Spectris Particle Measuring Systems IsoAir 310P User manual

IsoAir® 310P
Aerosol Particle Sensor
P/N 1000016128
OPERATIONS MANUAL
Without measurement there is no control

HEADQUARTERS
5475 Airport Blvd
Boulder, Colorado 80301 USA
T:[phone], [phone]
Instrument Service & Support
E: [phone]
Customer Response Center
T: [phone]
E: [e-mail]
GLOBAL OFFICES
BRAZIL
T: [phone]
E: [e-mail]
CHINA
T: [phone]
E: [email protected]om
FRANCE
T: [phone]
E: pmsfranc[email protected]om
GERMANY
T: [phone]
E: [e-mail]
ITALY
T: [phone]
E: [email protected]om
JAPAN
T: [phone]
E: [e-mail]
KOREA
T: [phone]
E: pmskore[email protected]om
MEXICO:
T: [phone]
E: [e-mail]
NORDIC
T: [phone]
E: [e-mail]
PUERTO RICO
T: [phone]
E: pmspuertoric[email protected]
SINGAPORE
T: [phone]
E: [e-mail]
TAIWAN
T: 886-3-5525300 Ext: 301
E: [e-mail]
UNITED KINGDOM
T: [phone]
E: [e-mail]
IsoAir® 310P
Aerosol Particle Sensor
Operations Manual
P/N 1000016128 Rev E

ii IsoAir 310P Aerosol Particle Sensor Operations Manual
IsoAir 310P Aerosol Particle Sensor Operations Manual
P/N 1000016128 Rev E
© 2018 by Particle Measuring Systems, Inc.
All Rights Reserved
IsoAir®is a trademark of Particle Measuring Systems, Inc.
Molex is®a registered trademark of the Molex Corporation.
Unistrut®is a registered trademark or trademark of Unistrut Corporation.
Windows®is a registered trademark or Microsoft Corporation
All trademarks appearing in this manual are the property of their respective owners.
DO NOT REPRODUCE OR DISTRIBUTE CONFIDENTIAL DOCUMENT
This confidential document contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this document may be reproduced,
distributed, or transmitted in any form without the prior written consent of Particle
Measuring Systems. The information contained in this document is subject to change
without notice.
Patent Information
The IsoAir 310P particle sensor is protected by the following patents held by Particle
Measuring Systems: US 6167107, Japan 3559782, Germany 60005581.3, and
UK GB1196832.
Wireless Radio Designators
FCC = F4AWLNN551, IC = 3913A-WLNN551 and
Japan Radio Type Certification = 208-150044
Quality Statement
The Quality Policy of Particle Measuring Systems is to strive to meet or exceed the
needs and expectations of our customers and to align the activities of all employees
with the common focus of customer satisfaction through continuous improvement in
the quality of our products and services.
Environmental Information
There are no potential means by which asbestos exposure is possible because there
are no materials in the design or manufacture of the IsoAir 310P equipment containing
asbestos.
This equipment must be properly disposed of at end-of-life by means of an authorized
waste management system. Contact our Customer Response Center at [phone]
or [phone] (International Telephone [phone]) or dismantling and
disposal information.

IsoAir 310P Aerosol Particle Sensor Operations Manual iii
Battery Disposal
Particle Measuring Systems, Inc. encourages users to check with their local
municipality for battery recycling. In North America, contact the Rechargeable Battery
Recycling Corporation (RBRC) at http://www.call2recycle.org/. In Europe, contact the
European Portable Batter4y Association (EPBA) http://www.epbaeurope.net/.
Manual Conventions
A warning in the text is used to notify the user of the potential for bodily injury or
death.
CAUTION
A caution in the text is used to highlight an item that if not done, or incorrectly done,
could damage the instrument and/or any materials or devices affected by the
instrument.
– — NOTICE — –
A notice in the text is an instructional communication regarding requirements or
policies issued by Particle Measuring Systems.
NOTE: A note in the text is used to highlight an item that is of operational
importance to the user.
It is important that you observe cautions and warnings while performing the
procedures described in this manual. Caution and warning labels are located on and
inside the instrument to alert you to potentially hazardous conditions. Please
familiarize yourself with this information.
WARNING

