Spektrum Firma SPMXSE1070 User manual

Spektrum Firma 70A Brushed Smart ESC
Spektrum Firma 70A Brushed Smart Regler
Spektrum Firma 70A Contrôleur à balais Smart
Spektrum Firma 70A Smart Brushed ESC

2
Scan the QR code and select the Manuals and Support quick
links from the product page for the most up-to-date manual
information.
Scannen Sie den QR-Code und wählen Sie auf der Produktseite
die Quicklinks Handbücher und Unterstützung, um die
aktuellsten Informationen zu Handbücher.
Scannez le code QR et sélectionnez les liens rapides Manuals
and Support sur la page du produit pour obtenir
les informations les plus récentes sur le manuel.
Scannerizzare il codice QR e selezionare i Link veloci Manuali
e Supporto dalla pagina del prodotto per le informazioni
manuali più aggiornate.
SPMXSE1070

3
NOTICE
All instructions, warranties and other collateral documents are
subject to change at the sole discretion of Horizon Hobby, LLC.
For up-to-date product literature, visit horizonhobby.com or
towerhobbies.com and click on the support or resources tab for
this product.
MEANING OF SPECIAL LANGUAGE
The following terms are used throughout the product literature
to indicate various levels of potential harm when operating this
product:
WARNING: Procedures, which if not properly followed, create
the probability of property damage, collateral damage, and
serious injury OR create a high probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create
the probability of physical property damage AND a possibility of
serious injury.
NOTICE: Procedures, which if not properly followed, create
a possibility of physical property damage AND a little or no
possibility of injury.
WARNING: Read the ENTIRE instruction manual to
become familiar with the features of the product before
operating. Failure to operate the product correctly can result in
damage to the product, personal property and cause serious
injury.
This is a sophisticated hobby product. It must be operated with
caution and common sense and requires some basic mechani-
cal ability. Failure to operate this Product in a safe and respon-
sible manner could result in injury or damage to the product or
other property. This product is not intended for use by children
without direct adult supervision. Do not attempt disassembly,
use with incompatible components or augment product in any

4
Age Recommendation: Not for children under 14 years.
This is not a toy.
NOTICE: This product is only intended for use with unmanned,
hobby-grade, remote-controlled vehicles and aircraft. Horizon
Hobby disclaims all liability outside of the intended purpose and
will not provide warranty service related thereto.
way without the approval of Horizon Hobby, LLC.This manual
contains instructions for safety, operation and maintenance. It is
essential to read and follow all the instructions and warnings in
the manual, prior to assembly, setup or use, in order to operate
correctly and avoid damage or serious injury.
Waterproof Component
Your new Spektrum®70A Brushed Waterproof ESC has been
designed and built to allow you to operate the product in many
“wet conditions,” including puddles, creeks, wet grass, snow and
even rain.
While waterproof, this component has not been designed to be
immersed in water for long periods of time and should NOT be
treated like a submarine. In addition, most metal parts, including
any screws and nuts, as well as the contacts in the electrical
cables, will be susceptible to corrosion if additional maintenance is
not performed after running in wet conditions.
To maximize the long-term performance of your ESC and to
keep the warranty intact, it should only be used as described
in the “Usage Conditions” section of this manual. Additionally,
the procedures described in the “Wet Conditions Maintenance”
section must be performed regularly if you choose to run in wet
conditions. If you are not willing to perform the additional care and
maintenance required, then you should not operate your vehicle in
those conditions.

