe latest files available for download
Additional help
If you still cannot find the information that you need, contact your Spectra Precision
reseller.
Use and care of the handheld
The device’s rugged design allows you to run your device in harsh outdoor environments.
Here are some considerations that will help you protect your device and get the most out
of it when working in very wet, hot or cold conditions.
Spectra Precision MobileMapper 50 Handheld User Guide | 18

1 Getting started
lThe handheld is rated IP67 but is not completely waterproof. IPx7 is defined as res-
istant to submersion in water up to 1 meter deep for up to 30 minutes. However, do
not unnecessarily immerse the handheld in water.
CAUTION – Make sure all sure the protective port covers are appropriately fitted to
any external ports, and that they are not damaged; if any protective port covers are
missing or damaged in any way, the IPx7 rating is compromised and the device is not
water-resistant.
lThe device is designed to resist damage for drops up to 4 ft (1.22 meters). However, the
device should not be dropped unnecessarily or subjected to any strong impact. Check
the fit of the SIM card, storage card, and battery after a drop.
lProtect the handheld from extreme temperatures. For example, do not leave the hand-
held on the dashboard of a vehicle.
lTemperature range: The operational temperature range is from -20 °C to +60 °C (-4 °F
to +140 °F). Although the device is designed to be rugged, do not leave it in direct sun-
light in excessive heat or in a vehicle in the sunlight for extended periods as the internal
temperature may exceed the operating or storage temperature limits, especially while
charging the battery.
Batteries perform best at room temperature. The battery has a stable capacity as
temperatures rise; however, the colder the temperature, the greater the reduction in
available battery capacity. Under very cold conditions (-20°C / -4 °F and below), the
battery capacity is noticeably reduced. To improve the battery performance in very
cold conditions, consider increasing the load on the battery, such as by adjusting the
backlight to full brightness. Increasing the battery load causes the battery to generate
heat, thus warming the battery and improving the performance.
lProtect the display from impact, pressure, or abrasive substances that can scratch it or
crack it. Use your finger or a capacitive stylus, and avoid using excessive pressure and
sharp or abrasive objects. To protect the touch screen from pressure and abrasive
objects, apply a screen protector; two are shipped with the device, and you can pur-
chase additional screen protectors if required. The use of ballpoint pens, nails or other
sharp objects to operate the touchscreen will scratch and/or damage the device.
lDo not use abrasive cleaners directly on the display. Doing so may void your warranty.
lKeep the outer surface free of dirt and dust. To clean the handheld, use a soft,
dampened cloth with either water or a diluted mild detergent. If a mild detergent is
used, ensure all soap residue is removed. Do not use any chemical cleaners and do not
put the device in the dishwasher.
lEnsure that the protective covers are re appropriately fitted to any external ports so
that they are kept free from dirt, dust, fluid ingress, and electrostatic discharge.
Spectra Precision MobileMapper 50 Handheld User Guide | 19

1 Getting started
Do not attempt to dismantle the device for repair. There are no user-serviceable parts
inside. For service, contact your local dealer.
Battery safety: Lithium-ion batteries are classified by the U. S. Federal Government as non-
hazardous waste and are safe for disposal in the normal municipal waste stream except
where prohibited by local or regional regulations. These batteries contain recyclable
materials and are accepted for recycling.
NOTE – In the event of battery failure, return the device to Spectra Precision or an
Authorized Service Provider. Spectra Precision disposes of used batteries in accordance
with local regulations.
lDo not disassemble or open, crush, bend or deform, puncture, or shred the battery
assembly. There are no user-serviceable parts in the battery assembly.
lDo not use the battery if plastic case is cracked, compromised or punctured.
lDo not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose to water or other liquids.
lDo not expose to fire, explosion, or other hazard. Do not expose to temperatures
above +70 °C (+158 °F).
lOnly use a charging system that has been qualified for use with the device.
lIn the event of a battery leak, do not allow the liquid to come in contact with the skin or
eyes. If contact has been made, flush the affected area with water and seek medical
advice.
Power supply safety: Use only AC adapters intended for the device. Other external power
sources may damage your product and void the warranty. Certification of this Class III
product is only valid with the power supply that shipped with the device.
lEnsure the input voltage on the power supply matches the voltage in your location.
Ensure the power supply has prongs compatible with your outlets.
lThe power supply is designed for indoor use only. Avoid using the power supply in wet
areas.
lUnplug the power supply from power when not connected to the device.
lDo not create a short circuit in the power output connector.
Spectra Precision MobileMapper 50 Handheld User Guide | 20