iv IsoAir 310P Aerosol Particle Sensor Operations Manual
CE – Declaration of Conformity
-
Declaration of Conformity
Application of Council Directive(s): 2014/30/EU, 2014/35/EU, 2014/53/EU,
RoHS 2011/65/EU
Standard(s) to which Conformity is Declared: EMC EN 61326-1:2013
Safety EN61010-1: 2010, 3rd, Ed.
EN 60825-1: 2014
RTTE ETSI EN 300 328
ETSI EN 301 893
Manufacturer’s Name: Particle Measuring Systems, Inc.
Manufacturer’s Address: 5475 Airport Boulevard
Boulder, CO 80301 USA
Manufacturer’s Telephone/FAX: + 1 3034437100 / + 1 3034496870
Distributor’s Name: Particle Measuring Systems, S.R.L.
Distributor’s Address Via di Grotte Portella 34
00044 Frascati (Roma) ITALY
Distributor’s Telephone/FAX: + 39 06 90530130 / + 39 06 9051315
Type of Equipment: Particle Sensor
Model No: IsoAir 310P
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and
Standard(s).
Signature: Signature:
Full Name: Scott MacLaughlin Full Name: Giovanni Scialo
Position: Director of Engineering Position: Vice President, Life Sciences
Place: Boulder Date: November 13, 2018 Place: Rome Date: November 13, 2018
CAUTION
If the equipment is used in a manner not specified by the manufacturer, the protection provided
by the equipment may be impaired.
All I/O cables and accessories must meet current factory specifications in order for this unit to
remain in compliance with CE marking requirements. Consult the factory for details.

IsoAir 310P Aerosol Particle Sensor Operations Manual v
Brief Table of Contents
Table of Contents - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - vii
List of Figures - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - xi
List of Tables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - xiii
Chapter 1: Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1
Chapter 2: Unpacking and Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1
Chapter 3: Configuring for Facility Net - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-1
Chapter 4: Facility Net Setup- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1
Chapter 5: 4-20 mA Output Option - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1
Chapter 6: 4-20 mA Input and Solid State Outputs - - - - - - - - - - - - - - - - - - - - - - - 6-1
Chapter 7: Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-1
Chapter 8: Maintenance- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-1
Chapter 9: Troubleshooting- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9-1
Appendix A: International Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-1
Appendix B: Serial Commands- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-1
Appendix C: Wi-Fi Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-1
Appendix D: Modbus - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-1
Appendix E: OPC Configuration and Operation- - - - - - - - - - - - - - - - - - - - - - - - - - E-1
Appendix F: 㦘㹡㒥㦘⹂䤓䓸德✛⏒侯 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - F-1

vi IsoAir 310P Aerosol Particle Sensor Operations Manual
This page is intentionally left blank.

IsoAir 310P Aerosol Particle Sensor Operations Manual vii
Table of Contents
Patent Information- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ii
Wireless Radio Designators - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ii
Quality Statement - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ii
Environmental Information - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ii
Battery Disposal - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - iii
Manual Conventions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - iii
CE – Declaration of Conformity - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - iv
List of Figures - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - xi
List of Tables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - xiii
Chapter 1. Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1
Front Panel- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
Status Light- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
Activity Light- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
Top - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
Bottom - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
Specifications- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-3
Accessories - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-4
Options - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-4
Chapter 2. Unpacking and Installation- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1
Unpacking the Sensor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1
Shipment Contents - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1
Not Included - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1
Sensor Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-2
Selecting a Location - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-3
Effective Sampling Probe Placement - - - - - - - - - - - - - - - - - - - - - 2-3
Setting Up a Remote Sampling System - - - - - - - - - - - - - - - - - - - - - - - 2-4
Installing the Sensor- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-4
Removing the Electronics Module - - - - - - - - - - - - - - - - - - - - - - - - 2-5
Drilling Holes for Conduit Fittings (as needed) - - - - - - - - - - - - - - 2-9
Mounting the Sensor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-9
Required Fasteners - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-10
Prepping the Support Surface - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-11
Attaching the Enclosure to the Wall - - - - - - - - - - - - - - - - - - - - - - 2-11
Connecting the Electrical Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-12
Replacing Fuses - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-13
Connecting Input-Output Cables - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-13