5
CAUTION: Failure to exercise caution while using this
product and comply with the following precautions
could result in product malfunction and/or void the warranty.
GENERAL PRECAUTIONS
• Read through the wet conditions maintenance procedures and
make sure that you have all the tools you will need to properly
maintain your ESC.
• Do not operate your ESC where it could come in contact
with salt water (ocean water or water on salt-covered roads),
contaminated or polluted water. Salt water is very conductive
and highly corrosive, so use caution.
USAGE CONDITIONS
Your ESC will operate successfully in any of the following,
individual-usage scenarios:
• 2 hours continuous operation in damp grass or vegetation.
• 2 hours continuous operation in heavy fog (95% humidity,
saturated air, condensing water).
• 1 hour continuous operation in light rain (<0.10 in/2.5mm
per hour).
• 15 minutes continuous operation in heavy rain (>0.30
in/7.6mm per hour).
• 1 hour continuous operation in light sleet (<0.10 in/2.5mm
per hour).
• 1 hour continuous operation in light snow (<0.25 in/6.35mm
per hour).
• 45 minutes continuous operation in standing or running fresh
water (the water level should always remain below the vehicle
frame), or constant splashing water, without any immersion of
waterproof component(s).
• 5 minutes continuous operation in standing or running fresh
water (the water level should never rise higher than 0.5 in
(about 10mm) above the vehicle frame), constant splash-

6
ing water, or frequent, intermittent immersion of waterproof
component(s).
• 1 hour continuous operation in damp sand, dirt, mud or snow
(the material level should always be below the vehicle frame),
constant splatter without any immersion or coverage of water-
proof component(s).
Furthermore, when appropriate maintenance procedures (as
described below) are performed promptly following exposure,
the ESC will remain best protected from corrosion or other
long-term, water-related damage.
WET CONDITIONS MAINTENANCE
• Gently rinse the mud and dirt off the ESC with a garden hose.
• Remove the battery pack(s) and dry the contacts.
• If you have an air compressor or a can of compressed air
available, blow off the ESC to help remove any water that
may have gotten into small crevices or corners. Dry any
water that may be inside a recessed connector housing.
• Let the ESC air dry before you store it. Water may continue
to seep or evaporate out of tight areas for a few hours.
NOTICE: This ESC is waterproofed for use in wet conditions.
Make sure the other components in your vehicle are waterproof
or water-resistant before driving in wet conditions.
191870 SPMXSEMC12 Manual

7
Contents
Waterproof Component ....................................................... 4
General Precautions.......................................................... 5
Usage Conditions.............................................................. 5
Wet Conditions Maintenance.............................................. 6
System Specifications ......................................................... 8
Wiring Diagram................................................................... 9
Installation........................................................................ 10
ESC and Transmitter Calibration......................................... 10
Operation ......................................................................... 11
ESC Programming via Switch Push Button.......................... 12
Programming the ESC via the SPMXCA200 Program Box .... 13
Programmable Features .................................................... 14
Programmable Values ....................................................... 15
LED Indicator and Motor Sounds........................................ 16
Troubleshooting Guide....................................................... 17
1-Year Limited Warranty.................................................... 19
Warranty and Service Contact Information .......................... 22
FCC Information................................................................ 23
IC Information................................................................... 24
Compliance Information for the European Union.................. 24

8
System Specications
Type Brushed
Constant/Peak 70A/200A
Function
Forward/Reverse; Forward/Brake/
Reverse, Forward/Brake
(Can be programmed via
SPMXCA200 or through the push
button on the switch)
Programming Port Optional Programming Box
Auxiliary Power
Outputs
(2) Standard Female Servo Con-
nectors for Lights, etc @ 6V/7.4V
(Power Supplied by BEC)
Vehicle Type 1/10 On-Road, Off-Road, Scaler,
Crawler
Optional Features
Can Be Programmed Via
SPMXCA200 or Through the Push
Button on the Switch
Battery Type/Input
Voltage
2–3 Cell Li-Po/Li-Fe; 5–9 Cell
Ni-MH/Ni-Cd
Recommended
Motor Type 540-/550-Size Motors
Compatible Motors
(Based on Battery
Voltage)
Below 8.4V; Down to 12T; Below
12.6V; Down to 35T
BEC Output 6V/7.4V – 4A (Shared Between
Receiver and Auxiliary Light Outputs)
Dimensions 36mm x 30mm x 18.2mm (w/o tabs)
Weight 1.76 oz (50 g)
Battery Connector IC3™Connector (EC3™compatible)
Motor Connector 4mm Female Motor Bullets

