Speed Queen AFNE9B Operator's manual

Quick Consumer
Manual

Two (2) lter
screen washers
Two (2) plain
rubber washers
Four (4) rubber
feet
Beaded strap
Installation
Parts included:
1. Move unit to area within 4 ft (1.2 m) of nal installation.
2.
3.
4.
5.
7. Connect washer to electrical power – on individual branch
circuit. Refer to serial plate for electrical ratings.
8. Run washer through one complete cycle to make sure it is
operating properly.
Welcome
Thank you for purchasing a Speed Queen®appliance. We value you as a customer.
At Speed Queen, leading performance is our daily reality. We seek to deliver an outstanding experience in every aspect of laundry.
Your machine was built to last 25 years in your home and Speed Queen support has been built to provide you with the best service in
the industry.
9. Check for leaks.
Two (2)
ll hoses
Two (2) plugs
Remove shipping materials.
• Remove lower panel (2 screws)
• Remove four (4) bolts securing shipping brace. Remove
brace and blue label
• Remove two (2) bolts from rear of washer
• Insert two (2) plugs into rear bolt holes
• Reinstall panel
Connect ll hoses – water pressure = 20-120 psi
[138-827 kPa].
• Flush water supply lines
• Use two lter screen washers with screen
facing faucet
• Use two rubber washers in end of hose
connecting to the machine
Connect drain hose to drain receptacle – 36 in. [91 cm]
recommended height.
• Use beaded strap to secure drain hose to drain
receptacle
Position and level the unit.
• Place four (4) rubber feet on leveling legs
• Unit must not rock
6. Wipe out inside of washtub.
7.
8.
4.
5.
3.
6.
2.
2.

Operating
5.
6.
7.
8.
9.
5.6. 9.
FR5 control
FF7 control
1. Prepare laundry 2. Add high eciency 3. Load laundry 4. Close door
(he) laundry supplies* 10.5 Kg maximum
loading capacity
5. Set cycle 6. Set temperature 7. Set spin speed 8. Set soil level 9. Press start/pause
(Electronic control only) (Electronic control only)
*Note: Pods must be placed in washtub with laundry.

Download full documentation and view installation and operating
videos for an immersive experience at Speedqueendoc.net or
scan the QR code below.
If you wish to receive printed documents at no cost, please
complete the order form and return by mail to the address below,
or email your request to [email protected].
Alliance Laundry Systems
Technical Communications
Shepard Street
P.O. Box 990
Ripon, WI 54971
United States
Order Form for
Printed Documentation
Model No.
Serial No.
Name
Address
Phone No.
Email Address
✂
Part No. 807602
May 2019
© Published by permission of the copyright owner –
DO NOT COPY or TRANSMIT
Speed Queen by Alliance Laundry Systems

消費者快速閱讀
手冊

兩(2)個過濾
網墊圈
兩(2)個普通
橡皮墊圈
四(4)個橡膠
腳套
串珠帶
安裝
內含部件：
1. 將裝置移動到最終安裝位置4英呎（1.2米）範圍內。
2.
3.
4.
5.
7. 為洗衣機接通電源 — 與單獨的分支
電路相連。參見序號銘牌，瞭解額定電功率。
8. 使洗衣機運行一個完整的週期，以確保其
運行正常。
歡迎
感謝您購買SpeedQueen®設備。我們重視客戶價值。
在Speed Queen，我們確保機器具有卓越的日常性能，並致力於在洗衣的各個方面提供最佳體驗。您的機器可供您在家中使用25年，且
Speed Queen支援服務可為您提供業內最好的服務。
9. 檢查洩漏情況。
兩(2)根
進水管
兩(2)個插塞
拆除運輸材料。
• 拆除底部面板（兩顆螺絲）。
• 拆除固定運輸支架的四(4)顆螺栓。拆除支架并清除藍色
標籤
• 拆除洗衣機背面的兩(2)顆螺栓。
• 將兩(2)個插塞插入背面的螺栓孔中。
• 重新安裝面板。
連接注水軟管 — 水壓 = 20-120 psi
[138-827 kPa]。
• 沖洗供水管
• 使用兩個過濾網墊圈，過濾網
朝向水龍頭。
• 在連接到機器的軟管端部
使用兩個橡膠墊圈
將排水軟管與排水容器相連 — 建議高度為36英吋[91公分]。
• 使用串珠帶將排水軟管固定到排水容器上
將機器放平。
• 將四(4)個橡膠腳套放在調平腳上
• 不得搖晃設備
6. 擦淨洗衣桶內部。
7.
8.
4.
5.
3.
6.
2.
2.

操作
5.
6.
7.
8.
9.
5.
6. 9.
FR5控制
FF7控制
1. 準備洗滌 2. 添加高效洗滌劑 3. 填入衣物 4. 關閉機門
洗滌織物* 不得超過10.5公斤
最大裝載量
5. 設置週期 6. 設置水溫 7. 設置脫水速度 8.設置污漬程度 9.按下Start/Pause
（僅限電子控制機型） （僅限電子控制機型） （啟動/暫停）按鈕
*注意：洗衣丸必須與衣物一同投入洗衣筒內。

通過登錄speedqueendoc.net或掃描下面的二維碼以下載完整文檔
並查看安裝和操作視頻，獲得沉浸式體驗。
如果您希望免費獲得列印的文檔，請填寫訂單並通過郵件返回以下
地址，或發送電子郵件至technicalcommunications@alliancels.
com。
Alliance Laundry Systems
Technical Communications
Shepard Street
P.O. Box 990
Ripon, WI 54971
United States
列印文檔
的訂單
型號
序號
名稱
地址
電話
電子郵箱地址
✂
文檔編號：807602
2019年5月
© 經版權所有者許可發佈 –
請勿複製或傳輸
Speed Queen，Alliance Laundry Systems
