Technical specifications
Lamp Type
Description
Voltage
Power
Nom. Tc
Lumen
PLP050-RGB
RGB color 50 mm
10-14 VAC
10 W
n.a.
400 lm
PLP100-RGB
RGB color 100 mm
10-14 VAC
45 W
n.a.
1700lm
PLP170-RGB
RGB color 170 mm
10-14 VAC
75 W
n.a.
3000 lm
PLP050-WH
Sun White 50 mm
10-14 VAC
6 W
7000K
600 lm
PLP100-WH
Sun White 100 mm
10-14 VAC
30 W
7000K
2600 lm
PLP170-WH
SunWhite 170mm
10-14 VAC
60 W
7000K
5500lm
PLP050-WW
Warm White 50 mm
10-14 VAC
6 W
3300K
540lm
PLP100-WW
Warm White 100 mm
10-14 VAC
30 W
3300K
2350 lm
PLP170-WW
Warm White 170 mm
10-14 VAC
60 W
3300K
4950lm
PLP050-BL
Blue fixed 50 mm
10-14 VAC
6 W
n.a.
165lm
PLP100-BL
Blue fixed 100 mm
10-14 VAC
25 W
n.a.
470 lm
PLP170-BL
Blue fixed 170 mm
10-14 VAC
60 W
n.a.
1450 lm
For operation only with a safety isolation
transformer
Minimum input voltage: 10 VAC 50/60 Hz
(at lamp terminals)
Nominal input voltage: 12 VAC 50/60 Hz
(at lamp terminals)
Maximum input voltage: 14 VAC 50/60 Hz
(at lamp terminals)
Power factor: > 0,90
IECProtectionClassIII
Operation on DC voltages is NOT allowed
Maximum water temperature: +40°C
Lampshavetobekept
out of ice zones
Ingress protection rate: IP68
measuredat3m
max depth = 3m

4
!
Remarks
Theluminaireismaintenance free
If the luminaire needs to be replaced, it needs to be completely removed from the water
Ifthe external flexible cable or cord of this luminaire isdamaged,it shall be exclusively
!
replaced by the manufacturer or his service agent or a similar qualified person in order
toavoid hazard
Adagio
pro
Pool lamps must be completely submerged into water during operation.
Fixing the lamps with adhesives or silicone kit into a niche is not allowed
Not following these instructions, will void warranty.
Box contents
ADAGIOPRO
Lamp (50,100
or 170 mm)
Connection Kit
ADAGIOPRO
( 513-0152 )
4mCable
Manual
Retrofit Kit
(only for 170mm models)

5
ENG
Installationinstructions
mounting face plate mounting the connector
Contact your local
distributor for
Toolset: 513-0151
( not included )
4mCable
Clips Nut
Lamp
Silicone Gasket
Connector
!
Details:
Page 6 & 7
Face Plate

Connector installation
o
--

7

7
ENG
4
5 6

8
Wiring instructions Setup 1
Pool
Fornewinstallations
Each lamp is connected to the transformer by a separate cable
Pool
house
SELECT
CABLESECTION&MAXIMUMLENGTH
4m cable included in lamp package
Separate cable ( not included )
! Always use a toroïdal transformer

9
ENG
SELECT
CABLESECTION&MAXIMUMLENGTH
LAMP TYPE 1,5mm2 2,5mm2 4,0mm2 6,0mm2 10mm2
VATRANSFORMER
(12VAC)*
PLP050-WH
PLP050-WW
PLP050-BL
77m
129m
207m
311m
519m
16 VA
PLP050-RGB
62m
103m
165m
248m
414m
12 VA
PLP100-WH
PLP100-WW
PLP100-BL
21m
35m
57m
85m
142m
56VA
PLP100-RGB
12m
20m
33m
50m
80m
48 VA
PLP170-WH
PLP170-WW
PLP170-BL
4m
7m
11m
16m
28m
147 VA
PLP170-RGB
6m
10m
16m
25m
42m
82VA
STABLE OPERATION OF THE POOL LIGHTS IS ONLY GUARANTEED WHEN THE INSTALLED CABLE CROSS SECTION
MATCHES OR EXCEEDS THE ADVISED VALUES IN THE ABOVE TABLE
* The transformer VA rating must be greater or equal to the sum of VA ratings of all connected lamps.
These cable lenghts are calculated with worst case voltage drops in the electrical wiring.

WiringinstructionsSetup2
10
Pool
Forexistingor other installations
All lamps are connected to the transformer via 1 cable
Pool
house
SELECT
CABLESECTION&MAXIMUMLENGTH
4m cable included in lamp package
Separate cable ( not included )
This setup is not preferred for installations
! where a PLP-REM(-300) is used