9
NOTICE: Always disconnect the battery from the ESC when
you have finished operating your vehicle. If you leave the
battery connected with the power switch in the OFF position,
the ESC will continue to draw current when connected to the
battery, resulting in possible damage to the battery through
over-discharge.
NOTICE: Do not connect a dedicated receiver battery to the
servo or programming ports. When the ESC/Receiver is turned
On it will provide the servo ports with 6V regulated power from
the main battery. If a dedicated receiver battery is connected to
the servo ports, the ESC/receiver may be damaged.
Power
Bullet
Connectors
Between ESC
and Motor
Programming
Button
Auxiliary (Light)
Connectors
Throttle
Connector to
Receiver
Heatsink
IC3 Power
Input
Connector
LED
Programming Port
Wiring Diagram

10
Installation
1. Determine how to mount the ESC as specified by your vehicle’s
instruction manual, or in an area with adequate airflow and
protection from damage. Ensure all wiring connections can be
reached prior to mounting.
2. Use double-sided foam tape or the mounting tabs with screws
on the bottom of the case to secure the ESC in position. The
switch can be mounted with double sided foam tape.
3. Connect the red power connectors together and the black
power connectors together between the ESC and the motor.
4. If you need to reverse the motor direction you can reverse the
power connections between the motor and ESC.
386902 SPMXSER1040 Manual
ESC and Transmitter Calibration
When using a new ESC it is important to calibrate it so the ESC
matches the throttle range on your transmitter. If you install a new
radio system, or make changes to the throttle/brake values in your
transmitter, you must redo the ESC Calibration Process. Failure to
calibrate the ESC to your radio system will result in the ESC not
working correctly. Set the Fail Safe on your radio to a neutral posi-
tion to ensure the motor stops in the event of a signal loss.
1. Power ON the transmitter, and begin with throttle values at
100% for dual rates and travel and at neutral for trim and
sub-trim.
Verify there are no ABS braking functions activated before
proceeding with calibration.
For transmitters without an LCD, turn the D/R knob to the max
setting, and center the throttle trim.
2. Connect a battery to the ESC.

11
Operation
1. Power on the transmitter.
2. Power on the receiver.
3. Disconnect the battery from the ESC after operation.
3. Press and hold the programming button on the switch case,
power on the ESC.
The red LED on the ESC will flash, and the motor will beep.
Release the programming button.
The ESC will enter the programming mode if the programming
button is not released within 3 seconds.
4. With the throttle trigger and trim in the neutral position, press
and release the programming button. The red LED will flash
once, and the motor will emit 1 tone.
5. Pull the throttle trigger to full throttle. Press and release the
programming button. The red LED will flash twice, and the
motor will emit 2 tones.
6. Push the throttle trigger to full reverse. Press and release the
programming button. The red LED will flash 3 times, and the
motor will emit 3 tones.
7. Power OFF the system with the ON/OFF switch.
8. Power ON the system with the ON/OFF switch. The system is
ready for operation
TIP: Beeps from the motor may be quiet and difficult to hear,
use the LED status to help verify settings.

12
ESC Programming via Switch Push Button
1. Power ON your transmitter. Connect a battery to the ESC and
power it ON.
NOTICE: The transmitter and receiver must be connected.
2. Press and hold the programming button for 1 second.
OPTIONAL: Press and hold the programming button for 5
seconds to reset all ESC programming options.
3. Release the programming button. The red LED will blink to
indicate it has entered programming mode
4. The red LED blinks (and the motor beeps) to indicate the pro-
gramming item. Press the programming button for 1 second in
order to toggle through the programmable items.
• 1 red LED blink for item one, 2 red LED blinks for item
2, etc.
• Items 5 and above: 1 long LED blink for item 5, 1 long
LED blink and 1 short LED blink for item 6, etc.
• Items 10 and above: 2 long LED blinks for item 10, 2 long
LED blinks and 1 short LED blink for item 11, etc.
5. Press and hold the programing button for 3 seconds when you
want to enter a programming item.
6. The LED blinks to indicate the programming value within the
item selection.
7. Press and hold the programming button for 3 seconds when
you want to select a programming value.
8. Power off the ESC.
9. Begin the process again to change any other programming
values. One long LED blink and one long beep will indicate
when the ESC is ready to run.

