Energenie MIHO007 User manual

Fitting and Wiring Instructions
1). Before commencing work, isolate the mains power supply and
remove the fuse in the fuse box or switch off the circuit breaker
in the consumer unit.
2). If unit is to be used as a replacement for an existing product,
remove existing unit from its location and disconnect the wiring.
3). This item will not fit into a 4 lug box. If such a box has been
previously installed the top and bottom lugs should be removed
or bent back to avoid contact with the interior.
4). Connect the wires as shown in appropriate wiring diagrams
overleaf. Use green/yellow sleeving on earth conductors that are
not insulated. Ensure terminals are properly tightened and no
bare wire is visible. Push back unit into mounting box making
sure conductors are not trapped.
5). Screw the unit module to the mounting box, please ensure
screws are sufficiently tight to support the product but please do
not over tighten as this may cause some deformation.
6) If the product has a decorative front cover plate over the module,
place the cover plate over the module and press firmly top and
bottom until all retaining clips have fully clipped into position. To
remove the decorative front cover plate, carefully insert a 3 mm
terminal screwdriver into the bottom slots and lift upward until all
the retaining clips disengage from the plastic module moulding.
Please ensure the decorative plate is held as it is released to
avoid it being dropped and damaged.
7). To reduce the risk of discolouration or tarnishing, avoid
installation on damp plaster.
8). These products must be installed in accordance with the
latest Building and IET wiring regulations. If in any doubt,
please contact a qualified electrician.
MIHO007 Double Wall Sockets
Mi Home
™

Typical Installation
L N
220-240V ~50Hz
Max. 13A
Resistive Load
Frequency 433.92 MHz
BS1363
Link to Earth
Terminal in
metal box
