Spectrum Industries LT-24 User manual

LT-24 Laptop Cart (H3)
#55174
Instructions:
(72) 052608
Velcro Wrap
(24) 052597-8
2" Velcro Hook & Loop
Before you begin, please make sure all parts and proper quantities are included.
Any parts damaged during shipment must be reported within 15 days of receipt.
To report information regarding damages or if you have any questions, please
call 1-800-235-1262.
Tools Required:
Adjustable Wrench
(4) 044555
Hole Plug
(2) 035252
Pinetree
Button
(2) 055001
Handle Mount
(2) 037282
1/4-20 Nut
Fiberlock
(10) 052605
1/4-20 x 15mm JC Bolts
(1) 052577B
Handle Gusset
(1) 025039
Allen Wrench
Cord Reel:
DESIGNED FOR INDOOR USE ONLY
Spectrum carts and lecterns are designed and constructed for indoor
use only. Moving or using outdoors or on excessively rough
surfaces may cause damage to the cart or casters and may void the
warranty. If an outdoor application is desired, please contact us to
discuss potential custom design solutions.
053465XR6 Page 1 of 4
A. Once the unit is unloaded from the skid, insert the cord reel plug through the lower grommet. Figure 1.
B. Plug the Cycle Charger plug into the Cord Reel power plug as shown.
C. Plug the second Cycle Charger plug into the Power Strip as shown. Additional accessories can now be powered from the Power Strip.
Note: The Master Switch on the Cycle Charger needs to be switched to the 'AUX' position to use the Power Strip.
Connect Plugs
1.
Cord Reel
To wall plug
Power Plugs from
Cycle Charger
Power Strip (use for additional accessories)
From Cord Reel
(through lower grommet) Figure 1
Rear View

A. Attach the Handle Gusset and Handle Mounts to the bottom of the Handle using 1/4-20 x 15mm JC Bolts. Figure 2.
Attach Handle
2.
Handle
Handle Assembly:
053465XR6 Page 2 of 4
Note: It is critical that all JC Bolts be used in
the attachment of the Handle.
A. Open the Instructor-side & Student-side doors. Attach the Handle Gusset to either end of the cabinet using 1/4-20 x 15mm JCBolts.
Do not completely tighten at this time.
B. Using 1/4-20 x 15mm JC Bolts and the 1/4-20 Locknuts, attach the Handle Mounts to the cabinet-one on each end. Move the shelves as
necessary to obtain access. Tighten all screws.
Attach Handle
3.
A. On each end of the cabinet there are unused holes that can be filled with the Hole Plugs provided. The 2 Pinetree Buttons are to
plug the holes on the opposite side of the Handle where the Gusset would attach.
Insert Hole Plugs
4.
Handle Gusset
1/4-20 x 15mm JC Bolt
Handle
Mount
Figure 2
1/4-20
Locknut

Instructor-Side
Attach 1 of the Velcro wraps provided, to
bundle cords and cables together.
Route cables leaving enough slack for
pulling tray in and out on the student
side, and choose a set of slots to anchor
cable(s).
Route the charge plug to the Student-
side to allow for ease of laptop charging
and removal.
Wide velcro strips are provided for
anchoringthe charger to the tray.
Bundle cords with
velcro wrap Using the slots
provided in tray,
anchor the cable(s)
hith
Plug charger into outlet
Cable Management Suggestions:
053465XR6 Page 3 of 4
w
h
ere necessary w
ith
velcro wrap.
Student-Side
Using the slots provided and a velcro
wrap, anchor the charge plug in a
convenient location for easy-access
Charger plug and
Velcro wrap
Velcro wrap shown in
one pair of slots

CYCLE
AB
B
AUX
A
OFF
AUX
45 60
30
120
90
180
Timer Instructions:
Master
Switch
The LT-24 Cart Timer is a 240 minute timed switch that provides accurate timing
between 15 - 240 minute increments. It is easy to set and operate.
The cycle timer is located on the Instructor-side of the unit. The timer has 24 outlets
which are controlled by the red lighted master switch. The master switch is a 3-position
rocker switch. The timer controls 24 outlets (12-A & 12-B) designated for the charging of
laptops. The outlets are controlled by the cycle switch and can alternate charging time
between cycle A and B. The 7 outlets located on the Student-side may be used for
various auxiliary applications.
1.) Plug the power cord into a 110-volt standard outlet.
2.) Plug the appropriate equipment into both Side “A” & “B”. Toggle the Master
Switch to the “CHARGE” position.
3.) To charge Side "A" ONLY, toggle the Cycle Switch to the "A" position.
4.) To charge Side "B" ONLY, toggle the Cycle Switch to the "B" position.
Cycle
Switch
053465XR6 Page 4 of 4
15 240
30
180
CAUTION!
The purpose of the timer is to prevent power overload while charging laptops in conjunction with
peripheral components. The charge mode is independent of the auxiliary mode to minimize risk of
power overage. To provide charging power to laptops, toggle the Master Switch to "CHRG". To
provide power to peripheral components, toggle the Master Switch to "AUX".
5.) To cycle charge BOTH "A & B", toggle the Cycle Switch to the "CYCLE"
position. Set the timer to the preferred cycling increment. After Side "A"
expires, the timer will activate Side “B” for the same period of time and will
continue to do so until the Master Switch is set to the "OFF" position.
Timer
