Prestigio Geovision 5330 BTFMTV User manual

EN - 1
CAUTION
1. To reduce the risk of electric shock, do not remove the cover (or back). No
user-serviceable parts inside. Refer servicing to qualified service personnel. Unplug the
product from the wall outlet before servicing or when it is unused for a long period of
time.
2. The manufacturer should not hold responsibility for the damage caused by any
substitutions and modifications of the product without authorization from the
manufacturer or authorized unit.
3. Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.
WARNING
The apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on the apparatus.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of un-insulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric to persons.
Important Safety
Instructions
EN

EN - 2
Accessories List
ITEM NAME QTY
Car Charger 1
Mounting Cradle 1
USB Cable 1
Stylus pen 1
Stylish Carrying case 1
Driver / Documentation CD 1
User Manual 1
Warranty Card 1
Accessories
EN

EN - 3
Front and Side View
1. LCD Touch Screen
Tap the screen with touch pen or finger to select menu commands or to enter
information.
2. Battery Status Indicator
The indicator glows in bright amber color when battery is fully charged and in red
color when charging.
3. microSD Slot
Receives microSD memory card for data access or memory expansion.
4. Mini-USB Port
Connects to USB Cable for data access or battery charging
5. Headphone Port
Connects to stereo headphones or headsets.
6. Reset Button
Press to restore system to factory default settings.
7. Power Button
Press to power ON/OFF device.
8. Speaker
Emits sound, voice or music.
9. Analog TV Antenna
Receives television signals
View of Main Unit
1
2
4
3
5
6
7
8
EN
9

EN - 4
NOTE:
Please always make sure that the device and any other external device
connected to the device are powered off and unplugged from the power
supply before attempting to connect the device to any external device.
Inserting microSD Card
zTo insert a microSD card, place
connector towards device and card
label towards the front side of the
device.
zTo remove a microSD card, gently
press the edge of the card to release
the safety lock and pull the card out
of the slot.
NOTE:
Please always make sure that no application is accessing the microSD
card before extraction.
Charging
1. Connecting to External USB Device
zFlip open the protective rubber cover towards the front of the device.
zInsert USB connector into the appropriate USB port.
zInsert the other USB connector into USB port on PC to start charging.
Device Connection
EN

EN - 5
2. Connecting to Car Charger
zFlip open the protective rubber cover towards the left side of the device.
zInsert USB connector into the appropriate USB port.
zInsert car charger connector into vehicle 12V accessory/cigarette socket to start
charging.
NOTE:
Please connect the car charger to
vehicle 12V accessory/cigarette
socket after vehicle engine is started
to protect the device from sudden
surges in current.
Connecting to Earphones
zFlip open the protective rubber cover towards the front of the device.
zInsert earphone plug (not included) into the appropriate earphone port to switch
audio output from device speaker to earphone.
NOTE:
Excessively loud volume is potentially detrimental to hearing. Please turn
down the volume before connecting the earphone and gradually turn up
the volume to a comfortable level.
Device Connection
EN

EN - 6
About Rechargeable Battery
The device is equipped with a built-in rechargeable battery. Please fully charge the
battery (for at least 8 hours) before initial use. The battery status indicator glows in red
color when charging and turns bright amber color when charging is complete. Charging
time is approximately 2 hours.
Working conditions and precautions for the rechargeable battery
zDevice with new batteries should be fully charged before initial use.
zBattery should only be used and charged when temperatures are between 0°~
37°C.
zIt is not necessary to start charging the device before the battery is fully discharged.
NOTE:
Please connect the car charger to vehicle 12V accessory/cigarette
socket after vehicle engine is started to protect the device from sudden
surges in current.
Cautions on Battery
Char
g
in
g
EN

EN - 7
NOTE:
zDo not operate the device while driving.
zPlease select an appropriate location on the dashboard or
windshield where the device will not obstruct driver field of vision.
Device Mounting Procedures
The device can be securely mounted on vehicle dashboard or windshield with the
mounting cradle included. Please follow procedures below to operate mounting cradle:
1. Select an appropriate location on windshield or dashboard where the device and
mounting cradle will not obstruct driver field of vision.
2. Please also make sure that the device has a clear view of sky to attain best GPS
reception.
zPlace device on the bracket with
bottom positioned on the appropriate
socket.
zPush on the top edge to securely
install device onto the cradle.
zLift the suction cup lever and press
the suction cup at desired location.
zPress down the suction cup lever to
secure the mounting cradle on the
surface.
zRotate the knob to adjust device to
desired viewing angle.
To Dismount Device
1. Push the tap on top of the mounting cradle to release the device.
2. Lift the suction cup lever to easily remove the suction cup from windshield or
dashboard.
Using Mounting
Cradle
EN

EN - 8
1. Press and hold Power Button
to turn on device.
2. Shortly after the greeting screen
is shown, the main menu will be
displayed.
3. Tap the corresponding buttons
with touch pen included to
navigate various functions.
4. Press and hold Power Button
to turn off the device or to allow
device to enter sleep mode.
Getting Started
EN

EN - 9
Shortly after the greeting screen is shown, main menu will be displayed automatically.
The main menu consists of the following sections.
Item Description
Displays time.
(Optional) Enable/disable Bluetooth function.
(Optional) Enable/disable FM-Transmitter function.
Show MicroSD/SDHC card.
Indicates electric quantity.
Press gh to select functions.
Main Menu
EN

