Speed Queen SFET07 User manual

Multi-Housing
Micro-DISPLAY Control
Commercial Washers & Dryers
Horizon®Line
www.speedqueen.com
AM10-0782
Washer & Dryer Specifications
SWFT71, SWFY71 Electric: SFET07, SFEY07 Electric: STET77, STEY77
Gas: SFGT09, SFGY09 Gas: STGT79, STGY79
Basket/CylinderVolume- cu. ft. (liters) 2.84 (80) 7.0 (198) 2.84 (80)/7.0 (198)
Width - in (mm) 26 7/8" (683) 26 7/8" (683) 26 7/8" (683)
Depth - in (mm) 28" (711) 28" (711) 28" (711)
Height* - in (mm) 43" (1092) 43" (1092) 76 5/8" (1946)
Weight - lb (kg) 250 (113) Electric: 150 (68) Electric: 360 (163)
Gas: 155 (70) Gas: 365 (166)
Shipping Weight - lb (kg) 270 (123) Electric: 160 (73) Electric: 390 (177)
Gas: 165 (75) Gas: 395 (179)
Cycle Time - minutes 27 45 27/45
Motor HP 1 HP, 750 W 1/3 HP, 5.5 amps 1/3 HP, 5.5 amps
1 HP, 750 W
Water Consumption - gal. per cycle 14.8 N/A 14.8
Water Factor - gal. per cu. ft. 5.2 N/A 5.2
Modified Energy Factor 2.16 N/A 2.16
Hot Water Usage - gal. per cycle 1.59 N/A 1.59
Water Pressure - psi (bar) Pressure fill – 20 to 120 N/A Pressure fill – 20 to 120
(1.4/8.3) (1.4/8.3)
Spin Speed - RPM 500, 650, 1000 N/A 500, 650, 1000
Cycle/Temperature Normal/Hot High 160º See washer and dryer
Normal/Warm Medium 155º columns for corresponding
Permanent Press/Warm Low 145º cycles and temperatures.
Delicate/Cold Delicate 115º
Electrical Specifications and 120/60/1-15 amp Electric: 120/240/60/1-30 amp See washer and dryer columns
Circuit Requirements 120/208/60/1-30 amp for electrical specifications and
Gas: 120/60/1-15 amp circuit requirements.
Motor - RPM Inverter Drive 60 Hz: 1725 60 Hz: 1725/Inverter Drive
Btu per Hour N/A 25,000 (6300 kcal) 25,000 (6300 kcal)
Heating Element** N/A 5350 W, 240 V 5350 W, 240 V
4750 W, 208 V 4750 W, 208 V
Type of Gas (Gas models only) N/A Factory-equipped natural/ Factory-equipped natural/
mixed gas. Convertible mixed gas. Convertible
to LP gas.*** to LP gas.***
Utility Connections - in (mm) N/A Gas: 3/8" NPT (9.5) Gas: 3/8" NPT (9.5)
Air Outlet Diameter - in (mm) N/A 4" (102) 4" (102)
Exhaust Airflow†- cfm (liters/sec.) N/A 220 (105) 220 (105)
Maximum Exhaust N/A 0.6" W.C. 0.6" W.C.
Static Back Pressure
Agency Approval cULus Electric: cULus Electric: cULus
Gas: CSA Star Gas: CSA Star
Activation Coin/Card-Ready Coin/Card-Ready Coin/Card-Ready
Self-Adjusting Rear Legs No No No
Top Finish Porcelain Porcelain N/A
Colors White White White
Door Type Window Solid Window
* Heights may vary slightly depending on leveling adjustments.
** Factory equipped 120/240/60/1 - may be field converted to 120/208/60/1 by qualified servicer.
*** IMPORTANT: Any product revisions or conversions must be made by the Manufacturer’s Authorized Dealers, Distributors, or local service personnel.
† Measured at point of exit from dryer.
At Speed Queen, we’re so confident that our heavy-duty commercial washers and dryers are Commercial Built to Last Longer, that we’re offering the
following limited warranty to prove it: Through three years†† — Any part of the washer, dryer or stack dryer. Through five years†† — The washer
transmission assembly, base and cabinet assembly including top, lid and door, against rust from inside out. Lifetime†† — The stainless steel washtub.
†† Parts only. Labor not included. See Speed Queen Warranty Bond for specifics.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements,
design and specifications subject to change without notice. The quality management system of Alliance Laundry Systems’ Ripon facility has been registered
to ISO 9001:2000.
