MeiTrack T633L User manual

MEITRACK T633L User Guide
MEITRACK T633L User Guide

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 2 -
Change History
File Name
MEITRACK T633L User Guide
Project
T633L
Creation Date
2019-04-11
Subproject
User Guide
Total Pages
15
Hardware
version
V1.0
Software version
V202 or later
Version
V1.0
Confidential
External Documentation

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 3 -
Contents
1 Copyright and Disclaimer........................................................................................................................................... - 4 -
2 Product Introduction ................................................................................................................................................. - 4 -
2.1 Product Features........................................................................................................................................... - 4 -
2.1.1 Idling Detection.................................................................................................................................... - 4 -
2.1.2 Fatigue Driving Detection .................................................................................................................... - 4 -
2.1.3 Controlling Buzzer Sounds ................................................................................................................... - 4 -
3 Product Functions and Specifications........................................................................................................................ - 5 -
3.1 Product Functions......................................................................................................................................... - 5 -
3.1.1 Position Tracking .................................................................................................................................. - 5 -
3.1.2 Anti-Theft............................................................................................................................................. - 5 -
3.1.3 Monitoring........................................................................................................................................... - 5 -
3.1.4 Other Functions ................................................................................................................................... - 5 -
3.1.5 Functions of Optional Accessories....................................................................................................... - 6 -
3.2 Specifications................................................................................................................................................ - 6 -
4 T633L and Accessories............................................................................................................................................... - 7 -
5 Appearance................................................................................................................................................................ - 8 -
6 First Use..................................................................................................................................................................... - 8 -
6.1 Installing the SIM Card.................................................................................................................................. - 8 -
6.2 Charging the Device...................................................................................................................................... - 9 -
6.3 LED Indicator................................................................................................................................................. - 9 -
6.4 Configuring Device Parameters by Meitrack Manager ................................................................................. - 9 -
6.5 Tracking by Mobile Phone............................................................................................................................. - 9 -
6.6 Common SMS Commands .......................................................................................................................... - 11 -
6.6.1 Setting the Speeding Alert(only work with OUT2 Port) – B07 ........................................................... - 11 -
6.6.2 Setting the Idling Alert – B14 ............................................................................................................. - 11 -
6.6.3 Setting Fatigue Driving – B15 ............................................................................................................. - 11 -
6.6.4 Setting the Driving License Type – C50 .............................................................................................. - 12 -
6.6.5 Setting the Duration of Buzzing(only work with OUT2 Port) – C51.................................................... - 12 -
7 Logging In to MS03 Tracking System........................................................................................................................ - 12 -
8 Installing the T633L.................................................................................................................................................. - 13 -
8.1 Installing GPS and 3G Antennas.................................................................................................................. - 13 -
8.2 Installing an I/O Cable................................................................................................................................. - 13 -
8.3 Device Connection Diagram........................................................................................................................ - 15 -

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 4 -
1Copyright and Disclaimer
Copyright © 2019 MEITRACK. All rights reserved.
and are trademarks that belong to Meitrack Group.
The user manual may be changed without notice.
Without prior written consent of Meitrack Group, this user manual, or any part thereof, may not be reproduced for
any purpose whatsoever, or transmitted in any form, either electronically or mechanically, including photocopying and
recording.
Meitrack Group shall not be liable for direct, indirect, special, incidental, or consequential damages (including but not
limited to economic losses, personal injuries, and loss of assets and property) caused by the use, inability, or illegality
to use the product or documentation.
2Product Introduction
The T633L is a brand new 4G vehicle tracker. This unit can connect to multiple accessories: RFID card reader, camera
and LED Nixie Tube Display. In addition, it supports driving behavior analysis, fuel level monitoring and temperature
monitoring and its performance has been significantly improved.
2.1 Product Features
2.1.1 Idling Detection
When the device detects that the vehicle stops moving for a long time and the ACC is on, an idling alert will be
generated and the buzzer will make sounds every 0.5 seconds. When the ACC is off or the vehicle starts moving, the
device will exit the idling state and the buzzer will not make sounds.
To implement this function, you must connect device's input 3 to ACC detection cable and output 2 to the buzzer, or
connect device's input 3 to ACC detection cable and ensure that the magnetic card reader supports buzzer alerts.
For details, see the section 6.6.2 "Setting the Idling Alert –B14."
2.1.2 Fatigue Driving Detection
When the device detects that the driver has been driving a vehicle for a long time, a fatigue driving alert will be
generated the buzzer will beep twice every 1 second.
To implement this function, you must connect device's input 3 to ACC detection cable and output 2 to the buzzer, or
connect device's input 3 to ACC detection cable and ensure that the magnetic card reader supports buzzer alerts.
For details, see the section 6.6.3 "Setting Fatigue Driving –B15."
2.1.3 Controlling Buzzer Sounds
When the device detects speeding, the buzzer will make sounds (BI-BI-BI-BI).
To implement this function, you must connect device's output 2 to the buzzer or ensure that the magnetic card reader
supports buzzer alerts.
For details, see the section 6.6.1 "Setting the Speeding Alert(only work with OUT2 Port) –B07."

