Spectrum LX
LED Light Therapy System
User’s Manual
Version: February 2017
SPECTRUM SCIENCE and BEAUTY
www.spectrumsciencebeauty.com.au
PH:1300 766 198

NOTICE
Read the user’s manual prior to operation!
CHAPTER 1 - GENERAL
Thank you for purchasing the LED Skin Rejuvenation System (Spectrum LX) by Spectrum
Science and Beauty. Every Spectrum LX has been thoroughly tested and has been shipped
in perfect operating condition. Carefully check the shipping carton for damage that may
have occurred during transport. If the carton appears to be damaged, carefully inspect your
machine for any damage and be sure all accessories necessary to operate the unit have
arrived intact. In the case damage has been found or parts are missing, please contact
Spectrum Science and Beauty.
1.0 Brief Introduction
Product Name: Spectrum LX LED Light Therapy System
1.1 Principle & Treatment range
1. Light penetrates to subcutaneous tissue.
2. The mitochondria absorbs the photon light energy and is energised.
3. The stimulated mitochondria produces ATP which causes the cell to reproduce
faster and function like younger cells.
4. The superluminous light promotes cell wall exchange stimulating the micro
circulation of the blood. The increase of cell reproduction and blood circulation
causes more collagen and elastin to bundle between the cells which leads to
reduced wrinkles and faster healing time. Skin will appear younger, plumper and
healthier looking within 2 –6 weeks.
5. By manipulating the wavelengths, cells can be turned on and off. Blue light LEDs
are used in the treatment of acne. Red light LEDs are used for PhotoDynamic
therapy (PDT).
THIS SYSTEM IS TO BE OPERATED BY QUALIFIED PERSONNEL ONLY.

1.2 Technical Specification
Model:
Spectrum Oringal LX
LED Colors:
Red(620nm-635nm),
Blue(415nm-465nm),
IR(825nm-835nm),
Blue, Red, Red + IR
Light Power:
0-10 Levels
Red Max: 40mW
Blue Max: 60mW
IR Max: 40mW
Light Frequency:
0-110 Hz
Time:
1-60 Minutes
Treatment Area:
50cm×20cm
LED Numbers:
1,260
Gross Weight:
20 KG
Dimension:
70cm×45cm×142cm
Packing Size:
40cm×60cm×100cm
Electrical:
100~240VAC, 50/60Hz
1.3 Working Environment
Environment temperature: 0°C ~ 40°C
Relative humidity: 30% ~ 85%
1.4 Storage Environment
Environment temperature: -20℃~ 70℃
Relative humidity: 10% ~ 95%
Store in a room with good ventilation.

CHAPTER 2 - INSTALLATION
The process of installation includes:
1. Unpack the unit
2. Assembly of its components and ensure that all connections are firmly in place.
3. Attach the power supply
4. Switch on the unit and test all functions of the system
2.1 Accessories/Parts
a - Adjusting arm g - Electrical outlet
b - LED treatment head h - Pedestal
c - Head adjustment knobs
d - Control Panel
e - On/Off switch
f - Power cord holder

2.2 Installation
Before unpacking the Spectrum LX make sure that the working environment conforms
to the requirements of this section.
Attach the wheels and support to the base of the main unit as shown below (fig 2.1).
Then attach the treatment head to the main body as follows. The wire from the head
attaches as shown (fig 2.2)
(fig 2.1) (fig 2.2)

CHAPTER 3 - OPERATION
The Spectrum LX is extremely easy to use.
A –Time adjust up and down + time display
B –Start and Pause button
C –Light frequency display and up and down adjustment
D - Light intensity display and up and down adjustment
A
B
D
C

3.1 Before and after the treatment
1. Remove all Jewelry from the client.
2. It is necessary to set different energy levels during the treatment procedure
according to the customer’s acceptance levels.
3. Aftercare instructions given by the clinician must be followed for best result.
Table 3.2- Treatment protocol of LED/ Time suggestion
TREATMENT
LED COLOUR
TIME (min)
RECOMMENDED
TREATMENT
COURSE
Acne
BLUE
20 minutes
10 treatments
Biweekly
Rejuvenation
RED/
INFRARED
20 minutes
10 treatments
Biweekly
Pigmentation
RED/
INFRARED
20 minutes
10 treatments
Biweekly
Scarring
RED/
INFRARED
20 minutes
10 treatments
weekly
Treatment Procedure
1. Cleanse the client’s skin.
2. If the customer’s skin is thick or rough exfoliation may be recommended before LED
treatment.
3. Place protective eyewear on client, using cotton pads underneath.
4. Adjust the LED panel to get the best angle, keep 10cm distance from skin.
5. Turn the machine on, using the start on/off switch.
6. Select the desired settings to ensure best clinical endpoint eg. Level 10, 50
frequency, 20 minutes.
7. Press start.
8. When timer is finished, remove protective eyewear and apply SPF 15 +
3.3 Contraindications
Clients with the following conditions shouldn’t be treated with this machine.
Pregnant & lactating
Pacemaker
Angiocardiopathy ( disease affecting both the heart & blood vessels)
Recent eye surgery
Epilepsy
Photosensitive medications

CHAPTER 4 - MAINTENANCE
1. Turn off power supply after treatments; pull out power cord if you are not using the
machine.
2. Avoid damage to the LED’s.
3. Clean the LED head constantly, turn off power supply and ensure machine has cooled
down before cleaning.
4. Do not use gasoline, alcohol or chemical cleaning agents to clean the treatment head
and surface of the machine.
5. Make sure treatment head is dry before use.
WARRANTY STATEMENT
Limited Warranty
This system is covered by a one year warranty from the date of delivery.
This Warranty does not cover:
Improper storage, use of improper cleaning agents or chemicals, negligence,
accidental damage, improper and/or unauthorised repairs.
Transportation costs to and from workshop.
Implied warranties, including those of merchantability and fitness for a particular
purpose, are limited to one year from date of delivery.
If the product has not been installed, operated, maintained or used in accordance with
the manufacturers instructions or specifications provided with the product.
If the operating and maintenance procedures outlined in the user manual is not
followed, including where it is specified for regular replacement, maintenance and
cleaning of certain parts.
To damage, malfunction or failure resulting from alterations, accident, misuse, abuse,
fire, liquid spillage, maladjustment of customer controls, use on an incorrect voltage,
power surges and dips, thunderstorm activity, acts of God, voltage supply problems,
tampering or unauthorised repairs by any persons, use of defective or incompatible
accessories, the operation of a computer virus of any kind, exposure to abnormally
corrosive conditions or entry by any insect, vermin or foreign object in the product.
Loss or damage arising from loss of use, loss of profits or revenue, or for any resulting
indirect or consequential loss of damage.