viii IsoAir 310P Aerosol Particle Sensor Operations Manual
Chapter 3. Configuring for Facility Net - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-1
Before You Begin - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-1
Configuring the Sensor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-2
Configuring Instrument Channels - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-6
Setting the Auto-Buffer Size- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-6
Chapter 4. Facility Net Setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1
Configuring the Software- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-2
Reviewing Channel Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-4
Configuring Analog Sensors- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-5
Analog Sensors Tab Field Definitions - - - - - - - - - - - - - - - - - - - - - 4-6
Configuring Analog Input (Optional) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-6
Configuring Run-Time Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-7
Configure Dialog Box Field Definitions - - - - - - - - - - - - - - - - - - - - 4-7
Button Descriptions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-8
Chapter 5. 4-20 mA Output Option - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1
Configuring 4-20 mA Output - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1
4-20 mA Out Status Channel (Optional)- - - - - - - - - - - - - - - - - - - - - - - 5-2
Status output settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2
2 Channel Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2
Particle Channel Scale Considerations - - - - - - - - - - - - - - - - - - - - - - - 5-3
Software Setup for 4-20 mA Output (Optional) - - - - - - - - - - - - - - - - - 5-3
Chapter 6. 4-20 mA Input and Solid State Outputs - - - - - - - - - - - - - - - - - - - - - - - - - 6-1
4-20 mA Input- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-1
Solid State Outputs - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-1
Analog Inputs: Connections and Configuration - - - - - - - - - - - - - - - - - - - 6-2
Connections - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-2
Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-3
Chapter 7. Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-1
Pump Flow Alarm and Shut-off - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-1
Detector Board- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-1
Chapter 8. Maintenance- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-1
Sterilization of Cleanroom- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-1
Calibration, Service, and Shipping - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-1
Chapter 9. Troubleshooting- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9-1
Appendix A. International Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-1
WARNING - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-1
AVERTISSEMENT - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-1
WARNUNG - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-1
ATTENZIONE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-1

IsoAir 310P Aerosol Particle Sensor Operations Manual ix
ADVERTENCIA- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-1
Hazard Symbols - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-2
Symboles de risque - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-2
Warnschilder - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-3
Simboli di pericolo - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-3
Simbolos de peligro - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-4
Appendix B. Serial Commands - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-1
Appendix C. Wi-Fi Configuration- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-1
Instructions for IsoAir 310P Configuration- - - - - - - - - - - - - - - - - - - - - - - - C-4
Router Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-4
Steps for IsoAir 310P Wi-Fi Configuration - - - - - - - - - - - - - - - - - - - - - C-4
Set the IsoAir 310P into Wi-Fi mode and select an IP address for the
instrument - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-4
Configure the Wi-Fi bridge - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-6
Hardware Details - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-9
Reset Button- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-9
Status LEDs- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-10
Tips - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-11
Setup Tips and Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-11
Getting Reliable Wireless Networking - - - - - - - - - - - - - - - - - - - - - - - - C-11
Wi-Fi Sensor Checklist - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-13
WiFi Certificate – FCC - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-14
WiFi Certificate – IoC - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-16
Appendix D. Modbus - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-1
Modbus Overview- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-1
Input Registers - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-2
Holding Registers - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-5
Coils - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-6
Data Packet Processing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-7
Associated Values for Specific Registry Entries - - - - - - - - - - - - - - - - - - - - D-8
Appendix E. OPC Configuration and Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - E-1
IsoAir 310P OPC Identification Data- - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-1
OPC Server Class ID - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-1
OPC Server Program ID - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-1
OPC Server Description - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-1
IsoAir 310P Data Access Tags - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-2
OPC Setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-3
OPC Server - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-4
Basic Setup- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-4
Connecting to the Server - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-5
OPC Server Class ID - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-5
OPC Server Program ID - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-5

x IsoAir 310P Aerosol Particle Sensor Operations Manual
OPC Server Description - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-5
Server Browsing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-5
Appendix F. 㦘㹡㒥㦘⹂䤓䓸德✛⏒侯  )

