SpeedyBee Master 5 V2 Instruction sheet

* (Note: 3D eect requirements, the actual object shall prevail)

CNC camera mount and camera side plate installation
1
2
M2*3
M3*5
Front top plate
Camera side plate
Install the front top plate
Antenna Installation Sequence
inse the O-ring into the antenna to
secure it on the TPU antenna base.

Choose a suitable VTX antenna base
Choose a suitable VTX antenna base
Install the plate on one side
and GPS base
Install the multi-function antenna base
SMA antenna base
M2.5*8
M2.5*8
Install the T-shaped antenna
(*Note: pictures for assembly reference only.
Frame doesn’t include antenna)
M3*23 stando
O3 Air Unit antenna base
Button head hex socket screw
GPS installation base
(Size:18*18*8mm)
Install the plate on the other side
1
2

M3*11
M3*14
M3*14
Install arms and anti-vibration module
(Complete the installation of 4 arms in turn)
Install the anti-vibration stack
module to the corresponding position
Back arm
Front arm
Install the screws on both sides
in the same way
*Notice: front and back arms
Front arm
Direction for drone head
Back arm
3
Install 4 arms in the same way
4
Screws pass through the bottom plate and
the intersection position of the arms in turn
1
2

M2*8
Install the middle plate to the corresponding
6 screw positions
Tighten the two press-in nuts
where the arms intersect
Install middle plate
middle plate
bottom plate
Place for capacitor and buzzer
1
2

Bottom protection silicone
(0.5mm)
M3*6
M2.5*6
M3*5
Combination of frame and CNC
camera mount
Frame and antenna base
combination
Combination with completed pas 1 and 2
Install 7075 stando
2
1
3
4

M3*6
M3*6
M3*6
M2*4
Finally, install the rear top plate and
batte anti-slip silicone
Install rear top plate and batte anti-slip silicone
Batte anti-slip silicone (2.5mm)
Rear top plate
Stack protector
*Notice: please change to M3*6 button head hex
socket screws if installing TPU protection at the
drone head pa.
1

5mm
Install the 3D printed foot mount to arms
Arm foot mount installation
Use screw of proper length based on the
motor installation
(*Notice: default screws are M3*8mm, M3*10mm)
M3*10
M3*8
12

M1.6*8
O3 Air Unit Installation Method
O3 Air Unit VTX
The 4 original screws at the bottom of the O3 Air Unit need to be removed
O3 Air Unit 6P ex cable
Pass through the top of the VTX
Master honeycomb heat sink

Recommend installing ESC in reverse horizontally 180°
*Note (After the ESC is installed reversely, remember to redene the correct position and
direction of motors 1-4.)
It is recommended to keep the power cable of ESC to be about 100mm.
Please refer to the used batte for actual length.
Suggesting place for main power cable

Capacitor
Buzzer
ESC power cable soldering and
recommended length for cable of motor
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140
1�1 Scale
Inner motor wire recommended
length: 110mm
外走线推荐电机线长为93mm
Outer motor wire recommended
length: 93mm
*Note: connect buzzer with mark to BZ+
of ight controller, and buzzer without
mark to BZ-
ESC ESC

Scan the QR code to get the installation guide.
We recommend you scan it through the SpeedyBee App for detailed instructions.
SpeedyBee APP Facebook QR CodeInstallation Guidance