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 5 -
3Product Functions and Specifications
3.1 Product Functions
3.1.1 Position Tracking
GPS + LBS positioning
Real-time location query
Track by time interval
Track by distance
Cornering report
Track by mobile phone
3.1.2 Anti-Theft
SOS alert
GPS antenna cut-off alert
External power supply cut-off alert
GPS blind spot alert
Remote vehicle fuel/power cut-off
Engine or vehicle door status alert
Towing alert
Geo-fence alert
3.1.3 Monitoring
Harsh acceleration and braking detection
Idling detection
Fatigue driving reminder and monitoring
Speeding reminder and monitoring
Driver authorization detection
Fuel level monitoring
Temperature monitoring
3.1.4 Other Functions
SMS/GPRS (TCP/UDP) communication (Meitrack protocol)
Built-in 8 MB buffer for recording driving routes (Store 4,096 GPRS cache records, 64 SMS cache records, and
65,536 GPS logs)
Mileage report
Low power alert for internal battery
Build-in 3-axis accelerometer
Over-the-Air (OTA) update

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 6 -
3.1.5 Functions of Optional Accessories
Optional Accessory
Function
Microphone & Speaker
Two-way calling OR monitoring
iButton
Identify the driver ID and grant permission to start the vehicle.
A53 resistive fuel level sensor
Detect the fuel level.
A52 digital temperature sensor + A61 sensor
box
Detect temperature.
2 RS232 ports
RFID reader
Identify the driver ID and grant permission to start the vehicle.
Monitor driver attendance by RFID report.
Ultrasonic fuel level sensor
Detect the fuel level.
4 RS485 ports
2 camera ports
Photographing and monitoring
2 A82 LED Nixie Tube Display
ports
Display driving speed in real time.
Magnetic/RFID Reader
Ultrasonic Fuel Sensor
Camera
A82 LED Nixie Tube Display
RS232-1
√
√
RS232-2
√
√
RS485-1
√
RS485-2
√
LED1_RS485
√
LED2_RS485
√
All above are the peripheral that T633L already supported. If necessary, Meitrack is capable of customizing any
peripherals like cameras, ultrasonic fuel sensor, LED display connected to T633L as long as they support RS232/RS485.
3.2 Specifications
Item
Specifications
Dimension
106 mm x 24.5 mm x 70 mm
Weight
190g
Power supply
DC 11.4–36 V/1.5 A
Backup battery
400 mAh/3.7 V
Power consumption
Current in sleep mode: 11 mA
Operating temperature
-20°C to 55°C
Operating humidity
5% to 95%
Working hour
45 hours in power-saving mode
4 hours in normal mode
LED indicator
Green indicator showing the GSM signal
Blue indicator showing the GPS signal
Button/Switch
1 SOS button (for sending SMSs or dialing)
1 power button
Memory
8 MB byte
Sensor
3-axis accelerometer (used to wake the device up by vibration and detect towing alerts)

