Speidel 47014 User manual

Translation of original
Operating Instructions
For
Pressure Cask
Item No.: 47014
Issue August 2011

TABLE OF CONTENTS
1GENERAL INFORMATION ............................................................................... 3
2SAFETY INSTRUCTIONS ................................................................................. 4
3GENERAL INFORMATION ............................................................................... 4
4INTRODUCTION OF THE PRESSURE CASK.................................................. 5
4.1 Components and scope of supply........................................................................................................... 5
4.2 Technical data ......................................................................................................................................... 5
4.3 Prior to first use ...................................................................................................................................... 5
4.4 How to place the pressure cask.............................................................................................................. 5
4.5 Transporting the pressure cask. ............................................................................................................ 6
4.6 How to clean the beverage cask ............................................................................................................. 6
4.7 How to store the pressure cask .............................................................................................................. 6
5HOW TO WORK WITH THE PRESSURIZED BEVERAGE CASK ................... 7
5.1 Filling the vessel with gas properly: ...................................................................................................... 7
5.2 Replacing the gas bottle: ........................................................................................................................ 8
5.3 Maintenance/Inspection: ........................................................................................................................ 8
6RANGE OF APPLICATION ............................................................................... 8
6.1 Sweet cider with any desirable alcohol level......................................................................................... 8
6.2 Low-alcoholic sweet cider ...................................................................................................................... 9
6.3 Containers that keeps your fermented beverage fresh........................................................................ 9
6.4 Soda water/carbonated mineral water.................................................................................................. 9
7TROUBLESHOOTING..................................................................................... 10
8WARRANTIES................................................................................................. 10
9EU CONFORMITY DECLARATION ................................................................ 12

Pressure cask
Page 3 of 16
1General information
Dear Customer,
You purchased a new product from Speidel. Thank you very much for your trust. When it
comes to our products, quality and functionality are of our primary concern.
Intended use:
This pressure cask was designed and manufactured to produce and store all kinds of
sweet cider, in particular unfermented juices. Fermentation itself or exterior pressure
prevents or slows down further fermentation, which keeps the juice/cider sweet or makes
it sweeter. Furthermore, it can also be used for the optimal storage of fermented juices
such as wine and fruit juices. The cask is not intended for and not suitable for the storage
of aggressive media or other fluids.
Operating instructions:
In order to ensure your new pressure cask will work reliably and safely from the first time
you use it and throughout its entire operating life, we have written these instructions.
Please read them carefully before using the product for the first time. If you follow these
tips and instructions carefully, the unit will work to your utmost satisfaction and will last
you for a long time to come. Should you decide to pass this product on to a third party,
please ensure to hand over the operating manual as well. To ensure, that you will enjoy
your newly purchased grinder, please observe the following safety and operating
instructions.
Declaration of Conformity
We, SPEIDEL Tank- und Behälterbau GmbH, herewith declare that the "Pressure cask"
referred to in these instructions to which this declaration relates, conforms with the
European requirements for food items and the Pressurised Equipment Directive 97/23/EG
.
Manufacturer:
Speidel Tank- und Behälterbau GmbH
Krummenstrasse 2
D-72131 Ofterdingen
Germany
www.speidels-hausmosterei.de
www.speidel-behaelter.de