IsoAir 310P Aerosol Particle Sensor Operations Manual xi
List of Figures
Chapter 1. Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1
Figure 1-1 IsoAir 310P Particle Sensor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
Chapter 2. Unpacking and Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1
Figure 2-1 Interior of IsoAir 310P Particle Sensor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-2
Figure 2-2 Knurled ring on the top of the IsoAir 310P box - - - - - - - - - - - - - - - - - - - - - - - - 2-5
Figure 2-3 Panel Screw Locations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-6
Figure 2-4 Accessory ribbon cable - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-7
Figure 2-5 Blower screws - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-8
Figure 2-6 Exhaust filter - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-8
Figure 2-7 Conduit Port Placement, Dual - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-9
Figure 2-8 Back panel showing mounting holes- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-10
Figure 2-9 AC Input Wiring Location on Rear - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-12
Figure 2-10 Connectors Wired to the Terminal Block- - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-13
Figure 2-11 4-20 mA input and solid state output connector- - - - - - - - - - - - - - - - - - - - - - 2-14
Figure 2-12 4-20 mA output connector - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-14
Chapter 3. Configuring for Facility Net - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-1
Figure 3-1 Example of the output from the help command: - - - - - - - - - - - - - - - - - - - - - - 3-5
Figure 3-2 Example of the output from the status command:- - - - - - - - - - - - - - - - - - - - - 3-5
Chapter 4. Facility Net Setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1
Figure 4-1 Add Instrument dialog box - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-2
Figure 4-2 IsoAir 310P Configuration dialog box - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-3
Figure 4-3 Channel Configuration tab in the IsoAir 310P Configuration dialog box
(for 4 channel mode) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-4
Figure 4-4 Analog Sensors tab in the IsoAir 310P Configuration dialog box- - - - - - - - - 4-5
Figure 4-5 Configure dialog box - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-7
Chapter 5. 4-20 mA Output Option- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1
Figure 5-1 Wiring for 4-20 mA output - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1
Chapter 6. 4-20 mA Input and Solid State Outputs - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-1
Figure 6-1 The 4-20 mA input board - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-1
Figure 6-2 Facility Net Analog Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-4

xii IsoAir 310P Aerosol Particle Sensor Operations Manual
Chapter 7. Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-1
Chapter 8. Maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-1
Chapter 9. Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9-1
Appendix A. International Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-1
Appendix B. Serial Commands - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-1
Appendix C. Wi-Fi Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-1
Figure C-1 Wireless Network Example - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-1
Figure C-2 Configuring an IsoAir 310P from a laptop- - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-3
Figure C-3 IsoAir 310P Status Command with Wi-Fi On- - - - - - - - - - - - - - - - - - - - - - - - - - - C-5
Figure C-4 Wi-Fi Card with Ethernet RJ-45 Female-Female Adapter for PC - - - - - - - - - - - C-6
Figure C-5 Wi-Fi Bridge Sample Web Page- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-7
Figure C-6 Wi-Fi Board in IsoAir 310P instrument - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-9
Figure C-7 Wi-Fi Bridge Rendering Showing Status LEDs - - - - - - - - - - - - - - - - - - - - - - - - - C-10
Appendix D. Modbus - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-1
Appendix E. OPC Configuration and Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-1
Appendix F. 㦘㹡㒥㦘⹂䤓䓸德✛⏒侯 )

