Speed Queen SCN100GF Installation instructions

QUANTUM STANDARD OPL CONTROL
For laundry managers requiring basic management options,Quantum
Standard comes with four cycle selections, two water levels and manual
programming. It also offers a maximum extraction speed of 100 G-force.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements,design and specifications subject to change without notice.The
quality management system of Alliance Laundry Systems’Ripon facility has been registered to ISO#9001:2000.
Printed in the U.S.A.
speedqueen.com
© 2012 Alliance Laundry Systems LLC AO12-0045
ON-PREMISES LAUNDRY HARDMOUNT SCN100GF
FEATURES & BENEFITS
• Advancedwaterprotectionalertsownersifthe
washerhasastuckdrain,slowdrainconditionor
leakinginletvalve,whichhelpsconservewater.
• Ruggeddoorhandleandnewlockmechanism
ensureeasyopeningandclosingandreliablelocking
—nomoredoorlockerrorcodes.
• Newdualtriple-lipsealsandastainlesssteelsleeve
aroundthetrunnion,deliverthestrongestlineof
defenseinprotectingthebearingsagainstthe
damagingeffectsofmoisture.
• Four-compartmentchemicaldispenseradds
chemicalsattherighttime,automaticallysaving
stafftime.Thenewdispenserdesigneliminates
over-sudsingconditions.
PRODUCT SPECIFICATIONS
SCN0100GF
Capacity 100 lb
Width 41 1/2”
Depth 52 5/8”
Height 56 3/16”
Cylinder Diameter 36”
Cylinder Depth 26”
Cylinder Volume 13.5 cu. ft.
Door Opening Size 18 1/2”
Door Bottom to Floor 17 3/4”
Wash Speeds 39 RPM
Extract Speed 443 RPM
Distribution Speed 70 RPM
Extract G-Force 100
Water Inlet 2 @ 3/4”
Drain Diameter 1 @ 3”
Drain Height To Floor 5 3/4”
Motor Size 5 HP
Electrical Specs
Voltage/Hz/Phase
X 200-208/220-240/50/60/1/3
Q 200-208/220-240/50/60/3 (electric heat)
P 380-415/50/60-3
N 440-480/50/60/3
Net Weight 1260 lb
Shipping Weight 1310 lb
Shipping Width 48”
Shipping Depth 58 5/8”
Shipping Height 65 3/4”
Agency Approvals cETLus, CE