Pressure cask
Page 4 of 16
2Safety instructions
Please consider the following instructions:
•Risk of suffocation! Only operate the pressure cask and it's ancillary equipment in
well ventilated rooms in order to prevent the risk of suffocation caused by escaping
CO
2
(e.g., when bleeding the pressure relief valve).
•The pressure cask has been designed for a maximum 10 bar! The pressure relief valve
has been set to a maximum pressure of 10 bar. If the pressure is exceeded, the valve
opens and gas will escape.
•The greatest possible care must be taken when working with or around any
pressurised equipment (e.g., cask, pressure reducing valves, gas bottles, etc.).
•Never store pressurised vessels in direct sunlight or operate these vessels inside
excessively hot rooms.
•When working with gases, a pressure reducing valve must be used that is set to a
maximum operating pressure of 10 bar. You may purchase an CO
2
pressure reducing
valve from us.
•Do not use the pressure cask as pressure reservoir or buffer vessel for gases with high
pressure thresholds/changing pressure loads, as is the case when constantly filling and
emptying cycles are being used.
•Individual components require merely a tight fit. Never use excessive torque!
•Do not use any tools to tighten the tap (A). Simply tighten all screws manually.
•Risk of injury! Never remove the tap (A), the blind plug (0) or the coupling unit (1)
while the cask is pressurised.
•The product shall only be used as stated in the description of its intended use, and
while technically safe and in flawless condition. Please ensure the units safe condition
prior to any use.
•Carefully read the operating instructions of the pressure cask and how to use the
pressure reducing valve.
Children and frail users:
•Risk of suffocation! For the safety of your children, please remove or keep all
packaging material (cardboard, Styrofoam, etc.) out of their reach.
•This cask and its accessories are not intended for the use by persons (including
children) with limited physical, sensory, or mental capabilities and shall not be
operated by persons lacking experience and/or knowledge about the equipment.
Unless, however, such person is supervised by another person who is familiar with
relevant safety regulations, or the personnel has been instructed on how to operate the
equipment properly.
•If children are present, they must be under constant supervision in order to ensure they
remain out of harm's way and do not play with the cask.
3General information
•Experts recommend CO
2
/carbon dioxide as application gas. Therefore, SPEIDEL
offers only accessory fittings for the use with carbon dioxide. For applications 1-3,
any gas used in the gastronomy can be used. However, you will need a special
pressure release valve and a different type of gas bottle. Please contact your gas
specialist.

Pressure cask
Page 5 of 16
•If purchasing a CO
2
bottle, a TÜV inspection is required every 10 years. Please
contact your gas specialist.
•To refill any gas bottle, we highly recommend contacting you local gas specialist. You
may also have your gas bottle refilled at a specialised beverage supply firm.
•If using CO
2
for pressurisation, please ensure that the gas bonds with the beverage and
carbonic acid is formed. If you remove the gas supply, the pressure inside of the cask
will be reduced (this is a natural reaction when carbonic acid forms in the beverage).
•When tapping the average, foam will be generated. Therefore, it is recommended to
use a mug with a large belly and opening.
•Never fill the pressure cask to its rim. Always leave at least several centimeters of air
space from the top.
•Use the tap carefully! Larger or coarse pieces of fruit should be filtered out after
pressing and before filling the cask.
•Ensure to keep oxygen out of the pressure cask.
4Introduction of the pressure cask
4.1 Components and scope of supply
Basic equipment:
•Stainless steel pressure vessel (unpacked)
•Tap (A) (in carton) consisting of: stainless steal threat with seal, pressure gauge (0 to
15 bar), certified safety valve, stainless steel riser pipe for top discharge with ball
valve, optional blind plug for gas set.
Accessories:
•Gas set consisting of coupler unit (1) , connecting the cask's threaded connection and
hose; hose (2), quick-release (3) to connect between hose and pressure relief valve,
seals (Order No.: 47015)
•Pressure relief valve for CO
2
. (Order No.: 47057)
•2-kg gas bottle (CO
2
/carbon dioxide). (Order No.: 47058)
•Cleaning brush, with drill attachment (Order No.: 47009)
4.2 Technical data
Cask dimensions: Ø40cm x H54cm
Dimensions incl. installed fittings Ø40cm x H83cm
Weight: 12.0 kg
Weight incl. tap: 13.5 kg
Max. operating pressure 10 bar
4.3 Prior to first use
Prior to its first use, ensure to clean the cask and the tap one more time – refer to Chapter
"Cleaning instructions for the pressure cask".
4.4 How to set up the pressure cask
Prior to its use, the pressure cask must be placed on a solid, stable, and level base frame.
Please note that the pressure cask can weigh up to 60 kg while filled. Avoid an unsteady