EN - 10
NOTE:
Do NOT store audio files in the built-in flash storage for it may result in
system malfunction. The flash storage is used to store system data and
should not be tempered at anytime.
Reminders regarding music playback function
zAudio files should be loaded in the SD card before connecting to device.
zAudio files can be imported to the SD card from PC by a variety of programs such
as Windows Media Player.
zThe loading process should be performed independently from the device.
zDo NOT attempt to use the device as a card reader device.
Playing Music
zInsert SD card with audio files loaded
before powering on the device.
zTa p o n to enter Music File List.
zTap on to exit the current
function.
zTap on to return to previous/ skip
to next page.
zTap on the desired audio file.
Audio Player Mode
EN

EN - 11
During Music Playback
zTap on / to return to previous/skip to next song.
zTap on to play/pause playback.
zTap on to stop playback.
zTap on to adjust volume.
zTap on to exit the audio player mode.
zTap on to select repeat/random/loop/sequential playback.
zTap on to enter play list.
zTap on and drag the bar slider to select desired starting time for
playback.
zTap on to return to homepage.
Audio Player Mode
EN

EN - 12
NOTE:
Do NOT store video files in the built-in flash storage for it may result in
system malfunction. The flash storage is used to store system data and
should not be tempered at anytime.
Reminders regarding video playback function
zVideo files should be loaded in the SD card before connecting to device.
zThe loading process should be performed independently from the device.
zDo NOT attempt to use the device as a card reader device.
Playing Video
zInsert SD card with video files loaded
before powering on the device.
zTap on to enter Video File List.
zTap on to exit the current
function.
zTap on to return to previous/ skip
to next page.
zTap on the video file and select the
desired video.
Video Player Mode
EN

EN - 13
During Video Playback
zTap on to exit the video player mode.
zTap on to play/pause playback.
zTap on to skip to next video.
zTap on to enter play list.
zTap on and drag the bar slider to select desired starting time for
playback.
zTap on to adjust brightness.
zTap on to adjust volume.
zDouble tap on to turn to full-screen mode.
Video Player Mode
EN

EN - 14
NOTE:
Do NOT store photo files in the built-in flash storage for it may result in
system malfunction. The flash storage is used to store system data and
should not be tempered at anytime.
Reminders regarding photo viewing function
zHigh resolution image files may considerably slow down device reading speed.
Image files with resolution 640 X 480 or lower is recommended.
zImage files should be loaded in the SD card before connecting to device.
zThe loading process should be performed independently from the device.
zDo NOT attempt to use the device as a card reader device.
Viewing Photo
zInsert SD card with image files loaded
before powering on the device.
zTap on to enter Photo List.
zTap on to exit the current
function.
zTap on to return to previous/ skip
to next page.
zTap on the photo file and select the
desired photo.
Photo Viewer Mode
EN

EN - 15
During Photo Viewing
zTap on to exit the photo mode.
zTap on / to zoom image out / in.
zTap on to rotate image 90° counter-clockwise.
zTap on to display in full-screen mode. Double tap the screen to resume.
zTap on to enter photo list.
zTap on / to return to previous / skip to next image file.
Photo Mode
EN

EN - 16
NOTE:
Do NOT store ebook files in the built-in flash storage for it may result in
system malfunction. The flash storage is used to store system data and
should not be tempered at anytime.
Reminders regarding E-book function
zE-book files should be loaded in the SD card before connecting to device.
zThe loading process should be performed independently from the device.
zDo NOT attempt to use the device as a card reader device.
zThe device supports the format of .TXT only.
Reading Text
zInsert SD card with text files loaded
before powering on the device.
zTap on to enter Ebook List.
zTap on to exit the current
function.
zTap on to return to previous/ skip
to next page.
zTap on the file and select the desired
text.
E-book Mode
EN

EN - 17
During Text Playback
zTap on to exit the E-book mode.
zTap on to enter E-book list.
zTap on / to return to previous / skip to next page.
zTap on to turn to the bookmark list.
zTap on to adjust the font size.
zTap on to change the font color.
zTap on to add the bookmark.
E-book Mode
EN

EN - 18
NOTE:
Do NOT store game files in the built-in flash storage for it may result in
system malfunction. The flash storage is used to store system data and
should not be tempered at anytime.
Reminders regarding Game function
zGame files should be loaded in the SD card before connecting to device.
zThe loading process should be performed independently from the device.
zDo NOT attempt to use the device as a card reader device.
Playing Game
zInsert SD card with game files loaded
before powering on the device.
zTap on to enter the game mode.
zTap on to exit the current
function.
Game Mode
EN

EN - 19
Tapon toenterAnalog TV mode detailed as follows.
zTap on to store the current TV channel.
zTap on / to manually/automatically search for a TV channel. Search
result is displayed in the list.
zTap on to delete the desired channel.
zTap on to select the region.
zTap on / to turn to previous/next item.
zTap on / to adjust volume.
zTap on to exit the Analog TV mode.
Analog TV
EN

EN - 20
Click button to enter into below interface, and choose the region you locate as
the below picture:
Click button and choose the channel you like to play from existing channels as
the following picture:
Analog TV
EN