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 7 -
Frequency band
T633L-E：
2G GSM:B3(1800)/B8(900)
3G WCDMA:B1(2100)/B5(850)/B8(900)
4G FDD:B1(2100)/B3(1800)/B5(850)/B7(2600)/B8(900)/B20(800)
T633L-A：
3G WCDMA:B2(1900)/B4(1700/2100)/B5(850)
4G FDD: B2(1900)/B4(2300)/B12(700)
T633L-AU：
2G GSM:B2(1900)/B3(1800)/B5(850)/B8(900)
3G WCDMA:B1(2100)/B2(1900)/B5(850)/B8(900)
4G FDD:B1(2100)/B2(1900)/B3(1800)/B4(2300)/B5(850)/B7(2600)/B8(900)/B28(700)
GPS sensitivity
-163 dB
Positioning accuracy
2.5m
I/O port
The device supports 3 digital input ports, 3 output ports, 2 AD input ports, and 1 1-Wire
digital temperature sensor (iButton) interface by default. At most 9 negative input OR
7 positive ports, 8 output ports, or 4 AD input ports can be configured. For details, see
the section 8.2 "Installing an I/O Cable."
2 RS485 ports (4 pins) for connecting to the LED Nixie Tube Display
2 RS485 ports (4 pins) for connecting to the camera
1 CAN bus interface (FMS protocol)
1 RS232 port (8 pins) for connecting to the magnetic card reader
1 extended RS232 port (4 pins) for connecting to the RFID reader
1 audio port (3.5 mm)
1 Micro USB port
4T633L and Accessories
T633L and standard accessories:
T633L tracker
External 3G antenna
External GPS antenna
I/O cable with an SOS button (2 meters)
CD download card
Optional accessories:
USB cable
iButton
Relay (12 V/24 V)
A53 fuel level sensor (voltage sensor)
A52 digital temperature sensor
RFID reader
Magnetic reader
Buzzer
Camera

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 8 -
A82 LED Nixie Tube Display
Speaker and microphone
CANBUS convertor cable
5Appearance
6First Use
6.1 Installing the SIM Card
1. Loosen the screws, and remove the front cover of the device.
2. Insert the SIM card into the card slot with its gold-plated contacts facing towards the Printed Circuit Board
(PCB).
3. Close the cover, and tighten the screws.
Note:
Power off the device before installing the SIM card.
Ensure that the SIM card has sufficient balance.
Ensure that the phone card PIN lock has been closed properly.
Ensure that the SIM card in the device has subscribed the caller ID service if you want to use your authorized

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 9 -
phone number to call the device.
6.2 Charging the Device
When you use the device for the first time, connect the device's GND (-Black) and Power (+Red) wires to 12 V or 24
V external power supply for charging. Ensure that the device is charged at least three hours. Eight hours are
recommended.
The device can be installed on a vehicle only after it is configured and tested.
6.3 LED Indicator
Press and hold down the power button for 3–5 seconds to start the device.
GPS Indicator (Blue)
Steady on
A button or an input is triggered.
Blink (every 0.1 seconds)
The device is being initialized or the battery power is low.
Blink (0.1 seconds on and 2.9 seconds off)
A GPS signal is received.
Blink (1 second on and 2 seconds off)
No GPS signal is received.
3G Indicator (Green)
Steady on
A call is coming in.
Blink (every 0.1 seconds)
The device is being initialized.
Blink (0.1 seconds on and 2.9 seconds off)
A base station signal is received.
Blink (1 second on and 2 seconds off)
No base station signal is received.
6.4 Configuring Device Parameters by Meitrack Manager
This section describes how to use Meitrack Manager (version 6.0.0.11 or later) to configure the device on a computer.
Procedure:
1. Install the USB driver and Meitrack Manager.
2. Connect the device to a computer by using the USB cable.
3. Run Meitrack Manager, then the following dialog box will appear:
Turn on the device, then Meitrack Manager will detect the device model automatically and the parameter page will
appear accordingly.
For details about Meitrack Manager, see the MEITRACK Manager User Guide.
6.5 Tracking by Mobile Phone
Call or send the 0000,A00 command by SMS to the device's SIM card number. The device will reply to an SMS with a
map link.

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 10 -
Click the SMS link. The device's location will be displayed on Google Maps on your mobile phone.
Note: Ensure that the device's SIM card number has subscribed the caller ID service. Otherwise, the tracking function
by mobile phone will be unavailable.
SMS example:
Now,061314 10:36,V,26,0Km/h,96%,http://maps.meigps.com/?lat=22.513781&lng=114.057183
The following table describes the SMS format:
Parameter
Description
Remarks
Now
Indicates the current location.
SMS header: indicates the current location
or the alert type.
061314 10:36
Indicates the date and time in MMDDYY
hh:mm format.
None
V
The GPS is invalid.
A = Valid
V = Invalid
26
Indicates the 3G signal strength.
Value: 1–32
The larger the value is, the stronger the
signal is. If the value is greater than 12, GPRS
reaches the normal level.
0Km/h
Indicates the speed.
Unit: km/h
96%
Indicates the remaining battery power.
None
http://maps.meigps.c
om/?lat=22.513781&l
ng=114.057183
Indicates the map link.
Latitude: 22.513781
Longitude: 114.057183
None