Pressure cask
Page 6 of 16
base frame. The room should be well ventilated and high temperatures or direct exposure
to sunlight should be avoided.
4.5 How to transport the pressure cask
The beverage cask must only be transported after it has been depressurized. In order to
prevent damage, the cask must be secured properly during transport.
4.6 How to clean the beverage cask
Please remember: hygiene is number one!
Only if you sterilize the cask and the tap inside and outside immediately prior to filling
the vessel can you be awarded with a delicious beverage. It is of utmost importance to
clean the vessel properly the first time. Hygiene is important to guarantee your success.
Therefore, SPEIDEL offers a cleaning brush that allows you to keep your pressure cask
spick and span.
When you are cleaning the vessel for the first time, use hot water to rinse it several times.
Use the brush (supplied) to clean the tap. Once the pressurised beverage cask has been
emptied, it must be cleaned thoroughly. Never let any remains become sticky and adhere
to the inside/outside of the vessel. Before refilling the vessel it may remain under residual
pressure; however, thorough cleaning shall always take place prior to the refilling
process.
Use commercially available cleaning agents to clean all stainless steel parts. Do not use
abrasive cleaners or sponges and brushes that may cause scratches. Please ensure to
remove all cleaning agent residue and rinse the pressurised beverage cask properly.
Moreover, we also recommend to use baking powder as cleaning age. Fill the vessel with
water. Add 1 to 3 packages of baking powder. Use the tap to close the cask and let it sit
for 1 to 2 days. Subsequently, rinse thoroughly.
These recommendations and instructions have been determined during numerous tests.
Those values are based on experience; however, we cannot provide any guaranties. Never
use chlorine or cleaning agents containing chlorine; it will damage the stainless steel.
Before opening the beverage cask, ensure the vessel has been depressurized
4.7 How to store the pressure cask
The pressurised beverage cask must be stored in a dry place. Avoid any contact with
ferrous or corroded equipment.
Only operate the pressurised beverage cask and its ancillary equipment in well ventilated
rooms in order to prevent the risk of suffocation caused by escaping CO
2
(e.g., when
bleeding the pressure relief valve).
Never store pressurised vessels in direct sunlight or operate these vessels inside
excessively hot rooms.
Keep children away from all gas fittings, pressure relief valves or gas bottles.

Pressure cask
Page 7 of 16
5How to work with the pressurized beverage cask
5.1 Filling the vessel with gas properly:
(for the use with a CO
2
/carbon dioxide gas connection)
1. The following additional equipment is required: SPEIDEL gas set, pressure relief
valve (adjustable from 0 - max. 10 bar) and lockable gas bottle with the respective
application gas, see accessories (carbon dioxide).
2. Use a socket wrench, size 6, to remove blind plug (0) from tap (A).
3. At the lower end (1a), screw coupler unit (1) including seal into the lock (0) of the
tap (A).
4. Firmly attach the hose's threaded connector (3b) to the exit port (4a) of the pressure
relief valve.
5. Now, connect the quick release of the hose (2a) to the male coupling (1b). Simply
press in – done!
6. The other end of the hose (2b) is pre-assembled with the threaded hose connection
(3a).
7. Subsequently, ensure all components are properly connected. Before connecting the
valve (4b), set the pressure relief valve to "ZU" (CLOSED) and totally remove the
operating pressure set screw (4c); this will prevent immediate pressure build-up.
8. Now, connect the relief valve (4d) with the proper gas bottle.
9. The system is now ready to be used. Depending on the application, the vessel can
now be pressurized to a maximum of 10 bar (should this pressure be exceeded, the
relief valve will be activated!)
10. Open the gas bottle. The bottle's pressure will be displayed on the pressure gauge.
Now, you can open the valve (4b) on the pressure relief valve and set the appropriate
pressure, using the setscrew (4c). The operating pressure will be displayed on the
pressure gauge and the relief valve.
(4a)
Connection
Gas bottle (4d)
(4c)
Hose (2)
SPEIDEL gas set (1-3)
(4b)
Seal
Coupler unit (1)
Quick release
(3)
SPEIDEL pressure relief valve
(4)
Tap (A)
Locking device (
0
)
(2a)
(2b)
(3b)
(3a)
(1a)(
1b
)