©Copyright 2010 Alliance Laundry Systems LLC
Printed in the U.S.A
Washers Dryers Stack Washer/Dryers
Commercial Built to Last Longer
Coin
SWFT71 Front Control Washer
SFET07 Front Control Electric Dryer
SFGT09 Front Control Gas Dryer
STET77 Electric Stack Washer/Dryer
STGT79 Gas Stack Washer/Dryer
Card
SWFY71 Front Control Washer
SFEY07 Front Control Electric Dryer
SFGY09 Front Control Gas Dryer
STEY77 Electric Stack Washer/Dryer
STGY79 Gas Stack Washer/Dryer
AM10-0782_Layout 1 12/9/10 8:58 AM Page 1

Horizon Quality Features
• The “Big Load Door” opening of 188.6 sq. in. is 132%
larger than that of the previous model.
• See-through door convenience with 180° swing for
easy loading.The hinge is a robust 10" steel piano
style to maintain door alignment.
• Frontmount supply dispenser automatically adds
detergent, bleach and softener.
Superior Drying Convenience
• A wide door opening of 2.06 sq. ft. is the industry’s
largest, offering residents the convenience of easy
loading and unloading.
• Door is reversible for installation flexibility (solid
door models only).The upfront lint filter is easy to
clean and secured.
Drying and Energy Dynamics
• Durable galvanized steel cylinder with extra-large 18 lb
capacity.The gentle tumble action minimizes wrinkles.
• Quiet, efficient blower system with superior airflow
of 220 cu. ft. per minute for fast drying and lower
operating costs.
• Efficient dryer heating with 25,000 Btu (gas models)
and 5,350 Watts (electric models).
Control Features
• LED display with price
• Door lock light
• Manual audit mode counts coins and cycles
(non-resettable)
MDC Programming Features
• Vend price - default $1.00 ($0.25 increments)
• Wash cycles - default (P.P. wash, two rinses)
• Drying time and temperatures
Smart Card Programming
• Time-of-day
promotion pricing
• Multi-level vend
• Dryer top-off
Activation Features
Coin Models
MDC laundry units are factory
equipped with high security
coin drops.
Five checks to validate the
coin and a reject slot to
return invalid coins.
Card Ready Models
The MDC laundry unit is
card-ready for interfacing
with a card reader supplier
of choice.
The MDC unit is activated
by the Smart Card reader.
The MDC display shows the
user beginning and ending
card balance.
Micro-DISPLAY Control
Dryer
Micro-DISPLAY Control
Washer
Micro-DISPLAY Control
Coin or Card-Ready
Today, multi-housing owners and managers are constantly
confronted with improving property security and
enhancing amenity services.They are challenged to
improve revenue cash flow, conserve energy and provide
ADA compliant laundry equipment.
Solutions to these issues are Speed Queen’s Micro-
DISPLAY Control (MDC) front load washers and dryers.
The Horizon®washers are ENERGY STAR®qualified.
They reduce water consumption and save energy over
conventional commercial top load washers.The attractive
front control design meets all ADA standards and will
brighten up any laundry room.
Residents will find the laundry process a breeze with
streamlined, easy-to-use Micro-DISPLAY Controls.
• Displays coin countdown to start cycle.
• Shows cycle time remaining.
• Remaining card balance on card operated models.
• Touch pad selectors for easy activation with LED
and sound enunciator signal.
• Blinking start pad signal.
• Bright, easy-to-read cycle status lights.
Your authorized Speed Queen laundry service provider
can design an MDC laundry room solution for any
property type.
• Non-resettable cycle and coin counters to monitor
laundry room activity.
• Diagnostics to expedite service.
Ultra, High-Efficient
Automatic Washer
• ENERGY STAR®qualified.
• Low water and energy consumption.
•The MDC offers four energy efficient wash cycles that
integrate into a six-speed wash system.
• Reversing wash action.
• Heavy-duty freestanding washer.
Card Reader
Coin Drop
• The stainless steel washtub has 5,499
perforated holes with three full-length
baffles to maximize mechanical wash
action for cleaner clothes.
• High speed extract of 1,000 RPM final spin
exerts 300 G-Force to maximize moisture
removal from clothes.
• All drive components (pulley, trunnion, tub
shaft and bearings) are manufactured
with rugged steel construction.
• Heavy-duty 1 HP drive motor with
reversing wash action.
• Freestanding design features four large
automotive size shocks so the washer
can be installed on most floor types
or levels.
Stack Washer/Dryer Saves
Space and Energy
• This innovative stacked concept takes up half
the floor space that a conventional washer
and dryer do when situated side by side.
• The freestanding softmount design can be
installed on most floors at any level.
• Both the washer and dryer have the same
hookups and connections as a standard
washer and dryer, so no additional plumbing
or electrical change is needed.
• Having a window in both the washer and
dryer enables customers to view their
entire laundering process.
