Spectrum Industries vLT-15 User manual

55323SR vLT-15 Laptop Cart w/ 8" Casters
vLT-15 Laptop Cart w/ 8" Casters
Owner's Manual
0110979 Page 1 of 6
IMPORTANT:
Before you begin, please make sure all parts and proper quantities are
included. Any parts damaged during shipment must be reported within 15
days of receipt. To report information regarding damages or if you have any
questions, please call 1-800-235-1262.
CAUTION:
Before using this product, read this manual and follow all safety and
operating instructions.
Spectrum Industries, Inc.
Chippewa Falls, WI 54729, USA
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for choosing Spectrum products!
55323SR
vLT-15 w/ 8" casters
0110979
Page
1
of
6

1. Handle and Cord Wrap Bracket Installation
A. Determine which side of the cart you would like the handle to be mounted (left or right-side) and attach the
handle to the side panel with (4) 1/4-20 x 15mm JC Bolts, and tighten securely. Figure 1A.
Note: If you have two swivel, and two rigid wheels on your cart (SR-version,) mounting the handle on
the same side of the cart as the two swivel wheels will provide more control of the cart when mobile.
B. Attach the cord wrap brackets to the side panels (left and right-side) with 1/4-20 x 15mm JC Bolts as shown
and tighten securely
Be sure the
brackets
are facing away from each other as shown
Read this owners manual before assembly or operation
Do not allow children to move cart
Move slowly and carefully when mobile
Safety
(1) 025039
4mm Hex Wrench
(12) 052605
1/4-20 x 15mm JC Bolt
(4) 0105648
Cord Wrap Bracket (100) 0102376
11" Zip Tie
Hardware package contents
Tools Required
4mm Hex Wrench
(included) Phillips Screwdriver
Assembly / Setup
Tools Required:
0110979 Pa
g
e 2 of 6
and
tighten
securely
.
Be
sure
the
brackets
are
facing
away
from
each
other
as
shown
.
C. Power cords can be routed through the lower side panel grommet as shown in Figure 1B.
D. Wrap excess cord around the cord brackets as necessary.
Figure 1A
1/4-20 x 15mm JC Bolts
(4) req'd
Handle
Side Panel
Cord Wrap
Bracket
1/4-20 x 15mm JC Bolts
(2) req'd per bracket
Figure 1B
Cord Wrap
Bracket
Power Cord
Lower Side Panel
Grommet
Note: Handle must be installed
before cord wrap brackets.
4mm Hex Wrench
0110979
Page
2
of
6

A. Open the rear door(s). Be sure the cart power strip cord(s) are unplugged.
B. Attach the laptop charge transformers to the cord management trays using the included zip
ties and cord management slots. Figure 2A & 2B. (Excess cords can be bundled with the
transformer if necessary.)
C. Charge cords can be routed to the laptops several different ways depending where the
charge jacks are located on your particular laptops. Figure 2C. Cords can be anchored with
the included zip ties as shown.
D. With the power strip switch in the 'OFF' position, plug the laptop transformers into the
cart's power strip(s), and the transformers into the laptops.
Note: On vLT-15 carts, the 16-outlet power strip can be mounted on the left or right-side of the
cart if necessary with the 4 mounting screws.
2. Cord Management & Setup
16-outlet Power Strip
Figure 2A
Power Switch &
Reset Button
Figure 2B
Charging
Transformer
Zip Tie
Top view of Cord
management tray
12' Power Cord
(separate circuit recommended for each power
strip, unless used in conjunction with alternating
cycle timer)
0110979 Page 3 of 6
Reset
Button
Figure 2C
Charge Cord
Position #1
Charge Cord
Position #2
Charge Cord
Position #3
Charging
Transformer
Laptop
Figure 2B
Power Strip
Zip Tie
Zip Ties
Zip Ties
0110979
Page
3
of
6

A. With the power strip switch turned to the 'OFF' poistion, plug the power strip into a wall outlet. Figure 3.
B. With power strip and laptops plugged in, flip the power switch to the 'ON' position to begin charging.
Laptop Charging (without optional timer or cord reel)
To wall
o
utlet
Power Strip
0110979 Page 4 of 6
A. Before moving the unit, unplug all power cords and wrap around the cord management brackets.
B. Be sure the casters are in the unlocked position and the door are closed.
C. Move the cart using the handle. After moving, lock the casters.
Moving the Cart
To wall
outlet
Figure 3
0110979
Page
4
of
6

Replacement Key Set
55142
Lectern Riser
18"W x 1713/16"D
95002
Velcro® Strap Kit
(16) 3/4" x 12”, and (32) 3/4" x 5”
Velcro® Straps
95004
Custom-Cut Logo
(Typical logo location on rear door)
55141
vLT-15 Options
15' Retractable Cord Reel Kit
(15-amp)
55326
Additional Steel Handle
(mounts on left or right-max 2 per unit) 27"W
55265
0110979 Page 5 of 6
0110979
Page
5
of
6

Warranty
WE WILL MAKE IT RIGHT FOR YOU!
We guarantee all Spectrum products to be free of all defects in materials and workmanship, for the original owner, for a period of ten years.
Any item deemed defective by Spectrum or the original manufacturer, under normal use conditions, will be repaired or replaced at
Spectrum’s discretion. This warranty applies to all products manufactured and distributed by Spectrum except the products listed below.
DESIGNED FOR INDOOR USE ONLY - Spectrum’s products have been designed and constructed for indoor use only. Moving or using
outdoors, or on excessively rough surfaces, may cause damage to the products and may void the warranty. If an outdoor application is
desired please contact us to discuss potential custom design solutions.
Spectrum is committed to provide complete customer satisfaction. Each of our products are manufactured from the best materials available
and each product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet
Customer Expectations).
Our Customer Service Help Line 1-800-235-1262 is ready to provide immediate attention to any questions, comments or concerns. Weare
available to answer your calls Monday through Friday from 7 am to 5 pm CST. In addition your product comments or concerns are welcome
via e-mail at: [e-mail].
Items that have a varying warranty include, but are not limited to, the following:
• Adjustable Crank/Electric Desk Legs (1 yr)
• Flat Panel Desk Gas Cylinders (1 yr)
• Adjustable Height Chair Parts – including frames, gas cylinders, wood and plastic parts, and control handles (7 yrs)
• Adjustable Height Chair Parts Casters (2 yrs)
• Adjustable Height Chair Upholstery - In-Stock Upholstery (2 yrs)
• Adjustable Height Chair Upholstery - Graded-In Fabrics and C.O.M (no warranty)
• Height Adjustable Columns and Lifts (1 yr)
• General Use Casters (1 yr)
• Electrical – ECA (1 yr)
• Electrical - Power Strips (1 yr)
• Electrical Surge Suppressors (lifetime)
• Electrical - Retractable Power Cords (1 yr)
• Keyboard/Mouse Trays (1 yr)
• Flat Panel Monitor Arm – General Parts (5 yrs)
• Flat Panel Monitor Arm – Gas Cylinders (2 yrs)
• CRT Monitor Arm (1 yr)
0110979 Pa
g
e 6 of 6
The warranty, as stated above, is effective as of 05/28/2009