Pressure cask
Page 8 of 16
5.2 Replacing the gas bottle:
If you would like to refill the bottle with additional gas, or you simply want to remove the
bottle because the pressure is insufficient, first close the bottle at the valve (4b) of the
pressure relief valve. Ensure that the gas bottle and the exit port (4b) of the pressure relief
valve are closed! Now, remove the quick release (2a) from the male coupling (1b). The
hose, pressure relief valve, and gas bottle can now be removed from the vessel. A check
valve (1) constantly safeguards the pressure inside of the cask.
5.3 Maintenance/Inspection:
•For safety reasons, the pressurized beverage cask must be inspected during regular
intervals. Here, compliance with all current national regulations pertaining to the safe
operation of pressure vessels is mandatory.
•If the vessel was damaged, immediate inspection is necessary.
•Maintenance/inspection is recommended at least once a year.
•Visible changes such as cracks or other damage are not acceptable.
•All threaded connections must be free of damage, must not show wear and tear and/or
contamination.
•The pressure limiting valves must remain clean at all times, as sticky residue is
common when handling juices.
•If purchasing a CO
2
bottle, a TÜV inspection is required every 10 years. Please
contact your gas specialist.
6Range of application
6.1 Sweet cider with any desirable alcohol level
Use the pressurized beverage cask without connecting it to the gas bottle or attaching any
additional fittings. Thus, the cask can be used without adding any ancillary equipment.
No tools are required! Do not remove the blind plug, item 0.
•If you prefer a clearer sweet cider with less alcohol content, it is recommended to
transfer the juice into another vessel after pressing and keep it there for 3 - 4 hours.
This will remove the cloudiness from the juice. Ensure to remove all spoiled fruit
prior to the pressing procedure.
•After pressing, or once the must has settled, fill the beverage cask immediately with
the respective fruit juice.
•Now, you can determine the alcohol content of the beverage. Once the cask has been
filled, immediately close it in order to obtain a sweet cider with less alcohol later on.
The longer you keep the cask open, the longer the fermentation will last, and the
alcohol level in the beverage will be increased. If the vessel is kept open for 3 to 4
days and subsequently closed, the result will be a much higher alcohol content. Ensure
that the juice will not ferment completely, otherwise, the beverage will not be left with
a residual sweetness, and additional fittings (see Application 3) will be required.
•As soon as the cask is closed, pressure is generated inside of the vessel caused by the
fermentation until this process is stopped on its own. This way, you will always have a

Pressure cask
Page 9 of 16
fruity beverage. Due to the constant tapping, the alcohol content will change slightly
during the course of time. The freshness, however, will always remain.
6.2 Low-alcoholic sweet cider
For the operation of the pressure cask an additional gas set, a pressure relief valve (CO
2
),
and a gas bottle (carbon dioxide) are required (see 'Accessories'). To operate the cask
with a gas connection, please read the section "Filling the cask with gas properly".
•When producing a non-alcoholic beverage, particular attention must be paid to
hygiene and the quality of the fruit that is to be used. Never use spoiled fruit. The
quality of the fruit juice depends on the grade and cleanliness of the fruit.
•It is recommended to transfer the juice into another vessel after pressing and keep it
there for 3 - 4 hours. This will remove the cloudiness from the juice.
•Subsequently, fill the pressure cask immediately with the fresh and clean juice.
•In order to prevent potential fermentation, add carbon dioxide at a pressure of 9 bar.
Keep the gas bottle and all fittings connected to the pressure cask. When removing the
gas bottle (see "Replacing the gas bottle"), it is normal that the pressure during CO
2
saturation is reduced (this is a natural reaction when carbonic acid forms in the
beverage).
•First, you will be left with a non-alcoholic fruit juice. During the course of time, the
alcohol content may increase slightly inside the pressure cask, due to the repeated
tapping. This is a natural process and cannot be completely remove without additives;
however, the high pressure clearly slows down this process.
•Please observe the following: The fresher the fruit, the longer you will be able to keep
your juice non-alcoholic.
6.3 Containers that keeps your fermented beverage fresh
For the operation of the pressure cask an additional gas set, a pressure relief valve (CO
2
),
and a gas bottle (carbon dioxide) are required (see 'Accessories'). To operate the cask
with a gas connection, please read the section "Filling the cask with gas properly".
•This procedure is widely used in the beverage industry. Carbon dioxide is used in
many beverages. Today, even beer brewers and wine makers use carbon dioxide.
Carbon dioxide effectively improves the quality of the beverage. During wine
production, adding CO
2
reduces the amount sulphurisation required.
•Add any fermented beverage (wine, cider, beer, etc.) to you pressure cask.
•Now, add carbon dioxide and pressurise the cask to 0.5 to 1 bar. The low pressure is
sufficient to keep the beverage fresh. Keep the gas bottle and all fittings connected to
the pressure cask.
6.4 Soda water/carbonated mineral water
For the operation of the pressure cask an additional gas set, a pressure relief valve (CO
2
),
and a gas bottle (carbon dioxide) are required (see 'Accessories'). To operate the cask
with a gas connection, please read the section "Filling the cask with gas properly".