AM10-0782_Layout 1 12/9/10 8:58 AM Page 2

Horizon Quality Features
• The “Big Load Door” opening of 188.6 sq. in. is 132%
larger than that of the previous model.
• See-through door convenience with 180° swing for
easy loading.The hinge is a robust 10" steel piano
style to maintain door alignment.
• Frontmount supply dispenser automatically adds
detergent, bleach and softener.
Superior Drying Convenience
• A wide door opening of 2.06 sq. ft. is the industry’s
largest, offering residents the convenience of easy
loading and unloading.
• Door is reversible for installation flexibility (solid
door models only).The upfront lint filter is easy to
clean and secured.
Drying and Energy Dynamics
• Durable galvanized steel cylinder with extra-large 18 lb
capacity.The gentle tumble action minimizes wrinkles.
• Quiet, efficient blower system with superior airflow
of 220 cu. ft. per minute for fast drying and lower
operating costs.
• Efficient dryer heating with 25,000 Btu (gas models)
and 5,350 Watts (electric models).
Control Features
• LED display with price
• Door lock light
• Manual audit mode counts coins and cycles
(non-resettable)
MDC Programming Features
• Vend price - default $1.00 ($0.25 increments)
• Wash cycles - default (P.P. wash, two rinses)
• Drying time and temperatures
Smart Card Programming
• Time-of-day
promotion pricing
• Multi-level vend
• Dryer top-off
Activation Features
Coin Models
MDC laundry units are factory
equipped with high security
coin drops.
Five checks to validate the
coin and a reject slot to
return invalid coins.
Card Ready Models
The MDC laundry unit is
card-ready for interfacing
with a card reader supplier
of choice.
The MDC unit is activated
by the Smart Card reader.
The MDC display shows the
user beginning and ending
card balance.
Micro-DISPLAY Control
Dryer
Micro-DISPLAY Control
Washer
Micro-DISPLAY Control
Coin or Card-Ready
Today, multi-housing owners and managers are constantly
confronted with improving property security and
enhancing amenity services.They are challenged to
improve revenue cash flow, conserve energy and provide
ADA compliant laundry equipment.
Solutions to these issues are Speed Queen’s Micro-
DISPLAY Control (MDC) front load washers and dryers.
The Horizon®washers are ENERGY STAR®qualified.
They reduce water consumption and save energy over
conventional commercial top load washers.The attractive
front control design meets all ADA standards and will
brighten up any laundry room.
Residents will find the laundry process a breeze with
streamlined, easy-to-use Micro-DISPLAY Controls.
• Displays coin countdown to start cycle.
• Shows cycle time remaining.
• Remaining card balance on card operated models.
• Touch pad selectors for easy activation with LED
and sound enunciator signal.
• Blinking start pad signal.
• Bright, easy-to-read cycle status lights.
Your authorized Speed Queen laundry service provider
can design an MDC laundry room solution for any
property type.
• Non-resettable cycle and coin counters to monitor
laundry room activity.
• Diagnostics to expedite service.
Ultra, High-Efficient
Automatic Washer
• ENERGY STAR®qualified.
• Low water and energy consumption.
•The MDC offers four energy efficient wash cycles that
integrate into a six-speed wash system.
• Reversing wash action.
• Heavy-duty freestanding washer.
Card Reader
Coin Drop
• The stainless steel washtub has 5,499
perforated holes with three full-length
baffles to maximize mechanical wash
action for cleaner clothes.
• High speed extract of 1,000 RPM final spin
exerts 300 G-Force to maximize moisture
removal from clothes.
• All drive components (pulley, trunnion, tub
shaft and bearings) are manufactured
with rugged steel construction.
• Heavy-duty 1 HP drive motor with
reversing wash action.
• Freestanding design features four large
automotive size shocks so the washer
can be installed on most floor types
or levels.
Stack Washer/Dryer Saves
Space and Energy
• This innovative stacked concept takes up half
the floor space that a conventional washer
and dryer do when situated side by side.
• The freestanding softmount design can be
installed on most floors at any level.
• Both the washer and dryer have the same
hookups and connections as a standard
washer and dryer, so no additional plumbing
or electrical change is needed.
• Having a window in both the washer and
dryer enables customers to view their
entire laundering process.