13
Programming the ESC via the SPMXCA200
Program Box
1. Begin with no battery connected.
2. Connect the cable for the programming box into the program-
ming port as shown.
3. Connect a battery and power ON the ESC.
OPTIONAL: The ESC settings can be reset to default by press-
ing “Reset” and then “OK” buttons.
4. Press Select button on the program box once.
5. Select the programming choices. Press SAVE after any
changes are made.
6. Power off the ESC.
7. Disconnect the cable for the programming box.

14
191870 SPMXSEMC12 Manual Programmable Features
1. Running Mode
2. Lipo Battery
3. Cutoff Voltage
4. Initial Start Force (%)
5. Max Forward Force (%)
6. Max Reverse Force (%)
7. Max Brake Force (%)
8. Initial Brake Force (%)
9. Drag Brake (%)
10. Drag Brake Rate (Level)
11. Neutral Range (%)
12. Start Mode / Punch (Level)
13. PWM Frequency
14. BEC Voltage
Programmable Values

15
1 2 3 4 5 6 7 8 9
1Fwd/Brk Fwd/Rev/Brk Fwd/Rev 2ON OFF 3Disabled Auto (Low) Auto (Med) Auto (High) 4 0 2 46 8 10 12 14 16 525 50 75 100 625 50 75 100 7 0 12.5 25 37.5 50 62.5 75 87.5 100 806.25 12.50 18.75 25 31.25 37.50 43.75 50 90510 50 60 70 80 90 100
10 1 2 3 45 6 7 8 9 11 3 4 5 6 78 9 10 12 12 1 2 3 4 56 7 8 9 13 1K 2K 4K 8K 16K 14 6.0V 7.4V
Programmable Values Blacked out cells with white text represent the default settings.

16
Feature LED Status Motor Sound
Ni-MH/Ni-CD Battery 1 Blink 1 Short Beep
2S Li-Po Battery 2 Blinks 2 Short Beeps
v Li-Po Battery 3 Blinks 3 Short Beeps
ESC Ready 1 Long Blink 1 Long Beep
During Operation LED Status
Stop OFF
Forward Partial Throttle Blinks
Full Throttle Solid
Reverse Partial Throttle Blinks
Full Throttle Solid
Partial Brake Blinks
Full Brake Solid
Battery Low Voltage Blinks
Overheat Blinks
LED Indicator and Motor Sounds
Upon powering on the ESC, the LED will blink and the motor will
emit a series of beeps to indicate its status.
First it will display the battery mode selection, second the drag
brake setting, and then it will indicate it is ready to operate.

17
386902 SPMXSER1040 Manual
Troubleshooting Guide
Problem Possible Cause Solution
ESC ON – No
motor function,
audible tone or
LED
Battery/connec-
tion issue
Recharge/replace
battery. Secure all
connections
Damaged ESC/
switch Repair/replace ESC switch/ESC
Damaged motor Repair/replace
Motor – Stops
and LED blinks
Low voltage
protection
When the ESC LED
blinks, recharge/
replace battery
Overheat
protection
When the LED blinks,
let motor/ESC cool,
change set up or
gearing to avoid
overheating
Motor – Acceler-
ates irregularly
Battery issue Repair damaged wir-
ing/replace battery
Incorrect gearing Adjust/replace gearing
Worn or dam-
aged motor Repair/replace motor
Motor – Does not
turn continuously
in response to
throttle
ESC/motor
damaged Repair/replace wiring or motor/ESC
Motor – Slows
but will not stop
Incorrect
transmitter/ESC
calibration
Adjust throttle travel/
other throttle settings
on the transmitter/
ESC. Repeat the ESC
Calibration Procedure