Pressure cask
Page 10 of 16
•Take advantage of your good quality domestic water. Information about the quality
and characteristics of your domestic water can be obtained from your respective local
authorities.
•Safe you money - and no more lugging heavy cases of mineral water When
considering a three-person household and regular usage, the pressure cask including
all fittings will pay for itself within approx. one year (depending on daily usage).
•Fill your pressure cask with potable water up to approx. 3 litres less than the total
volume. This leaves a greater effective area for the carbon dioxide to react with the
water and ensures a faster saturation.
•Subsequently, close the keg and pressurize (9 bar) the vessel with carbon dioxide.
After approx. 24 hours the water inside a 50 litre keg will have been saturated and you
are left with slightly carbonated mineral water.
•After more saturation (max. 2 days), you may shut off the carbon dioxide supply and
properly remove the gas bottle (see “Replacing the gas bottle”).
•The colder the drinking water that you're using to produce the soda, the better and
faster the saturation occurs.
•As soon as the CO
2
dissolves in the water it is formed into carbonic acid, and the
pressure drops to approximately 3 to 5 bar.
7Troubleshooting
Never repair the cask/fittings yourself; always consult a qualified technician. In order to
avoid any kind of danger, components may only be replaced or repaired by the
manufacturer, our customer service department, or a qualified technician.
8Warranties/procedure
Warranty claims are excluded if:
•the information and instructions provided in this operating manual have not been
observed,
•the pressure cask and its equipment were operated improperly, handled incorrectly, or
were insufficiently maintained. This also includes the proper and approved spare
parts, and if operating equipment have not been used as recommended by the
manufacturer,
•the pressure cask was used contrary to its intended application,
•existing safety equipment on the keg and its connecting parts or inside the filling and
discharging fittings was not used, disconnected or maintained/inspected incorrectly,
•modifications were carried out without the prior written permission of the
manufacturer,
•pertinent safety regulations were not taken into consideration during the operation of
the pressure cask,
•changes or modification without the express permission by the manufacturer are
carried out,
•the pressure cask was modified by unauthorized personnel.
•Only such juices and additives may be stored that do not present a risk of corrosion for
the cask itself and its equipment.

Pressure cask
Page 11 of 16
•The beverage cask must only be transported after it has been depressurized.
•Only the following equipment components shall be used with the pressure keg:
(1) pressure gauge,
(2) pressure limiting valve (safety valve).
Warranties:
•All legal warranty conditions apply. The warranty period for the use by non-
commercial consumers is reduced to the regulations applicable to commercial
customers, if such non-commercial consumer uses the product - even if only in part -
for commercial purposes.
•Any warranty claim presented to us or one of our dealerships must be accompanied by
a copy of the purchase order. In order to verify our warranty, please refer to the terms
and conditions mentioned below.
•To ensure prompt processing of all warranty claims, discrepancies must be brought to
our attention immediately after detection and must be submitted in writing, including a
description of the defect and, if possible, photographs should be attached to the claim.
•Warranties do not apply to defects caused by noncompliance with the operating
manual, improper handling, or normal wear and tear to be expected of the product.
Warranty claims are also excluded for fragile parts or consumables, such as seals,
gaskets, etc. Furthermore, warranty claims are excluded if repairs are performed by
personnel other than authorized representatives or dealerships.
Processing:
In the unlikely event that your product requires repair during the warranty period, please
contact us, submitting the respective warranty claim. The fastest and easiest option is
returning the unit, or presenting a notice of defect to your authorized
dealer/representative, or by contacting us directly:
E-mail: [email protected]
or fax to: 0049 – (0)7473 -9462-99
Please indicate your complete address and contact information. Furthermore, we
require the type designation of the equipment under claim, a short description of the
malfunction (if possible, please include photographs), the date of purchase (copy of
the invoice) and the name of the dealership from where you have purchased the new
product.
Once we have verified your notice of effect, we will contact you as soon as possible and
explain further procedures. Please do not ship the unit as "carriage forward", "freight
collect" or by similar shipping methods.