AM10-0782_Layout 1 12/9/10 8:58 AM Page 2

Multi-Housing
Micro-DISPLAY Control
Commercial Washers & Dryers
Horizon®Line
www.speedqueen.com
AM10-0782
Washer & Dryer Specifications
SWFT71, SWFY71 Electric: SFET07, SFEY07 Electric: STET77, STEY77
Gas: SFGT09, SFGY09 Gas: STGT79, STGY79
Basket/CylinderVolume- cu. ft. (liters) 2.84 (80) 7.0 (198) 2.84 (80)/7.0 (198)
Width - in (mm) 26 7/8" (683) 26 7/8" (683) 26 7/8" (683)
Depth - in (mm) 28" (711) 28" (711) 28" (711)
Height* - in (mm) 43" (1092) 43" (1092) 76 5/8" (1946)
Weight - lb (kg) 250 (113) Electric: 150 (68) Electric: 360 (163)
Gas: 155 (70) Gas: 365 (166)
Shipping Weight - lb (kg) 270 (123) Electric: 160 (73) Electric: 390 (177)
Gas: 165 (75) Gas: 395 (179)
Cycle Time - minutes 27 45 27/45
Motor HP 1 HP, 750 W 1/3 HP, 5.5 amps 1/3 HP, 5.5 amps
1 HP, 750 W
Water Consumption - gal. per cycle 14.8 N/A 14.8
Water Factor - gal. per cu. ft. 5.2 N/A 5.2
Modified Energy Factor 2.16 N/A 2.16
Hot Water Usage - gal. per cycle 1.59 N/A 1.59
Water Pressure - psi (bar) Pressure fill – 20 to 120 N/A Pressure fill – 20 to 120
(1.4/8.3) (1.4/8.3)
Spin Speed - RPM 500, 650, 1000 N/A 500, 650, 1000
Cycle/Temperature Normal/Hot High 160º See washer and dryer
Normal/Warm Medium 155º columns for corresponding
Permanent Press/Warm Low 145º cycles and temperatures.
Delicate/Cold Delicate 115º
Electrical Specifications and 120/60/1-15 amp Electric: 120/240/60/1-30 amp See washer and dryer columns
Circuit Requirements 120/208/60/1-30 amp for electrical specifications and
Gas: 120/60/1-15 amp circuit requirements.
Motor - RPM Inverter Drive 60 Hz: 1725 60 Hz: 1725/Inverter Drive
Btu per Hour N/A 25,000 (6300 kcal) 25,000 (6300 kcal)
Heating Element** N/A 5350 W, 240 V 5350 W, 240 V
4750 W, 208 V 4750 W, 208 V
Type of Gas (Gas models only) N/A Factory-equipped natural/ Factory-equipped natural/
mixed gas. Convertible mixed gas. Convertible
to LP gas.*** to LP gas.***
Utility Connections - in (mm) N/A Gas: 3/8" NPT (9.5) Gas: 3/8" NPT (9.5)
Air Outlet Diameter - in (mm) N/A 4" (102) 4" (102)
Exhaust Airflow†- cfm (liters/sec.) N/A 220 (105) 220 (105)
Maximum Exhaust N/A 0.6" W.C. 0.6" W.C.
Static Back Pressure
Agency Approval cULus Electric: cULus Electric: cULus
Gas: CSA Star Gas: CSA Star
Activation Coin/Card-Ready Coin/Card-Ready Coin/Card-Ready
Self-Adjusting Rear Legs No No No
Top Finish Porcelain Porcelain N/A
Colors White White White
Door Type Window Solid Window
* Heights may vary slightly depending on leveling adjustments.
** Factory equipped 120/240/60/1 - may be field converted to 120/208/60/1 by qualified servicer.
*** IMPORTANT: Any product revisions or conversions must be made by the Manufacturer’s Authorized Dealers, Distributors, or local service personnel.
† Measured at point of exit from dryer.
At Speed Queen, we’re so confident that our heavy-duty commercial washers and dryers are Commercial Built to Last Longer, that we’re offering the
following limited warranty to prove it: Through three years†† — Any part of the washer, dryer or stack dryer. Through five years†† — The washer
transmission assembly, base and cabinet assembly including top, lid and door, against rust from inside out. Lifetime†† — The stainless steel washtub.
†† Parts only. Labor not included. See Speed Queen Warranty Bond for specifics.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements,
design and specifications subject to change without notice. The quality management system of Alliance Laundry Systems’ Ripon facility has been registered
to ISO 9001:2000.
©Copyright 2010 Alliance Laundry Systems LLC
Printed in the U.S.A
Washers Dryers Stack Washer/Dryers
Commercial Built to Last Longer
Coin
SWFT71 Front Control Washer
SFET07 Front Control Electric Dryer
SFGT09 Front Control Gas Dryer
STET77 Electric Stack Washer/Dryer
STGT79 Gas Stack Washer/Dryer
Card
SWFY71 Front Control Washer
SFEY07 Front Control Electric Dryer
SFGY09 Front Control Gas Dryer
STEY77 Electric Stack Washer/Dryer
STGY79 Gas Stack Washer/Dryer
AM10-0782_Layout 1 12/9/10 8:58 AM Page 1