11
PLP050-WH
1
129m
207m
311m
519m
PLP050-WW
2
3
64m
43m
103m
69m
155m
103m
259m
173m
PLP050-BL
4
32m
51m
77m
129m
PLP050-RGB
1
103m
165m
248m
414m
2
3
51m
34m
82m
55m
124m
82m
207m
138m
4
25m
40m
62m
103m
PLP100-WH
1
35m
57m
85m
142m
PLP100-WW
2
3
17m
11m
28m
19m
42m
28m
71m
47m
PLP100-BL
4
8m
14m
21m
35m
PLP100-RGB
1
20m
33m
50m
80m
2
3
10m
-
16m
11m
25m
16m
40m
26m
4
-
8m
12m
20m
ENG
SELECT
CABLESECTION&MAXIMUMLENGTH
LAMP TYPE QTY 2,5mm2 4,0mm2 6,0mm2 10mm2
VATRANSFORMER
(12VAC)
16
32
48
64
12
24
36
48
56
112
168
224
48
96
144
192
PLP170-WH
1
7m
11m
16m
28m
147
PLP170-WW
2
3
-
-
5m
-
8m
5m
14m
9m
294
441
PLP170-BL
4
-
-
-
7m
588
PLP170-RGB
1
10m
16m
25m
42m
82
2
3
-
-
8m
5m
12m
8m
21m
14m
164
246
4
-
-
6m
10m
328
STABLE OPERATION OF THE POOL LIGHTS IS ONLY GUARANTEED WHEN THE INSTALLED CABLE CROSS SECTION
MATCHES OR EXCEEDS THE ADVISED VALUES IN THE ABOVE TABLE

12
Wiringremarks
For installations with PLP-REM & PLP-REM-300
Third party equipment such as frequency inverters and electric motors can generate
excessive noise on the 230VAC /400VAC power line.
This noise might be injected into the adjacent 12VAC power line and disturb the power
line communication towards the Adagio
Pro
RGB lights.
To prevent this, please take care of the following:
Keep230VAC / 400VACpowerlinecablesatleast50cmseparatedovertheir
! full length from the 12VAC power line towards any RGB lights
Do not mix 12VAC and 230VAC
/ 400VAC power line cables into the same cable
!
trays

13
ENG
Pool
Pool
house
12VAC to lamps
(**)
230VAC Min. 50cm
230VAC/400VACtothirdpartyequipment
(**) Do not mix 12VAC and 230VAC / 400VAC power line cables into the same cable trays

2 --
RetrofitinPAR56niche(onlyPLP170)
1
Silicone
tube

15
PR
OGRAM
1
to
7
PR
OGRAM
8
to
11
PR
OGRAM
12
to
14
ENG
14 Color programs (only for RGB lamps)
7 fixed colours
. DEEP BLUE SEA
1
Saturated blue
. DAYLIGHT BLUE
2
Light blue
. SUNSET
3
Orange red
4dynamiccolors
. JUNGLE, BEACH
Saturated blue
8
Light blue, Azur blue
Mid blue, Light blue
(slowlychanging)
. VOODOO
Red, Wine red 9
Purple, Bordeau
(slowlychanging)
3 white tones
. WARM WHITE
12
Warm white
. NEUTRAL WHITE
Neutral white
13
. SUN WHITE
14
Cool white
. LOVE IS IN THE AIR
Red
4
. FOREST SPRING
Green
5
. DISCO
Lila, pink, peach, 10
light yellow,
light green, light blue
(quicklychanging)
. PARTY
. THINK PINK
Pink
6
. SUNSHINE
Yellow
7
Blue, azure blue, 11
green,green/red,
red,red/blue, lila,
light pink, peach,
yellow, light green,
light blue, lila
(slowlychanging)
Dimming possible
If PLP-REM or PLP-REM-300
are used

16
Synchronizing & color changing
Manualsynchronization
1. Switch ON the 12 VAC line voltage and make sure that all lamps light up.
2. Switch OFF the 12 VAC line voltage and wait for at least 20 sec.
3. Switch ON and switch OFF
4. Switch ON and switch OFF
5. Switch ON
6. The lamps should all be on the “Deep Blue Sea”, program 1 showing fixed blue light.
Changing colors
Quickly turn the lamps OFF and back ON
The lamp will jump to the next color program ( 1 --> 14 )
Memorizing the last color
Turn the lamp OFF for MINIMUM 20 seconds
The last chosen color has now been memorized
PLP-REM or PLP-REM-300 can also be used to control the lamps.
Synchronization and color changing are much easier, and more intelligent features
like dimming or DMX control are possible.

17
ENG
Troubleshooting
PROBLEM SOLUTION
. The pool light is flickering
. Several pool lights in the
pool show different
color programs
1. Switch the lamps ON
For RGB lamps: select the Sun White color program
2. Remove the lamp from the water, unscrew the clips nut,
pullback thegasketand theblack cable jacket, soyou can
reach the brass contacts inside the connector block
(do not remove the connector block)
3. Measure the voltage at the lamp terminals (while the lamp
isstillON)
4. The voltage at the lamp should be at least 10VAC 50/60hz.
If the measured line voltage is below 10VAC:
A. Check the output voltage at the transformator terminals.
Thisvoltageshouldbebetween12VACand14VAC.
Verify that the used transformator VA rating is sufficient
for powering all connected lamps
B. If the transformator output voltage is ok, then install a
thicker cable between the transformator and the lamp.
(wiring instructions p. 8-13)
Make sure that all lamps are connected to the same 12VAC
powerline. Execute the synchronization as explained on p.16

18