Pressure cask
Page 12 of 16
9EU Conformity Declaration

Pressure cask
Page 13 of 16

Pressure cask
Page 14 of 16

Pressure cask
Page 15 of 16

Pressure cask
Page 16 of 16
de Sie vermissen eine Betriebsanleitung in einer verständlichen Sprache. Dann kontaktieren Sie bitte Ihren
zuständigen Händler oder Importeur.
en You miss an instruction manual in an accessible language. Then please contact your local dealer or distributor.
fr Vous manquez un manuel d'instructions dans un langage accessible. Alors s'il vous plaît contacter votre
revendeur ou distributeur local.
es ¿Echa de menos un manual de instrucciones en un lenguaje accesible. Entonces, por favor contacte a su
vendedor o distribuidor local.
pt Você perde um manual de instruções em linguagem acessível. Então, por favor contacte o seu revendedor ou
distribuidor local.
pl Tęsknisz instrukcja w przystępnym językiem. Następnie skontaktuj sięz lokalnym sprzedawcąlub
dystrybutorem.
no Du savner en bruksanvisning på et lett tilgjengelig språk. Deretter kan du kontakte din lokale forhandler eller
distributør.
fi Menetät ohjekirjanen ymmärrettävällä kielellä. Sitten ota yhteyttä paikalliseen jälleenmyyjään tai
maahantuojaan.
sv Du missar en bruksanvisning på ett lättillgängligt språk. Vänligen kontakta din lokala återförsäljare eller
distributör.
da Du går glip af en brugsvejledning på et tilgængeligt sprog. Så kontakt din lokale forhandler eller distributør.
it Ti manca un manuale di istruzioni in un linguaggio accessibile. Quindi contattare il rivenditore o distributore
locale.
el Χάνετε από εγχειρίδιο χρήσης σε προσιτή γλώσσα. Στη συνέχεια, επικοινωνήστε µε τον τοπικό αντιπρόσωπο ή
διανοµέα.
hu Hiányzik egy használati utasítás hozzáférhetınyelven. Ezután vegye fel a kapcsolatot a helyi forgalmazóval
vagy a forgalmazó.
nl Je mist een handleiding in een toegankelijke taal. Neem dan contact op met uw lokale dealer of distributeur.
ro E dor de tine un manual de instrucŃiuni într-un limbaj accesibil. Apoi, v rug m s contactaŃi distribuitorul local
sau distribuitor.
ru Вы не пропустите инструкцию на доступном языке. Тогда, пожалуйста, свяжитесь свашим местным
дилером или дистрибьютором.
sk Vám chýba návod na použitie v zrozumiteľným jazykom. Potom sa obráťte sa na miestneho predajcu alebo
distribútora.
sl Pogrešaš navodila v razumljivem jeziku. Potem se obrnite na lokalnega prodajalca ali distributerja.
bg Можете да пропуснете инструкциите за употреба на достъпен език. Тогава, моля свържете се сместния
дилър или дистрибутор.
sr Мисс Иоу упутства на приступачан језику. Затим контактирајте локалног дистрибутера или
дистрибутера.
hr Vi propustiti pouku priručnik na pristupačan jeziku. Zatim obratite se svojem lokalnom zastupniku ili
distributeru.
cs Vám chybí návod k použití v srozumitelným jazykem. Pak se obraťte se na místního prodejce nebo distributora.
tr Eğer erişilebilir bir dilde bir kullanım kılavuzu özledim. Daha sonra yerel satıcınıza veya distribütör başvurun.
zh 你错过易懂的语言中的一个指导手册。那么请联系您当地的经销商或分销商。
ja あなたがアクセス可能な言語での取扱説明書を欠場。その後、お近くの販売店または特約店までご
連絡ください。
ko 당신은 접근 언어로 사용 설명서를보고 싶어요. 그런 다음 해당 지역의 대리점 또는 대리점에
문의하시기 바랍니다.
th คุณพลาดคูมือการเรียนการสอนในภาษาที่สามารถเขาถึง
จากนันกรุณาติดตอตัวแทนจําหนายหรือตัวแทนจําหนายใกลบานของคุณ
vi Bạn bỏlỡmột sách hướng dẫn bằng ngôn ngữdễtiếp cận. Sau ñó xin vui lòng liên hệñại lý ñịa phương của
bạn hoặc nhà phân phối.