IsoAir 310P Aerosol Particle Sensor Operations Manual xiii
List of Tables
Declaration of Conformity - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -iv
Chapter 1. Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1
Table 1-1 Specifications- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-3
Chapter 2. Unpacking and Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1
Chapter 3. Configuring for Facility Net - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-1
Table 3-1 Cable Pinouts, RS-232 Straight-Through - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-1
Table 3-2 HyperTerminal Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-2
Chapter 4. Facility Net Setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1
Table 4-1 Configuration dialog box field definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-3
Chapter 5. 4-20 mA Output Option- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1
Chapter 6. 4-20 mA Input and Solid State Outputs - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-1
Table 6-1 Wiring connections for current-output sensor- - - - - - - - - - - - - - - - - - - - - - - - - - 6-2
Table 6-2 Wiring connections for voltage-output sensor- - - - - - - - - - - - - - - - - - - - - - - - - - 6-2
Chapter 7. Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-1
Chapter 8. Maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-1
Chapter 9. Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9-1
Appendix A. International Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-1
Appendix B. Serial Commands - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-1
Appendix C. Wi-Fi Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-1
Table C-1 LED Status Descriptions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-10
Table C-2 Wireless Data Rate versus Signal Strength- - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-12
Table C-3 Sensor Settings- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-13
Table C-4 Setting Checklist- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - C-13
Appendix D. Modbus- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-1
Table D-1 Input register – Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-2
Table D-2 Input register – Data Packet- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-3
Table D-3 Holding registers - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-5
Table D-4 Coils - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-6
Table D-5 Associated values for specific registry entries - - - - - - - - - - - - - - - - - - - - - - - - - - D-8

xiv IsoAir 310P Aerosol Particle Sensor Operations Manual
Appendix E. OPC Configuration and Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-1
Table E-1 Data Tags - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-2
Appendix F. 㦘㹡㒥㦘⹂䤓䓸德✛⏒侯 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - F-1

IsoAir 310P Aerosol Particle Sensor Operations Manual Page 1-1
Chapter 1
Introduction
The IsoAir 310P particle sensor is designed to provide cleanroom and isolator
monitoring. When environmental particles go out of specification, the instrument can
initiate an alarm to halt operation and help identify the cause.
The IsoAir 310P particle sensor generates its own vacuum with an internal pump with
HEPA-filtered discharge. The pump-generated vacuum delivers a stream of sample air
to the sensor. Sample flow is monitored and reported with a patented three-pressure
transducer system.
Available options include:
1Three 4-20 mA outputs: one for fault status and two for particle counts
2Three 4-20 mA inputs for environmental sensors and 5 solid state outputs for a
possible local light control tower to mimic the local LEDs
3Wireless communication
To manage the data, the IsoAir 310P particle sensor integrates all data into a single
record and sends this record to the FacilityPro or Facility Net FMS system. FacilityPro
can be programmed to monitor and archive the data, print reports, generate and
manage alarms, and so on. Additional communication protocols include Modbus and
OPC for wider third-party system integration. Communications can also be done via
Ethernet using Particle Measuring Systems protocols into customer systems.

Page 1-2 IsoAir 310P Aerosol Particle Sensor Operations Manual
Chapter 1 Introduction Front Panel
Front Panel
The front panel includes two LED's, the status light and the activity light.
Status Light
The Status light (three-color LED) indicates the operational status of the instrument
and is programmable.
Activity Light
The Activity LED flashes when particles are detected.
Figure 1-1 IsoAir 310P Particle Sensor
Top
The top of the enclosure contains the sample inlet port.
Bottom
The bottom of the enclosure contains the power and communication connections as
well as the exhaust port. Power and communications are made through the two
factory-supplied conduit cable glands.