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 11 -
6.6 Common SMS Commands
6.6.1 Setting the Speeding Alert(only work with OUT2 Port) – B07
SMS sending: 0000,B07,Driving speed,Buzzer mark
SMS reply: IMEI,B07,OK
Description:
Driving speed: The parameter value ranges from 0 to 255. Unit: km/h. When the driving speed is 0, the speeding alert
will be disabled.
When the buzzer mark is 0(default) and speeding is detected, the buzzer will make sounds to alert users.
When the buzzer mark is 1and speeding is detected, the buzzer will not make sounds.
Example:
Sending: 0000,B07,40,0
Reply: 353358017784062,B07,OK
6.6.2 Setting the Idling Alert – B14
SMS sending: 0000,B14,Duration of low speed,Driving speed,Alert time
SMS reply: IMEI,B14,OK
Description:
Duration of low speed: The parameter value ranges from 0 to 60000. The default value is 900. Unit: second.
Driving speed: The parameter value ranges from 0 to 200. The default value is 5. Unit: km/h.
Alert time: The parameter value ranges from 0 to 60000. The default value is 120. Unit: second.
If you want to read idling parameters, send 0000,B14.
Example:
Sending: 0000,B14,180,5,120
Reply: 353358017784062,B14,OK
6.6.3 Setting Fatigue Driving – B15
SMS sending: 0000,B15,Consecutive driving time,Alert time,ACC off time
SMS reply: IMEI,B15,OK

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 12 -
Description:
Consecutive driving time: The parameter value ranges from 0 to 1000. The default value is 240. Unit: minute.
Alert time: The parameter value ranges from 0 to 60000. The default value is 300. Unit: second.
ACC off time: The parameter value ranges from 0 to 1000. The default value is 20. Unit: minute.
If you want to read fatigue driving parameters, send 0000,B15.
Example:
Sending: 0000,B14,180,5,120
Reply: 353358017784062,B14,OK
6.6.4 Setting the Driving License Type – C50
SMS sending: 0000,C50,Driving license type 1,Driving license type 2,…Driving license type n
SMS reply: IMEI,C50,OK
Description:
Driving license type: The parameter value ranges from 0 to 65535. At most 16 types of driving licenses are supported.
The default parameter value is 0, indicating that no driving license type is set.
If you want to read all types of driving licenses, send C50.
After a new parameter value is set, the existing parameter values will be deleted.
Example:
Sending: 0000,C50,24,12
Reply: 353358017784062,C50,OK
6.6.5 Setting the Duration of Buzzing(only work with OUT2 Port) – C51
SMS sending: 0000,C51,Time
SMS reply: IMEI,C51,OK
Description:
Time: indicates the maximum duration that the buzzer sounds. Unit: minute; value range: 0–255; default value: 10.
When the parameter value is 0, the buzzer will sound all the time once it is pressed.
Example:
Sending: 0000,C51,10
Reply: 353358017784062,C51,OK
For details about SMS commands, see the MEITRACK SMS Protocol.
Note:
1. The default SMS command password is 0000. You can change the password by using Meitrack Manager and
SMS command.
2. The device can be configured by SMS command with a correct password. After an authorized phone number is
set, only the authorized phone number can receive the preset SMS event report.
7Logging In to MS03 Tracking System
Visit http://ms03.trackingmate.com, enter the user name and password, and log in to the MS03. (Purchase the login
account from your provider.)
For more information about how to add a tracker, see the MEITRACK GPS Tracking System MS03 User Guide (chapter
4 "Getting Started").
The MS03 supports the following functions:

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 13 -
Track by time interval or distance.
Query historical trips.
Set polygonal geo-fences.
Bind driver and vehicle information.
View various reports.
Send commands in batches.
Support OTA updates.
For details, see the MEITRACK GPS Tracking System MS03 User Guide.
8Installing the T633L
8.1 Installing GPS and 3G Antennas
Connect the 3G antenna to the connector which is labeled "GSM". The 3G antenna is non-directional, so you can hide
it in any place of a vehicle.
Connect the GPS antenna to the connector which is labeled "GPS". It is recommended that the antenna is facing up
to the sky and the antenna side with words is downwards. Secure the antenna by using double sided tapes.
Note: Do not install the GPS antenna at a metal covered place.
8.2 Installing an I/O Cable
The I/O cable is a 12-pin cable, including the power, analog input, digital temperature sensor input, and
negative/positive input and output interfaces.
1
Power(+)
3
Input1
5
Input2
7
Input3
9
Fuel sensor
11
Input 2
2
GND(-)
4
GND(-)
6
Input3
8
AD input 1
10
Input 1
12
1-wire
Pin Number
Color
Description
1 (Power +)
Red
Positive charge of the power input, connected to the positive charge
of the vehicle battery. Input voltage: 11.4–36 V.
2 (GND)
Black
Ground wire, connected to the negative charge of the vehicle
battery or to the negative terminal.
3 (Input 1)
White
Digital input 1, negative trigger (SOS button by default)
4 (GND)
Black
Ground wire, connected to input 1 (SOS button)
5 (Input 2)
White &
brown
Digital input 2 (negative trigger)
Connect to a door trigger signal cable to detect vehicle door status.
(Most Chinese, Korean, and Japanese cars are negative edge-
triggered.)
The port can be set to positive trigger, AD input 3 (0–30 V), or output
5.
6 (Output 3)
Yellow
& red
Output 3
Valid: low level (0 V)

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 14 -
Invalid: open collector
Maximum voltage for output open collector (invalid): 40 V
Maximum current for output low voltage (valid): 500 mA
Connect to an external relay to remotely cut off the vehicle fuel
cable or engine power supply.
The port can be set to positive or negative input 6.
7 (Input 3)
White &
red
Digital input 3 (positive trigger)
Connect to the vehicle ACC cable by default to detect the vehicle
ACC status.
The port can be set to negative trigger, AD input 4 (0–30 V), output
6.
8 (AD Input 1)
Blue
Analog input 1 with 12-bit resolution and valid voltage 0–30 V
Connect to an external sensor, such as the fuel level sensor.
The port can be set to positive or negative input 4 or output 7.
9 (Fuel level sensor input)
Blue &
brown
Analog input 2 with 12-bit resolution and valid voltage 0–30 V
There is a white plug on the AD cable, and the cable is connected to
the A53 fuel level sensor by default.
The port can be set to positive or negative input 5 or output 8.
10 (Output 1)
Yellow
Output 1
Valid: low level (0 V)
Invalid: open collector
Maximum voltage for output open collector (invalid): 40 V
Maximum current for output low voltage (valid): 400 mA
Connect to an external relay to remotely cut off the vehicle fuel
cable or engine power supply.
The port can be set to positive or negative input 7.
11 (Output 2)
Yellow
&
brown
Output 2
Valid: low level (0 V)
Invalid: open collector
Maximum voltage for output open collector (invalid): 40 V
Maximum current for output low voltage (valid): 400 mA
Connect to an external relay to remotely cut off the vehicle fuel
cable or engine power supply.
The port can be set to positive or negative input 8.
12 (1-wire, Digital
temperature sensor or
iButton input port)
Green
TTL3.3V level
Connect to the A52 digital temperature sensor or iButton by default
by using the A61 sensor box.
The port can be set to negative input 9 or output 4.
Note: The DC or AC voltage that is greater than 3.3 V is not allowed.
Otherwise, the device may be damaged.
Noted:
Based on all above, T366L could support at most 9 digital inputs, 8 outputs, 4 AD ports:

MEITRACK T633L User Guide
Copyright © 2019 Meitrack Group All rights reserved. - 15 -
Set to DIN high level trigger
Set to DIN low level trigger
Set to AD
Set to output
Pin 3(white)
√(IN1)
Pin 5(White&Brown)
√(IN2)
√(IN2)
√(AD3)
√(OUT5)
Pin 6(Yellow&Red)
√(IN6)
√(IN6)
√(OUT3)
Pin 7(White&Red)
√(IN3)
√(IN3)
√(AD4)
√(OUT6)
Pin 8(Blue)
√(IN4)
√(IN4)
√(AD1)
√(OUT7)
Pin 9(Blue&Brown)
√(IN5)
√(IN5)
√(AD2)
√(OUT8)
Pin 10(Yellow)
√(IN7)
√(IN7)
√(OUT1)
Pin 11(Yellow&Brown)
√(IN8)
√(IN8)
√(OUT2)
Pin 12(Green)
√(IN9)
√(OUT4)
8.3 Device Connection Diagram
If you have any questions, do not hesitate to email us at [email protected].
