Sper scientific 800047 User manual




Oxygen Pen
800047
Instruction Manual

- 2 -
TABLE OF CONTENTS
INTRODUCTION. . . . . . . . . . . . . . .
FEATURES . . . . . . . . . . . . . . . . . . .
MATERIALS SUPPLIED. . . . . . . . .
FRONT PANEL DESCRIPTION. . .
CALIBRATION. . . . . . . . . . . . . . . . .
MEASUREMENT PROCEDURES. .
BATTERY REPLACEMENT. . . . . . .
SPECIFICATIONS. . . . . . . . . . . . . .
WARRANTY . . . . . . . . . . . . . . . . . .
4
5
5
6
7
9
13
14
16

- 3 -
INTRODUCTION
The Sper Scientific Oxygen Pen (Model
800047) is designed to read oxygen in
the air.
At standard temperature and pressure,
oxygen is a colorless, odorless,
tasteless diatomic gas with the
molecular formula O2.
Applications for the meter include O2
monitors and detectors, environmental
studies, IAQ, food storage and
refrigeration, bio-technology (oxygen
incubators and anaerobic cultivators),
security systems, air conditioning,
oxygen shortage alarm systems, fire
alarms, and fuel cell systems.

- 4 -
MATERIALS SUPPLIED
FEATURES
 Dual display with O2 and
air temperature measurement
 Highly reliable, galvanic cell type O2
sensor with temperature
compensation, withstands acidic
gases (i.e., CO2)
 Microprocessor circuit ensures high
accuracy
 Durable and compact ABS-plastic
housing
 Data hold
 Auto-power-off
 Low battery indicator
 Meter
 4 AAA batteries
 Instruction Manual
 Soft Carrying Case

- 5 -
FRONT PANEL DESCRIPTION
Oxygen/
temperature
sensor
POWER
HOLD
REC
LCD display
Battery
compartment/
cover

- 6 -
CALIBRATION
For best results, perform the calibration
procedure in a large and ventilated
environment:
Note…
The oxygen value of air (20.9%) is
used for calibration.
1. Press POWER to turn the meter on.
2. Wait at least 3 minutes until the
displayed reading becomes stable
and shows no fluctuation.
3. Press HOLD and REC
simultaneously until “CAL” appears
on the primary display of the LCD.
(The secondary display will show
20.9.)
4. Release HOLD and REC. “CAL will
flash on the LCD for several

- 7 -
CALIBRATION
seconds, then the meter will return
to Normal Mode, display a value that
is ± 0.1% of 20.9 O2, and complete
the calibration procedure.

- 8 -
MEASUREMENT PROCEDURES
O2and Air Temperature
Measurement
1. Press POWER to turn the meter on.
Note…
Press POWER again to turn the unit off.
2. Point the oxygen/temperature
sensor toward the intended
measurement area.
3. The O2value appears on the primary
display as %O2. The temperature
value appears on the secondary
display as °C or °F.
Hold Function
1. During measurement, press HOLD
to freeze the current readings on the
display. “Hold” will appear on the
LCD.

- 9 -
MEASUREMENT PROCEDURES
2. Press HOLD again to release the
hold function.
Record Data
The data record functions holds one
maximum and one minimum reading in
memory. To record:
1. Press REC to start recording. “REC”
will appear on the LCD.
2. With “REC” on the display, press
REC. “REC MAX” and the maximum
value will appear on the LCD.
Note…
To delete the maximum value, press
HOLD. The display will show “REC” on-
ly and the meter will resume exe-
cuting the memory function.

- 10 -
MEASUREMENT PROCEDURES
3. Press REC again. “REC MIN” and
the minimum value will appear on
the LCD.
Note…
To delete the minimum value, press
HOLD. The display will show “REC” on-
ly and the meter will resume exe-
cuting the memory function.
4. To exit the data record function,
press REC for at least 2 seconds.
The display will return to the current
reading.
Note…
The maximum and minimum values will
NOT be saved when you exit the
memory function or when the meter is
turned off.

- 11 -
MEASUREMENT PROCEDURES
Setting the Temperature Unit
1. Press POWER to turn the meter off.
2. Press and hold down the HOLD
button. While HOLD is still being
pressed, press POWER until the
temperature unit (°C or °F) appears
on the display. Release the HOLD
button. The temperature unit will
change from °C or °F (or °F or °C).
Note…
The meter will default to the last
temperature unit selected when turned
off and then on again.
Auto Power Off
1. To save battery life, the meter will
automatically turn off after 10
minutes of inactivity. Press REC to
disable this function.

- 12 -
BATTERY REPLACEMENT
The low battery icon will appear
on the left side of the LCD to indicate
the need for battery replacement. To
replace:
1. Press POWER to turn the meter off.
2. Rotate the battery cover located on
the bottom of the unit to loosen and
remove.
3. Remove the old batteries and
replace with 4 new AAA 1.5V
batteries, ensuring correct polarity.
4. Replace the battery cover and rotate
to tighten into place.

- 13 -
SPECIFICATIONS
O
2Air
Temperature
Accuracy ± (1%
reading +
0.2% O2)
(Following
calibration)
± 0.8°C,
± 1.5°F
Range 0 ~ 30% O20 ~ 50°C,
32 ~ 122°F
Resolution 0.1% O20.1°C, 0.1°F
Response
Time ≤15 seconds
Environment
Pressure
Range
0.9 to 1.1
atmosphere
Expected
Lifetime
(O2Sensor)
≥2 years
Sensor Galvanic cell
type
Thermistor

- 14 -
SPECIFICATIONS
Circuit Custom one-chip of
microprocessor LSI circuit
Sampling
Time Approximately 1 second
Operating
Temperature 0 ~ 50°C;
(For best results: 23 ± 5°C)
Operating
Humidity < 80% RH
Battery 4 DC 1.5 V (UM4/AAA)
batteries
Power Current Approximately DC 4.0 mA
Weight 6 oz (175 g)
Dimensions 7x 1 ½ x 1 ½”
(180 x 40 x 40 mm)
LCD
Dimensions 28 x 19 mm

- 15 -
The contents of this manual may not be
reproduced or transmitted in any form or by
any means electronic, mechanical, or other
means that do not yet exist or may be
developed, including photocopying,
recording, or any information storage and
retrieval system without the express
permission from Sper Scientific.
Oxygen Pen 800047
Copyright ©2010 by Sper Scientific
ALL RIGHTS RESERVED
Printed in the USA

- 16 -
WARRANTY
Sper Scientific warrants this product against
defects in materials and workmanship for a
period of one (1) year from the date of
purchase, and agrees to repair or replace any
defective unit without charge. If your model has
since been discontinued, an equivalent Sper
Scientific product will be substituted if available.
This warranty does not cover probes, batteries,
battery leakage, or damage resulting from
accident, tampering, misuse, or abuse of the
product. Opening the meter to expose its
electronics will void the warranty.
To obtain warranty service, ship the unit
postage prepaid to:
SPER SCIENTIFIC LTD
8281 E. Evans Rd., Suite #103
Scottsdale, AZ 85260
The defective unit must be accompanied by a
description of the problem and your return
address. Register your product online at
www.sperscientific.com, or return your warranty
card within 10 days of purchase.
Revised 9/23/2013