Specifications Chapter 1 Introduction
IsoAir 310P Aerosol Particle Sensor Operations Manual Page 1-3
Specifications
Particle Measuring Systems reserves the right to change specifications without notice.
Table 1-1 Specifications
Channel Options Model 310P: 0.3, 0.5, 1.0, and 5.0 µm.
Data output can also be set to 0.5 and 5.0µm only.
Flow rate 1.0 CFM (28.3 LPM).
Vacuum source Internal reciprocal blower is quiet, cool-running, long-lived, with no
contaminating carbon vanes. Pump output is HEPA filtered, and
discharged from the bottom of the enclosure.
Pump shutoff An automatic shutoff activates if the pump fails, or if the system
detects that the probe cap is on the sample probe while the pump is
running. The system may try to restart, based on the user-defined
configuration.
Calibration Calibration materials used are traceable to the US National Institute
of Standards and Technology.
Unit is calibrated to ISO 21501-4 requirement.
Zero count level ≤ 7.07 counts/m3
Maximum particle
concentrationa
Model 310P: 1,374,269 particles/ft3
Exterior surface Passivated stainless steel (Grade 316 L)
Communications Particle Measuring Systems protocols via:
- Ethernet (data, instructions)
- RS-232 (instrument configuration and diagnostics only)
- Modbus TCP
- OPC communications
- Optional 4-20 mA output (2 data channels plus 1 status channel)
- Optional 5 solid-state outputs and 3 4-20 mA inputs
Wireless Wireless communications is available as an option
Controlling software FacilityPro, Facility Net, Pharmaceutical Net, OPC client, or Modbus
client
Data security Unalterable data; 21 CFR Part 11compatible transfer via FacilityPro,
Facility Net.
Backup storage of 3,000 samples, including flow data.
Status indicators Ethernet
Programmable
Status:
Activity:
Three-color LED
One-color LED
4-20 mA
Interface
Laser and flow status:
Activity:
Three-color LED
One-color LED
Dimensions (w, h, d) 10 12 6inches (25 30 15 cm)
Weight 20 pounds (9kg)
Power 100 – 240 VAC, 1 A, 50 – 60Hz universal power supply
AC input voltage fluctuation shall not exceed + 10%

Page 1-4 IsoAir 310P Aerosol Particle Sensor Operations Manual
Chapter 1 Introduction Specifications
Accessories
Standard • Stainless steel ISP (Isokinetic Sampling Probe) with cap and chain
• 2 ferrites PMS part number EL136
• Operations Manual
• Zero count filter
• 3 meters of Bev-a-line 3/8 ID tubing
Options
Option 1 4-20 mA output Three 4-20 mA outputs:
• 2 for particle counts
• 1 for fault status
Option 2 4-20 mA input Three 4-20 mA inputs with 24 VDC Nominal
50 mA maximum current
Solid state
outputs
Five solid state outputs and a ½ Amp 24 DC supply output to
mimic the status indicator
Switched relay
contacts for
external circuits
48 V, ½ Amp maximum
Option 3 Wireless
communication
Wireless communication capability for select countries
Fuses 250 V, 1 A, 5 x 20 mm, T
Laser classification Class 1 per EN60825-1
Internally a Class 3B laser is used per EN60825-1
Operating
environment
Temperature: 39 - 95 F (4 – 35 C)
Humidity: 5 – 95%, non-condensing
Altitude: 0 - 6,562 ft (0 – 2000 m)
Installation
requirements
Indoor use only
Pollution degree 2
Over voltage category II
Ordinary protection (not protected against harmful ingress of
moisture)
Class I Equipment (Electrical earth ground from the mains power
source to the product input is required for safety.)
Ambient
environmental
pollution degree
Degree 2
Chassis protection Ordinary protection (not protected against harmful ingress of
moisture)
Indoor/outdoor Indoor use only
a. Less than 10% coincidence loss at maximum recommended ambient concentration.

IsoAir 310P Aerosol Particle Sensor Operations Manual Page 2-1
Chapter 2
Unpacking and Installation
Unpacking the Sensor
>> To unpack the sensor:
1Carefully open the shipping container and remove the IsoAir 310P particle sensor
shipment. Inspect each part for damage.
2If any components are damaged, notify the shipper and Particle Measuring Systems
and repackage the unit in the original packing materials.
3If the system is undamaged, store the packing materials for future transport needs.
Warranties may not apply if return shipping containers are inadequate.
Shipment Contents
Each IsoAir 310P particle sensor is shipped with the following items:
• IsoAir 310P particle sensor
• 2 ferrites PMS part number EL136
• ISP (Isokinetic Sampling Probe) with cap and chain
• Sample tubing: 3 meters of Bev-a-Line 3/8-inch I.D.
• Zero-count filter
Not Included
The following items are not included. You will need to provide them:
• Ethernet cable
• Computer, loaded with FacilityPro or Facility Net software
• Other external software used with OPC or Modbus or computer