18
Problem Possible Cause Solution
Steering Servo –
Operates; motor
does not run
Damaged motor
Test the motor apart
from the vehicle
system, repair/replace
motor as needed
Incorrect
transmitter/ESC
calibration
Adjust throttle travel/
other throttle settings
on the transmitter/
ESC. Repeat the ESC
Calibration Procedure
Steering/Motor –
Do not function
Low battery
voltage Recharge/replace
Wrong model
memory selected
on transmitter
Select correct
model settings on
your transmitter, refer
to transmitter and/or
receiver manual
Receiver not
bound to trans-
mitter
Bind transmitter to
receiver, refer to trans-
mitter and/or receiver
manual
Vehicle – Does
not operate at full
speed
Battery issue Recharge/replace
Incorrect
transmitter/ESC
calibration
Adjust throttle travel/
other throttle settings
on the transmitter/
ESC. Repeat the ESC
Calibration Procedure
Troubleshooting Guide

19
1-Year Limited Warranty
What this Warranty Covers – Horizon Hobby, LLC, (Horizon)
warrants to the original purchaser that the product purchased (the
“Product”) will be free from defects in materials and workmanship
for a period of 1 year from the date of purchase.
What is Not Covered – This warranty is not transferable and
does not cover (i) cosmetic damage, (ii) damage due to acts of
God, accident, misuse, abuse, negligence, commercial use, or
due to improper use, installation, operation or maintenance, (iii)
modification of or to any part of the Product, (iv) attempted service
by anyone other than a Horizon Hobby authorized service center,
(v) Product not purchased from an authorized Horizon dealer, (vi)
Product not compliant with applicable technical regulations, or (vii)
use that violates any applicable laws, rules, or regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON
MAKES NO OTHER WARRANTY OR REPRESENTATION,AND
HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES
OF NON-INFRINGEMENT, MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE. THE PURCHASER ACKNOWLEDGES
THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL
SUITABLY MEET THE REQUIREMENTS OF THE PURCHASER’S
INTENDED USE.
Purchaser’s Remedy – Horizon’s sole obligation and purchaser’s
sole and exclusive remedy shall be that Horizon will, at its option,
either (i) service, or (ii) replace, any Product determined by Horizon
to be defective. Horizon reserves the right to inspect any and all
Product(s) involved in a warranty claim. Service or replacement
decisions are at the sole discretion of Horizon. Proof of purchase
is required for all warranty claims. SERVICE OR REPLACEMENT AS
PROVIDED UNDER THIS WARRANTY IS THE PURCHASER’S SOLE
AND EXCLUSIVE REMEDY.
Limitation of Liability – HORIZON SHALL NOT BE LIABLE FOR
SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES,

20
191870 SPMXSEMC12 Manual
LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN
ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN
CONTRACT, WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY
OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Further,
in no event shall the liability of Horizon exceed the individual price
of the Product on which liability is asserted. As Horizon has no
control over use, setup, final assembly, modification or misuse, no
liability shall be assumed nor accepted for any resulting damage
or injury. By the act of use, setup or assembly, the user accepts all
resulting liability. If you as the purchaser or user are not prepared
to accept the liability associated with the use of the Product,
purchaser is advised to return the Product immediately in new and
unused condition to the place of purchase.
Law – These terms are governed by Illinois law (without regard
to conflict of law principals). This warranty gives you specific legal
rights, and you may also have other rights which vary from state to
state. Horizon reserves the right to change or modify this warranty
at any time without notice.
WARRANTY SERVICES
Questions, Assistance, and Services – Your local hobby store
and/or place of purchase cannot provide warranty support or ser-
vice. Once assembly, setup or use of the Product has been started,
you must contact your local distributor or Horizon directly. This will
enable Horizon to better answer your questions and service you
in the event that you may need any assistance. For questions or
assistance, please visit our website at www.horizonhobby.com,
submit a Product Support Inquiry, or call the toll free telephone
number referenced in the Warranty and Service Contact Informa-
tion section to speak with a Product Support representative.
Inspection or Services – If this Product needs to be inspected
or serviced and is compliant in the country you live and use
the Product in, please use the Horizon Online Service Request
submission process found on our website or call Horizon to obtain
